Kellfri 27-DC User manual

27-DC
GARDEN TRAILER WITH TOW BAR
READ THIS MANUAL CAREFULLY BEFORE USING THE PRODUCT !!!
TRANSLATED FROM THE ORIGINAL


INTRODUCTION
Thank you for choosing a product from Kellfri AB. By following general safety information,
operating instructions and common sense, you will have many years of enjoyable use of the
product. Kellfris equipment and products are aimed to be use by active farmers with high
demands on functionality.
PRODUCT INFORMATION
Tipping trailer with clevis hitch for garden tractor or smaller ATV, tiltable oor with oor catch.
The oor catch is released with a foot pedal and the oor is tipped by hand, a 410 kg load
capacity, rubber balloon wheels and UV-resistant powder-coated nish. Fold-down sides with
high rails and opening tailgate.
PRODUCT INFORMATION
The trailer is designed to transport loose materials or branches / logs to a maximum load of
410 kg for a Garden tractor or small ATVs.
TECHNICAL DATA
Width 840 mm
Platform Size 1500 x 775 x 515 mm
Wheels 16”x 5”
Max load 410 kg
Weight 58 kg
Total height 970 mm
Total length 2050 mm
L x W x H 2050 x 840 x 970 mm


BASIC SAFETY INSTRUCTIONS
Before using the equipment or product, and for the safety of yourself and others, you must
read the safety instructions and the instruction manual and understand its contents. Always
keep the safety instructions and instruction manual handy for users of the equipment or prod-
uct. For the safety of both yourself and others, it may be a good idea to read through the safety
instructions every now and then. If the safety instructions or instruction manual gets dam-
aged or in any other way cannot be used, new copies may be ordered from:
Kellfri AB, Munkatorpsgatan 6, 532 37 SKARA
Sweden. Tel.: [phone] (Pls. contact the retailer)
The general safety instruction is also available from Kellfris website: www.kellfri.co.uk
Do not use this equipment if you are feeling sick, tired or in inuence of alcohol. Nor if you
are under the inuence of strong medications or drugs, suering from strong depression or
severe mental illness. Always follow the general trac rules and regulations and the rules of
the Animal Welfare Act. Persons under 15 years old and people with mental illness may not
use these product.
DANGER!
Careful!
NB!
Warning symbols identify important safety aspects in this manual to help you and others avoid danger and ac-
cidents. When using the machine: Take extreme caution!
Warning!
This symbol indicates that a serious accident will occur if the instructions in the manual are not followed.
The accident results in serious injury, possibly death or serious property damage.
This symbol indicates that an accident will occur if the instructions in the manual are not followed. The
accident results in serious injury or property damage.
This symbol indicates that an accident could occur if the instructions are not followed. The accident
results in personal injury or property damage.
NB indicates the potential for the breakdown if the instructions are not followed.


PRODUCTSAFETY INFORMATION
Read the towing vehicle manual.
• Always check the performance of the machine combination to be use with the trailer
to ensure the safety and function. The trailer is not equipped with any lighting device:
mount magnetic tail lights or equivalent if necessary.
• When disconnecting, make sure the trailer standing on level ground.
• Drive straight up or down in steep terrain.
• Avoid driving with a fully loaded trailer in slopes.
• Do not drive down steep slopes if the risk is too high that the trailer will tip over
• Never overload the cart! Maximum load 410kg
• Never leave the driver’s seat until the towing vehicle is braked.
• Danger zone 5 meters. No one other than the operator may be present within the danger
zone during work with the trailer.
• The operator may under no circumstances stand underneath a suspended load.
• The trailer may not be parked with the load unattended!
• When the trailer is to be disconnected, it must be done unloaded , on a at surface and
the trailer wheels secured with appropriate blocks.
• Use only the trailer for its intended use
• The trailer may not under any circumstances be driven on highways.
The product must not in any circumstances
be modied without permission from the
manufacturer. Unauthorized modication of
the machine and/or accessories can cause fatal
injuries or death to operator or others.
Warning!


WARNING LABELS
Make sure that the warning labels are always visible, clean the warning labels if necessary. Do
not wash with high pressure washer directly on the warning label. If any part of the decal is
worn or label becomes frayed or otherwise unreadable, order new decals.
SYMBOL Explanation
Read the manual
Turn o the engine and remove the key from the ignition
when repairing or when leaving the vehicle even for a
short moment.
Danger zone 5 m
Do not stand underneath a suspended load
Warning! Moving parts
Risk child accident!
Children is not allowed near the machine
Prohibition to stay on the machine
The product is CE marked
INSTRUCTION FOR EMERGENCIES
In case of an emergency please dial 112.
Keep cell phone or emergency phone available specially when working alone. First aid kit and
re extinguishers must be kept easily accesable during all work, maintenance and service.
PERSONAL PROTECTION
Always use appropriate protective equipment. Do not wear loose clothing or jewelry when
working with the tool.


SURROUNDINGS
Check and make sure that the area is clear of people, children and objects before switching
on or using the equipment. Risk of serious personal injury. Be especially careful if children are
in the area where the equipment is being use or stored. Check that there are no low-hanging
power lines within the work area. Be careful when working on slopes and near ditches. Always
work alone with equipment designed for single - purpose tools/products. Never have junk/
debris lying in your work area. Have work spaces clean. Always respect the danger zone.
Danger!
Children in the area should be supervised.
BEFORE USE
Read the instruction manual carefully. Be sure that you understand the safety information,
instruction manual and warning labels. Use common sense when using the trailer and use ap-
propriate personal protective equipment. Always check the performance of the machine com-
bination to be used. It’s highly important, these harmonize and match in a satisfactory man-
ner. This is to ensure the equipment function and your and others’ safety. Do visual inspection
before use. Fix or replace damaged and worn parts immediately to reduce the risk of injury.
Lubricate moving parts and check that all screw-nuts and bolts are tightened. Learn and re-
member the correct working methods. Beginners should always keep a low speed, use ex-
treme caution before routine and product knowledge is achieved. The user/customer is re-
sponsible to handle the situation correctly. The product should not be taken into use unless it
can be done in a safe way for the user.
• Check the tire pressure, recommended pressure 25 psi / 1 bar.
OPERATING THE MACHINE
Only people who understand the safety information and instruction manual to oper-
ate this equipment or product. Be aware and cautious while working with the equip-
ment or product, and use only the tool or product in the manner described in the
instruction manual. When working with equipment that has moving parts there is a
risk of crushing. Be careful when working with the equipment with hydraulic hoses
since oil under pressure can penetrate the skin. Seek medical attention immediately
if this occurs. Always work alone with the tools that are intended for this. Respect
equipment danger zone.
Warning!
The trailer is not designed for transporting people, do not let anyone
ride in the trailer while driving.


• Check that the trailer is intact before connecting it to the vehicle
• Never drive with the rear of the trailer in the tilted position
• Always make sure the trailer is properly attached to the towing vehicle and does not
come loose
• Never overll the trailer, excess load may cause the trailer and towing vehicle to lose trac-
tion and slip out of control
• Do not load more than the maximum load of 410 kg
• Fill the trailer only with appropriate load, heavy load could cause the trailer to be dicult
to maneuver and the platform dicult to tilt.
• Use only the trailer for its intended use
• Use only approved towing vehicles to tow the trailer with the (Garden Tractor / ATV)
• Always make sure that the combined weight of the towing vehicle and the driver must
always be greater than the weight of load.
• DO NOT tow the trailer on public roads. The trailer is not approved for driving on public
roads
• Maximum speed when driving 15km / h
• Do not make any sudden turns, it can cause the garden tractor / ATV’s wheels to rub
against the trailer platform
• Always slow down before turning
Warning!
For safety, this product should only be used in the manner
described in this manual. The user is responsible for the in-
struction to be read through and followed.
AFTER USE
• Make sure the trailer standing on level ground when disconnecting.
• When parking on inclined ground, place block at the wheels before disconnecting.
• To prolong the life of your trailer, do not let it stand outside. Keep it covered.
• Clean, rinse with water and dry your cart.
TRANSPORT AND STORING
Make sure the area is clear of people, children and objects prior to transportation. Always be
extra careful during transport and movement. Ensure that the equipment or product is well
anchored and that existing transport safety devices are installed. Always place the load as low
as possible. Respect the danger zone even in the transport and movement.When lifting, never
stand underneath a suspended load. Trailer used to transport should have functioning brakes.
Always keep the tool or product in a dry place, preferably under cover when not in use. Make
sure that the equipment or product is stable and not likely to tip over. Never let children play
at the storage site. Keep in mind the risk of tipping!


MAINTENANCE AND SERVICE
Make sure the equipment is stable and not likely to tip over during maintenance and service.
Disconnect the trailer from the vehicle while the defects are xed.
Replace damaged and worn parts immediately to reduce the risk of injury. Use only spare
parts with equivalent performance to reduce the risk of damage and failure. Perform mainte-
nance, servicing and inspections according to the recommendations.
Regularly check the condition of the trailer.Tighten wheel bolts and nuts as necessary. If cracks,
twisting, bending, glitches or fatigue is detected, stop using the equipment immediately and
repair the equipment. Avoid the use of the tool at lower temperatures than -20C and higher
temperatures than +30C.
• Always check the air pressure of the wheels, the air pressure shall always be about 25 psi
(about 1 bar). Never pump wheels more than necessary
• Check the wheel axle and wheel bearings, lubricate them regularly.
• Clean the trailer carefully before storing it especially when it will be stored a longer pe-
riod. When stored for a long period it is recommended that the vehicle is stored under a
roof or covered with tarpaulin.
• Check all bolts and nuts are tightened after maintenance and service.
• Always test the machine before work is started.
Warning!
Never use a tool or product
with defect safety equipment.
RECYCLING
Disposal of the product, the machine should be disassembled and transported to the munici-
pality recycling station. Contact your municipality for further information.


Position Description QTY Position Description QTY
A Bottom plate of the bed 1 U Platform foot 1
B Wheel shaft support 2 V Pin - Hitch 1
C Tow bar 1 W Towing bracket 1
D Sidegate - left 1 X Handle A 1
E Sidegate- right 1 Y Handle B 1
F Side gate 2 Z Handle sleeve 2
G Front door 1 AA R-pin Ø3 6
H Front gate 1 AB Flat Washher Ø6 2
I Release lever 1 AC Flat washer Ø8 2
J Tailgate 1 AD Flat washer Ø20 4
K Wheel 2 AE Bolt M6x16 8
L Backgate left rail 1 AF Bolt M4x16 12
M Backgate right rail 1 AG Bolt M8x16 8
N The wheel axle 1 AH Hex Bolt M8x20 1
O Clamp 6 AI Hex Bolt M6x95 1
P Washer 6 AJ Nylock nut M6 9
Q R-pin 8 AK Nylock nut M8 11
R Ring pin 1 AL Nylock nut M4 12
S Spacer 2 AM Nut M6 2
TPin 2


Position Description QTY
A Bottom plate of the bed 1
B The wheel shaft support 2
C Tow bar 1
D Dropside - left 1
E Dropside- right 1
F Side gate 2
G front gate 1
H front door 1
I Tailgate 1
J Backgate left rail 1
K Backgate right rail 1
L The wheel shaft 1
M Platform foot 1
N Wheel 2
A
D
E
C
L
N
H
F
F
J
K
M
G
I
B


AA BB CC DD
EE FF GG
1. Mount platform feet (M) on the platform bottom plate
(A), secure with M6x16 (BB) and M6 nylock nut (FF). Do
not tighten the bolts yet.
BB M6x16 Bolt
FF M6 Nylock
ASSEMBLY:
Prepare all parts before assembly, check that none of the parts are missing.
Tools needed for assembly: measuring tape, screwdrivers, 10 mm and 13 mm wrenches
2. Install the support wheel axle 2st (B) on the platform
bottom plate (A), secure with M8x16 (CC) and M8 nylock
nut (EE). Do not tighten the bolts yet.
CC M8x16 Bolt
EE M8 Nylock


3. Mount tow bar (C) on the wheel shaft support (B).
Inserting the wheel shaft through the wheel support (B)
and tow bar (C). Tighten all bolts from Step 1-3
4. In the following order, assemble Ø20 at washer (GG),
wheels (N) and the Ø20 at washer (GG) and secure with
R-pin (DD)
GG Ø20 Flatwasher
DD R-pin Ø3
5. Install the rails (J & K) on the back of each dropside (D
& E), secure with M6x16 (BB) and nylock nut M6 (FF) on
each side.
BB M6x16
FF Nylock nut M6
AA R-pin


6. Install the front gate (G) on the bottom plate (A) and
secure with R-pin (AA). Lock the front gate in place on
the left and right sides of the gates (D & E)
AA R-pin
7. Push the tailgate in the rails of the dropsides.
Note: To lock the tailgate in place, the tailgate pins are
mounted into the holes on the side gates.
8. Install the side gates (F) on the drop sides. Mount the
gate in front (H) secure in place with 2xs R-pin (DD)
DD R-pinØ3


9. The trailer will not tip when the R-pin Ø3 (DD) is mount-
ed on the tow bar

In order to tip the trailer, remove the R-pin from the tow-
ing bar and tip it manually by hand.
DD R-pin Ø3


We are grateful for your help pointing out any inaccuracies in the Kellfri product delivered to you. Before making a complaint
read Kellfris general warranty and sales conditions in our catalog as well as the enclosed User’s manual that comes with the
machine.
Please ll in the details below and attach photo and other information in order to process your request.
Buyer: Customer number:
Adress: Invoice number:
E-mail: Phone nr:
Defect product / part:
Problem description:
Describe the sequence of events:
Other:
Submit Complaint form and photo to:
Kellfri AB
Division of Services : Contact Kellfri retailer
Or e-mail service.
[email protected]
Signiture: Date:
When was the product delivered? When was the product taken into
operation?
Did the product functioned as it should
upon the rst operation?
Complaint form

Kellfri AB
Phone: [phone] - 242 50
Fax: [phone] - 168 33
E-mail: [email protected]
EGFÖRSÄKRAN OM MASKINENS ÖVERENSTÄMMELSE, ORIGINAL
EC-DECLARATION OF CONFORMITY
According to 2006/42/EC, Annex 2A
Kellfri AB
Munkatorpsgatan 6
532 37 Skara, Sweden
Declares that the machine
Name: 27-DC
Type: Garden trailer with tow bar
Complies with all applicable provisions of the Machinery Directive 2006/42/EC.
Other equipment must meet the hardware requirements of the Directive.
Tina Baudtler, CEO --
WARRANTY TERMS AND CONDITIONS
Validity of the warranty - Kelifri’s Warranty is valid  months from the date of purchase.
This warranty replaces - Compensation for spare parts after acknowledgment that the
fault lies on the material or manufacturing defects.
This guarantee do not
cover
• Labour costs
• Travel expenses
• Any modication that the buyer himself has/had made.
• Any consequential damages that occurred due to damage
to the machine.
• Damage due to normal deterioration of the machine, inade-
quate: service, user inexperience or use of spare parts which
are not original.
• Wear parts such as hoses, seals, oils, and mechanical belts
Kellfri AB is constantly working on further developing their products and therefore reserves the right
to modify, among other things the design and appearance without further notice.
CUSTOMER SERVICE
You are always welcome to give your feedbacks, reviews or ask us about our tools and products.
