kd frames KD Lounger Full User manual

PARTS
Instructions for:
Manufactured by:
(2) K-22 SEAT SLAT - 52”
(2) K-23 LOUNGER SLAT - 52”
(2) K-2L SEAT RAIL - 37”
(7) K-24 MIDDLE SLAT - 48”
K-6L BACK LEG (Left) (1)
K-6R BACK LEG (Right) (1)
K-25
K-4
H-19
2
(4) K-15 SLAT CAP - 20”
PARTS LIST
BACK RAIL
K-1 2
K-2 2
SEAT RAIL
2
PROP
K-4
K-25 1
PROP CONNECTOR
4
4
8
K-16
11” LOUNGER SLAT CAPS
2
K-24
MIDDLE SLATS
7
32
H-11
WOOD DOWEL
20
H-19
1 - 3/4” WOOD SCREW
K-3 2
LOUNGER RAIL
2
K-6
BACK LEG (Left and Right)
2
K-7
SEAT LEG
2
K-8
LOUNGER LEG
K-22 2
SEAT SLATS
K-23 2
LOUNGER SLATS
K-15
20” SLAT CAPS
4
K-21
BACK SLATS
2
(2) K-7 SEAT LEG - 9”
(2) K-21 BACK SLAT - 52”
(1) K-25 PROP CONNECTOR - 44”
(2) K-3 LOUNGER RAIL - 24”
(2) K-16 LOUNGER SLAT CAP - 11”
(2) K-8 LOUNGER LEG - 9”
(2) K-4 PROP - 15”
(2) K-1 BACK RAIL - 29”
Press the Prop Connector (K-25) onto
the Wood Dowels on the Props (K-4)
and attach with Wood Screws (H-19).
H-8 2-1/4” CLEVIS PIN
H-5 HAIR PIN
H-12 3-1/4” CLEVIS PIN
394 Dairy Pak Rd. • Athens, GA 30607
kdframes.com • [email protected]
(1) K-29 LEG CONNECTOR - 38”
1
K-29
LEG CONNECTOR
v. 111
Push Wood Dowels (H-11)
all the way into holes as
shown.
1
K-2L SEAT RAIL (2)
K-3 LOUNGER RAIL (2)
K-4 PROP (2)
K-1 BACK RAIL (2)
K-8 LOUNGER LEG (2)
sku# 7832-KD-F
KD Lounger Full

Be sure that the Props
are on the inside of the
Back Rails.
4
Be sure that the
Prop Connector
is below the
Back Rails.
Please double-check your work
at this time. Any error in this
assembly will cause serious
problems later.
H-8
Be sure that the
Prop Connector
goes below the Back
Rails.
3
K-1
H-5
H-8
K-6L
K-6R
H-12
H-12
Attach the Left and Right Back Legs (K-6) to the
outside of the BackRails using
the 3-1/4” Cevis Pins (H-12).
Do not put on the Hair Pins at this time.
5
Make sure that the cut-away part
of the Back Legs face in so that
they will support the Back Rails.
First, place the Seat Rails (K-2L)
onto the 3-1/4” Clevis Pins and
secure with Hair Pins (H-5).
6
K-2L
K-2L
Attach the Back Rails (K-1) to the outside of the
Prop Assembly using 2-1/4” Clevis Pins (H-8).
Let the Prop Assembly swing down so that the Prop
Connector can go below the Back Rails as shown.
Secure the Clevis Pins with Hair Pins (H-5).
Second, secure the Back Legs
with Wood Screws (H-19).
(These screws are self-tapping
and do not need pilot holes.)
H-19
H-19

11
9
Using (3) Middle Slats (K-24)
push the Wood Dowels
into the edge holes on
(2) Slat Caps (K-15).
K-15
K-24
K-21
K-23
K-16
K-24
10
Using (3) Middle Slats (K-24)
push the Wood Dowels
into the edge holes on
(2) Slat Caps (K-15).
K-15
K-24
K-22
Use (1) Middle Slat (K-24) and
push the Wood Dowels
into the edge holes on
(2) Lounger Slat Caps (K-16).
Attach the Seat Legs (K-7) and the
Lounger Rails (K-3) to the Seat Rails
using 3-1/4” Clevis Pins (H-12).
Secure the Clevis Pins with and Hair
Pins (H-5).
7
H-12
K-3
H-12
K-7
K-7
Make sure that the cut-away part
of the Seat Legs (K-7) face out so
that they will support the Seat
Rails.
Find the (2) Back Slats (K-21)
and push them onto the Wood
Dowels on the Slat Caps.
Find the (2) Lounger Slats
(K-23) and push them onto the
Wood Dowels on the Lounger
Slat Caps.
Attach the Lounger Legs (K-8) to the
Lounger Rails using 2-1/4” Clevis Pins
(H-8) and secure with Hair Pins.
Then push the Leg Connector (K-29) onto
the Wood Dowels on the Lounger Legs
and attach with Wood Screws (H-19).
8
H-8
H-8
K-8
H-1
Find the (2) Seat Slats (K-22)
and push them onto the Wood
Dowels on the Slat Caps.
K-29

Knockdown Frameworks, Inc. warrants all of its products for five years against any defects that are due to
faulty materials or workmanship. We will promptly correct such defects by repair or replacement, at our option,
without charge. This warranty covers product defects only and will expire five years after date of purchase by the
original consumer purchaser, with proof of purchase required.
This warranty does not apply to damage caused by and resulting from misuse, neglect, accident, or improper
operation, maintenance, storage, transportation, or handling of the product. This warranty is for the original
consumer purchaser for residential use only and does not apply if the product is used in any commercial
application (such as rental property). This warranty does not cover any incidental or consequential damages. If
you feel that you have a claim under this warranty, please contact the store from which it was purchased. If this is
not possible, call 800-543-3393 for advice on handling your claim.
This futon frame is made with Tulip Poplar. Any green tint in the wood will change to light brown in a few weeks.
This will happen in 20 to 30 minutes if placed in direct sunlight. Tulip Poplar can be left unfinished, clear finished,
stained, or painted. I prefer the lighter stains over the darker ones because the wood is fairly porous. My favorite
is a clear finish with no stain. Satin polyurethane (oil or water based) works well.
Painting: It is best to start with an interior primer and lightly sand before painting.
Staining: Lightly sand before staining. Wipe stain on with a rag until you get the desired color. If you are going to
use a top coat (such as polyurethane), do not sand again until after the first coat, and then be careful not to sand
away the stain.
Finishing: All finishes work well with Tulip Poplar. A simple wax finish over stain (Minwax for example) is easy. An
oil finish such as Danish oil can be used. Or a clear top coat such as polyurethane works well to seal the wood.
With polyurethanes, the first coat acts as a sanding sealer. So you should lighty sand (180 - 220 grit sandpaper)
after the first coat, wipe the wood clean, and then build up coats for the desired effect.
H-19
Back
Slat Deck
Seat
Slat Deck
Push the Slat Decks down onto
the Wood Dowels and attach
with Wood Screws (H-19).
12
Lounger
Slat Deck
Note:
Wood Screws are
self-tapping and do not
need pilot holes.
Operation:
Bed position:
Lounger position with
footrest flat:
Lounger position with
footrest down:
Sofa position:
Lift up Back and
swing down Prop
onto notches on
Seat Rail.
Swing Lounger Legs up
under Footrest.
Lift up Seat and swing
Footrest underneath.
Adjust Back to a
comfortable position.
Note:
The base may need to be
shifted to get the dowels to
align with the holes.
