kd frames Nomad 7964-NO-XT User manual

2
Instructions for
Nomad Bed
Extra-Long Twin
Manufactured by
N-80 BED RAIL (2)
N-38 REGULAR SLAT (10) N-39 CONNECTOR SLAT (2)
N-41 BED ENDS (2)
Use 2-1/2” Bolts (H-21) and Cross Dowels (H-3) to
attach Bed Rails (N-80) and Connector Slats (N-39).
Leave the bolts loose until Step 2.
Place Regular Slats (N-38)
into the pockets and
then tighten the bolts.
1
HARDWARE LIST
1
H-10 HEX WRENCH
H-3 CROSS DOWEL
12
4
H-21 2 - 1/2” BOLT
8
H-1 3” BOLT
Parts:
H-21
H-3
NOTE:
Bolts should be just loose
enough to insert the Regular
Slats.
NOTE:
When the Slats are all in
their pockets, tighten the
bolts.
394 Dairy Pak Rd. • Athens, GA 30607
kdframes.com • [email protected]
N-15L LEFT LEG (2)
H-20 1 - 1/2” WOOD SCREW
8
N-15R RIGHT LEG (2)
Tool needed:
#2 Phillips screw driver
sku# 7964-NO-XT

Knockdown Frameworks, Inc. warrants all of its products for five years against any defects that are due to faulty materials or workmanship. We will promptly correct such
defects by repair or replacement, at our option, without charge. This warranty covers product defects only and will expire five years after date of purchase by the original
consumer purchaser, with proof of purchase required.
This warranty does not apply to damage caused by and resulting from misuse, neglect, accident, or improper operation, maintenance, storage, transportation, or handling
of the product. This warranty is for the original consumer purchaser for residential use only and does not apply if the product is used in any commercial application (such as
rental property). This warranty does not cover any incidental or consequential damages. If you feel that you have a claim under this warranty, please contact the store from
which it was purchased. If this is not possible,call 800-543-3393 for advice on handling your claim.
Use 3” Bolts (H-1) and
Cross Dowels (H-3) to attach the
Bed Deck to the Bed Ends
with the rail pockets facing in.
PLEASE RETIGHTEN
BOLTS
AFTER 30 DAYS
H-1
4
H-3
NOTE:
Rail pockets must
face to the inside.
This futon frame is made with Tulip Poplar. Any green tint in the wood will change to light brown in a few weeks. This will happen in 20 to 30 minutes
if placed in direct sunlight. Tulip Poplar can be left unfinished, clear finished, stained, or painted. I prefer the lighter stains over the darker ones
because the wood is fairly porous. My favorite is a clear finish with no stain. Satin polyurethane (oil or water based) works well.
Painting: It is best to start with an interior primer and lightly sand before painting.
Staining: Lightly sand before staining. Wipe stain on with a rag until you get the desired color. If you are going to use a top coat (such as
polyurethane), do not sand again until after the first coat, and then be careful not to sand away the stain.
Finishing: All finishes work well with Tulip Poplar. A simple wax finish over stain (Minwax for example) is easy. An oil finish such as Danish oil can
be used. Or a clear top coat such as polyurethane works well to seal the wood. With polyurethanes, the first coat acts as a sanding sealer. So you
should lighty sand (180 - 220 grit sandpaper) after the first coat, wipe the wood clean, and then build up coats for the desired effect.
NOTE:
Install Bed Deck with
slats closer to top.
Align a Left Leg (N-15L) and Right Leg (N-15R)
so that the rail pockets are on the front.
Turn the leg Connector (N-41) so that the
pocket holes are facing the front, also.
Then push the dowels into the holes on the
legs. Repeat for the other bed end.
POCKET SCREW HOLES
SHOULD BE ON THE
SAME SIDE AS THE RAIL
POCKETS
WOOD SCREWS
GO IN THESE
POCKET HOLES
Use a phillips screw driver to attach
the Legs to the Leg Connector using
(4) 1 - 1/2” Wood Screws (H-20).
Repeat for the other bed end.
N-41
3
N-15L
N-15R
