Kellfri 27-V1500 User manual

Carefully read the operating instructions
before using the product!
Operating instructions translated from Swedish
27-V1500
ROLLER, TOWED

Table of contents
Kellfri designs and supplies ecient, aordable machinery and components for forestry,
agriculture, construction and gardening in Sweden, the rest of the Nordic region and Europe.
Please note that the information in this document is general and may not pertain to your
particular machine. We therefore recommend that you always read and follow the safety
instructions and the instructions in the machine's operating manual.
Kellfri is not liable for any errors in this document.
TABLE OF CONTENTS
Introduction 3
Product information 3
Application 3
Safety instructions 4
Instructions for emergency situations 4
Personal protection 4
Surroundings 5
Before use 5
Use 6
After use 6
Maintenance and service 7
Transportation and set-up 7
Recycling 7
Warning decals 8
Product safety information 9
Connecting 9
Filling with water 9
When laying new peat or grass seeds 10
When levelling the lawn 10
Exploded diagrams and materials list 11
Notes 12 - 14
Deviation form 15
Warranty conditions 16


Table of contents
INTRODUCTION
Thank you for choosing a product from Kellfri AB. Compliance with the safety instructions,
operating manual and sound common sense will guarantee many years of enjoyment using
the product. Kellfri’s attachments and products are aimed at self-employed farmers, horse
enthusiasts and other country-dwellers who have stringent demands on performance.
PRODUCT INFORMATION
Kellfri's towed roller is connected behind your ATV or rider mower. Supplied with both pin tow
coupling and ball coupling. To achieve maximum weight, the roller is lled with water. The
robust design makes the roller the perfect tool for compacting and levelling soil, for example
for lawns or newly sowed surfaces.
Supplied unassembled.
AREA OF USE
The roller is primarily designed for preparing and levelling the soil for new grass seeds or turf
to ensure a good transition between the soil and new roots or seeds.
TECHNICAL DATA 27-V1500
Working width 1500 mm
Filled max. weight 200 kg
Total width 1,650 mm
Weight 65 kg

Table of contents
SAFETY INSTRUCTIONS
Before using the equipment or product, and for the safety of yourself and others, you must
read the safety instructions and instruction manual and understand their contents. Always
keep the safety instructions and operating manual handy for users of the equipment or
product. For the safety of both yourself and others, it may be a good idea to read through
the safety instructions every now and then. If the safety instructions or the operating manual
are damaged, or become unusable for any other reason, new copies may be ordered from:
KellfriAB, Munkatorpsgatan 6, SE-532 40 SKARA, Sweden.
The safety instructions can also be downloaded from Kellfri’s website: www.kellfri.co.uk
Do not use the equipment or product if you feel ill, tired or are under the inuence of alcohol.
Do not use the equipment or product if you are taking prescribed medication or drugs, or
suering from severe depression or mental illness. Always comply with general rules of the
road and applicable rules stipulated by animal welfare legislation. People under the age of 15
are not allowed to use the equipment.
INSTRUCTIONS FOR EMERGENCY SITUATIONS
In case of emergency, call 112
Always have a mobile phone or emergency phone available when working alone. A rst-aid
kit and re extinguisher must be kept in an easily accessible location when carrying out any
work, maintenance or service.
Warning!
The original design of the machine must not, under any circumstances, be modied
without the approval of the manufacturer. Unauthorised modications and/or accessories
may cause life-threatening injuries or death to users and others.
PERSONAL PROTECTION
Always use suitable protection equipment. Do not wear loose clothing or jewellery while
working with the equipment. Long hair should be tied up when working with equipment
that has moving parts. Use protective gloves to avoid the risk of burns if hot surfaces such
as exhaust pipes are touched, and to avoid oil and petrol getting in contact with the skin. Ear
defenders must be worn whilst the engine is running.
Kellfri is not liable for any modications, changes or rebuilds carried out by customers.
Where the machine is used professionally, employers are responsible for ensuring that users of the
machine have theoretical and practical knowledge of the machine and that work is performed in
a safe manner. Stay informed by complying with work environment legislation; contact your local
work environment authority for more information.


Table of contents
SURROUNDINGS
Check that the work area is free from bystanders and objects before hitching or using the
equipment. Otherwise, there is a risk of serious injury. Be extra careful if there are children in
the vicinity of the area where the equipment or product is used or stored. Check that there
are no low-hanging electrical cables within the work area. Exercise caution when working on
slopes and close to ditches.
Always work alone with equipment or products that are made for working alone. Never leave
rubbish in the work area, and keep work surfaces clean. Always respect the equipment’s risk zone.
Do NOT let anyone ride on the roller!
BEFORE USE
Carefully read the safety instructions and the operating manual. Make sure that you under-
stand the safety instructions, the operating manual and warning decals. Use common sense
and suitable personal protective equipment when using the product. Always check the
performance of the machine combination to be used. It is important that these are compat-
ible and work satisfactorily together. This is to ensure that the equipment or product works as
expected, and to guarantee the safety of yourself and others. Carry out a visual inspection of
the equipment or product before use. Repair or replace damaged or worn parts immediately
to reduce the risk of injury. Grease moving parts and check that all nuts and bolts are tight-
ened. Repair if necessary. Learn and remember the correct working method. Beginners must
work slowly until they have learned how the machine or product works.
Check the drum for leaks before each use.
Users/customers are responsible for ensuring users can handle the situation. If a user feels
that the machine is dangerous to use, they should not use it until they have received thorough
training.
WARNING!
Never use equipment or products with defective safety components.
Children must not be left unsupervised in the area!
Warning!

Table of contents
USE
Only those who understand the safety instructions and the operating manual may use the
equipment or product. Exercise caution and care when working with the equipment or
product, and only use it as described in the instruction manual.
There is a risk of crushing when working with equipment that has moving parts. Reduce speed
when working on slopes and uneven ground. Always work alone with equipment that is made
for working alone. Respect the equipment’s risk zone.
For further information about your machine, read the machine’s operating manual.
DANGER!
CAUTION!
NOTE
Warning symbols identify important safety aspects in this manual in order to help you and others avoid dangers
and accidents. When using the machine: Be extremely careful!
Warning!
This symbol indicates that a serious accident will occur if the directions in the operating manual are not
followed. The accident will lead to serious injury, possibly death, or serious damage.
This symbol indicates that an accident will occur if the directions in the manual are not followed.
Theaccident will lead to serious injury or damage.
This symbol indicates that an accident may occur if the directions are not followed.
The accident will lead to injury or damage.
NOTE indicates the risk of a breakdown if the directions are not followed.
Where the machine is used professionally, employers are responsible for ensuring that users of the
machine have theoretical and practical knowledge of the machine and that work is performed in
a safe manner. Stay informed by complying with work environment legislation; contact your local
work environment authority for more information.
AFTER USE
• Ensure that the equipment/product is standing on level ground when it is disconnected.
Use stabilisers, if included with the product/tool.
• Wash, rinse with water and dry if necessary.
• Re-lubricate if necessary.


Table of contents
MAINTENANCE AND SERVICE
• Make sure that the equipment is stable and cannot tip over when carrying out maintenance
and service work.
• Replace damaged or worn parts immediately to reduce the risk of injuries.
• Carry out maintenance, service and checks in line with recommendations.
• Only use spare parts with equal performance to reduce the risk of injuries and breakdowns.
Check that all nuts and bolts are tightened after maintenance and service work.
Always test the roller before starting work.
IMPORTANT! Avoid over-lubricating. Dirt collects easily on exposed grease and causes
increased wear. After lubrication, wipe o excess grease.
TRANSPORTATION AND SETUP
• Check that the work area is free from bystanders, children and objects before driving o.
• Always observe additional caution during transport and moving.
• Ensure that the equipment or product is well anchored and that available transport lash-
ings are tted.
• Always position the load as low as possible. All protruding loads should be well anchored.
• Respect the risk zones even during transport and moving.
• Do not permit anyone to walk under suspended loads when carrying out lifts.
• Trailers used for transport should have brakes in working order.
• An SMV sign must be attached when travelling on public roads.
• Check tyre pressure - see information on the sidewalls of the tyres. Do not exceed the
maximum pressure!
• Always store the equipment or product in a dry place, preferably under a roof, when not
in use.
• Before long-term storage, the machine should be thoroughly cleaned and lubricated.
• The drum should be emptied of water before long-term storage. (Especially important
during winter.)
• Ensure that the equipment or product is stable and cannot tip over.
• Never permit children to play at the storage site.
• Be aware of the tipping risk!
RECYCLING
For scrapping, the equipment/product must be dismantled and transported to
arecycling station designated by your local authority. Contact your local authority
for further information.
Kellfri AB has a policy of continuous product development and therefore reserves the right to
make modications, e.g. to the design and appearance of the product, without prior notice.

Table of contents
WARNING DECALS
Make sure warning decals are always visible and clean them when necessary. Do not use a
high-pressure washer directly on the warning decal. If apart with a decal is replaced, or the
decal becomes worn or in any other way unusable, order a new set of decals.
SYMBOL EXPLANATION
Read the operating manual! Before starting work.
Caution! Before maintenance, servicing, and connecting and
disconnecting the roller, the engine must be switched o
and the ignition key removed.
Risk zone 5 m
Respect the equipment’s risk zone!
Warning! Risk of crushing!
Warning! Keep o the roller!
Warning! Accident risk for children!
Children are not allowed near the roller.
Always store the product on a dry surface, preferably under
aroof, when not in use.
The product is CE-marked
Product name:
Type:
Weight:
Year of manufacture:
Serial no.: 2006/42/EC


Table of contents
PRODUCT SAFETY INFORMATION
• Carry out a visual inspection of the equipment before use.
• Keep away from the roller during work and transport.
• Be careful when transporting the roller on country roads and comply with the trac
regulations. Make sure that the tractor has sucient weight at the front for safe driving.
Avoid strong jerking motions.
• When servicing, place the equipment on a level surface.
• Only the driver of the tractor may be near the machine while it's operational.
• Do not let anyone ride on the roller!
CONNECTING
• Connect the equipment to an ATV or ride-on mower.
• Do not forget to t the locking pins.
• Ready for use.
• Keep an eye on the work area while working.
FILLING WITH WATER
• Extra weight may be needed when levelling uneven ground.
• Connect the equipment to the towing vehicle.
• Move the roller until the plug on the side of the roller is positioned at the top.
• Loosen the plug.
• Fill the roller with water, use a hose.
• Screw the plug back on.
• Ready for use.
• When draining the water: Move the roller until the plug is positioned at the bottom of the
roller. Unscrew the plug. When the water has stopped running, screw the plug back on.
The roller may need to be tipped to empty all the water.
FILLER/DRAIN PLUG

 Table of contents
WHEN LAYING NEW PEAT OR GRASS SEEDS
• Connect the roller behind the towing vehicle, follow the correct connection and lling
procedure for the roller if extra weight is required.
• Check the area to be levelled. Make sure that there are no stones protruding in the work
area. Clear the area of large stones or foreign objects.
• Start dragging the roller across the ground in long straight lines.
• Make sure that the ground is level. Some areas may need to be done in a few stages.
• Continue to pull the roller over the area until the surface is smooth and even.
• Place turf or seeds over the area.
• Pull the roller over the newly laid peat/seed to help the grass roots or seeds make good
contact with the soil.
• Keep the area well-watered until the peat or seeds grow well.
WHEN SMOOTHING THE GRASS MAT
• Dig about 7–10cm around the bulged area or hole. Remove the grass and ll the hole
with soil at the same level with the lawn. Put the grass back in place.
• Pull the roller over the area until it is smooth and even with grass inll. If the area does not
appear to be even, try watering and then drag the roller over the area again. Repeat the
same procedure for each bump.
Roller with loosening tips.


Table of contents
ITEM NO. DESIGNATION QUANTITY
1 Drum 1
2 Washer 1
3 Plug 1
4 Joint bushing 2
5 Grease nipple 2
6 M10 x 55 bolt 2
7 Ø10 at washer 2
8 Locking nut M10 2
9 Bracket U-bracket 1
10 Bolt M8x50 4
11 Flat washer Ø8 4
12 Locking nut M8 4
13 Bracket T-bracket 1
14 Pin tow bar 1
15 Tow bar ball hitch 1
16 Bolt M12 x 70 2
17 Flat washer Ø12 2
18 Locking nut M12 2

 Table of contents
NOTES:


Table of contents
NOTES:

 Table of contents
NOTES:


Table of contents
We are grateful for your help in pointing out any defects in the product supplied to you by Kellfri. Before making a claim, read
Kellfri’s general purchase terms and conditions in our catalogue or on our website www.kellfri.co.uk, and in the operating
manual if supplied. The manual can also be downloaded from www.kellfri.co.uk/manuals
Please fill in the details below and attach photos as documentation so that we can process your case optimally. In order for us
to get as good an understanding as possible of any faults, please take at least 3 photos of the defective part of the machine/
equipment and 1 picture on the type plate. (NB! Do not forget to attach the pictures to the e-mail when you send the form!)
If the product was purchased from a dealer, please contact the dealer in the first instance.
REASON YES
11) Transport damage*
(09) Product complaint*
(04) Wrong goods delivered
(03) Wrong quantity
Purchaser**: Customer number**:
Address**: Invoice number:
E-mail**: Daytime telephone**:
Customer’s signature: Date:
Signature: Date:
Dealer: Invoice number:
When was the product supplied? When was the product put into operation? Was the product working on delivery?
Product name/article number**:
Serial number:
DEVIATION FORM
Description of fault**:
Describe the course of events:
Miscellaneous:
Edition: 21 December 2020
YES NO
REASON YES
(05) Wrong price
(02) Ordered by mistake/Charge-back
(99) Other reason*
* Fill in form below
To be filled in by the dealer
Case number:
Required elds**

Kellfri AB
E-mail: [email protected]
In accordance with 2006/42/EC, Appendix 2A
Kellfri AB
Munkatorpsgatan 6
SE-532 40 Skara, Sweden
Hereby declares that the machine
Name: 27-V1500
Type: Roller, towed
Conforms with all applicable requirements in the Machinery Directive 2006/42/EC.
Other equipment must comply with the Machinery Directive’s requirements.
WARRANTY TERMS AND CONDITIONS
The warranty’s validity - Kellfri’s warranty is valid for 12 months from the date of purchase
The warranty covers - Reimbursement for parts replaced after a material fault or
manufacturing fault has been verified.
The warranty does not cover - Labour costs
- Travel costs
- A machine that the purchaser himself has modified,
or has been modified by a third party.
- Any additional costs arising as a result of damage to the machine.
- Damage due to normal wear and tear of the machine,
substandard servicing, the user’s inexperience or
use of spare parts that are not original.
- Wear parts such as hoses, seals, oil and belts.
You are always welcome to give feedback or ask us about our equipment and products.
Kellfri AB has a policy of continuous product development and therefore reserves the right
to make modifications, e.g. to the design and appearance of the product, without prior notice.
CUSTOMER SERVICE
EC DECLARATION OF CONFORMITY FOR MACHINERY, ORIGINAL
Last updated 14/12/2021
Kjell Johansson
Product Development Manager
