KISANKRAFT KK-IC-650D User manual

KisanKraft®
Warranty Certificate
(DEALER COPY)
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Product
Agricultural
Inter-Cultivator
KisanKraft
Invoice Date
Brand
KisanKraft
KisanKraft
Invoice No.
Model
KK-IC-650D
WARRANTY
PERIOD
6MONTHS
FOR THE SPECIFIED PERIOD FROM THE DATE OF
SALE OR DELIVERY WHICHEVER IS EARLIER.
Dealer’s
Invoice Date
Dealer’s Invoice No.
Buyer’s Info (Name, Address, Phone, etc.):
Dealer’s Stamp (Address, Phone, TIN, etc.):
Buyer’s Sign
Dealer’s Sign
Warranty Policy
What is covered: KisanKraft Limited and its manufacturers warrant this product tobefree from
defects in material or workmanship. All parts defective in material and workmanship are
covered.
This warranty will only cover defects arising under normal usage.
This warranty is limited to repair or replacement by KisanKraft Limited or its manufacturers of
such parts as appear to KisanKraft or its manufacturers, upon inspection, to be defective in
material and/or workmanship. KisanKraft or its manufacturers make no warranty with respect
to items not manufactured or sold by them. No onsite warranty is provided by KisanKraft
Limited or its manufacturers. Defective items must be brought/sent to our Authorized Dealer
or KisanKraft Limited’s office for service.
What is not covered: The warranty shall become null and void and neither KisanKraft Limited
nor any of its manufacturers, noritsauthorized dealers assume any responsibility,if the failure
was caused by the following:
(1) Operation of product with incorrect fuel or lubricants, (2) Incorrect usage of machine or
misuse, (3) Lack of maintenance, (4) Negligence, (5) Accident or physical damage, (6) Repairs
made by unauthorized parties and/or with unauthorized parts, (7) Improper set up,
adjustments, tampering or altered products (8) Any modification to the product what-so-ever.
Important: (1) Normal maintenance and adjustments to the product is the responsibility of the
customer. (2) Normal wear and tear are not covered under warranty. (3) Rubber/plastic parts
and consumables suchas blades, clutch and clutch-bell, sparkplugs, nylon line, air-filters, fuel-
filters, oil seals and gaskets etc. are not covered under the warranty. (4) Electrical Motor,
Electrical Parts, Battery Etc. are not covered under the warranty.
Incidental / Consequential Loss: KisanKraft Limited or its manufacturers will not be liable for
general damages, including bodily injuries, or for incidental or consequential damages
including, but not limited to, lossof use, loss of profits, loss of production, expense of substitute
equipment or other commercial loss or damage.
Limitation of Liability: This limited warranty is in lieu of all other express warranties,
obligations, or liabilities. Any implied warranties, obligations, or liabilities, including, but not

KisanKraft®
Warranty Certificate
(DEALER COPY)
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
limited to, any implied warranty of merchantability shall be limited in duration to the applicable
warranty period. Any action for breach of any warranties hereunder, including, but not limited
to, any implied warranty of merchantability must be brought within the applicable warranty
period.
Modifications of Warranty: No agent, representative, dealer, or employee of KisanKraft
Limited or any of its manufacturers has the authority to increase or alter the obligations of this
warranty.
Assignment / Transfer of warranty: The warranty cannot be assigned and shall not transfer if
the product is resold by the first buyer. The above warranties are extended to the first end user
(original purchaser), and no warranty is made, norauthorized tobe made assignableon resale
by the first end user.
What you must do to obtain limited warranty service: To obtain performance of any obligation
under this warranty for failure during the applicable warranty period, you must deliver the
defective product, to the nearest Authorized Dealer, along with proof-of-purchase
(invoice/receipt). KisanKraft Limited, its manufacturers and its dealers reserve the right to
inspect the claimed defective part(s) to determine if the malfunction is the result of a defect
covered by this warranty. Please note that the decision of KisanKraft Limited with respect to
any warranty claim is final.
After-sales Service (Including Warranty): KisanKraft Limited does not sell directly to
consumers. All sales or supplies are made through Authorized Dealers. It is the responsibility
of the Authorized Dealer to provide all after-sales service to consumers. Any warranty claim
should be raised by dealer to KisanKraft Limited as per warranty policy.
Jurisdiction: All disputes are subject to Bangalore court’s jurisdiction.
Notes:
➢This purchase is not contingent upon a product demonstration. The purchaser shallsatisfy
himself with the product, including any product demonstration or verification of any
function, before buying. KisanKraft Limited or its authorized dealers, including online
sellers, shall not be liable to give any on-site demonstration after purchase of any of the
product.
➢Any product once used will not be taken back by KisanKraft Limited.
➢Warranty and After Sale Services (including but not limited to installation, Demonstration,
Repair, Routine Maintenance etc.), should be done through the Authorized Dealer selling
this product.
➢Dealers should have their own technician to provide After Sales Services to their
Customers. KisanKraft Limited provides free training to Authorized Dealer’s technicians
at KisanKraft Limited’s head office, on request from Authorized Dealer.

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650P
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 3 of 49
User Manual
KisanKraft Limited
Warehouse: 818 3B1 to 818 3B18, Podalakur - Sangam Road, Prabagiripatnam,
Podalakur, Nellore - 524345, Andhra Pradesh, INDIA
Head Office: Sri Huchhanna Tower, #4,1st Main,7-A Cross, Maruthi Layout,
Dasarahalli, HAF Post, Hebbal, Bangalore 560024, Karnataka, INDIA
♦Bangalore (HO) ♦Ahmedabad ♦Bhopal ♦Bhubaneswar ♦Coimbatore
♦Guwahati ♦Hubli ♦Hyderabad ♦Jaipur ♦Karnal
♦Kolkata ♦Lucknow ♦Nellore ♦Pune ♦Raipur

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650P
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 4 of 49
CONTENTS
Before Getting Started................................................................................................ 7
Application.................................................................................................................. 7
Safety Instructions...................................................................................................... 7
Product Overview..................................................................................................... 13
Installation Method ................................................................................................... 14
Operation Instructions............................................................................................... 15
Maintenance............................................................................................................. 17
Adjustment methods and data .................................................................................. 19
Technical Specification............................................................................................. 21
Part Diagram............................................................................................................ 22

KisanKraft®
Warranty Certificate
(CUSTOMER COPY)
This warranty is null & void, if you fail to register the warranty with KisanKraft
by sending the KisanKraft Copy with dealer’s stamp.
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Product
Agricultural
Inter-Cultivator
KisanKraft
Invoice Date
Brand
KisanKraft
KisanKraft
Invoice No.
Model
KK-IC-650D
WARRANTY
PERIOD
6MONTHS
FOR THE SPECIFIED PERIOD FROM THE DATE
OF SALE OR DELIVERY WHICHEVER IS
EARLIER.
Dealer’s
Invoice
Date
Dealer’s Invoice No.
Buyer’s Info (Name, Address, Phone, etc.):
Dealer’s Stamp (Address, Phone, TIN, etc.):
Buyer’s
Sign
Dealer’s Sign
Warranty Policy
What is covered: KisanKraft Limited and its manufacturers warrant this product to be free
from defects in material or workmanship. All parts defective in material and workmanship
are covered.
This warranty will only cover defects arising under normal usage.
This warranty is limited to repair or replacement by KisanKraft Limited or its manufacturers
of such parts as appear to KisanKraft or its manufacturers, upon inspection, to be defective
in material and/or workmanship. KisanKraft or its manufacturers make no warranty with
respect to items not manufactured or sold by them. No onsite warranty is provided by
KisanKraft Limited or its manufacturers. Defective items must be brought/sent to our
Authorized Dealer or KisanKraft Limited’s office for service.
What is not covered: The warranty shall become null and void and neither KisanKraft Limited
nor any of its manufacturers, nor its authorized dealers assume any responsibility, if the
failure was caused by the following:
(1) Operation of product with incorrect fuel or lubricants, (2) Incorrect usage of machine or
misuse, (3) Lack of maintenance, (4) Negligence, (5) Accident or physical damage, (6)
Repairs made by unauthorized parties and/or with unauthorized parts, (7) Improper set up,
adjustments, tampering or altered products (8) Any modification to the product what-so-ever.
Important: (1) Normal maintenance and adjustments to the product is the responsibility of
the customer. (2) Normal wear and tear are not covered under warranty. (3) Rubber/plastic
parts and consumables such as blades, clutch and clutch-bell, sparkplugs, nylon line, air-
filters, fuel-filters, oil seals and gaskets etc. are not covered under the warranty. (4) Electrical
Motor, Electrical Parts, Battery Etc. are not covered under the warranty.
Incidental / Consequential Loss: KisanKraft Limited or its manufacturers will not be liable for
general damages, including bodily injuries, or for incidental or consequential damages
including, but not limited to, loss of use, loss of profits, loss of production, expense of
substitute equipment or other commercial loss or damage.

KisanKraft®
Warranty Certificate
(CUSTOMER COPY)
This warranty is null & void, if you fail to register the warranty with KisanKraft
by sending the KisanKraft Copy with dealer’s stamp.
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Limitation of Liability: This limited warranty is in lieu of all other express warranties,
obligations, or liabilities. Any implied warranties, obligations, or liabilities, including, but not
limited to, any implied warranty of merchantability shall be limited in duration to the
applicable warranty period. Any action for breach of any warranties hereunder, including,
but not limited to, any implied warranty of merchantability must be brought within the
applicable warranty period.
Modifications of Warranty: No agent, representative, dealer, or employee of KisanKraft
Limited or any of its manufacturers has the authority to increase or alter the obligations of
this warranty.
Assignment / Transfer of warranty: The warranty cannot be assigned and shall not transfer
if the product is resold by the first buyer. The above warranties are extended to the first end
user (original purchaser), and no warranty is made, nor authorized to be made assignable
on resale by the first end user.
What you must do to obtain limited warranty service: To obtain performance of any
obligation under this warranty for failure during the applicable warranty period, you must
deliver the defective product, to the nearest Authorized Dealer, along with proof-of-purchase
(invoice/receipt). KisanKraft Limited, its manufacturers and its dealers reserve the right to
inspect the claimed defective part(s) to determine if the malfunction is the result of a defect
covered by this warranty. Please note that the decision of KisanKraft Limited with respect to
any warranty claim is final.
After-sales Service (Including Warranty): KisanKraft Limited does not sell directly to
consumers. Allsales or suppliesare made through Authorized Dealers. It isthe responsibility
of the Authorized Dealer to provide all after-sales service to consumers. Any warranty claim
should be raised by dealer to KisanKraft Limited as per warranty policy.
Jurisdiction: All disputes are subject to Bangalore court’s jurisdiction.
Notes:
➢This purchase is not contingent upon a product demonstration. The purchaser shall
satisfy himself with the product, including any product demonstration or verification of
any function, before buying. KisanKraft Limited or its authorized dealers, including
online sellers, shall notbe liable to give any on-site demonstration after purchase of any
of the product.
➢Any product once used will not be taken back by KisanKraft Limited.
➢Warranty and After Sale Services (including but not limited to installation,
Demonstration, Repair, Routine Maintenance etc.), should be done through the
Authorized Dealer selling this product.
➢Dealers should have their own technician to provide After Sales Services to their
Customers. KisanKraft Limited provides free training to Authorized Dealer’s technicians
at KisanKraft Limited’s head office, on request from Authorized Dealer.

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 7 of 49
Before Getting Started
Thank you for purchasing our Inter-cultivator.
•This manual contains information on operation and maintenance of the Inter-cultivator, which is
based on the most recent product information available at the time of approval for printing. We
reserve the right to make amendments without prior notice and without incurring any obligation for
sequences.
•No part of this publication may be reproduced without written permission.
•This manual should be considered a permanent part of the cultivator and remain with it if it is resold.
•Please pay special attention to statements preceded by the following words:
WARNING
Indicates a strong possibility of severe personal injury or death if instructions are not
followed.
CAUTION
Indicates a possibility of personal injury or equipment damage if instructions are not
followed.
NOTE
Gives helpful information.
Application
The Inter-cultivator is suitable for Intercultural/weeding operations the sandy soil and clay soil of canopied
vegetables base, slopes with gradient less than 10%, paddy field with the depth of water surface to hard layer
not more than 250mm. For weedy and deep plots, remove the weeds before using the Inter-cultivator to
cultivate the land. Assemble blades on both side of intercultivator and use pin to fixed blades to do
Intercultural/weeding operations. Take off resistance rod and assemble ditching blade, for ditching work.
Safety Instructions
Important:
•When the engine is starting, turn the shift lever to the “Neutral Position”.
•Be careful when Intercultivator is working.
•Check the blades.
•The fuel and oil must be suitable and clean.
•Release clutch before gear shifting and slow down the engine. It is safer when engine is slow
down.
•Fuel is easy to catch fire and exploded.
•When working in paddy field or on a slope, use the reverse gear carefully.
•This Inter-cultivator is designed to give safe and dependable service if
operated according to the instructions.
•Read and understand the Operation Manual before operating the Inter-
cultivator. Failure to do so could result in personal injury or equipment
damage.
•Exhaust gas contains poisonous carbon monoxide.
•Never run the cultivator in enclosed areas.
•Be sure to provide adequate ventilation during installation and operation.

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 8 of 49
•The rotating parts are sharp and runs at high speed.
•Accidental contact can cause serious injury. Keep your hands and feet away
from the parts while the engine is running.
•Stop the engine and disengage the tines clutch before inspection or
maintenance of the tines.
•Disconnect the spark plug cap to prevent any possibility of accidental
starting, wear heavy gloves to protect your hands from the tines when
clearing the tines or when inspecting or replacing the tines.
SAFETY LABEL LOCATIONS:
These labels warn you of potential hazards that can cause serious injury. Read the labels and safety notes
and precautions described in this manual carefully.
Operator Responsibility:
•Keep the Inter-cultivator in good operating condition. Operating a cultivator in poor or questionable
condition could result in serious injury.
•Be sure all safety devices are in working order and warning labels are in place. These items are
installed for your safety.
•Make sure that the safety covers (Fan cover, recoil starter cover) are in place.
•Know how to stop the engine and tines quickly in case of emergency.
•Understand the use of all controls.
•Keep a firm hold on the handlebars, they may tend to lift during clutch engagement.
•Don’t allow anyone to operate this cultivator without proper training to avoid injury.
•Wear sturdy, fully covered footwear. Operating this Inter-cultivator on barefoot or with open toe
shoes or sandals increase your risk of injury.
•Dress sensibly. Loose clothing may be caught by moving parts, increasing your risk of injury.
•Always stay alert. Operating this cultivator when you are tired, ill or under the influence of alcohol
or drugs may result serious injury.
•Keep all persons and pets away from the Intercultural/weeding operations area.
•Make sure the drag bar is in place and properly adjusted.
Child Safety:
•Keep children indoors and supervise all the time while any outdoor power equipment is being used
nearby. Young children move quickly and are attracted especially by the cultivator and
Intercultural/weeding operations.

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 9 of 49
•Never assume children will remain where you last saw them. Be alert and turn the cultivator off if
children enter the area.
•Children should never be allowed to operate the cultivator even under adult supervision.
Thrown Object Hazard:
•Objects hit by the rotating tines can be thrown from the cultivator with great force and may cause
severe injury.
•Before Intercultural/weeding operations clear the Intercultural/weeding operations area of sticks,
large stone wire glass etc.
•Cultivate only in daylight.
•Pieces thrown from worn or damaged tines can cause serious injury. Always inspect the tines
before using the Inter-cultivator.
Fire and Burn Hazard:
•Diesel is extremely flammable and Diesel vapor can explode.
•Take extreme care when handling Diesel. Keep Diesel out of reach of children.
•Refuel in a well-ventilated area with the engine stopped.
•Allow the engine to cool before refueling. Fuel vapor or spilled fuel may be ignited.
•The engine and exhaust system become very hot during operation and remain hot for a while even
after stopping. Contact with hot engine components can cause burn injuries and can ignite some
materials.
•Avoid touching a hot engine or exhaust system.
•Allow the engine to cool before performing maintenance or storing the cultivator indoors.
Carbon Monoxide Poisoning Hazard:
•Exhaust contains poisonous carbon monoxide a colorless and odorless gas. Breathing exhaust
can cause loss of consciousness and may lead to death.
•If you run the engine in an area that is confined or even partially enclosed, the air you breathe could
contain a dangerous amount of exhaust gas. To keep exhaust gas from building-up, provide
adequate ventilation.
Operation on Slope
•When Intercultural/weeding operations on slopes, keep the fuel tank less than half full to minimize
fuel spillage.
•Intercultural/weeding operations across the slope (At equally spaced intervals) rather than up and
down it.
•Be very careful when changing the direction of the cultivator on a slope.
•Do not use the cultivator on a slope for more than 10°.
•The maximum safe grade angle shown is for reference purpose only and should be determined
according to the type of the tool. Before starting the engine, check that the Inter-cultivator is not
damaged and in good condition. For your safety and safety of others, exercise extreme care when
using the Inter-cultivator up or down the hill.
Training
•Please read this manual carefully and learn how to operate and use the weeder.
•Don’t allow children and anyone without proper training to operate this weeder to avoid injury.

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 10 of 49
•Keep all persons (especial the kids) and pets away from the weeding working area.
Preparation
•Move all the sundries away from the weeder working area.
•Before engine starting, be sure the clutch is disengaged, and the shift lever is in the neutral position.
•It is not allowed to operate the weeder without wearing proper coat. Wearing the antiskid shoes
can improve the stability on the slide surface.
•Be careful the fuel, it is extremely flammable.
•Using the proper tank to store the fuel.
•It is not allowed to refuel when engine is working or before engine cooled. Refueling the lube oil
into the tank is not permitted.
•Refuel in a well-ventilated area with the engine stopped.
•Before starting, tightening the fuel cap, and cleaning the spilled fuel.
•When engine running, any adjustment is not allowed (except the special adjustment
recommended by manufacturer).
•Please wear the safety glasses for any operation, such as: preparation, operation, and
maintenance.
Operation
•Keep your hands and feet away from the rotating parts while engine is running.
•Be careful to operate on (or across) the cobble road, pavement, or highroad. Be careful the
potential risk and traffic. Taking the passenger is not allowed.
•Please stop the engine and check if the weeder be broken after striking sundries. It is not allowed
to start or operate before it is repaired if broken.
•Attention the operation floor, avoid slipping down.
•Any unusual vibration is the sign of fault should stop and inspect machine immediately.
•Stop the engine, while leaving the operation position, cleaning the rotor, doing maintenance,
adjusting, or checking the machine.
•After using, should do the preventive measures, such as: disengage the power output, gear in
neutral position, engine off.
•Before cleaning, maintenance and inspection, the engine should be off, and ensure all the moving
parts to be stopped.
•Exhaust contains poisonous gas; don’t use the weeder in enclosure space.
•No protective devices, no operation the weeder.
•Keep away from the kids and pets.
•To avoid over weeding depth, and over speed, cause the machine overload.
•The weeder should not be run in high speed on the slippery road, be careful the back situation
when using backward gear.
•Keep people away from the machine.
•Use only genuine parts or their equivalents (such as: wheel bob-weight, balancing weight, cabin
etc.).
•Don’t operate the weeder in poor view or weak light environment.
•Be careful to operate on hard land because the blade into land can push the weeder forward. In
this case, release the handlebar, don’t try to control it.

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 11 of 49
•Do not use the weeder on slope.
•When the weeder goes up or down the slope, should prevent tip-over.
Maintenance and Storage
•Keep the weeder, attached device and components in good operation condition.
•At set intervals, check if the bolts fasten to ensure the weeder in safe operation condition.
•Indoor storage, away from the fire. Cool the engine before indoor storage.
•For long-period storage, should keep this manual well, too.
•Don’t try to repair the machine, otherwise you have the proper tools and disassemble,
assemble and maintenance manual.
Safety warning indication
△
!Warning
No smoking: this machine uses Diesel which is
flammable
A1 Fire safety sign

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 12 of 49

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 13 of 49
A2 fire safety sign
Safety warning position
Product Overview
1
Handle frame
2
Flameout switch
3
Oil switch
4
Diesel engine
5
Bumper
6
Walking round assy.
7
Rotary parts
8
Fender parts
9
Output clutch handle
10
Clutch handle

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 14 of 49
Applicable Scope
1. Ditching
The ditching (table), the direction of the blade (fig), adjust the height of the rear wheel according to the
depth of the ditching. The armrest can be rotated to the side or back of the machine to operate the
ditching work
2. Ridge
Adjust the machine according to the ditching operation requirements. And adjust the angle of the
fender to control the falling point of the soil for ridging.
3. Rotary
Replace the rotary blade, remove the rear wheel and switch to rotary for weeding work.
Installation Method
Assembly after unpackaged:
1. Take out the machine and accessories from the package.
2. Fix the body of the weeder, install left, right wheels on both side of the output shaft of walking case, and
use pin 8*73 and pin to fix it; then install the rear wheel, adjust height, tighten the locking bolt to secure
it.
3. Install ditching (ridging) blade: install the ditching device into the two ends of the output shaft (blade in
front) in weeding case and fix it with pin.
4. Fender (or narrow fender) and side fender installation: attach the left and right fenders to the weeder,
install the hex bolts M6*12 and the lock nuts M6(8 pcs each), and tighten the bolts and nuts with an 8-
10mm wrench, install the fender adjustment block to the fender, install the hex bolts M8*16 and lock nuts
M8 (2pcs each), then install the side genders on both sides and tighten the small handle. (if the fender

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 15 of 49
and side fender have been installed to the machine after unpacking, this step can be omitted)
5. Check the whole machine, see if there are no missing parts and other missing parts in the accessory box,
and then follow the instructions to perform the next steps
Operation Instructions
Before sending the weeder out of factory, adjusting and debugging is done, for comfortable and easier
using, the user should inspect and adjust it again.
◆1. Daily Checking
1.1 Check all the bolts in the connecting part ensure all of them are tightening.
1.2 Checking the handles (throttle, Clutch and gear shifting lever), make them flexible and in the
correct position.
1.3 Put the shift lever in the neutral gear place.
1.4 Add oil:
a. Add lube oil () to crankcase as Photo III shows.
b. Put the engine at horizontal position. Insert the dipstick into the filler neck without
screwing it in. Get the dipstick out, check the oil level. The oil level should be the
mentioned position in the dipstick. (Look at Photo III).
c. Refuel air cleaner with oil, disassembling the synthetic glass cover tent below the
cleaner, and refuel 0.1L No.20 oil.
1.5 Add fuel;
1.6 Make preparation following the user manual before starting machine.
△
!Attention
Don’t rotate dipstick, don’t add lube oil between upper level and
lower level.
◆2. Weeder adjustment
△
!Attention
Please put the Intercultivator on firm land level before adjusting the
handle height to prevent the handle from collapsing accidentally.

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 16 of 49
2.1 Handle frame adjustment
Adjust the height and direction of handle frame by lock hands.
2.2 Weeding depth adjustment
Control the weeding depth by adjusting the height of the resistance rod. Rod going down,
weeding depth decreased; Rod going up, weeding depth increased.
◆3. Engine start and stop
△
!Attention
Shift lever must be in the neutral gear position
3.1 Shift lever must be in the neutral gear position before starting the weeder.
3.2 Start the Diesel engine following the steps of user manual.
3.3 Engines should run in the low speed (1450-1750r/min) for 2-3 minutes without load.
3.4 Check if the engine runs normally, if abnormal, please turn it off and repair.
△
!Attention
The Intercultivator must running-in before starting
using. Check Chapter VI for running-in method.
◆4. Operation
4.1 Starting weeder: Clutch bar should be disengaged, and all gear shifting levers should be in
neutral gear position, and then start the engine following the usual manual.
4.2 Running: Put gear shifting handle in the required gear position, clench the clutch handlebar to
make the weeder work/walk.
4.3 Parking:
a) Loosen Clutch handlebar.
b) Put Gear shifting lever to Neutral position.
c) Following the user manual, if need to turn off the engine
△
!Attention
Park the Intercultivator on flatland.
5. Operation attention
△
!Attention
5.1 When using Intercultivator, you should pay attention to the working situation and sound of
every part, check if the connection is good. There mustn’t be loosed connection. If there is
abnormal situation, please stop the Intercultivator and check.
5.2 Never carry out work with heavy load if Intercultivator has not been used for a long time,
especially the new ones or the repaired ones.

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 17 of 49
5.3 Pay attention to the oil level of Diesel engine, walking case and gear box. When they are
insufficient, please refuel them.
5.4 Never cool the Diesel engine in the way of water-pouring.
5.5 Prevent Intercultivator from falling down when Intercultural/weeding operations.
5.6 Never install Intercultivator with rotary blades when walking on sand or stone to avoid
damaging blades.
5.7 After Intercultural/weeding operations, please clear away dirtiness on the Intercultivator, such
as mud, grass and
Maintenance
Due to rotary situation, abrasion and load change of mini weeder, bolts will become loose, and parts will be
worn during the work. These changes will destroy the proper working state of mini weeder, create abnormal
fitting clearance, degrade output of Diesel engine, increase oil consumption, lead to the maladjustment of
spare parts, increase malfunction of mini weeder. All these will seriously affect the working efficiency of mini
weeder. To decrease the frequency of the above-mentioned accidents, prevention of maintenance work
must be done strictly and regularly to keep the mini weeder in a good technical state and prolong its life.
◆1. Running-in of mini weeder
◇1.1 As for running-in of Diesel engine, please refer to its instruction.
◇1.2 If mini weeder is new or is just heavily repaired, it should work without load for one hour.
After the mini weeder works with light load for five hours, all oil in gear box and crankcase of Diesel
engine should be drained immediately. Afterwards, you should refuel adequate clean Diesel oil, pull
the starting grip 5~10 times, then drain it. Refuel the lube oil for 4 hours running-in, then can use
the weeder normally.
◆2. Technical maintenance table of mini weeder
◇2.1 Every-time maintenance (before and after work)
•Listen and check if there is malfunction of every part (such as abnormal noise, overheat,
loose screw and so on).
•Check if there is oil leakage from Diesel engine, gear box and running gear.
•Check if the oil level of Diesel engine and gear box is between the upper and lower limit
of dipstick.
•Clean the whole machine and spare parts which are with mud, grass, and oil stain
regularly.
•Do daily record.
◇2.2 Primary maintenance (per 150 hours)
•Carry out maintenance work based on all contents of every-time maintenance.
•Wash gear box, running gearbox and change lube oil.
•Check and adjust clutch, shift system and reverse gear system.
◇2.3 Secondary maintenance (per 800 hours)
•Carry out maintenance work based on all contents of primary maintenance.
•Check all gears and bearings. If they are fretted severely, please replace them.
•Check other parts of mini weeder, such as: rotary blades or bolts and so on. If there is
damage, please replace them.
◇2.4 Technical inspection (per 1500-2000 hours)
•Take the whole machine to the specific maintenance station and have a check. If the
spare parts are severely fretted, they must be changed or repaired according to the
situation.

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 18 of 49
◆3. Technical maintenance of mini weeder
Working
intervals
Maintenance
contents
everyday
Work with
half load
for 8
hours
Work for
1 month
or 20
hours
Work for
3 months
or 150
hours
Every
year or
1000
hours
Per 2
years or
2000
hours
Check &
tighten nuts,
bolts
√
Check and
refuel lube
√
Check and
change lube
√（1st
time）
√（2nd
time）
√（3rd
time or
more）
Check if there
is oil leakage
√
Clean mud,
grass, and oil
stain
√
Debug
malfunction
√
Adjust
operation
parts
√
Tighten the
belt
√
Gear and
bearing
√
◆4. Long-period storage of mini weeder
When mini weeder needs storing for a long period, the following measures should be taken to
prevent tarnishing.
◇4.1 Wash oil stain and clean dust on the machine.
◇4.2 Drain lube oil in the gear box and refuel new oil.
◇4.3 Paint pickling oil on non-aluminum parts where there is no paint.
◇4.4 Store mini weeder in the dry, safe place where there is enough aeration.
◇4.5 Properly keep the attaching tools, certificates of conformity and instruction of mini weeder.

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 19 of 49
Adjustment methods and data
The abrasion of friction plates and the clutch shifting fork will make malfunction of clutch after using for a long
time, in this case, should adjust clutch accordingly.
◇1.1 Clutch cable adjustment
◇1.1.1 Every weeder must be equipped with one set of clutch limit usually open sleeve, which cannot be
replaced by a common clutch cable.
◇1.1.2 When adjusting the clutch, must make sure the small sleeve running in the scale range. When loosen
clutch handlebar, the main output shaft should be stopped immediately. Please replace a new clutch
cable if the small sleeve runs out of the scale range.
◇1.1.3 When adjust clutch cable, please make the clutch cable adjusting rod on both clutch shifting fork arm
and armrest-frame in the proper position, and then tighten the nut to lock them.
Requirement
The small sleeve must work in the scale range after all adjustment done.
◆2. Adjustment of throttle cable
◇2.1 Adjust throttle cable, make throttle handle can reach the fastest and slowest position, then tighten the
throttle switch with locking bolt.

KisanKraft®
Agricultural Inter-Cultivator
KK-IC-650D
: www.kisankraft.com
: [e-mail]
: +91.80. 6835 7800
Page 20 of 49
Troubleshooting
◆1. Common troubles and solutions
Phenomenon
Reason
Solution
Abnormal noise
on gear
Over abrasion of the
gear or improper
installation
Reinstall or replace the gear
Gear cannot run
smoothly
Improper installation
Reinstall the gear
Overheat of the
machine
Less lube oil in the
tank
Add lube oil as required
Too narrow space
between gears
Reassembly
Two narrow spaces
between bearings
Readjust
Oil leakage on
the linkage of
gear box
The connecting bolt
is loosened
Tighten the bolt
Oil leakage
Sealing gasket is
broken
Replace the sealing gasket
Oil leakage on
the output shaft
Lip-shaped oil seal is
broken
Replace the oil seal
Oil leakage on
the oil-draining
hole
O Ring is broken
Replace the O ring
Screw plug is
loosened
Tighten it accordingly
Oil leakage on
the tank
Small holes on the
tank
Welding or paint the holes
◆2. Other troubles and solutions
Phenomenon
Reason
Solution
Rotary blades are broken off
Hit stones or bricks when
using
Replace it, pay attention to
avoid the stones and bricks
Controlling cable is broken off
Long-time working
abrasion
Replace the cable
