Kendall Howard Performance Series Quick guide

KENDALL HOWARD
Assembly and Maintenance Manual
Workbenches LAN Stations
And Accessories

Your New Performance
Workstation
Congratulations on your new Kendall Howard Performance LAN Station
Workbench. This manual will step you through the assembly process. If you have
trouble, please feel free to call our customer service department from 8:30 AM to 5:30
PM CST.
Step 1. Inventory
Please be sure that you unpack the crate completely and take a complete inventory of
what you have received. This will save you much time if parts are missing and you
have to stop in the middle of the build process. We take every precaution to ensure
that you do receive all parts required; however accidents do happen in shipping that
may cause the loss of a key part. If you suspect that you are missing parts, please
contact our customer service department immediately at 651-340-1400. You will need
to have your order confirmation number before you call.
PART QTY
Levelers 4
Table Sides (1 left, 1 right 2
Cross Bars 6
Upper Shelf Supports 4
Upper Shelf Channels 2
Lower Shelf 1
Upper Shelf 2
Work Surface 1
Cable Tray/Back Support 1
PART QTY
¾” Round Plastic End Cap 16
1 ½” Square Plastic End Cap 4
1 ½” x 2” Rectangle End Cap 4
Channel Nut 8
1 ½ Hex Drive Bolt 16
2 ½” Hex Drive Bolt 4
T-Handle Hex Wrench 1
Cross Head Screw 12 (24”)
15 (48”), 24 (72”), 30 (96”)

Step 2. Assemble the Upper Shelves
Place the upper shelves so that the hardware inserts are facing up. Next, place one of
the cross bars on the shelf lining up the holes on the shelf with the brackets on the
cross bar. Insert (2) cross head screws but DO NOT FULLY TIGHTEN. You will
notice a small gap between the bracket and the shelf. This was designed so that after
the bench is assembled, you will tighten all the cross head screws which will pull the
shelf down tight against the frame.
With the shelves still in the same position as in step 2, place a left and a right shelf
support on the shelf and attach with (2) 1 ½ Hex Drive Bolts.

Step 3. Assemble the Work Surface
With the work surface placed with the hardware inserts facing up, attach 2 cross bars to
the shelf with (4) cross head screws but DO NOT FULLY TIGHTEN. You will
notice a small gap between the bracket and the shelf. This was designed so that after
the bench is assembled, you will tighten all the cross head screws which will pull the
shelf down tight against the frame.

Step 4. Assemble the Lower Shelf
Place the lower shelf so that the hardware inserts are facing up. Next, place two of the
cross bars on the shelf lining up the holes on the shelf with the brackets on the cross
bar. Insert (4) cross head screws but DO NOT FULLY TIGHTEN. You will
notice that one of the crossbars will overlap the shelf. This feature will be used if you
purchased the bottom add-on shelf.
5

Step 5. Frame Assembly
On this step you may want to have someone help you with the assembly. Attach the
Lower shelf to left side with (2) 1 ½ Hex Drive Bolts. Next assemble the Right side in
the same way. DO NOT FULLY TIGHTEN YET.
Screw in the (4) Levelers provided into the bottom of the frame (Not shown in the
picture). If you purchased the optional caster kit, you may replace the levelers with the
casters at this point.

Step 6. Attach the Work Surface
Stand the bench in its upright position and place the work surface on top of the bench.
Attach work surface with (4) 1 ½ Hex Drive Bolts on each side. You may now tighten
both the Hex Drive Bolts and the cross head screws on both the work surface and the
lower shelf.
7

Step 7. Attach Cable Tray and Shelf Channels
Place the Cable Tray/Shelf Support in the correct position and insert (4) 2 ½” Hex
Drive Bolts. Next, turn the Channel Nut onto each of the 4 bolts just until the nut is
flush with the end of the bolt and pointing up. IMPORTANT: MAKE SURE
THAT THE GROOVES IN THE CHANNEL NUT ARE FACING THE
BENCH. There should be about 1” of space between the nut and the frame.
.
Hold the shelf channel over the (2) channel nuts while tightening the Hex Drive Bolts
with T-Handle provided. As you tighten the bolts, the channel nuts will turn and lock
into place. Make sure when completing this step that both channels are at the same
height.

Step 8. Attach Upper Shelves
Insert a 1 ½ Hex Drive Bolt into each shelf support hole and place a channel nut onto
the bolt as you did for step 9. Remember to keep the hex bolt facing up and down.
Place the shelf on the shelf channel with the channel nuts inside. Tighten the bolts and
cross head screws. Make sure these bolts are very tight.

Step 9. Add the Plastic End Caps
Insert the plastic end ¾” round caps into the left and right side frames as well as the
upper shelf supports.

Maintaining Your New Workbench
Your new Kendall Howard Performance Workbench is constructed with some of the
highest quality materials available today. To keep your Workbench looking new, we
recommend cleaning it regularly damp cloth using a mild soap and water solution.
•Do not use abrasive cleaners.
•Keep work surface away from petroleum products
•Keep away from open flames. Shelving is constructed from a wood
product and is not fire proof.
•If you opted for casters on your bench, moving the bench around may
loosen the hardware over time. Periodically check that all bolts and
screws are tightened.
•Do not exceed the weight thresholds for your bench. This could result
in serious injury or death.
11

Limited Warranty
General:
Under certain circumstances we offer with our products the following One Year Warranty Against Defects in
Material and Workmanship. Please read your Warranty carefully. This Warranty sets forth our
responsibilities in the unlikely event of defect and tells you how to obtain performance under this Warranty.
ONE YEAR LIMITED WARRANTY
AGAINST DEFECTS IN MATERIAL AND WORKMANSHIP
KENDALL HOWARD PRODUCTS COVERED:
Performance Series LAN Benches and Workstations
Terms of Warranty:
As provided herein, the Kendall Howard product is warranted to be free of defects in material and
workmanship for a period of one year from the date of product purchase from Kendall Howard, not to exceed
fifteen (15) months from the date of product manufacture. The date of purchase will be determined only from
the Kendall Howard sales order acknowledgment. If any part or portion of the Kendall Howard product fails
to conform to the Warranty within the Warranty period, Kendall Howard, at its option, will furnish new or
factory remanufactured products for repair or replacement of that portion or part.
Warranty Extends to First Purchaser for Use, Non-transferable:
This Warranty is extended to the first person, firm, association or corporation for whom the Kendall Howard
product specified herein is originally sold for use in the United States (the "User"). This Warranty is not
transferable or assignable without the prior written permission of Kendall Howard.
Assignment of Warranties:
Kendall Howard assigns to User any warranties which are made by manufacturers and suppliers of
components of the Kendall Howard product and which are assignable, but Kendall Howard makes NO
REPRESENTATIONS as to the effectiveness or extent of such warranties, assumes NO RESPONSIBILITY
for any matters which may be warranted by such manufacturers or suppliers and extends no coverage under
this Warranty to such components.
Drawings, Descriptions:
Kendall Howard warrants for the period and on the terms of the Warranty set forth herein that the Kendall
Howard product will conform to the descriptions contained in Kendall Howard final invoices, orders,
proposals (as modified) and other Kendall Howard descriptive documents ("Descriptions"). Kendall Howard
does not control the use of any Kendall Howard product. Accordingly, it is understood that the Descriptions
are NOT WARRANTIES OF PERFORMANCE and NOT WARRANTIES OF FITNESS FOR A PARTICULAR
PURPOSE.
Warranty Claims Procedure:
Within a reasonable time, but in no case to exceed ninety (90) days, after User's discovery of a defect, User
shall contact Kendall Howard at 1-651-340-1400. Subject to the limitations specified herein, a Kendall
Howard customer service representative will repair or replace the non-conforming Kendall Howard product
warranted hereunder, without charge for materials. User will not be charged for labor if performed within
ninety (90) days of product purchase. In all other instances, User will be charged for labor performed at
Kendall Howard’s then current rates. Kendall Howard shall assume shipping costs for replacement products
and return of the defective product to Kendall Howard. Warranty coverage will be extended only after
Kendall Howard inspection discloses the claimed defect and shows no signs of treatment or use which
would void the coverage of this Warranty.
12

Warranty Performance of Component Manufacturers:
It is Kendall Howard’s practice, consistent with its desire to remedy Warranty defects in the most prompt and
effective manner possible, to cooperate with and utilize the services of component manufacturers and their
authorized representatives in the performance of work to correct defects in the Kendall Howard components.
Accordingly, Kendall Howard may utilize third parties in the performance of Warranty work, including repair
or replacement hereunder, where, in Kendall Howard’s opinion, such work can be performed in less time,
and with less .
Items Not Covered By Warranty:
THIS WARRANTY DOES NOT COVER DAMAGE OR DEFECT CAUSED BY misuse, improper application,
wrong or inadequate electrical current or connection, negligence, inappropriate on site operating conditions,
repair by non-Kendall Howard designated personnel, accident in transit, tampering, alterations, a change in
location or operating use, exposure to the elements, Acts of God, theft or installation contrary to Kendall
Howard 's recommendations or specifications, or in any event if the Kendall Howard serial number has been
altered, defaced, or removed.
THIS WARRANTY DOES NOT COVER installation costs, external circuit breaker resetting or maintenance
or service items and further, except as may be specifically provided for herein, does NOT include labor or
shipping costs arising from the repair or replacement of the Kendall Howard product, or any part thereof, or
charges to remove same from any premises of User.
THIS WARRANTY IS VOID if User alters the product in any way.
Limitations:
•THIS WARRANTY IS IN LIEU OF AND EXCLUDES ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
•USER'S SOLE AND EXCLUSIVE REMEDY IS REPAIR OR REPLACEMENT OF THE KENDALL
HOWARD PRODUCT AS SET FORTH HEREIN.
•IF USER'S REMEDY IS DEEMED TO FAIL OF ITS ESSENTIAL PURPOSE BY A COURT OF
COMPETENT JURISDICTION, KENDALL HOWARD'S RESPONSIBILITY FOR PROPERTY
LOSS OR DAMAGE SHALL NOT EXCEED ONE TIMES THE NET PRODUCT PURCHASE
PRICE.
•IN NO EVENT SHALL KENDALL HOWARD ASSUME ANY LIABILITY FOR INDIRECT,
SPECIAL, INCIDENTAL, EXEMPLARY OR CONSEQUENTIAL DAMAGES OF ANY KIND
WHATSOEVER, INCLUDING WITHOUT LIMITATION LOST PROFITS, BUSINESS
INTERRUPTION OR LOSS OF DATA, WHETHER ANY CLAIM IS BASED UPON THEORIES
OR CONTRACT, NEGLIGENCE, STRICT LIABILITY, TORT, OR OTHERWISE.
Miscellaneous:
•NO SALESPERSON, EMPLOYEE OR AGENT OF KENDALL HOWARD IS AUTHORIZED TO
ADD TO OR VARY THE TERMS OF THIS WARRANTY. Warranty terms may be modified, if at
all, only by a writing signed by a Kendall Howard officer.
•This Warranty is effective as of the date of Kendall Howard receipt of full payment and supersedes
all previous warranties. Kendall Howard reserves the right to supplement or change the terms of
this Warranty in any subsequent warranty offering to User or others.
•In the event that any provision of this Warranty should be or becomes invalid and/or
unenforceable during the warranty period, the remaining terms and provisions shall continue in
full force and effect.
•User shall complete the attached User Information Card and forward it to Kendall Howard within
thirty (30) days of receipt of the Kendall Howard product.
•This Warranty is given in and performance hereunder is to be construed under the laws of the
State of Minnesota.
•This Warranty represents the entire agreement between Kendall Howard and User with respect to
the subject matter herein and supersedes all prior or contemporaneous oral or written
communications, representations, understandings or agreements relating to this subject.
13
