kd frames Savannah 7244 User manual

Instructions for
Savannah Lounger
Twin #7244
Use a small hammer to tap
Wood Dowels (H-11) all the
way into holes as shown.
1
Manufactured by
(2) LM-35 BACK MIDDLE SLAT (35”)
(4) L-16 SLAT CAPS (18”)
(2) L-14 LOUNGER LEG (12”)
(2) L-17 LOUNGER SLAT CAPS (10”)
L-2 LEFTARM
L-1 RIGHTARM
(2) L-20 BACK RAILS (27”)
(2) L-21 SEAT RAILS (27”)
(2) L-35 LOUNGER SLAT (35”)
(2) L-37 SEAT SLAT (37”)
(2) L-39 BACK SLAT (39”)
(2) L-40 STRETCHER (40”)
(2) LM-33 SEAT MIDDLE SLAT (33”)
(1) LM-31 LOUNGER MIDDLE SLAT (31”)
HARDWARE LIST
H-6
6
WASHER
28
H-11
WOOD DOWEL
14
H-19
1 1/2” SCREW
H-8 10 CLEVIS PIN
H-3 8
CROSS DOWEL
H-5 6
HAIR PIN
H-1 3” BOLT 8
H-10 1
HEX WRENCH
H-9 4
PLASTIC ROLLER
(2) L-22 LOUNGER RAILS (24”)
L-20 BACK RAILS (2)
L-21 SEAT RAILS (2)
L-22 LOUNGERRAILS (2)
Note:
Arms are packed
in a seperate box.
Tools needed:
#2 Phillips Screw Driver
Small Hammer
394 Dairy Pak Rd. •Athens, GA 30607
kdframes.com • [email protected]
PARTS
(1) L-41 LEG CONNECTOR (35”)
L-14 LOUNGER LEG (2)

3
2
Findthe(2)LM-35BackMiddleSlatsand
press theminto(2)L-16SlatCaps.
L-35
L-16
LM-35
4
H-19
L-22
LOUNGER
RAILS
Findthe(2)L-39BackSlatsandpress
themontotheSlatCapsasshown.
H-19
L-20
BACK
RAILS
Findthe(2)L-20BackRails.
Presstheslatdeckontothe
wooddowelsandattachwith
(4)WoodScrews(H-19).
6
5
Findthe(2)LM-33SeatMiddleSlats
andpresstheminto(2)L-16SlatCaps.
L-37
L-16
LM-33
7
Findthe(2)L-37SeatSlatsandpress
themontotheSlatCapsasshown.
H-19
L-21
SEAT
RAILS
Findthe(2)L-21SeatRails.
Presstheslatdeckontothe
wooddowelsandattachwith
(4)WoodScrews(H-19).
9
8
FindtheLM-31LoungerMiddleSlat
andpressinto(2)L-17LoungerSlat
Caps.
L-35
L-17
LM-31
10
Findthe(2)L-35 LoungerSlatsand
pressthemontotheSlatCapsas
shown.
Findthe(2)L-22LoungerRails.
Presstheslatdeckontothewooddowels
andattachwith(4)WoodScrews(H-19).

Knockdown Frameworks, Inc. warrants all of its products for five years against any defects that are due to faulty materials or
workmanship. We will promptly correct such defects by repair or replacement, at our option, without charge. This warranty covers
product defects only and will expire five years after date of purchase by the original consumer purchaser, with proof of purchase
required.
This warranty does not apply to damage caused by and resulting from misuse, neglect, accident, or improper operation,
maintenance,storage,transportation, or handling of the product. This warranty is for the original consumer purchaser forresidential
use only and does not apply if the product is used in any commercial application (such as rental property). This warranty does
not cover any incidental or consequential damages. If you feel that you have a claim under this warranty, please contact the store
from which it was purchased. If this is not possible, call 800-543-3393 for advice on handling your claim.
H-1
H-3
L-40
H-8
H-9
11
Attach the Plastic Rollers (H-9) to the
Back Caps with Clevis Pins (H-8).
Attach the Seat to the Back
using the Clevis Pins (H-8).
Secure the Clevis Pins
with the Hair Pins (H-5).
12
H-8
H-8
H-5
L-40
•Attach the Stretchers (L-40) to theArms using
3” Bolts (H-1) and Cross Dowels (H-3).
Leave all of the bolts loose at this time.
• Carefully put the back in place, making sure that the
rollers go into the slots.
• When all 4 rollers are in the 4 slots, tighten the bolts.
• Pull forward on the Seat to convert to the bed position.
•Attach the Lounger to the Seat using Clevis Pins (H-8).
•Attact the Lounger Legs (L-14) to the Lounger using Clevis Pins (H-8).
• Secure the Clevis Pins with Washers (H-6) and Hair Pins (H-5).
•Attach the Leg Connector (L-51) using 1 - 1/2” Wood Screws (H-19).
13
H-8
H-8
H-5 H-6
H-19

To convert from bed
position to lounger,
lift up the back section.
Then fold Lounger Legs
under Lounger section.
Reverse steps to
convert back to bed.
To convert from bed to chair,
you must start in the bed position.
First, fold Lounger Legs
under Lounger section
Next, lift Seat and fold
Lounger section uner.
Then lift back to convert
to Chair position.
Operation:
