1. THE A7 MIG GUN 500-G
This document provides product information for the
Kemppi A7 MIG Gun 500-g.
Kemppi MIG/MAG guns for automatic welding are
designed for demanding professional use. They are
suitable for use in all MIG units equipped with Kemppi
robotic MIG wire feeders and power sources
2. PREFACE
Congratulations on your purchase of this product. Used
correctly, Kemppi products can signicantly increase the
productivity of your welding, and provide many years of
economical service.
This operating manual contains important information on
the use, maintenance, and safety of your Kemppi product.
The technical specications of the equipment can be
found in the chapter “Technical data” and at the end of
this manual.
Please read the manual carefully before using the
equipment for the rst time. For your own safety and that
of your work environment, pay particular attention to the
safety instructions in the manual.
For more information on Kemppi products, contact
Kemppi Oy, consult an authorized Kemppi dealer, or visit
the Kemppi Web site: www.kemppi.com.
The specications presented in this manual are subject to
change without prior notice.
Disclaimer
While every eort has been made to ensure that the
information contained in this guide is accurate and
complete, no liability can be accepted for any errors
or omissions. Kemppi reserves the right to change the
specification of the product described, at any time,
without advance notice. Do not copy, record, reproduce,
or transmit the contents of this guide without prior
permission from Kemppi.

4
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
3. IDENTIFICATION
The welding gun system Kemppi A7 MIG Gun 500-g is used
in industry and in the trade for welding using inert gases
(MIG) or active gases (MAG). This model is gas-cooled
and can be used in all welding positions. These operating
instructions describe only the welding gun system A7 MIG
Gun 500-g. The welding gun system may only be operated
as supplied or with authentic Kemppi spare parts.
Figure 1: Kemppi A7 MIG Gun 500-g
4. CE MARKING
This device fulls the requirements of the following EU
directives:
• The Machinery Directive, 2006/42/EC
• The EMC Directive, 2004/108/EC
• The RoHS Directive, 2011/65/EU
5. SAFETY
Read and follow the additional safety instructions
enclosed.
5.1 Designated use
The gas-cooled welding gun system A7 MIG Gun 500-
g must be used for robot and automatic application as
described in this manual. Designated use also includes
complying with the prescribed operation, maintenance,
and servicing conditions.
Any use other than that described under“Designated use”
is considered contrary to the intended use.
Unauthorized conversions or power-increasing modi-
cations are not allowed.
The warranty does not cover wear parts and damage due
to overloading or improper use.
5.2 Responsibilities of the user
• Keep the operating instructions within easy reach
in the location of the device for reference, and
include the operating instructions when handing
over the product.
• Installation, operation, and maintenance work
may only be carried out by qualied personnel.
Qualied personnel are persons who, on account
of their special training, knowledge, experience,
and familiarity with the relevant standards, are
able to assess the tasks assigned to them and
identify possible dangers.
• Keep all other persons out of the work area.
• Follow the accident prevention regulations of the
relevant country.
• Ensure good lighting of the work area, and keep
the area clean.
• Observe the following standards and guidelines
in particular:
• 89/391/EEC: Directive on the introduction
of measures to encourage improvements in
the safety and health of workers at work
• 2009/104/EC: Directive concerning the
minimum safety and health requirements
for the use of work equipment by workers
at work
• 2004/108/EC: Directive on the
harmonization of the laws of the Member
States relating to electromagnetic
compatibility The occupational health and
safety regulations of the country in question
• Regulations on occupational safety and
accident prevention
5.3 Personal protective equipment
To avoid danger to the user, using personal protective
equipment (PPE) is recommended in these instructions.
PPE consists of the following:
• Protective clothing
• Safety goggles
• A class-P3 respiratory mask
• Gloves
• Safety shoes

5
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
5.4 Signs used in the documentation
Items in the manual that require particular attention, to
minimize damage and personal injury, are indicated with
a three-level notication and warning system. Read these
sections carefully, and follow the instructions.
Note: These items give the user a useful piece of
information.
Caution: A cautionary item describes a situation that
may result in damage to the equipment or system.
Warning: Warnings describe a potentially dangerous
situation. If not avoided, it will result in personal harm or
fatal injury.
5.5 Warning and notice signs
The following warning and notice signs can be found on
the product:
Read and observe the operating instructions!
These markings must always be legible. They must not be
covered, obscured, painted over, or removed.
5.6 Emergency instructions
In the event of an emergency, immediately interrupt the
following:
• The power supply
• The ow of compressed air
Further measures are described in the operating
instructions or in the documentation of other peripheral
devices.
5.7 Operation safety
Please study these operation safety instructions and
respect them when installing, operating, and servicing
the machine.
The welding arc and spatter
The welding arc harms unprotected eyes. Be careful also
with reecting ashes from the arc. The welding arc and
spatter burn unprotected skin. Wear safety gloves and
protective clothing.
Danger of re or explosion
Pay attention to re safety regulations. Remove ammable
or explosive materials from the welding location. Always
reserve sucient re-ghting equipment at the welding
location. Be prepared for hazards in special welding jobs –
for example, the danger of re or explosion in welding of
container-type work pieces.
Fire can break out from sparks even several hours after
the welding is completed!
Cables
Always check the cables before operating the equipment.
Replace damaged cables without delay.
Damagedcables maycauseinjury orstart are.Connection
cables must not be compressed or make contact with
sharp edges or hot work pieces.
The welding power circuit
Isolate yourself by using proper protective clothing, and
do not wear wet clothing. Never work on a wet surface or
use damaged cables. Do not place the MIG gun or welding
cables on the welding machine or on other electric
equipment. Do not press the MIG gun’s switch if the gun is
not directed towards a work piece.
Welding fumes
Make sure that there is sufficient ventilation during
welding. Take special safety precautions when welding
metals that contain lead, cadmium, zinc, mercury, or
beryllium.

6
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
5.8 Product safety
Hazards caused by improper use
If improperly used, the device can present risks to people and physical property.
• Use the device in accordance with its designated use only.
• Do not convert or modify the device to enhance its performance without
appropriate authorization.
The device may only be used by qualied personnel.
• The product has been developed and manufactured in accordance with state-of-
the-art technology and the recognized safety standards and regulations. These
operation instructions warn you against unavoidable residual risks to users, third
parties, devices, or other physical property.
Disregarding these warnings may result in risks to human life and health, harm to
the environment, or other physical damage.
• The product may only be operated in unmodied, technically perfect condition,
within the limits described in these instructions.
• Always observe the limit values specied in the technical data. Overloads lead to
destruction.
• Safety features of the device must never be disassembled, bridged, or otherwise
bypassed.
• During welding work outdoors, use suitable protection against the weather
conditions.
• Check the electrical device for any damage and for proper functioning in
accordance with its designated use.
• Never expose the electrical device to rain, and avoid damp or wet environments.
• Protect yourself from electrical accidents by using insulating mats and wearing
dry clothing.
• Never use the electrical device in areas subject to a risk of re or explosion.
• Arc welding may cause damage to the eyes, skin, and hearing. When working
with the device, always use the prescribed protective equipment.
• Metal vapors, especially from lead, cadmium, copper, and beryllium, are all
hazardous to the health! Ensure that sucient ventilation or extraction systems
are in use. Always ensure compliance with the legal limit values.
• Using clean water, rinse work pieces that have been degreased with chlorinated
solvents, to prevent the risk of phosgene gas forming. Do not place degreasing
baths containing chlorine in the vicinity of the welding area.
• Adhere to the general re protection regulations, and remove ammable
materials from the vicinity of the welding work area before starting work.
• Keep suitable re-extinguishing equipment ready for use in the work location.

7
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
6. TECHNICAL DATA
This chapter provides the technical data of the gun.
6.1 General data
The table below provides general torch data in line with EN 60 974-7.
Type of voltage DC
Polarity of the electrodes Usually positive
Wire types Commercially available round wires
Type of use Automatic
Voltage rating Peak value of 141 V
Protection type of the machine
side connections
IP3X (EN 60 529)
Shielding gas (DIN EN 439) CO and mixed gas M21
6.2 Product-specific data
This table provides product-specic torch data as laid out in EN 60974-7.*
Type Type of
cooling
Load ED Wire Ø Gas ow Weight
CO M21
A7 MIG G (A) (A) (%) (mm) (l/min)
500-g gas 500 40 100 0.8–1.6 10–30 900
* For pulse-arc operation, the load gures are reduced by up to 35%.
Figure 2: Torch neck lengths Figure 3: Torch neck diameters
6.3 Abbreviations
DC Direct current
ED Duty cycle
MIG Metal inert gas
MAG Metal active gas
MAC value Maximum allowable concentration of harmful substances in the
work location
Voltage rating Insulation resistance, electric strength, and protection class
TCP Tool center point
6.4 The type plate
The Kemppi A7 MIG Gun welding gun system is identied by a sticker or a Kemppi
logo. When contacting our service sta, please remember to check the production
stamp located near the Kemppi logo on the gun neck.

8
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
7. DELIVERY SCOPE
The standard scope of delivery for the hose assembly includes the following
components:
• Kink protection on the torch neck side with an integrated switch cover
• Kink protection on the machine side with a central plug
• Operating instructions
For the initial assembly, the following components are required, depending on the
welding task at hand.
• Torch neck (in the preferred size and geometry)
• Mount (required for attachment to the robot)
• Set-up parts and wear parts (ordered separately)
We oer this cable assembly in a gas-cooled version only. Order data and part numbers
can be found in the current Kemppi spare-parts and wear-parts list. For the complete
system, you will require a setting device. It must be ordered separately and depends on
the conguration. The contact information for consulting and ordering can be found
on the Internet, at www.kemppi.com.
8. TRANSPORT
The components are carefully checked and packed; however, damage may still occur
during shipping.
Checking procedure on
receipt of goods
Check that the shipment is correct by referring to the
shipping note.
In case of damage Check the package and components for damage (perform
a visual inspection).
In the event of problems If the goods have been damaged during transport, contact
the last carrier immediately. Keep the packaging (for
possible checks by the carrier).
Packaging for return of
the goods
Use the original packaging and the original packaging
materials. If you have questions about the packaging and
safety during shipment, please consult your supplier.
9. STORAGE
The appropriate physical conditions for storage in a closed room are 25 °C to 55 °C.

9
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
10. FUNCTIONAL DESCRIPTION
The functioning welding gun system Kemppi A7MIG Gun
500-g comprises the following components:
Figure 4: Welding gun system A7 MIG Gun 500-g
1
5
4
3
2
1. Torch neck
2. Connection module
3. Hose assembly
4. Central plug
5. Mount
Risk of injury due to unexpected start-up
For the entire duration of maintenance, servicing,
unmounting, and repair work, the following instructions
must be adhered to:
• Switch o the power supply.
• Cut o the compressed air supply.
• Pull the power plug.
All elements together form an operating unit that
provides a plasma arc for welding when supplied with
the appropriate operation resources. The welding wire
required for welding is fed through the welding gun
system A7 MIG Gun 500-g all the way to the contact
tip. The contact tip transmits the welding current to the
welding wire, producing an arc between the welding wire
and work piece. The light arc and the molten pool are
protected by the inert gas (MIG) or active gas (MAG).
10.1 The neck
Standard A7 MIG Gun 500-g necks are available in the
following geometries: straight, 22°, 35°, and 45° bends.
Special designs will be manufactured upon request,
depending on the application.
The uniform interface at the connecting module makes all
torch necks compatible with one another.
10.2 The connection module
The connection module establishes the connection
between the welding torch and the hose assembly.
10.3 The mount
The mount is used to attach the welding gun system to the
robot via the Kemppi robot mount.
10.4 The hose assembly
The gas-cooled hose assembly provides the welding torch
with all components required for welding, such as welding
current, shielding gas, and air.

10
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
11. INSTALLING THE ROBOT GUN
Risk of injury due to unexpected start-up
For the entire duration of maintenance, servicing,
unmounting, and repair work, the following instructions
must be adhered to:
• Switch o the power supply.
• Cut o the compressed air supply.
• Pull the power plug.
Read the safety instructions in this manual and the
separate safety instructions.
The system may only be installed by authorized personnel.
11.1 Assembling the A7 MIG Gun 500-g
neck
This section describes how to assemble the A7 MIG Gun
500-g neck.
Figure 5: A7 MIG Gun 500-g neck assembly
2
3
4
7
8
6
5
1
1. Gas nozzle
2. Contact tip
3. Tip adapter
4. Gun neck
5. Neck liner connection module
6. Allen key
7. Adjustable wrench
Proceed as follows:
1. Screw the replaceable tip adapter (3) into the torch
neck (4), and tighten it, using an adjustable wrench
(8).
2. Screw the contact tip (2) into the tip adapter (3),
and tighten it with the adjustable wrench (8).
3. Screw the gas nozzle (1) onto the tip adapter (3) by
hand.
4. Insert the torch neck (4) all the way into the
connecting module (6).
5. Tighten the hexagonal-head screws by using the
Allen key (7).
6. Insert the neck liner (5) on the connection side
through the connecting module (6) into the torch
neck (4).

11
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
11.2 Connecting the hose assembly to the gun
This section describes how to assemble the A7 MIG Gun 500-g neck.
Figure 6: Connecting the hose assembly to the gun
1 2
3
4
7 68
5
1. Connection module
2. EMERGENCY STOP cable
3. Control line
4. Air-blast hose
5. Central plug connection
6. Hose assembly
7. Robot mount
Proceed as follows:
8. Select the proper wire type and the corresponding wire guide. See Section 12.3
for details on cutting the wire to size and on correct mounting.
• Wire liners for steel and stainless steels
• PA liners for aluminum, copper, nickel, and stainless steels 5. Joining the
hose assembly with the gun
9. Lay the hose assembly (7) straight, and attach it to the connection module (1) on
the gun neck side.
10. Slide the ready-to-use wire guide from the central plug (5) up to the stop in the
changeable body, and screw it down by using the connection nut (6).
If required, connect the EMERGENCY STOP cable (2) of the robot mount (8) to the hose
assembly (7). See Section 11.4.
11.3 Mounting the wire feeder side connection
This section describes how to mount the wire feeder side connection. See Section 11.2.
Proceed as follows:
1. Check that the wire guide has been fastened in place correctly.
2. Join the central plug (5) and the central socket at the wire feed unit, and secure them
with a connection nut (6).
3. Fasten the air-blast hose (4) to the air-blast and spraying unit or the air-blast valve.
Seal the connection gas-tight if the “Cleaning with compressed air” option will not be
in use.

12
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
11.4 Connecting the control line
The control line is normally delivered with a pre-soldered amphenol plug, which is
compatible with the Kemppi wire feeder. Otherwise, choose a compatible plug for your
wire feeder and solder it to the corresponding wires in accordance with the assignment
plan.
Figure 7: Connecting the control line
The color codes are:
• a = green
• b = white
• c = brown
• d = yellow (insulated)
• e = gray (insulated)
• f = blue (insulated)
• g = pink (insulated)
• h = black
• i = purple
• j = red (insulated)
11.5 Setting the shielding gas quantity
This section describes how to set the shielding gas quantity.
The type and quantity of the shielding gas depend on the welding task and the gas
nozzle geometry.
To prevent the shielding gas supply from becoming clogged by impurities, the cylinder
valve must be opened briey, before connection of the cylinder. This will blow out any
impurities that may be present.
Make all shielding gas connections gas-tight.
Proceed as follows:
1. Connect the shielding gas cylinder to the wire feeding system.
2. Set the gas quantity on the pressure reducer of the shielding gas cylinder.
11.6 Introducing the wire
This section describes how to introduce the wire.
Each time you change the wire, make sure that the beginning of the wire is burr-free.
Proceed as follows:
1. Insert the wire in the wire feed unit as specied by the manufacturer.
2. Press the“Current-less wire feed” button at the wire feed unit.

13
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
12. OPERATION
Shortness of breath and poisoning caused by inhaling
phosgene gas
Phosgene gas is formed during the welding of work pieces
that have been degreased with chlorine-containing
solvents.
Do not inhale fumes and vapors.
Ensure a sucient supply of fresh air.
Rinse the work pieces with clear water prior to welding.
Do not place degreasing baths containing chlorine in the
vicinity of the welding area.
Risk of burns
During welding work that sprays sparks, glowing work
pieces or hot slag can produce ames.
Check the work area for seats of re.
Make suitable re-extinguishing materials available in the
work location.
Allow the work pieces to cool down after welding.
Before performing welding work, fasten the ground clamp
properly to the work piece or the welding table.
Dazzling of the eyes
The arc produced by welding may damage the eyes.
Wear suitable protective clothing and eye protection.
The welding torch may only be operated by qualied
personnel.
Ensure that all required parameters, such as the welding
current and wire feed, have been set at the welding power
supply in accordance with your welding task.
12.1 The welding process
This section describes the welding process.
Proceed as follows:
1. Open the shielding gas cylinder.
2. Switch on the power supply.
12.2 Completing the welding process
This section describes how to quit when the welding
process has been done.
Proceed as follows:
1. Wait until the shielding gas ow has subsided.
2. Close the shut o valve for the gas supply.
3. Switch o the power supply.

14
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
12.3 Maintenance and cleaning
Scheduled maintenance and cleaning are prerequisites for
a long service life and trouble-free operation.
Once a month, thoroughly clean the robot mount to
remove all dirt and welding spatter.
Risk of injury due to unexpected start-up
For the entire duration of maintenance, servicing,
unmounting, and repair work, the following instructions
must be adhered to:
• Switch o the power supply.
• Cut o the compressed air supply.
• Pull the power plug.
Electric shock
Dangerous voltages can be produced because of defective
cables.
• Check all live cables and connections for proper
installation.
• Replace any parts that have suered damage,
deformation, or wear.
The maintenance intervals listed are recommended
values and assume single-shift operation.
• Maintenance and cleaning work may only be
carried out by qualied and trained specialists.
• Always wear your personal protective clothing
when performing maintenance and cleaning
work.
• Remove adhering welding spatter.
• Check all screw joints for a tight t.
• The maintenance intervals listed are
recommended values and assume single-shift
operation.
12.3.1 Cleaning the wire guide
This section describes how to clean the wire guide.
Risk of injury
Serious injuries can be caused by parts articulating rapidly.
When cleaning the wire guide with compressed air, wear
suitable protective clothing – in particular, safety goggles.
Proceed as follows:
1. Unscrew the hose assembly from the machine side,
and lay it straight.
2. Unscrew the retaining nut, and pull out the wire
liner or PA liner.
3. Clean the wire feed hose from both sides with
compressed air.
4. Slide the adjusted wire liner or PA liner into the wire
feed hose, and secure with a retaining nut.

15
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
12.3.2 Shortening the wire liner
This section describes how to shorten the wire liner.
Unused wire liners or PA liners have to be shortened to
the actual length of the hose assembly.
Mounting of plastic liners is similar to mounting of
wire liners. Refer to the operating instructions of the
manufacturer of the wire feeder.
Plastic liners are used for aluminum. Plastic liners and
fastening material are available on request.
Figure 8: Shortening the wire liner
2
1
6
5
4
3
1. Support sleeve
2. Central plug
3. Hose assembly
4. Retaining nut
5. Collet chuck
6. Liner
Proceed as follows:
1. Lay out the hose assembly (3) straight.
2. Disconnect the central plug (2) from the feed unit.
3. Remove the old liner (6), and replace it with a new
one. Then insert the non-insulated side into the
central plug (2) as far as it will go.
4. Place the support sleeve (1), turned 180°, on the
new spiral liner (6) (on the side without the liner).
5. Cut o the protruding wire liner (6). The liner must
be even with the support sleeve (1).
6. Screw the collet chuck (4) onto the spiral liner (6) as
far as it will go.
The position of the wire guide can be checked
through the sight hole of the collet chuck (5).
7. Slide the collet chuck (5) and the wire liner (6) into
the central plug (2) as far as they will go.
8. Slide the support sleeve (1), with the thread side
rst, into the central plug (2), and tighten it.
9. Attach the hose assembly (3) to the central plug (2),
using the retaining nut (4).
12.3.3 Cleaning the gun neck
This section describes how to clean the gun neck.
To increase the availability time of the welding robot,
Kemppi oers an option for automated gun cleaning.
Proceed as follows:
1. Remove the gas nozzle.
2. Remove welding spatter, and spray the gas nozzle
with a suitable anti-spatter agent.
3. Check the wear parts for visible damage, and
replace any damaged parts if doing so is required.
4. Replace the equipment kit if it is worn or dirty.
5. Clean the separating point and O-rings with a
silicone-free sealing grease.
6. Check the TCP after each use and after any
collisions. Use, for example, an alignment jig to do
this.

16
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
13. TROUBLESHOOTING
Risk of injury due to unexpected start-up
For the entire duration of maintenance, servicing, unmounting, and repair work, the
following instructions must be adhered to:
• Switch o the power supply.
• Cut o the compressed air supply.
• Pull the power plug.
In the event of any doubts or problems, please contact your retailer or the
manufacturer.
Please also consult the operating instructions for the other welding components,
such as the power supply and air pressure line.
Problem Cause Solution
Gun neck gets hot Contact tip not tightened Check and tighten
Contact tip loose on the neck side. Check and tighten, and direct toward the work piece
No push-button function Control line interrupted or defective Check/repair
Wire burned solid in the contact tip Wrong parameters set Check or correct the setting(s)
Contact tip worn out Replace
Irregular wire feed Guide spiral liner / PA liner clogged Clean in both directions with compressed air, or replace the liner if
necessary
Contact tip and wire diameter not correctly matched Replace contact tip
Wrong contact pressure set at the wire feed unit Correct as specied by manufacturer
Arc between gas nozzle and work piece Spatter bridge between contact tip and gas nozzle Clean and spray gas nozzle interior
Unstable arc Contact tip not matched to the wire diameter, or increase in contact
tip diameter
Check contact tip
Wrong welding parameters set Correct welding parameters
Wire guide unit worn out Replace wire guide unit
Pore formation Strong spattering in the gas nozzle Clean gas nozzle
Insucient or missing gas cover Check gas cylinder contents and pressure setting
Air currents blow shielding gas away Shield welding area with partitions

17
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
14. UNMOUNTING
This section describes how to unmount the welding gun.
Unmounting may only be carried out by specialist personnel. Please make sure that
the shutdown procedures are strictly observed before the unmounting work begins.
Ensure this also for the components integrated into the welding system.
Risk of injury due to unexpected start-up
For the entire duration of maintenance, servicing, unmounting, and repair work, the
following instructions must be adhered to:
• Switch o the power supply.
• Cut o the compressed air supply.
• Pull the power plug.
For the entire duration of maintenance, servicing, unmounting, and repair work, the
following instructions must be adhered to:
• Switch o the power supply.
• Cut o the compressed air supply.
• Switch o the entire welding system.
• Pull the power plug.
See also Section 12.2.
Proceed as follows:
1. Disconnect the hose assembly from the wire feed.
2. Remove the parts to be disconnected (changeable body, mount, robot mount, and
gun neck).
14.1 Disposal
For disposal, the locally applicable regulations, laws, provisions, standards, and guidelines
must be observed. For the welding torch system to be properly disposed of, it must be
unmounted rst.
14.2 Materials
This product consists for the most part of plastics, steel, and non-ferrous metals. Steel
and non-ferrous metals can be melted down, so iron materials are almost innitely
recyclable. The plastic materials used are marked in preparation for appropriate sorting
of the materials for later recycling.
14.3 Consumables
Oils, greases, and cleaning agents must not contaminate the ground or enter the
sewer system. These materials must be stored, transported, and disposed of in suitable
containers. Please observe the relevant local regulations and the disposal instructions on
the safety data sheets supplied by the manufacturer of the consumables. Contaminated
cleaning tools (brushes, rags, etc.) must also be disposed of in accordance with the
information provided by the manufacturer of the consumables
14.4 Packaging
The shipping packaging has been reduced to a minimum. Packaging materials are
always selected with attention to their recyclability.

18
A7 MIG Gun 500-g© Kemppi Oy 2016 1616
OPERATING MANUAL
15. PRODUCT CODES FOR ORDERING
Gun neck Product code
Gun neck A7 MIG 500-g 0° * SP600621
Gun neck A7 MIG 500-g 22° SP600622
Gun neck A7 MIG 500-g 35° SP600623
Gun neck A7 MIG 500-g 45° SP600624
* For the correct cable length, inform Kemppi of the robot
type and the robot manufacturer.
Robot gun mount Product code
Gun mount T3 W SP600574
Gun mount T3 G SP600575
Gun mount T1 W SP600588
Gun mount T1 G SP600589
Gun mount T2 L SP600605
Gun mount T2 XL SP600606
Segment holder for T2 gun mount SP600608
Consumable parts for A7 MIG guns
Item Type Product code
Contact tip holder CONTACT TIP ADAPTER M8 G500 (copper) SP600629
Contact tip Life + Wire Ø Hole Ø
0.8 0.9 W007919
0.9 1.05 W007920
1.0 1.15 W006826
1.2 1.6 W006518
1.4 1.8 W007921
Gas nozzle Gas nozzle, bottle form, NW 16 SP600626
Gas nozzle, bottle form, NW 16/0 SP600643
Gas nozzle, bottle form, NW 16/-2 SP600644
Gas nozzle, conical, NW 16/+3 SP600645
Gas nozzle, conical, NW 16/0 SP600627
Gas nozzle, conical, NW 16/-2 SP600646
Gas diuser SP600563
Nozzle insulator Insulator SP600561
Insulator, high-temp. SP600562
Neck liner (For wire brake module)
Neck liner W500, steel 1.0-1.2 SP600564
Liner Liner chili 2.0/4.7, 2.5 m, ROBOT PP SP600667
Liner chili HP 2.0/4.7, 2.5 m, ROBOT EU SP600666
Liner chili HP 2.0/4.7, 2.5 m, ROBOT PP SP600668
Liner chili 2.0/4.7, 2.5 m, ROBOT EU SP600665
PP = Power pin
HP = Heat protection
EU = Euro connection

And you know.
