kd frames 7936-RD-36 User manual

Manufactured by
Instructions for
Rolling Drawer
Knockdown Frameworks, Inc. warrants all of its products for five years against any defects that are due to faulty materials or workmanship. We will promptly correct such
defects by repair or replacement, at our option, without charge. This warranty covers product defects only and will expire five years after date of purchase by the original
consumer purchaser, with proof of purchase required.
This warranty does not apply to damage caused by and resulting from misuse, neglect, accident, or improper operation, maintenance, storage, transportation, or handling of
the product. This warranty is for the original consumer purchaser for residential use only and does not apply if the product is used in any commercial application (such as rental
property). This warranty does not cover any incidental or consequential damages. If you feel that you have a claim under this warranty, please contact the store from which it
was purchased. If this is not possible, call 800-543-3393 for advice on handling your claim.
8
1
H-4 2” WOOD SCREWS
H-10 HEX WRENCH
D-36 SIDE PANELS (2)
(8) D-12 SLATS (12”)
D-18 END PANELS (2)
This futon frame is made with Tulip Poplar. Any green tint in the wood will change to light brown in a few weeks. This will
happen in 20 to 30 minutes if placed in direct sunlight. Tulip Poplar can be left unfinished, clear finished, stained, or
painted. I prefer the lighter stains over the darker ones because the wood is fairly porous. My favorite is a clear finish
with no stain. Satin polyurethane (oil or water based) works well.
Painting: It is best to start with an interior primer and lightly sand before painting.
Staining: Lightly sand before staining. Wipe stain on with a rag until you get the desired color. If you are going to use a
top coat (such as polyurethane), do not sand again until after the first coat, and then be careful not to sand away the
stain.
Finishing: All finishes work well with Tulip Poplar. A simple wax finish over stain (Minwax for example) is easy. An oil
finish such as Danish oil can be used. Or a clear top coat such as polyurethane works well to seal the wood. With
polyurethanes, the first coat acts as a sanding sealer. So you should lighty sand (180 - 220 grit sandpaper) after the first
coat, wipe the wood clean, and then build up coats for the desired effect.
Parts:
HARDWARE LIST:
394 Dairy Pak Rd. • Athens, GA 30607
kdframes.com • [email protected]
WHEELS
H-W
4
H-34 3/4” WOOD SCREWS
8
Tool Required: #2 Phillips-Head Screwdriver.
(4) D-18 CONNECTORS (18”)
sku# 7936-RD-36

1
Make sure that the
Wheels face the
inside
Place the 2 End Panels
(with the Wheels facing in)
between the Side Panels (D-36)
and attach with 2” Screws (H-4).
H-4
Make sure that the
Wheels face the
inside
Make sure that the
slots for the Slats face
the inside.
Attach two Wheels (H-W) to one of the
End Panels (D-18) using four of the 3/4”
Screws (H-34). Repeat for other End
Panel.
H-W
H-34
4
D-18
D-12
Push four Slats D-12 into one of the
Connectors D-18. Then attach another
Connector onto the other end of the Slats, as
shown in the diagram. Repeat this process
with the remaining Slats and Connectors.
2
Attach the assemblies from Step 2 on one of
the Side Panels D-36. Then push the other
Side Panel onto the other end.
3
D-36
