Kioti CK2810 User manual
FORWARD
Make sure to read this manual carefully and keep it handy for future reference.
When leasing or transferring this tractor, deliver this manual together with the tractor.
< NOTE >
Congratulations, and welcome to the world of CK2810 / CK3010H ownership, where serious work is made fun again!
DAEDONG IND.
Co., LTD
the KIOTI Engineering Department.
familiarize themselves with the KIOTI CK2810 / CK3010H, it is the policy of KIOTI tractor to provide an owners manual
found in this manual, your KIOTI
Please feel free to contact DAEDONG IND. CO.,LTD / DAEDONG-USA, INC
M56(TB110)(CK2810)-호주판-OM-00.ind1 1 2012-10-15 오후 5:28:42
This manual was compiled in compliance with the ISO 3600, standards and the instructions contained here comply with
the requirements of the Machinery Directive 2010/52/EU in force in the European Community. For tractors sold or used
outside the European Community, local laws will apply.
Safety devices discussed in this manual.
DESCRIPTION NON CANOPY CANOPY
1. ROPS (protection against rollover) Yes No
2. FOPS (protection against falling objects) No No
3. OPS (protection against penetration of objects from sides)
protection against hazardous chemicals
No
(CategoryⅠ)
No
(CategoryⅠ)
ISO 3600 EU STANDARDS
M56(TB110)(CK2810)-호주판-OM-00.ind2 2 2012-10-15 오후 4:39:02
1
2
3
4
5
6
7
8
9
10
SAFETY PRECAUTIONS ................................
PRECAUTIONS BEFORE OPERATION .........
SPECIFICATIONS............................................
DESCRIPTION OF OPERATING SYSTEM .....
OPERATION ....................................................
3- POINT HITCH .............................................
MAINTENANCE ...............................................
STORAGE AND DISPOSAL............................
TROUBLESHOOTING .....................................
INDEX...............................................................
SECTION
TABLE OF CONTENTS
3-POINT HITCH IMPLEMENT AND
LOADER OPERATION
M56(TB110)(CK2810)-호주판-OM-00.ind3 3 2012-10-15 오후 5:28:42
TABLE OF CONTENTS
SAFETY PRECAUTIONS ....................................1-1
BEFORE OPERATING THE TRACTOR................... 1-2
OPERATING THE TRACTOR................................... 1-5
DRIVING THE TRACTOR......................................... 1-9
PARKING THE TRACTOR ..................................... 1-11
OPERATING THE PTO........................................... 1-11
USING 3-POINT HITCH.......................................... 1-12
SERVICING THE TRACTOR .................................. 1-12
SAFETY PRECAUTIONS WHEN USING THE
LOADER .............................................................. 1-16
SAFETY DECAL MAINTENANCE ......................... 1-19
................................... 1-19
........................................................................
...................
PRECAUTIONS BEFORE OPERATION .............2-1
VEHICLE IDENTIFICATION NUMBER..................... 2-2
.........................................
.............................................
...............................
ESSENTIAL REPLACEMENT PARTS ..................... 2-4
.......................................................... 4
.......................................................................... 4
.........................................
.................................................
SPECIFICATIONS................................................3-1
GENERAL SPECIFICATIONS .................................. 3-2
EXTERN ..............................................
.........................................
..
.......................
TRAVELING SPEED................................................. 3-7
IMPLEMENT LIMITATIONS...................................... 3-8
................................. 8
M56(TB110)(CK2810)-호주판-OM-00.ind4 4 2012-10-15 오후 5:28:42
TABLE OF CONTENTS
DESCRIPTION OF OPERATING SYSTEM .........4-1
EXTERIOR VIEW...................................................... 4-3
SWITCH .................................................................... 4-5
................................... 4-
.................................................................. 4-
................................................ 4-7
................................................ 4-8
INSTRUMENT PANEL .............................................. 4-9
................................................................................ 4-9
.............. 4-1
................................................................ 4-1
..............4-11
.................4-11
....................................... 4-1
........................ 4-1
.................................................... 4-1
............................................ 4-1
............................. 4-1
................................. 4-14
............ 4-14
........................................ 4-14
.................. 4-1
....................... 4-1
................. 4-1
OPERATING THE CONTROLS .............................. 4-16
...................................................... 4-18
.................................................. 4-18
.................................................. 4-19
....................................
........................................................... 1
.............................................................. 1
.............................................
...............................................
............................................
...................................... 4
.....................................................
.............................................
................. 7
........................... 7
........................................................ 7
M56(TB110)(CK2810)-호주판-OM-00.ind5 5 2012-10-15 오후 5:28:42
TABLE OF CONTENTS
.........................................................
.................................. 1
..............................................
TREAD...........................................................................
..................................................
............................................... 7
OPERATION ........................................................5-1
PRE-OPERATION CHECK ....................................... 5-2
OPERATING THE ENGINE ...................................... 5-3
................................................
...................................... 7
............................................... -7
................................................................. 8
............................................................ 9
OPERATING THE TRACTOR................................. 5-10
........................................................................
OPERATING THE TRACTOR................................. 5-10
...................... 1
............................................................
.......................................................................
...................................................................... 1
.................................................. 7
PREC
............................................................. 17
...... 8
........................................ 18
.. 9
.......................... 1
............................................... 1
.. 4
3-POINT HITCH IMPLEMENT AND LOADER
OPERATION .....................................................6-1
REMOVAL AND INSTALLATION OF 3-POINT HITCH
IMPLEMENT (WITH PTO SHAFT) ........................... 6-2
OPERATION TIP FOR 3-POINT HITCH ELEMENTS... 6-5
.........................................
M56(TB110)(CK2810)-호주판-OM-00.ind6 6 2012-10-15 오후 5:28:42
TABLE OF CONTENTS
P
........................................................
....................................
............................................. 7
............................................... 8
HANDLING LOADER .............................................. 6-9
A ..
.....................................................1
........................................................
..............................................
MAINTENANCE...................................................7-1
MAINTENANCE CHECK LIST ................................. 7-3
D.................................................... 7-
............................. 7-4
LUBRICANTS ........................................................... 7-7
MAINTENANCE CODE ............................................ 7-8
.................................... 7-8
.............................. 7-8
............ 7-9
............................ 7-1
.................................7-11
...............7-11
......... 7-1
.. 7-1
... 7-1
...................... 7-1
... 7-1
.. 7-1
.................. 7-17
.................................. 7-17
................... 7-18
............. 7-19
.......................................
.....................................
..
........................................
..........................
................................................................ 4
M56(TB110)(CK2810)-호주판-OM-00.ind7 7 2012-10-15 오후 5:28:42
TABLE OF CONTENTS
................................
...............................................
.......... 7
..................................... 8
....................... 8
........ 8
......................................................... 9
...............................................................
... 1
............................................... 1
..............................................
...........................................
STORAGE AND DISPOSAL................................8-1
TRACTOR STORAGE .............................................. 8-2
............................................................ 8-
................................................. 8-
............................ 8-4
USAGE AND DISPOSAL.......................................... 8-4
TROUBLESHOOTING.........................................9-1
ENGINE TROUBLESHOOTING ............................... 9-2
TRACTOR TROUBLESHOOTING ........................... 9-4
INDEX.................................................................10-1
M56(TB110)(CK2810)-호주판-OM-00.ind8 8 2012-10-15 오후 5:28:42
SAFETY AND VEHICLE DAMAGE WARNING
This manual includes information titled as WARNING, CAUTION, IMPORTANT and
NOTE. These titles indicate the following:
NOTE
provided.
WARNING
This indicates that a condition may result in harm, serious
injury or death to you or other persons if the warning is not
heeded. Follow the advice provided with the warning.
!
CAUTION
This indicates that a condition may result in damage to your
vehicle or its equipment if the caution is not heeded. Follow
the advice provided with the caution.
This mark indicates emphasis on notable characteristics of
working procedures, and information about technology for
easier operation.
IMPORTANT
M56(TB110)(CK2810)-호주판-OM-00.ind9 9 2012-10-15 오후 5:28:43
Engine coolant temperature
Engine oil-pressure
Power take-off clutch control-off position
Power take-off clutchcontrol-on position
Turn signal
Differential lock
Position control - Lowering
Preheat
UNIVERSAL SYMBOLS
KIOTI tractor.
M56(TB110)(CK2810)-호주판-OM-00.ind10 10 2012-10-15 오후 5:28:44
1
SAFETY PRECAUTIONS
1
BEFORE OPERATING THE TRACTOR....................... 1-2
OPERATING THE TRACTOR....................................... 1-5
DRIVING THE TRACTOR............................................. 1-9
PARKING THE TRACTOR ......................................... 1-11
OPERATING THE PTO............................................... 1-11
USING 3-POINT HITCH.............................................. 1-12
SERVICING THE TRACTOR ...................................... 1-12
SAFETY PRECAUTIONS WHEN USING THE LOADER
.. 1-16
SAFETY DECAL MAINTENANCE ............................. 1-19
DECAL MOUNTING LOCATION ...............................................1-19
DECALS ....................................................................................1-20
CAUTIONS FOR DECAL MAINTENANCE ...............................1-23
M56(TB110)(CK2810)-호주판-OM-01.ind1 1 2012-10-15 오후 4:09:04
1
-
2CK2810 / CK3010H
A careful operator is the best opera-
tor. Most accidents can be avoided
by observing certain precautions. To
help prevent accidents, use these
safety precautions, and pay attention
to the job at hand. If you can prevent
an accident, your time will have been
well spent.
BEFORE OPERATING THE TRACTOR
5. Keep safety decals clean of dirt
and debris.
6. Watch where you are going at all
times so that you are able to avoid
obstacles that can cause injury or
damage to your tractor.
7. When starting the tractor make
sure your path is clear of people to
avoid accidents caused by sudden
movements.
8. Before making reverse movements
with your tractor, you should al-
ways check to see that the path is
clear.
1.It is recommended that you read
and understand this entire manual
before operation of your new trac-
tor. Failure to do so could result in
accidents or injury.
2.Only persons who are properly
trained should be allowed to oper-
ate the tractor.
3. Read and follow all warning labels
and decals afxed to the tractor.
4. Replace any missing or damaged
decals as soon as it is practi-
cal. A list of decals is shown on
page1-19~22.
051O101C 051O102C
M56(TB110)(CK2810)-호주판-OM-01.ind2 2 2012-10-15 오후 4:09:05
1
-
3
SAFETY PRECAUTIONS
1
16. All persons using the tractor
should have knowledge of its
proper operation and should read
this manual carefully.
17. Never dismount the tractor with-
out setting the parking brake,
lowering the implement to the
ground and shutting of the tractor.
18. No modiations should be made
to your KIOTI tractor.
12. Do not start the engine while
standing on the ground.
13. Only the operator should ride on
the tractor unless a passenger
seat is installed. Keep bystand-
ers away from the tractor while in
operation.
14. When getting on and off the trac-
tor, handholds and step plates
should always be used. This will
help to prevent accidental slips
trips and falls.
15. Be sure to scrape off mud or soil
from your shoes before mounting
the tractor.
051O103C 051O104C 051O105C
9. Never operate this tractor or
any other agricultural equipment
while under the inuence of alco-
hol, drugs or while fatigued.
10. While working in cooperation
with other tractors always com-
municate your intentions.
11. Never start your tractor by short-
ing across the starter.
M56(TB110)(CK2810)-호주판-OM-01.ind3 3 2012-10-15 오후 4:09:06
1
-
4CK2810 / CK3010H
A ROPS should never be modified
by welding, grinding or cutting, as
this can weaken the ROPS structure.
If any components of the ROPS unit
is damaged, it must be replaced.
If the ROPS unit is removed or loos-
ened for any reason, the parts should
be fitted back to their original posi-
tions and all bolts should be properly
torqued.
21. Extra caution should be taken
when driving tractors with nar-
row tread widths. For added
stability you should adjust your
rear wheel tread width, see page
4-25.
19. Before starting your tractor you
should depress the clutch and
make sure that all shift levers are
in the neutral position and park-
ing brake is applied.
20. For your safety ROPS with a
seat belt is recommended for all
applications.
051O106C 051O107C
Always use seat belt when the
tractor is equipped with a ROPS.
Never use the seat belt when
tractor is not equipped with a
ROPS or ROPS is folded up.
•
NOTE
M56(TB110)(CK2810)-호주판-OM-01.ind4 4 2012-10-15 오후 4:09:07
1
-
5
SAFETY PRECAUTIONS
1
2. Avoid accidental contact with gear
shift levers while the engine is run-
ning. Unexpected tractor move-
ments can result in bodily injury.
3. Do not park your tractor on a steep
incline, and remember to shut off
the engine and PTO before dis-
mounting the tractor.
OPERATING THE TRACTOR
051O109C051O108C
H11O109A
Do not jump on or off the trac-
tor. It may cause injuries. Al-
ways face the tractor, use the
hand rails and steps, and get
on or off slowly. Maintain a
minimum three point contact
to avoid falling. (Both hands
on rails and one foot on the
step, or one hand on the hand
rail and both feet on the steps)
•
WARNING
1. Always mount or dismount the trac-
tor from left side.
Always grip a hand rail on the fender.
M56(TB110)(CK2810)-호주판-OM-01.ind5 5 2012-10-15 오후 4:09:07
1
-
6CK2810 / CK3010H
5. Make sure that all pressure lines
are tight before starting the tractor.
6. Pull only from the drawbar. Never
hitch anything to the axle housing
or any other point except the draw-
bar. Pulling from any other location
only increase the risk of serious
personal injury or death.
7. Improper use of the draw-bar, even
if correctly positioned, can cause a
rear overturn.
8. Do not overload an attachment
or towed equipment. Use proper
counterweights to maintain tractor
stability. Hitch heavy loads to the
draw-bar only.
M55O117A
4. Do not operate your tractor in an
enclosed building without proper
ventilation. Exhaust fumes contain
carbon monoxide and may cause
serious injury or death.
051O110C
(1) Drawbar (2) Towing Hook
H11O110A
M56(TB110)(CK2810)-호주판-OM-01.ind6 6 2012-10-15 오후 4:09:08
1
-
7
SAFETY PRECAUTIONS
1
12. If the front of the tractor tends to
rise up when heavy implements
are attached to the three point
hitch, weights should be installed
on the tractor. Do not operate the
tractor with a light front end.
051O112C
9. Check for correct coupling be-
tween tow hook and trailer. See
the Towing Attachments chapter.
10. Use ballast weight as recom-
mended. Never add more ballast
to compensate a higher load than
allowed. Reduce load for safety.
11. A safety chain will help control
drawn equipment should it be
accidentally separated from the
draw-bar while transporting. Us-
H11O682A
ing the proper adaptor parts,
attach the chain to the tractor
draw-bar support or other speci-
ed anchor location. Provide only
enough slack in the chain to per-
mit turning. See your Dealer for a
chain with a strength rating equal
to, or greater than the gross
weight of the towed machine.
M56(TB110)(CK2810)-호주판-OM-01.ind7 7 2012-10-15 오후 4:09:09
1
-
8CK2810 / CK3010H
15. Do not leave equipment in the
raised position when the vehicle
is stopped or unattended.
16. When using implements or at-
tachments with your tractor you
should rst read their respective
owner’s manual. You should al-
ways keep their safe operation
procedures in mind.
17. You should be familiar with your
equipment and its limitations.
18. If abused or used incorrectly your
tractor can become dangerous to
you and bystanders. Overload-
ing your tractor or using unsafe
equipment can also be danger-
ous and should be avoided.
Refer to the "Specifications of
Implement Limitation", which out-
lines the maximum load for safe
tractor operation.
19. Driving forward out of a ditch
or steep inclines can cause the
tractor to tip over backwards. To
avoid this you should back out of
these positions. Four wheel drive
tractors can give you a false
sense of security in the tractors
ability to maneuver out of these
positions, so extra caution should
be taken.
20. Never try to get on or off a mov-
ing tractor.
051O114C051O113C
13. Always use the proper ballast
weight on your tractor when us-
ing rear implements.
14. Watch front and rear to avoid
obstacles at row ends, near trees
and around other obstructions.
Drive carefully to avoid injury
from penetration of objects
from sides, because this ma-
chine does not comply to OPS.
•
WARNING
M56(TB110)(CK2810)-호주판-OM-01.ind8 8 2012-10-15 오후 4:09:09
1
-
9
SAFETY PRECAUTIONS
1
21. When working in groups, always
let the others know what you are
going to do before you do it.
22. Never "freewheel". Disengaging
the clutch or shifting into neutral
while descending a slope as this
could lead to a loss of control.
23. Do not operate near ditches,
holes, embankments, or other ter-
rain features which may collapse
under the tractor’s weight. The
risk of tractor upset is even higher
when the ground is loose or wet.
051O115C
1.Lock the brake pedals together
when traveling at road speeds.
Brake both wheels simultaneously
when making an emergency stop.
Uneven braking at road speeds
could cause the tractor to tip over.
DRIVING THE TRACTOR
(1) Interlock
(2) Brake Pedal (L) (3) Brake Pedal (R)
MANUAL TYPE
051O116C
051O117C
HST TYPE
M56(TB110)(CK2810)-호주판-OM-01.ind9 9 2012-10-15 오후 4:09:10
1
-
10 CK2810 / CK3010H
3. Make sure that the Slow Moving
Vehicle (SMV) sign is clean and
visible. Use hazard lights as re-
quired.
4. Observe all local trafc and safe-
ty regulations.
5. Turn the headlights on. Dim them
when meeting another vehicle.
6. Drive at speeds that allow you to
maintain control at all times.
7. Do not apply the differential lock
while traveling at road speeds.
As the tractor may lose the ability
to steer.
8. Avoid sudden movements of the
steering wheel as this can cause
a loss of control of the tractor.
This risk is especially great when
traveling at road speeds.
9. Do not operate an implement
while the tractor is on the road.
Lock the three point hitch in the
raised position.
10. When towing other equipment,
use a safety chain and place an
SMV emblem on it as well.
(1) SMV Emblem
051O119C
2.Always slow the tractor before
turning. Turning at high speed may
tip the tractor over or cause an op-
erator to lose control of the tractor.
051O118C
M56(TB110)(CK2810)-호주판-OM-01.ind10 10 2012-10-15 오후 4:09:11
This manual suits for next models
1
Table of contents
Other Kioti Tractor manuals
