kd frames Nomad 2 XL-Twin User manual

Knockdown Frameworks, Inc. warrants all of its products for five years against any defects that are due to faulty materials or workmanship. We will promptly correct such
defects by repair or replacement, at our option, without charge. This warranty covers product defects only and will expire five years after date of purchase by the original
consumer purchaser,with proof of purchase required.
This warranty does not apply to damage caused by and resulting from misuse, neglect, accident, or improper operation, maintenance, storage, transportation, or handling
of the product. This warranty is for the original consumer purchaser for residential use only and does not apply if the product is used in any commercial application (such as
rental property). This warranty does not cover any incidental or consequential damages. If you feel that you have a claim under this warranty, please contact the store from
which it was purchased. If this is not possible,call 706-543-9397 for advice on handling your claim.
Instructions for
Nomad 2
XL-Twin
Manufactured by
A-80 BED RAIL (4) - 80”
A-17 REGULAR SLAT (20) - 17” A-17-C CONNECTOR SLAT (4) - 17”
HARDWARE LIST
1
H-10 HEX WRENCH
H-3 CROSS DOWEL
24
24
H-21 2 - 1/2” BOLT
Parts:
394 Dairy Pak Rd. • Athens, GA 30607
kdframes.com • [email protected]
sku# 2364-N2-XT
A-34F BED ENDS (2) - 34”
Tool needed:
#2 Phillips screw driver
Align a Left Leg (A-15L) and Right Leg (A-15R)
so that the rail pockets are on the front.
Turn the Bed End (A-34F) so that the
pocket holes are facing the front.
Then push the dowels into the holes on the
legs. Repeat for the other Bed End.
WOOD SCREWS
GO IN THESE
POCKET HOLES
Use a phillips screw driver to attach
the Legs to the Leg Connector using
(4) 1 - 1/2” Wood Screws (H-20).
Repeat for the other Bed End.
1
RAIL POCKETS MUST
ALL BE ON THE
SAME SIDE
A-15L
A-15R
THESE POCKETS
SHOULD BE TOWARDS
THE TOP
H-20 1 - 1/2” WOOD SCREW
8
A-15L LEFT LEG (2) A-15R RIGHT LEG (2)

This futon frame is made with Tulip Poplar. Any green tint in the wood will change to light brown in a few weeks. This will
happen in 20 to 30 minutes if placed in direct sunlight. Tulip Poplar can be left unfinished, clear finished, stained, or
painted. I prefer the lighter stains over the darker ones because the wood is fairly porous. My favorite is a clear finish
with no stain. Satin polyurethane (oil or water based) works well.
Painting: It is best to start with an interior primer and lightly sand before painting.
Staining: Lightly sand before staining. Wipe stain on with a rag until you get the desired color. If you are going to use a
top coat (such as polyurethane), do not sand again until after the first coat, and then be careful not to sand away the stain.
Finishing: All finishes work well with Tulip Poplar. A simple wax finish over stain (Minwax for example) is easy. An oil
finish such as Danish oil can be used. Or a clear top coat such as polyurethane works well to seal the wood. With
polyurethanes, the first coat acts as a sanding sealer. So you should lighty sand (180 - 220 grit sandpaper) after the first
coat, wipe the wood clean, and then build up coats for the desired effect.
Insert Connector Slats (A-17-C) into the
pockets that have holes. Secure using
2 - 1/2” Bolts (H-21) and Cross Dowels
(H-3). Leave the bolts loose at this time.
PLEASE RETIGHTEN
BOLTS
AFTER 30 DAYS
3
4
Next insert all Regular Slats (A-17),
then tighten the 2 - 1/2” Bolts (H-21).
H-3
H-21
Use 2 - 1/2” Bolts (H-21) and
Cross Dowels (H-3) to attach
Bed Rails (A-80) to the Bed Ends.
The pockets in the Bed Rails
should be facing in and open to
the top of the Rails.
Leave all bolts loose until
everything is attached. Then
tighten all bolts.
PLEASE RETIGHTEN
BOLTS
AFTER 30 DAYS
2
H-21
H-3
NOTE:
Place the best looking rail
on the outside to make
your frame look its best.
NOTE:
Rail pockets must
face the inside.
