Kellfri 35-HKK User manual

Carefully read the operating
instructions before using the product!
Operating instructions translated from Swedish
35-HKK
HYDRAULIC STRIMMER

Kellfri designs and supplies ecient, aordable machinery and components for forestry, agriculture,
construction and gardening in Sweden, the rest of the Nordic region and Europe.
We recommend that you always read and follow the safety instructions and the instructions in the machine’s
operating manual.
Kellfri is not liable for any errors in this document.
Before operation, please bear in mind the following:
- Check oil level and lubricating grease. Rell as needed.
- Check tightness of bolts and nuts.
For more information, see the manual.
TABLE OF CONTENTS
Introduction 3
Product information 3
Safety instructions 4
Instructions for emergency situations 4
Personal protection 4
Surroundings 5
Before use 5
Use 6
After use 6
Maintenance and service 7
Transportation and set-up 7
Recycling 7
When using machine/equipment connected to tractor 8
Machines/equipment connected to hydraulics 9
Environment 9
Risks and hazards associated with the use of grassland machinery 10 - 11
Warning decals 12
Chemicals 13
Connecting the equipment 14
Operation and speed 14
Relief spring (Anti-obstacle system) 14
Transport mode 15
Hydraulic hoses 16
Assembly instructions 17 - 24
Installing the hydraulic motor 35-HKK 21 - 22
Hydraulic diagram 23
Troubleshooting 25
Exploded diagrams and materials list 26 - 32
Notes 33 - 34
Deviation form 35
Warranty terms and conditions 36


Table of contents»
INTRODUCTION
Thank you for choosing a product from Kellfri AB. Compliance with the safety instructions,
operating manual and sound common sense will guarantee many years of enjoyment using
the product. Kellfri’s equipment and products are aimed at self-employed farmers, horse
enthusiasts and other country-dwellers who have stringent performance demands.
PRODUCT INFORMATION
• Powerful blades
• Hydraulic side shift adjustment
• Large number of possible settings
• Powerful spring-loaded cutting disc
• On three-point linkage, front or back
Extremely powerful strimmer for tractor’s three-point linkage, front or rear mounted.
With hydraulic side shift adjustment and spring-loaded cutting disc for eective cutting under
fences and close to buildings, railings and road verges. The guard plate hits the post and springs
back out of the way to return to its starting position, ensuring a close cut around the post.
Robust abradable blades that can cope with the toughest vegetation and robust guard plate
at base prevents blades from hitting the ground.
THE MACHINE’S FUNCTION
The equipment is intended solely for mowing grass. The machine is not designed for mowing
grass on large areas of grass, but only for mowing grass around trees, the sides of houses, fences
or similar.
TECHNICAL DATA 35-HKK
Length 2400 mm
Width 1500 mm
Height 850 mm
Working width 800 mm
Blades 2 pcs
Motor Parker 23 cc (built-in pressure limiter)
Oil ow
Max. pressure
Minimum 30l/min– maximum 60l/min
190 bar
Rotors 1 pc
3-point linkage Cat. 1 & 2
Weight 168 kg
Important! Before using the Strimmer, top up with grease.
See page 15 for instructions.

Table of contents»
SAFETY INSTRUCTIONS
Before using the equipment or product, and for the safety of yourself and others, you must
read the safety instructions and operating manual and understand their contents. Always keep
the safety instructions and operating manual handy for users of the equipment or product.
For the safety of both yourself and others, it may be a good idea to read through the safety
instructions every now and then. If the safety instructions or the operating manual are
damaged, or become unusable for any other reason, new copies may be ordered from:
Kellfri AB, Storsvängen 2, 532 38 SKARA, Sweden.
The safety instructions can also be downloaded from Kellfri’s website: www.kellfri.co.uk
Do not use the equipment or product if you feel ill, tired or are under the inuence of alcohol.
Do not use the equipment or product if you are taking prescribed medication or drugs,
or suering from severe depression or mental illness. Always comply with general rules of the
road and applicable rules stipulated by animal welfare legislation. People under the age of 15
are not allowed to use the equipment.
INSTRUCTIONS FOR EMERGENCY SITUATIONS
In case of emergency, call 112.
Always have a mobile phone or emergency phone available when working alone. A rst-aid
kit and re extinguisher must be kept in an easily accessible location when carrying out any
work, maintenance or service.
Warning!
The original design of the machine must not, under any circumstances, be modied without
the approval of the manufacturer. Unauthorised modications and/or accessories may cause
life-threatening injuries or death to users and others.
PERSONAL PROTECTION
Always use suitable protection equipment. Do not wear loose clothing or jewellery while
working with the equipment. Long hair should be tied up when working with equipment
that has moving parts. Use protective gloves to avoid the risk of burns if hot surfaces such
as exhaust pipes are touched, and to avoid oil and petrol getting in contact with the skin.
Ear defenders must be worn whilst the motor is running.
Kellfri is not liable for any modications, changes or rebuilds carried out by customers.
Where the machine is used professionally, employers are responsible for ensuring that users of the
machine have theoretical and practical knowledge of the machine and that work is performed
in a safe manner. Stay informed by complying with work environment legislation; contact your
local work environment authority.


Table of contents»
SURROUNDINGS
Check that the work area is free from bystanders and objects before hitching or using the
equipment. Otherwise, there is a risk of serious injury. Be extra careful if there are children in
the vicinity of the area where the equipment or product is used or stored. Check that there
are no low-hanging electrical cables within the work area. Exercise caution when working
on slopes and close to ditches.
Always work alone with equipment or products that are made for working alone. Never
leave rubbish in the work area, and keep work surfaces clean. Always respect the equipment’s
risk zone.
BEFORE USE
Carefully read the safety instructions and the operating manual. Make sure that you
understand the safety instructions, the instruction manual and warning decals. Use common
sense and suitable personal protective equipment when using the product. Always check the
performance of the machine combination to be used. It is important that these are compatible
and work satisfactorily together. This is to ensure that the equipment or product works
as expected, and to guarantee the safety of yourself and others. Carry out a visual inspection of
the equipment or product before use. Repair or replace damaged or worn parts immediately
to reduce the risk of injury. Grease moving parts and check that all nuts and bolts are
tightened. Repair if necessary. Learn and remember the correct working method. Beginners
must work slowly until they have learned how the machine or product works.
Users/customers are responsible for ensuring users can handle the situation. If a user
feels that the machine is dangerous to use, they should not use it until they have received
thorough training.
WARNING!
Never use equipment or products with defective safety components.
Children must not be left unsupervised in the area!
Warning!
Important! Before using the Strimmer, top up with grease. (See page .)
All lubrication points are greased after every 30 hours of use.
NOTE: Slowly and carefully pump in grease to prevent damage to the bearing seals.
Be extra careful when using a high-pressure grease gun.

Table of contents»
USE
Only those who understand the safety instructions and the operating manual may use
the equipment or product. Exercise caution and care when working with the equipment
or product, and only use it as described in the instruction manual.
There is a risk of crushing when working with equipment that has moving parts. Exercise
caution when working with equipment with hydraulic hoses, as oil under pressure can
penetrate the skin. Immediately seek medical attention if this should occur. Always work
alone with equipment that is made for working alone.
Respect the equipment’s risk zone.
For further information about your machine, read the machine’s operating manual.
DANGER!
CAUTION!
NOTE!
Warning symbols identify important safety aspects in this manual in order to help you and others avoid dangers
and accidents. When using the machine: Be extremely careful!
Warning!
This symbol indicates that a serious accident will occur if the directions in the operating manual are not
followed. The accident will lead to serious injury, possibly death, or serious damage.
This symbol indicates that an accident will occur if the directions in the manual are not followed.
The accident will lead to serious injury or damage.
This symbol indicates that an accident may occur if the directions are not followed.
The accident will lead to injury or damage.
NOTE indicates the risk of a breakdown if the directions are not followed.
Where the machine is used professionally, employers are responsible for ensuring that users of the
machine have theoretical and practical knowledge of the machine and that work is performed
in a safe manner. Stay informed by complying with work environment legislation; contact your
local work environment authority.
AFTER USE
• Ensure that the equipment/product is standing on level ground when it is disconnected.
Use stabilisers, if included with the product/tool.
• Wash, rinse with water and dry if necessary.
• Re-lubricate if necessary.


Table of contents»
MAINTENANCE AND SERVICE
• Make sure that the equipment is stable and cannot tip over when carrying out maintenance
and service work.
• Replace damaged or worn parts immediately to reduce the risk of injuries.
• Carry out maintenance, service and checks in line with recommendations.
• Only use spare parts with equal performance to reduce the risk of injuries and breakdowns.
• All electrical repairs and electrical connections must be carried out by a qualied person.
Check that all nuts and bolts are tightened after maintenance and service work.
Always test the mower before starting work.
IMPORTANT! Check the oil level and lubricate grease points regularly.
IMPORTANT! Avoid over-lubricating. Dirt collects easily on exposed grease and causes
increased wear. After lubrication, wipe excess grease o from couplings.
Kellfri AB has a policy of continuous product development and therefore reserves the right
to make modications, e.g. to the design and appearance of the product, without prior notice.
TRANSPORTATION AND SETUP
• Check that the work area is free from bystanders, children and objects before driving o.
• Always observe additional caution during transport and moving.
• Ensure that the equipment or product is well anchored and that available transport
lashings are tted.
• Always position the load as low as possible. All protruding loads should be well anchored.
• Respect the risk zones even during transport and moving.
• Do not permit anyone to walk under suspended loads when carrying out lifts.
• Trailers used for transport should have brakes that work.
• An SMV sign must be attached when travelling on public roads.
• Check tyre pressure - see information on the sidewalls of the tyres. Do not exceed
the maximum pressure!
• Always store the equipment or product in a dry place, preferably under a roof,
when not in use.
• Ensure that the equipment or product is stable and cannot tip over.
• Never permit children to play at the storage site.
• Be aware of the tipping risk!
RECYCLING
For scrapping, the equipment/product must be dismantled and transported
to a recycling station designated by your local authority. Any liquids should
be collected and transported to a recycling station designated by your local
authority. Contact your local authority for further information.
DANGER!
WARNING: Pressurised oil and fuel leaks can penetrate skin and cause serious
injuries. Do not use your hands to locate leaks. Use a piece of paper or cardboard
to look for leaks.

Table of contents»
FOR USING MACHINE/EQUIPMENT CONNECTED TO TRACTOR
PAY ATTENTION TO THE FOLLOWING:
• Carefully read the machine’s operating manual before using the machine! It is important
that you understand the directions in the manual.
• Keep the work area clear of children and other people. Moving parts increase the risk
of accidents.
• Never put your hands or feet under the machine without rst switching o the
equipment and the tractor’s engine.
• Never leave the equipment with the tractor engine running. Turn o the engine and
apply the parking brake when you leave the equipment – even for a short period.
• Always disengage the machine before performing service or maintenance work.
• Never leave the machine in a raised position. There can be a loss of pressure in
the hydraulics and the machine can drop to the ground.
• Ensure that all guards are in place and cannot come loose.
• The entire length of the PTO shaft must be protected. Ensure that the safety chain
is well anchored.
• Only the driver of the tractor may be present in the vicinity of the machine while it
is in operation.
• Before operation, ensure that there are no stones protruding from the eld.
• Never exceed the PTO shaft’s speed. (Recommended speed for most operation is 540 rpm.)
• Always adjust the rotor speed to the type of work to be carried out.
• Never use the machine if it is unbalanced.
• Do not try to remove jammed objects while the motor is running. Ensure that the motor
and the rotors have stopped before carrying out any measures on the machine.
• Ejection warning! Respect the machine’s risk zone of 15 - 25 m.
• Never hand over the machine to someone else until you are sure that they have
the necessary knowledge of the machine.
• It is prohibited to stand between the tractor/loader and the machine during attachment
and detachment.
• Operate a new machine at low speed and without a full load for the rst few hours.
• Exercise caution when working near power lines and telephone lines.
• Do not operate the machine if substantial vibrations develop. Stop the machine
immediately and inspect it.
• Before you connect or disconnect the hydraulic hoses, ensure that there is no longer
any pressure in the system. Pull the hydraulic handle from side to side several times
in order to remove pressure from the hydraulic hoses.
• Carry out a visual inspection of the equipment before use. Lubricate moving parts and
check that nuts and bolts are tightened. Repair or replace damaged or worn parts.
• When you disconnect quick couplings, ensure that you protect them after use, so that
they are not exposed to dirt.
• The tractor/loader should be tted with an ABE2 or ABE3 re extinguisher. Contact your
insurance provider.


Table of contents»
MACHINERY/EQUIPMENT CONNECTED TO HYDRAULICS
Be careful when you connect your machine or equipment to a hydraulic hose.
• Warning for high pressure, risk of penetration injury.
• Before repairs or maintenance are carried out, the system must be relieved of any
remaining pressure.
• Switch o the tractor and move the hydraulic levers back and forth to release any
pressure that may still be in the oil hoses and pipes before starting any work on them
or the hydraulic cylinders.
• Clean the lter in the suction pipe after 10 hours’ work.
• Immediately replace hydraulic hoses if cracks or wear are detected.
• Do not adjust the valve settings. Incorrect adjustment can result in damage to the machine
and/or injury.
• The hydraulic system must only be operated using hydraulic oil intended for the purpose.
Check the oil level before you start the machine!
• When commissioning a new machine, it is recommended that the hydraulic oil is changed
after the rst 10 hours of operation, in order to remove any dirt or metal chips which
may have got into the hydraulic system.
NOTE: The oil becomes hot when it ows through the hydraulic system. Check the oil temperature at regular
intervals in order to avoid overheating. Stop the machine if the oil becomes overheated and allow the oil
to cool down.
ENVIRONMENT
DANGER!
Pressurised oil and fuel leaks can penetrate skin and cause serious injuries. Do not use your
hands to locate leaks. Use a piece of paper or cardboard to look for leaks.
• Disposal of oil and other waste
• Improper disposal of oil or other waste may be hazardous to
the environment.
• When oil is emptied from the machine, it must be poured into
a leak-proof container suitable for oil. It is not permissible to store
oil in a container used for food or drink, in order to avoid the oil
being consumed by mistake and causing serious injury.
• It is prohibited to spill oil on the ground, or pour it into a drain
or anywhere leading to a water source.
• Discarded oil, fuel, coolant, brake uid, lters and batteries must
not be thrown away or emptied in just any manner. Contact your
local authority for further information.

 Table of contents»
RISKS AND HAZARDS ASSOCIATED WITH THE USE OF GARDEN MACHINERY
Risk of crushing
Observers can be injured when the machine is lowered in the cutting position. Pasture toppers
have crushing points around the hinge areas and between the 3-point linkage and the main
body. Respect the risk zone of 15 m!
Rotating blades
WARNING! Any person can risk injury by putting their hands or feet under the machine when
it is lifted from the ground and the blades are still rotating. Nobody is allowed in the vicinity
during operation or when the machine is running.
Risk of crushing
This risk is common in mechanical transmission devices such as belt drives, bevel gears
and rollers.
Ensure that all guards are correctly tted.
Rotating blades
Risk when disengaging machine
The heavier a rotating part is, the longer it will continue to rotate after the wheel drive
has been disconnected. This property is called free-wheeling. Rotating blades and other
components such as drive shafts, etc. will continue to spin round after the wheel drive
has been disconnected. Injuries occur:
• When the operator disconnects the equipment and attempts to clean or adjust the
machine before the components have stopped rotating.
• When the shear bolt in the PTO shaft protection breaks and the rotors continue to spin,
while the PTO has stopped. The operator’s awareness is of key importance for safety
around rotating parts. Never raise the machine while the blades are still rotating!
Risk of ejected objects
Machines that cut grass eject material during operation. Foreign objects such as stones, sticks
and other debris can nd their way under the machine and be ejected at great speed. Metal
guards at the sides and front prevent these objects being ejected, but this is no guarantee that
they will always capture everything.
Observers or animals standing in the way of an ejected object can suer serious
injury. Never operate the machine when there are observers nearby. Respect the
equipment’s risk zone of 15-25 m!
Noise
Note that the machine is intended for outdoor use and that the operator’s position is the driver’s
seat of the tractor. It is advisable to read the directions given in the tractor manual and
maintenance instructions. The sound pressure level during operation exceeds 70 dB.
Hearing protection must therefore be worn during operation.
Accidents involving slipping and falling are often a result of:
• Slippery surface
• Uneven steps and work platforms.
The risk of slips and falls can be reduced considerably by exercising good judgement.


Table of contents»
All unprotected rotating machine parts increase the risk of accidents. Accidents usually occur
when loose-tting clothing or long hair is caught and wrapped around rotating parts, such as
PTO shafts or drive shafts on the machine. Ensure that all guards are correctly tted.
Drive safely on public roads
• Always follow trac safety rules on public roads, and following the regulations applying
to driving a tractor with towed equipment on a public road.
• Check that reectors, warning signals and/or warning ags indicating protruding
equipment is tted to the machine or tractor. These indicators must be correctly mounted,
and must be visible and easy for drivers of other vehicles to see.
• Observers must not lean against or climb onto the machine during transport or during
work. NEVER allow anyone to travel on the machine!
• The maximum transportation speed must not exceed 20 km/h
• Brake regulations: If the gross weight of the trailer exceeds the gross weight of the towing
vehicle, the trailer must be equipped with a brake. For further information, contact the
trac authorities.
• IMPORTANT! Mark protruding equipment clearly with additional lights or suitable reectors.
It is important that the equipment is visible! If you are driving on a public road, any load
or equipment protruding in front of or behind the tractor must be marked. In darkness,
at dusk or dawn or in weather with poor visibility, the load must be marked with a white
reector and lantern at the front and a red reector and lantern at the rear. In daylight
you can mark the load with a ag or a piece of fabric in colours which are easy to notice,
such as red and yellow.
• Think about front-loaded equipment. As well as marking front-loaded equipment clearly,
you can also try to make front-loaded equipment such as a bucket, bale spike or pallet
forks less aggressive if another driver should collide with it.
• Before going out onto public roads, it is also always advisable to look over your vehicle
and check that the brake system on the following vehicle is working, and that your tow bar
eyes are not too worn. A worn out towing eye can break if subjected to a heavy load, and
you can lose the cart.
• It is also advisable to check that the SMV sign is clearly visible from behind. If it is obscured
by any equipment or load behind, you must hang an additional one at the rear of the
vehicle train.

 Table of contents»
WARNING DECALS
Make sure warning decals are always visible and clean them when necessary. Do not use
a high-pressure washer directly on the warning decal. If a part with a decal is replaced, or the
decal becomes worn or in any other way unusable, order a new set of decals.
SYMBOL EXPLANATION
Read the operating manual! Before starting work.
Ejection warning. Keep your distance!
No one should be in the vicinity of the machine during
operation. Risk zone 15 m.
Warning! Rotating blades.
Keep o the machine!
The machine is intended for working alone.
Risk of accidents to children.
Warning! Oil jet from hydraulic hose
Warning! Pressure in the line can penetrate the skin.
If this occurs, seek immediate medical attention.
Always store the product on a dry surface, preferably under a roof,
when not in use.
The equipment is CE marked.
POSITION OF THE WARNING DECALS
The CE plate is located on
the three-point linkage.
General warnings are located
on the parallel boom.
Warning of rotating blades on the blade guard.
Product name:
Type:
Weight:
Year of manufacture:
Serial no.:
2006/42/EC


Table of contents»
CHEMICALS
To maximise the service life of a product/equipment, maintenance - and not least preventive
maintenance - is important, and this is largely what greases and oils do. Carefully read
the operating manuals for your new products or equipment to ensure correct maintenance
and service life and that the warranty remains valid!
Lubricating greases
First aid measures.
Inhalation - In the event of unintended inhalation of fumes, move the injured person into
fresh air.
Skin contact - Wash with soap and water. Contact a doctor in the event of eczema or skin
complaints.
Eye contact - Remove contact lenses, if any, before rinsing. Rinse thoroughly with large
amounts of water, including under the eyelids. Contact a doctor if discomfort remains.
Ingestion - DO NOT induce vomiting. Drink water in small quantities. In the event of ingestion
or discomfort, contact the poison information service or a doctor.
Hand protection - Wear protective gloves.
Eye protection - Avoid contact with eyes. Wear approved protective goggles.
Body protection - Suitable protective clothing.
Respiratory protection - No protection is necessary during normal handling.
Grease should be stored well sealed in a cool place in a well-ventilated area. Storage
temperature must not exceed 45°C. Keep away from heat, ames and sparks. The function and
strength of materials such as steel, plastic, oils, grease, etc. deteriorates considerably at very
low temperatures (-20 to -30°C).
Degreasing
To ensure the best lubricating eect, you need to clean parts of the product or equipment
from time to time. We recommend degreasing to achieve thorough cleaning and to remove
all residues of old lubricant, which may contain destructive particles.
Keep chemicals out of the reach of children and animals.

 Table of contents»
CONNECTING THE EQUIPMENT
• Connect the machine to the tractor’s rear three-point linkage.
• NOTE: Remove the transport safety device before starting work.
• Connect the pressure hose (1/2" hose) to the tractor’s hydraulic outlet. Note: The return
hose (3/4" hose) must be connected to the free return on the tractor. Raise the
equipment and check its function. Connect leakage line directly to tank. Max. 0 bar
• Ready for use.
DRIVING AND SPEED
The amount of grass to be cut determines the forward speed; low speed usually produces the
best results. Start at the lowest possible speed; ensure that the mower is working eciently
with the motor at maximum RPM without straining.
Recommended ow min. 30L/min.– max. 60 L/min.
Max. 190 bar.
It is important to always listen to the motor to ensure that the motor and mower are working
eciently. Slow down or stop the motor if it starts to labour. Expected speed is much lower
when the machine is working hard.
Adjusting the cutting head’s distance from the tractor
• Always switch o the tractor’s engine before making any adjustments to the machine.
• Place the machine on the ground, t the stabilisers.
• Remove the pin from the beam and pull out or push in the cutting head to adjust
the distance. Ret the pin.
RELIEF SPRING ANTIOBSTACLE SYSTEM
Anti-obstacle system causes the unit to spring away
when it hits an obstacle.
• The tension of the spring should be adjusted
before using it to cut thick grass.
• When cutting in an area of dense growth,
the spring must be tensioned.


Table of contents»
TRANSPORT MODE
When the mower is to be moved from one workplace to another, it must be put in transport
mode. The tractor engine must be switched o and the rotor completely stationary before
adjusting to transport mode.
Remove all grass from the mower before leaving the eld. Never move from one place to another
with the rotor running.
INSPECTION
It is very important to check the machine regularly in order to detect and prevent wear
and tear, damage, etc.
• Grease moving parts regularly. All lubrication points should be greased after every
30 hours of use. NOTE: Slowly and carefully pump in grease to prevent damage to the
bearing seals. Be extra careful when using a high-pressure grease gun.
NOTE: Grease nipples located under the machine
IMPORTANT! FOR REPAIRS OTHER THAN THE PREVIOUSLY LISTED ADJUSTMENTS, CONTACT YOUR LOCAL DEALER.

 Table of contents»
HYDRAULIC HOSES
• Inspect all hydraulic hoses and couplings daily to ensure that they are in good condition.
• Pay particular attention to any chafed outer casing.
• Any damage or leaks must be rectied immediately.
• Hoses with a damaged metal braid should be replaced.
• If a coupling is leaking, it must be replaced.
The hose is weakened when installed in twisted
position. In addition, pressure pulses in a twisted hose
tend to wear out threads and loosen connections.
Important!
To avoid twisting when replacing the hose, use two
wrenches to loosen and tighten.
Medium hose, PRESSURE 1/2"
Marked RED.
Connect the pressure hose is
to the tractor’s hydraulic outlet.
Thicker hose, RETURN 3/4"
Marked BLUE.
The return hose must be
connected to a free return
on the tractor.
Max. back pressure
return 10 bar.
If the hoses are tted incorrectly, the gasket in the motor is pushed out, resulting in leakage.
The motor cannot be used until the gasket has been replaced. Pressure in the leakage line must not
exceed pressure in the return hose.
WARNING!
Narrower hose, LEAKAGE LINE
Marked DARK BLUE.
Connect directly to tank.
Max. 0 bar.
Warning! Must never be
connected to the return!
Warning! It is forbidden
to plug the leakage line!
1/2” quick coupling
3/8" external straight Banjo 1/4" x 14mm
1/2” quick coupling
DRAIN
0 bar
PRESSURE
LÄCK
0 bar
TRYCK
TANK RETURN RÜCKLAUF
LECK
0 bar
DRUCK


Table of contents»
ASSEMBLY INSTRUCTIONS
-point frame cutting head
rubber stop
suspension beam for cutting head
Bolt kit
 x Mx
 grease nipples
hydraulic motor
wheels

 Table of contents»
) Lift the -point frame, t the cutting head suspension and remove the sleeve from the shaft
to t the cutting head.
) Fitting the cutting head.
Lubricate the shaft before tting the cutting head. See gures below:
FIGURE 
t
FIGURE  FIGURE 
FIGURE 
Lubricate


Table of contents»
Ret the sleeve
FIGURE 
FIGURE 
FIGURE 
) Fit the wheels.

 Table of contents»
) Lift and turn the machine so that you can t grease nipples under the machine. Warning:
risk of crushing. Make sure that the machine cannot topple over. Fit the grease nipples and
lubricate all joints.
FIGURE 
FIGURE 
lift and turn
t and tighten bolts
t and lubricate
FIGURE 
) Fit hydraulic motor and check hydraulic couplings.
