Roman ChaiR
Owner’s Manual
KF-RC
215-00123
10/06 Rev A

2
Table of Contents
Before You Start 3
Important Safety Information 4
Assembly 5 - 8
Parts List 9
Exploded View 10
Warranty Information 11

KEYS FITNESS SERIES
MODEL: KF-RC
QUESTIONS?
CALL
1-888-340-0482
Monday-Friday
8:30-5:30 Central Time
When calling please have the following product information available:
3
Model Name :
Date Mfg.:
PO # :
Serial #:
Model Name Decal Location
THANK YOU for making this unit a part of your exercise program.
Keys Fitness assures the very best in value, appearance, durability
and biomechanics.
This manual will guide you through the assembly process. If at
any time you are having trouble with the assembly or use of this product, then
please contact us at our Keys Fitness Help line. We have trained service techni-
cians on site to take care of you, our valued customer.
REGISTRATION CARD
To avoid unnecessary delays in warranty parts and to insure that a permanent
record of your purchase is on file with our company, be sure to send in the war-
ranty registration card or register on-line at www.keysfitness.com within 10 days
of purchase.
Before You Start

4
Important Safety Information
Prior to assembly, remove components from the box and verify that all the listed parts were
supplied.
WARNING!
Before using this unit or starting any exercise program, consult your
physician. This is especially important for persons over the age of
35 and/or persons with pre-existing health problems. Keys Fitness
Products LP assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
It is the owner’s responsibility to ensure that all users of this unit
have read the Owner’s Manual and are familiar with safety informa-
tion and precautions.
SAFETY PRECAUTIONS
• This unit should only be used on a level surface and is intended for
indoor use only. Keys Fitness recommends an equipment mat be
placed under the unit to protect the floor or carpet and for easier
cleaning.
• Wear comfortable, good-quality walking or running shoes and
appropriate clothing. Do not use this unit with bare feet, sandals,
socks or stockings!
• Always examine your unit before using to ensure all parts are in
working order.
• Do not leave children unsupervised near or on the unit.
• Service to your unit should only be performed by an authorized
service representative, unless authorized and/or instructed by a
Keys Fitness technician. Failure to follow these instructions will void
the warranty.
NOTE:Hand tighten bolts and nylon nuts until machine is fully assembled.
Read all precautions and instructions in this manual before using this equipment.

STEP 1A
Connect Rear Upright (2) to Rear Base Frame (1) with Bolt (21),
Washers (28) and Nylon Lock Nut (26).
STEP 1B
Connect U Base Tube (5) to Front Upright (4) with Bolts (22),
Washers (28) and Nylon Lock Nuts (26).
A
B
5
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly

STEP 2
Connect Rear Upright (2) to Front Upright (4) using Cross Beam (3).
Secure with Bolts (19), Washers (27) and Nylon Lock Nuts (25).
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly
6

STEP 3
Slide Adjustable Leg Hold (7) down onto Rear Upright (2) and
secure by screwing Pop Pin into Adjustable Leg Hold (7).
Slide Bolt (21) into Rear Upright (2) and secure with Washers (28)
and Nylon Lock Nut (26).
Slide Upholstered Roller Pads (10) onto Adjustable Leg Hold (7) and
secure with Roller Pad Tube Caps (12). We recommend using a
rubber hammer to secure Roller Pad Tube Caps (12).
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly
7

STEP 4
Connect Pad Support (6) to Front Upright (4) using Bolts (20),
Washers (28) and Nylon Lock Nuts (26).
Secure Pads (8) to Pad Support (6) with Bolts (23) and Washers
(28).
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly
8

KF-RC Parts List Rev A
Ref # Part # Description Qty
1 223-00992 FRAME, REAR BASE KF-RC 1
2 223-00993 UPRIGHT, REAR KF-RC 1
3 223-00994 FRAME, CROSS KF-RC 1
4 223-00996 FRONT UPRIGHT, KF-RC 1
5 223-00995 TUBE, U BASE KF-RC 1
6 223-00997 PAD SUPPORT, KF-RC 1
7 219-00494 SLIDING CARRIAGE, KF-RC 1
8 228-00227 PAD, KF-RC 2
9 210-00178 POP PIN, LOCKING KF-RC 1
10 206-00395 FOAM PADDING, 100X22X180 KF SERIES 2
11 206-00103 LAT BAR GRIP - KPS 2
12 206-00390 PLUG, ROLLER PAD TUBE CAP, KF SERIES 2
13 206-00392 FOOT CAP, RIGHT 50.8 KF SERIES 4
14 206-00393 FOOT CAP, LEFT 50.8 KF SERIES 4
15 206-00327 PLASTIC SLEEVE, 63.5X88.9-50.8X76.2 2
16 206-00394 PLUG, 50.8X76.2 KF SERIES 3
17 206-00391 SQUARE PLUG, 50.8 KF SERIES 4
18 206-00138 ROUND PLUG 25 2
19 202-00655 SCREW, BUTTON HEAD SOCKET CAP M12X75 4
20 202-00694 SCREW, BUTTON HD SOCKET CAP M10X100 2
21 202-00690 SCREW, BUTTON HD SOCKET CAP M10X90 2
22 202-00634 SCREW, M10X80 BUTTON HEAD SOCKET CAP 2
23 202-00635 SCREW, M10X30 BUTTON HEAD SOCKET CAP 4
24 202-00659 SCREW, BUTTON HEAD SOCKET CAP M8X25 8
25 202-00092 NYLON NUT, M12 4
26 202-00091 NYLON NUT, M10 6
27 202-00222 WASHER, 13X26X2 KPSFI #32 8
28 202-00223 WASHER, 11X23X2 16
29 202-00094 WASHER 8, 9*28*2 8
9
Parts List

10
Exploded View
