Keys Fitness Leverage Squat KPS-LS User manual

O W N E R ’ S M A N U A L
KPS-LS
L EVERAGE S QUAT
Questions?
Call our toll free Keys Fitness Helpline
1-800-683-1236

V
THANK YOU for making this Power System unit a part of
your exercise program. Keys Fitness and our Power System
Series assures the very best in value, appearance, durability
and biomechanics.
This manual will guide you through the assembly process. If at any time
you are having trouble with the assembly or use of this product, then
please contact us at our Keys Fitness Helpline. We have trained service
technicians on site to take care of you, our valued customer.
POWER SYSTEM SERIES
MODEL: KPS-LS
QUESTIONS?
CALL
1-800-683-1236
Monday-Friday
8:30-5:30 Central Time
When calling please have the following product information available:
• Product Series
• Model #
• Part Number
• Part Description
REGISTRATION CARD
To avoid unnecessary delays in warranty parts and to insure that a perma-
nent record of your purchase is on file with our company, be sure to send
in the warranty registration card or register on-line at www.keysfitness.com
within 10 days of purchase.

BEFORE YOU START
Prior to assembly, remove components from the box and verify that all the listed parts
were supplied.
Before using this unit or starting any exercise program, consult your physician. This is
especially important for persons over the age of 35 and/or persons with pre-existing
health problems. Keys Fitness Products LP assumes no responsibility for personal
injury or property damage sustained by or through the use of this product.
It is the owner’s responsibility to ensure that all users of this unit have read the Owner’s
Manual and are familiar with safety information and precautions.
SAFETY INFORMATION WARNING!
X
SAFETY PRECATIONS
• This Power System unit should only be used on a level surface and is intended for
indoor use only. Keys Fitness recommends an equipment mat be placed under the
unit to protect the floor or carpet and for easier cleaning.
• Wear comfortable, good-quality walking or running shoes and appropriate clothing.
Do not use this unit with bare feet, sandals, socks or stockings!
• Always examine your unit before using to ensure all parts are in working order.
• Do not leave children unsupervised near or on the unit.
• Service to your Power System unit should only be performed by an authorized serv-
ice representative, unless authorized and/or instructed by a Keys Fitness technician.
Failure to follow these instructions will void the warranty.

ASSEMBLY
STEP 1
1
34 31
31
32
32
31
2
36
31
3
Y
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Connect Front Base (1) to Middle Base (2)
with Bolts (34), Washers (31) and Nylon
Lock Nuts (32).
Connect Main Upright (3) to Middle Base
(2) with Bolts (36), Washers (31) and
Nylon Lock Nut (32).

ASSEMBLY
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Z
STEP 2
4
6
7
35
31
35
31
32 31
31 36
32
31
32
31
Attach Angle Plate (4) to frame with Bolts (36) (35), Washers
(31) and Nylon Lock Nuts (32).
Connect Left (6) and Right (7) Legs to Main Upright with Bolts
(35), Washers (31) and Nylon Lock Nuts (32).

[
29
28
28
30
27
11
30
28
Place Pillow Block Bearings (27) onto Main Arm (11) and
secure to Main Upright with Bolts (30), Washers (28) and
Nylon Lock Nuts(29).
ASSEMBLY
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
STEP 3

48 18
14 43
41
15
15
41
42
47
10
46 44
45
13
17
Complete Pin Handle assembly as shown below. Insert Slide
Support (10) into Main Arm and secure with Pin Handle.
STEP 4
ASSEMBLY
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
\

]
8
9
33
31
34
31
5
31
33
50 31 32
12
Attach the Front (9) and Rear (8) Pads to the Main Arm as shown with Bolts (33)
and Washers (31).
Connect Olympic Adapters (12) to the Main Arm using Bolts (34), Washers (31) and
Nylon Lock Nuts (32). Make sure that the Olympic Adapters are assembled so that
they point upwards in order to keep the Olympic Plates from sliding off.
ASSEMBLY
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
STEP 5

PARTS LIST
# DESCRIPTION QTY
1 front base 1
2 middle base 1
3 main upright 1
4 angle plate 1
5 weight holder 2
6 left leg 1
7 right leg 1
8 rear pad 2
9 front pad 2
10 slide support 1
11 main arm 1
12 olympic adapter 2
13 pin 1
14 pin handle 1
15 link plate 2
16 small grip 1
17 nut plug 1
18 spring 1
19 grip 2
20 plug 40*70 1
21 plug 45 3
22 plug 48 5
23 plug 50 2
24 plug 25*50 2
25 bumper 1
26 rubber spacer 3
27 pillow block bearing 2
28 washer 13*26*2 8
29 nylon locknut M12 4
30 bolt M12*40 4
31 washer 11*23*2 37
32 nylon locknut M10 12
33 bolt M10*30 12
34 bolt M10*70 6
35 bolt M10*75 3
36 bolt M10*95 4
37 washer 9*16*1.6 1
38 allen bolt M8*25 1
39 spring washer 10 2
40 washer 10*30*2 2
41 washer 5.5*10*1 4
42 shoulder bolt M5*25 2
43 nylon locknut M5 2
44 washer 6.6*12*1.6 2
45 allen bolt M6*25 1
46 nylon locknut M6 1
47 bolt M8*55 1
48 nylon locknut M8 1
49 allen bolt M10*30 2
50 plate 2
^

EXPLODED VIEW
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19 20
21
22
23
24
24
25
26
21
27
28
30
29
28
33
32
32
33
34
36
37
38
39
40
41
42
43
44
46
45
47 48
49
22
34
31
33
31
32
31
31
32
31
31
31 35
30
31
50
44
31
32
35
32
