kd frames Charleston Plus Queen User manual

Instructions for
Charleston Plus
Queen
Manufactured by
A-80-P BED RAIL (4) -
A-28 REGULAR SLAT (28) - 28” A-28-C CONNECTOR SLAT (4) - 28”
Parts:
394 Dairy Pak Rd. • Athens, GA 30607
sku# 3991-CP-Q
A-50-F FOOTBOARD (1) - 56”
Tool needed:
#2 Phillips screw driver
Align the Left Footboard Leg (A-15L) and
Right Footboard Leg (A-15R) so that the
rail pockets are on the front.
Turn the Footboard (A-56-F) so that the
pocket holes are facing the front.
Then push the dowels into the holes on the legs.
WOOD SCREWS
GO IN THESE
POCKET HOLES
Use a phillips screw driver to attach
the Legs to the Bed End using
(4) 1 - 1/2” Wood Screws (Black) (H-20).
1
RAIL POCKETS MUST
ALL BE ON THE
SAME SIDE
A-15L
A-15R
THESE POCKETS
SHOULD BE TOWARDS
THE TOP
FOOTBOARD ASSEMBLY
A-15L FOOTBOARD LEFT LEG (1) 15”
A-15R FOOTBOARD RIGHT LEG (1) 15”
A-56-HB HEADBOARD BOTTOM (1) - 56”
A-56-HT HEADBOARD TOP (1) - 56”
A-40L HEADBOARD LEFT LEG (1) 40”
A-40R HEADBOARD RIGHT LEG (1) 40”
A-22 HEADBOARD PICKET (6) 22”
A-22-P HEADBOARD PICKET (3) 22”
(with pocket holes)
HARDWARE LIST
1
H-10 HEX WRENCH
H-3 CROSS DOWEL
24
24
H-21 2 - 1/2” BOLT
H-20 1 - 1/2” WOOD SCREW (black)
16
kdframes.com • [email protected]

2
Attach the Headboard Legs (A-40-L and A-40-R)
to the Headboard by pushing them onto the
dowels. Be sure that the rail pockets are all
facing the same side. Then use (6) 1-1/2” Wood
Screws (Black) (H-20) to attach the Legs.
3
RAIL POCKETS MUST
ALL BE ON THE
SAME SIDE
FRONT VIEW
BACK VIEW
Push the 6 Headboard Pickets (A-22) and the 3
Headboard Pickets (A-22-P) into holes on the
Headboard Bottom (A-56-HB) . The 3 pickets in
the middle (A-22-P) should be the ones with
pocket holes (see back view picture).
Then push the Headboard Top (A-56-HT)
down onto the pickets.
Use a Phillips screwdriver to attach the 3 middle
pickets with 1-1/2” Wood Screws (Black) (H-20).
THE 3 PICKETS (A-22-P)
WITH POCKET HOLES
GO HERE
A-50-HT
A-50-HB
A-22
A-22
HEADBOARD ASSEMBLY
A-40L
A-40R

Use 2-1/2” Bolts (H-21) and
Cross Dowels (H-3) to attach
Bed Rails (A-80) to the Headboard
and Footboard. The pockets in the
Bed Rails should be facing in and
open to the top of the Rails.
Leave all bolts loose until
everything is attached. Then
tighten all bolts.
H-21
H-3
NOTE:
Place the best looking rail
on the outside to make
your frame look its best.
NOTE:
Rail pockets must
face the inside.
Insert Connector Slats (A-28-C) into the
pockets that have holes. Secure using
2 - 1/2” Bolts (H-21) and Cross Dowels
(H-3). Leave these loose at this time.
5
4
H-3
H-21
