Kilotech Integrator C30 User manual

Integrator C15/C30
Manual
Contents subject to change without notice
Version 01.02
05/2015
Ce manuel est disponible en français à www. ilotech.com

2
TABLE OF CONTENTS
TABLE OF CONTENTS .................................................................................................................. 2
Introduction .............................................................................................................................. 3
General Precautions ................................................................................................................... 4
Speci ications............................................................................................................................. 5
Outline ...................................................................................................................................... 5
Unpacking and setup.................................................................................................................. 6
Contents .................................................................................................................................... 6
Display and keypad .................................................................................................................... 7
Faceplate .................................................................................................................................................... 7
Symbols on Display .................................................................................................................................... 7
Keypad ........................................................................................................................................................ 8
Layout and characters ................................................................................................................................ 8
Key combinations ....................................................................................................................................... 9
Weighing operations ................................................................................................................ 10
Key functions ............................................................................................................................................10
Store/program PLU’s ................................................................................................................ 11
Recall PLU ................................................................................................................................ 13
Recall direct PLU .......................................................................................................................................13
Recall indirect PLU’s .................................................................................................................................13
Miscellaneous transaction .......................................................................................................................13
Parameter setting .................................................................................................................... 14
Business name .........................................................................................................................................14
LCD contrast .............................................................................................................................................15
Auto off ....................................................................................................................................................15
Internal code ............................................................................................................................................16
Communication settings ..........................................................................................................................16
The system will automatically reboot a ter changing the above parameter settings .................. 18
Set date and time .....................................................................................................................................18
Group code...............................................................................................................................................19
Bac feed ..................................................................................................................................................19
Origin setting ............................................................................................................................................20
LCD test ....................................................................................................................................................20
Format o barcode or printing ................................................................................................. 21
RS-232 cable pinout or host .................................................................................................... 21
Printer cable pinout (OS-203/213) ............................................................................................. 21
Error codes .............................................................................................................................. 22
Communication output ormat ................................................................................................. 23
Host ..........................................................................................................................................................23
Print format with OS-203 / 213 printer ....................................................................................................23
Available Label formats ............................................................................................................................23
Display Character Re erence ..................................................................................................... 25
Troubleshooting ....................................................................................................................... 26

3
Introduction
Than you for choosing a Kilotech Scale. We appreciate your business and hope that you will enjoy using your
scale. Should you require support, please contact your local dealer from whom you have purchased. Happy
Weighing!

4
General Precautions
Avoid lengthy exposure to heat
or cold.
Allow the scale to acclimate to normal room temperature before
use.
Allow sufficient warm up time. Turn the scale on and wait for a few minutes to allow the internal
components a chance to stabilize before weighing.
Do not leave a load or weight
on a scale for a prolonged
period of time.
Do not tamper with the scale
yourself.
This will void the warranty. Contact your local distributor to
properly repair your scale.
Do not dissemble the scale
yourself.
This will void the warranty. Contact your local distributor to
properly repair your scale.
Do not load beyond max cap
the maximum weight limit.
Do not pull the plug by its cord
when unplugging.
Do not use the scale near fire
or corrosive gas.
Do not spill water or immerse
in water.
Avoid placing the scale near a
heater.
It could cause a fluctuation to the indicator reading.
Always ma e sure to use a
Kilotech approved adapter.
Do not drop the scale or apply
a sudden shoc .
Do not drag the scale.
Avoid exposing to other
electromagnetic devices.
These devices emit RF and can cause unstable readings. If your
scale should perform poorly, try moving the scale to a different
room or location.
Level the scale or ma e sure it
is on an even surface.
A scale used on an uneven surface may provide an unstable
reading.
Scale should be used within
stated temperature & humidity
limits.

5
Speci ications
Product Number
Product Name
C15
C30
Capacity
15 g / 30lb
30
g / 60lb
Graduation 0-6 g:2g/6-15 g: 5g
0-15lb:0.005lb/15-30lb:0.01lb
0-15 g:5g/15-30 g:10g
0-30lb: 0.01lb/30-60lb:0.02lb
Weighing Modes g, lb
Display 0.73”,18 digits：6 digit for weight reading，6 digit for unit
price
，
6 digit for total price
Bac Li
ght
Yes and adjustable
Auto Power Off
Yes
Power
12Vdc
≥500mA with positive center AC adaptor
Battery 6Vdc4AH lead-acid battery
Product Dimensions
355 × 370 × 131mm/ 14" x 14.6" x 5.2"
Platter Size
335 × 225mm / 13" x 8.9"
Operating Temperature / Humidity -10° C - 40° C / 14° F - 104° F / <90% RH non condensing
Unit price range 0.00 - 9999.99 $/ g or $/lb
Total price range 0-999.99$ (limited by bar code)
RS232
RS232(optional) USB(virtual RS232,optional)
Real Time Cloc
Yes
PLU
265 including 5 dir
ect PLU
（
Addr: 1
-
5
）
Measurement Canada and NTEP
Outline
Interface: (1) Main switch (2) AC power adapter input (3-4) RS232 and USB

6
Unpacking and setup
•Remove the scale from the box and place it on a firm, level surface.
•Avoid locations with rapid temperature changes, excessive dust, moisture, air currents, vibrations,
electromagnetic fields, heat or direct sunlight.
•Adjust the leveling feet until the bubble is centered in the circle of the level indicator (located on the
front panel).
•NOTE: Ensure that the scale is level each time its location is changed.
•Before using the scale for the first time, the internal rechargeable battery should be fully charged for at
least 12 hours.
•Connect the supplied AC adapter to the power input receptacle underneath the scale. Plug the AC
adapter into a power outlet and the battery will begin charging.
•If the scale will be stored or transported in the future, save the pac aging material to ensure the best
possible protection for the scale.
Contents
•Scale
•6Vdc4AH lead-acid battery (installed in scale housing)
•12Vdc/2000mA UL adapter with positive center
•Manual

7
Display and keypad
Faceplate
Symbols on Display
WEIGHT - Weight display window
 - Centre-of-zero annunciator
 – TARE annunciator
/ - Weight unit annunciator
UNIT PRICE - Unit price display window
 – Save mode annunciator
/ - Unit price per g/lb annunciator
TOTAL PRICE($) - Total price display window
 - Data output annunciator
 - Charging annunciator
 - AC Adapter in-use annunciator

8
Keypad
- : numeric eys, Used to enter numerical data or alphabets
- : Direct PLU eys, Used to directly recall the stored unit price
: Clear the recorded data
: Confirm the operation or data entered
: Save the tare weight and/or unit price
: Used to set the scale to zero
: Used to tare the scale.
: Enter program PLU mode
: Enter recall PLU mode
: Transmit data to the communication port
: Used to switch between units
: Turns the scale on and off and functions as exit ey in programming mode
Layout and c aracters
0 space ( ) ÀÂÆÇÈÉÊË Î
ÏÔÙÛÜ
1ABC
2DEF 3GHI
4JKL 5MNO
6PQRS 7TUV
8WXYZ 9

9
Key combinations
Press both ey simultaneously and hold down for more than three seconds.
(for details on these operations, please see their respective sections in the manual)
+ : Used to enter the business’s name setup mode
+ : Used to enter the LCD’s contrast setup mode
+ : Used to enter the auto-off time setup mode
+ Used to display A/D inner code or wor ing voltage
+ : Used to enter RS232 parameters setup mode
+ : Used to enter the date and time setup mode
+ : Used to enter Group Code setup mode
+ : Used to set OS-203/213 Bac Feed setup mode
+ Used to enter OS-203/213 Origin setup mode
+ : Enter LCD test mode

10
Weighing operations
Key functions
Power on/o
•When the scale is off, first ma e sure the power switch on the bottom of the right hand side of
the scale is ON. Press on/off ey to power on the scale.
•Press on/off for more than 3s to power off the scale.
Zero
•The zero ey is used to zero out the small difference on the weight display.
•The scale will display “Err” when the weight to be zeroed is outside the range
•If a tare is set, the ZERO ey function is not avalible
Tare
•Weight tare: Place the receptacle (box, bowl etc…) on the scale, and when the reading is stable,
press tare ey to tare the weight.
•Key tare: Key in nown tare weight and press tare ey.
•To clear Zero or Tare, press their respective buttons.
•The tare weight and unit price will be auto cleared after transaction is completed and item has
been removed from the platter.
Save
•When activated, this function will prevent auto clearing of the unit price or tare-weight.
•When active, the save indicator is activated.
Units key
•Use the ey to shift between “ g”, “lb” . Note: Unit price will be set to zero during switching
•You cannot switch units when a tare is active.
Print
•Used to transmit the data over the RS232 or USB. When the price has been computed, press
print ey output the data via RS232 according to the setting style to ma e a price label. (see
appendix for layout example)

11
Store/program PLU’s
To cancel and return to normal mode at any time, press
Weight
Display
Total
Price
Display
Unit Price
Display
Keys used Comment
0.00 0.00 0.00 Press to start
St.PLU ADDR
Enter address using numerical eys
~
To confirm press
The system will overwrite any
previous data
The address range is from 1
to 265
1-5 is for direct unit price
St.PLU NAME
Enter product name using numerical
ey
~
To confirm press
Use the numerical eys to
select the letter needed
Only the last six characters
will show
Max length is 20 characters
St.PLU INGRDT
Enter ingredients using
numerical eys
~
To confirm press
This field is only visible when
activated
(Host, PRTd60, PRDnd6)
Max 80 characters
St.PLU LIFE
Enter shelf life using numerical eys
~
To confirm press
Refers to shelf life of the
product.
Max number of days = 253
St.PLU
“Unit.0”
( g) or
“Unit.1”
(lb)
Use the ey to switch
To confirm press

12
Weight
Display
Total
Price
Display
Unit Price
Display
Keys used Comment
St.PLU UNIT.P
Enter price using numerical eys
~
To confirm press
St.PLU Tare
Enter tare weight using numerical
eys
~
To confirm press
St.PLU ITEM.C
Enter item code using numerical eys
~
To confirm press
If the PLU data has been
changed, the unit price
window will briefly display
“Save” and the total price
window will briefly display
“Data.ch”.
Repeat the steps for the next PLU or press to return to the normal weighing mode.

13
Recall PLU
Recall direct PLU
Recall a PLU that is stored under a speed ey by pressing ey, the stored unit price will be
displayed in unit price window. The total price window will display “DUP. xx”, and then the actual total price
will appear.
Recall indirect PLU’s
Icon Weight
Display
Total Price
Display Unit Price Display Con irm or Exit Comment
rc.PLU ADDR
Enter the unit price
using numerical eys
~ ie010.
The address range is
from 1 to 265,
To confirm press
To exit and
return to regular
weighing mode
Press
The unit price
window will display
the recalled unit
price. The total price
window displays
“PLU.xxx”(xxx is the
Address) and then
will go bac to the
normal total price
displaying mode
later, using the new
unit price, tare
weight, new weight
unit, trade name,
and shell life)
Miscellaneous transaction
Use the numerical eys ~ , to enter unit price (range: 0000.00～9999.99).
The programmed price can be cleared by pressing the ey.
The unit price will be cleared automatically after weighing and removing the objects.

14
Parameter setting
To cancel and return to normal mode at any time, press the ey
Business name
Weight
Display
Total Price
Display
Unit Price Display Keys used
Comment
0.00 0.00 0.00
Press both
+
simultaneously and hold
down for more than three
seconds
bUSI.N1 XXXXXXXXXXXX
Enter first line of Business
name using numerical ey
~
To confirm press
Displays the
last 12
characters
Max length is
20 characters
bUSI.N1 XXXXXXXXXXXX
Enter second line of
Business name using
numerical ey
~
To confirm press

15
LCD contrast
Weight
Display
Total Price
Display
Unit Price Display Keys used
Comment
0.00 0.00 0.00
Press both
+
simultaneously and hold
down for more than three
seconds
Setup LCd.CST X
~
To confirm press
X = value
currently set
Setup BLGT.MD x
~
To confirm press
0 = always on
1 = always off
2 = Auto
matic
Auto off
Weight
Display
Total Price
Display
Unit Price Display Keys used
Comment
0.00 0.00 0.00
Press both
+
simultaneously and hold
down for more than three
seconds
Setup A.OFF.t XX
~
To confirm press
XX = value
currently set
in minutes
Max delay =
30 min
00 = auto
off disabled

16
Internal code
Weight
Display
Unit Price
Display
Total Price Display Keys used
Comment
0.00 0.00 0.00
Press both
+
simultaneously and hold
down for more than three
seconds
UoL.x.x CodE xxxxxx
To continue press
UoL.x.x =
wor ing
voltage
Code = A/D
internal count
Communication settings
To cancel and return to normal mode at any time, press the ey
The settings in bold are de ault
Weight
Display
Unit Price
Display
Total Price Display Keys used
Comment
0.00 0.00 0.00
Press both
+
simultaneously and
hold down for more
than three seconds
Setup 232.out XXXXXX
Chose format using
numerical eys
~
To confirm press
Communication format
options.
0 = HOST:
1 = PRTd40
2 = PRTd60
3 = PRTNd4
4 = PRTNd6
(see appendix for details)
Setup 232.bps XXXXXX
Choose baud rate using
numerical eys
~
To confirm press
baud rate options
1 = 1200bps
2 = 2400bps
3 = 4800bps
4 = 9600bps
5 = 19200bps

17
Weight
Display
Unit Price
Display
Total Price Display Keys used
Comment
Setup 232.dFt XXX
Choose parity rate
using numerical eys
~
To confirm press
Parity options
1 = 8N1
2 = 7O1
3 = 7E1
Setup Prtd.Ft XXXXXX
Choose format using
numerical eys
~
To confirm press
0 = CANADA YY-MM-DD
1 = USA
DD-MMM-YY
2 = Num
Numerical format
Setup B.PRT.FT XXXX
Choose format using
numerical eys
~
To confirm press
0 = 5I4P
1 = 4I5P
2 = 5I5P
3 = 4I6P
See Appendix for details
barcode formats
Setup USb.oUt XXXX
Choose format using
numerical eys
~
To confirm press
0 = None
USB disabled
1 = Host,
USB activated
.
Setup Usb.bps XXXXX
Choose baud rate using
numerical eys
~
To confirm press
baud rate options
1 = 1200bps
2 = 2400bps
3 = 4800bps
4 = 9600bps
5 = 19200bps

18
Weight
Display
Unit Price
Display
Total Price Display Keys used
Comment
Setup Usb.dft XXX
Choose baud rate using
numerical eys
~
To confirm press
Format options
1 = 8N1
2 = 7O1
3 = 7E1
Setup Urt.CFt
XXX
Choose format setting
using numerical eys
~
To confirm press
0 = None
1 = SN
Data will be transmitted
when the print ey is
pressed and scale is stable
The system will automatically reboot after changing the above parameter settings
Set date and time
Weight Display
Unit Price
Display Total Price Display Keys used Comment
0.00 0.00 0.00
Press both
+
simultaneously and
hold down for more
than three seconds
.
Setup dAtE xx.xx.xx
Enter date using
numerical eys
~
To confirm press
format：
YY.MM.DD
Setup timE xx.xx.xx
Enter time using
numerical eys
~
To confirm press
Format：
hh.mm.ss

19
Group code
Weight Display
Unit Price
Display Total Price Display Keys used Comment
0.00 0.00 0.00
Press both
+
simultaneously and
hold down for more
than three seconds
Setup GroUP.C XX
Enter time using
numerical eys
~
To confirm press
Default = 00
Range = 00~
99
Back feed
Weight Display
Unit Price
Display Total Price Display Keys used Comment
0.00 0.00 0.00
Press both
+
simultaneously and
hold down for more
than three seconds
Setup bA .FEd XXXXXX
Choose mode
using numerical eys
~
To confirm press
Printer must
be on and
connected
0 = disable
1 = enable

20
Origin setting
Weight Display
Unit Price
Display Total Price Display Keys used Comment
0.00 0.00 0.00
Press both
+
simultaneously and
hold down for more
than three seconds
Setup orG|| XXX
Set value using
numerical eys
~
To confirm press
Range =
0-255
LCD test
Weight Display
Unit Price
Display Total Price Display Keys used Comment
0.00 0.00 0.00 Press both
and
simultaneously and
hold down for more
than three seconds
Press ey to
exit
