Kellfri 27-V18ATV User manual

27-V18ATV
ATV ROAD DRAG
CAREFULLY READ THE OPERATING INSTRUCTIONS BEFORE USING THE PRODUCT!!
TRANSLATED FROM THE ORIGINAL

2
INTRODUCTION
Thank you for choosing a product from Kellfri AB. By following the general safety information
and the instruction manual and by using common sense, you will have a great and safety use
of your Kellfri product for many years. Kellfris tools and products aimed at the self operateing
farmer with high demands on functionality.
PRODUCT INFORMATION
Grader with rotatable edge steel for ATV or small tractor, angled steel and individually adjust-
able wheels for grading road angles. Powerful wheels, stable fully galvanised frame for half
pallet, 50 mm rotatable ball coupling, working width 180 cm, blade length 193 cm. Wheels
adjustable 15 cm individually, making it easy to retract gravel verges into the road, scrape and
level roads, courtyards and paddocks, etc.
ART. NO 27-V18ATV
Length 1950 mm
Working width 1800 mm
Height Adjustable up to 150 mm
Weight 85 kg
Wheels 4.80/4.00-8
Wheel width 1600 mm
Ball coupling 50 mm
INTENDED USE
Intended to scrape gravel paths, horse riding tracks and bridleways.

3
SAFETY INSTRUCTIONS
Before using the equipment or product, and for the safety of yourself and others, you must
read the safety instructions and the instruction manual and understand its contents. Always
keep the safety instructions and instruction manual handy for users of the equipment or prod-
uct. For the safety of both yourself and others, it may be a good idea to read through the
safety instructions every now and then. If the safety instructions or instruction manual gets
damaged or in any other way cannot be used, new copies may be ordered from:
Kellfri AB, Munkatorpsgatan 6, 532 37 SKARA
Sweden. Tel.: [phone] (Pls. contact the retailer) https://www.kellfri.co.uk/
Do not use the equipment or product if you feel ill, tired or are under the inuence of alcohol.
Do not use the equipment or product if you are taking prescribed medication or drugs. Always
comply with general rules of the road and applicable rules stipulated by the Protection of An-
imals Act. People under the age of 15 are not allowed to use the equipment.
Warning!
The product must not in any circumstances be
modied without permission from the manufac-
turer. Unauthorized modication of the machine
and/or accessories can cause fatal injuries or death
to operator or others.
PRODUCT SAFETY INSTRUCTIONS
• It is the user’s responsibility to read through the instructions and comply with them.Read
the ATV manual before connecting the implement.
• Always check that the performance of the machine combination to be used with to ga-
rantuee safety and funtionality.
• Never leave the driver’s seat until the brakes on the towing vehicle have been applied.
• The risk area is 5 metres. Only the operator is allowed to be within the risk area while the
trailer is in use.
• When unhitching the implement, it must be empty and on a level surface with the trailer
wheels secured using suitable brake blocks.
• To stop the implements movements in the event of emergency, stop the ATV.
• The implement is not equipped with lights and is only intended to be used during the
day. If necessary, the implement can be tted with a magnetic rear light.
• An SMV sign must be attached when travelling on public roads.
• The road drag is tted with a 50 mm ball coupling. Regularly check the coupling for wear
and tear. EU has regulations on how fast a tractor with a non-brake trailer is allowed to go.
Comply with these regulations.
• Make sure that ATV’n has enough weight in the front for safe driving. Avoid fast move-
ments.
• When servicing the equipment, put the implement on level ground.

4
WARNING DECALS
Make sure that the warning decals are always visible, clean the warning labels if necessary. Do
not wash with high pressure washer directly on the warning label. If any part of the decal is
worn or label becomes frayed or otherwise unreadable, order new decals.
When traveling on public roads, SMV plate must be xed,visiblely and clearly.
SYMBOL
EXPLANATION
Read the operating manual!
Stop the engine for repairs
Risk zone 5 m
Greasing after 10 hours of operation
Retighten all bolts and connections
Warning! Accident risk for children!
Children are not allowed in the vicinity ofthemachine
Prohibition to stay on the machine
The product is CE marked
INCASE OF EMERGENCIES
In case of an emergency please dial 112.
Keep cell phone or emergency phone available specially when working alone. First aid kit and
re extinguishers must be kept easily accesable during all work, maintenance and service.
PERSONAL PROTECTIVE EQUIPMENT
Wear suitable clothing and footwear. Do not wear loose clothing or jewelry when working
with the equipment. Remember to put up long hair when working with equipment that ro-
tates. Wear protective gloves during maintenance.

5
SURROUNDINGS
Check and make sure that the area is clear of people, children and objects before switching
on or using the equipment. Risk of serious personal injury. Be especially careful if children are
in the area where the equipment is being use or stored. Check that there are no low-hanging
power lines within the work area. Be careful when working on slopes and near ditches.
Always work alone with equipment designed for single - purpose tools/products. Never have
junk/debris lying in your work area. Have workspaces clean. Always respect the risk zone.
BEFORE USING
Read the instruction manual carefully. Be sure that you understand the safety information, in-
struction manual and warning labels. Use common sense when using and use the appropriate
personal protective equipment Always check the performance of the machine combination
to be used. Importantly, these harmonize and match in a satisfactory manner. This is to ensure
the implement function and your and others’safety.
Visually inspect the gear or the product before use. Fix or replace damaged and worn parts
immediately to reduce the risk of injury. Lubricate moving parts and check that all screw-nuts
and bolts are tightened. Clearing when necessary.
Learn and remember the correct working methods. Beginners should always keep a low
speed, use extreme caution before routine and product knowledge is achieved. The user/cus-
tomer is responsible to handle the situation correctly. The product should not be taken into
use unless it can be done in a safe way for the user.
USE / OPERATION
Only people who understand the safety information and instructions in this manual may op-
erate the equipment. Be alert and careful when working with the machine and only use the
tool or product in the manner described in this manual. When working with equipment that
has moving parts, there is always the risk of injury. Be careful when working with equipment
equipped with hydraulic hoses ,oil under pressure can penetrate the skin. Seek medical at-
tention immediately if this occurs. Always work alone with the tools that are dened as single
porpose tools. Respect the equipment’s danger zone.
Warning!
For safety, this product should only be used in
the manner described in this manual. The user is
responsible for the instruction to be read through
and followed.
DANGER!
Children in the area should be supervised.

6
IMPLEMENT CONNECTIVITY
• Check that the equipment is not damaged before connecting it to the vehicle.
• Mount the implement to the towing vehicle. Secure the ball-coupling
• Set the desired height of the blade.
• Drive and control the implement.
USE
• Check the surface before driving
• Reduce speed when working on slopes and uneven terrain.
• Practice the movement pattern calmly and methodically.
• Maximum speed when driving 10 km / h.
• If the ground need more weight during processing, the frame is made to carry a half
pallet to use as barlast.
Warning!
Never use faulty safety equipments!
TRANSPORT AND STORING
Make sure there are no people, children and foreign objects around the area before transport-
ing the machine. Always take an extra caution during the transport. Ensure that the product
is well secured and that transport brackets are mounted. Always place the load as low as pos-
sible. Respect the danger zone even during transport. When lifting the equipment, never go
underneath suspended loads. Trailer used for transport should have working brakes.
Always store the machine in a dry place preferably underneath a cover when not in use. Ensure
that the product is stable and not likely to tip over. Never let children play where the machine
is being stored. Always keep in mind the risk of tipping!

7
ART. NO. SPARE PARTS LIST V18 ATV
R27-V18ATV.001 Blade
R27-V18ATV.002 Wheel incl. height adjustment
STORAGE
To extend the life of the product,keep it under cover when not in use.
MAINTENANCE AND SERVICE
Ensure that the unit is stable and cannot tip over during maintenance and service. Replace
damaged or worn parts immediately to reduce the risk of abrasion. Always perform mainte-
nance, service and inspection, as recommended. Use only original replacement parts or spare
parts with equivalent performance to reduce the risk of damage.
Check all nuts and bolts are tightened after performning maintenance and service.Never weld
towing eye as it alters the strength!Contact Kellfri for spare parts.

8
1 x Frame
1 x Tow bar
1 x Grader blade
2 x Wheels - left and right wheel
INSTALLATION INSTRUCTIONS
Check so that all parts are included, the mounting bolts are mounted on the frame.

9
1. Attach the wheels to the frame, note: right and left wheels
INSTALLATION INSTRUCTIONS

10
3. Mount the drawbar, then place the trailer gently on the ground. Check and tighten all
bolts.
2. Flip the frame and then mount the blade, be careful and ensure that the frame assembly
can not overturn.

11
We are grateful for your help pointing out any inaccuracies in the Kellfri product delivered to you. Before making a complaint
read Kellfris general warranty and sales conditions in our catalog as well as the enclosed User’s manual that comes with the
product.
Please ll in the details below and attach photo and other information in order to process your request.
Buyer: Customer number:
Adress: Invoice number:
E-mail: Phone nr:
Defect product / part:
Problem description:
Describe the sequence of events:
Other:
Submit Complaint form and photo to:
Kellfri AB
Division of service: (Contact Kellfri retailer)
Munkatorpsgatan 6
532 37 Skara
Or e-mail service.
[email protected]
Signiture: Date:
When was the product delivered? When was the product taken into
operation?
Did the product functioned as it should
upon the rst operation?
KELLFRI AB
Munkatorpsgatan 6
SE-532 37 SKARA
Phone: [phone]
Fax. [phone]
Web
www.kellfri.se
E-mail
[email protected]
Issue: 2014-01-01
Complaint form

Kellfri AB
Telefon: [phone] - 242 50
Fax: [phone] - 168 33
E-post: [email protected]
EGFÖRSÄKRAN OM MASKINENS ÖVERENSTÄMMELSE, ORIGINAL
EC-DECLARATION OF CONFORMITY
According to 2006/42/EC, Annex 2A
Kellfri AB
Munkatorpsgatan 6
532 37 Skara, Sweden
Declares that the machine
Name: 27-V18ATV
Type: ATV Road Drag
Complies with all applicable provisions of the Machinery Directive 2006/42/EC.
Other equipment must meet the hardware requirements of the Directive
Tina Baudtler, VD
WARRANTY TERMS AND CONDITIONS
Validity of the warranty - Kelifri’s Warranty is valid  months from the date of pur-
chase
This warranty replaces - Compensation for spare parts after acknowledgment that
the fault lies on the material or manufaturing deects.
This guarantee do not
cover
• Labour costs
• Travel expenses
• Any modication that the buyer himself has/had made.
• Any consequential damages that occured out of damage
to the machine.
• Damage due to normal deterioration of the machine, in-
adequate: service, user inexperience or use of spare parts
which are not original.
• Wear parts such as hoses, seals, oils, and mechanical belts
Kellfri AB is constantly working on further developing their products and therefore reservesthe
right to modify, among other things the design and appearance without notice
CUSTOMER SERVICE
You are always welcome to give your feedbacks, reviews or ask us about our tools and products.
Latest version: 2015-09-24
