OPERATION MANUAL
EK 135L
Battery-powered
Crimping Tool
HE.13451_A © 01/2013 R&D-2
Serialnummer
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
Register this product at www.klauke.com

2
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
Description
The EK135L Battery-powered, High-speed Crimping
Tool is a hand-held, self-contained crimping tool
intended to crimp aluminum and copper connectors
onto electrical cable.
This tool has a retraction stop feature which allows the
operator to stop the retraction motion of the ram to
shorten cycle time.
This tool is protected by U.S. Patent No. 6,206,663,
6,276,186, 6,401,515, and 6,718,870.
Safety
Safety is essential in the use and maintenance of
Klauke tools and equipment. This manual and any mark-
ings on the tool provide information for avoiding hazards
and unsafe practices related to the use of this tool.
Observe all of the safety information provided.
Purpose of this Manual
This manual is intended to familiarize all personnel with
the safe operation and maintenance procedures for the
following Klauke tool:
EK135L Battery-powered Crimping Tool
Keep this manual available to all personnel.
Replacement manuals are available upon request at
no charge at www.klauke.com.
Do not discard this product or throw away!
For recycling information, go to www.klauke.com.
KEEP THIS MANUAL
Table of Contents
Description ..................................................................... 2
Safety ............................................................................. 2
Purpose of this Manual .................................................. 2
Important Safety Information ..................................... 3–4
Identification................................................................... 5
Specifications................................................................. 5
Adapter Kits................................................................ 6–8
Setup .............................................................................. 8
Operation.................................................................. 9–10
Die Selection ................................................................ 11
Connector Selection..................................................... 11
Maintenance................................................................. 12
Troubleshooting............................................................ 13

3
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
IMPORTANT SAFETY INFORMATION
SAFETY
ALERT
SYMBOL
This symbol is used to call your attention to hazards
or unsafe practices which could result in an injury or
property damage. The signal word, defined below,
indicates the severity of the hazard. The message
after the signal word provides information for pre-
venting or avoiding the hazard.
Immediate hazards which, if not avoided, WILL result
in severe injury or death.
Hazards which, if not avoided, COULD result in
severe injury or death.
Hazards or unsafe practices which, if not avoided,
MAY result in injury or property damage.
Read and understand all of the
instructions and safety information
in this manual before operating or
servicing this tool.
Failure to observe this warning
could result in severe injury or death.
Electric shock hazard:
This tool is not insulated. When
using this unit on or near energized
electrical lines, use proper personal
protective equipment.
Failure to observe this warning
could result in severe injury or death.
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection could
result in serious eye injury from
flying debris or hydraulic oil.
Skin injection hazard:
Do not use hands to check for oil
leaks. Oil under pressure easily
punctures skin. If injured, seek
medical attention immediately to
remove oil.
Failure to observe this warning
could result in serious injury, gan-
grene, or death.
Do not use solvents or flammable
liquids to clean the tool body.
Solvents or flammable liquids could
ignite and cause serious injury or
property damage.
An incomplete crimp can cause a fire.
Use proper die, connector, and cable combina-•
tions. Improper combinations can result in an
incomplete crimp.
The relief valve sounds and the ram automatically•
retracts to indicate a completed crimp. If you do
not hear the sound of the relieve valve or the ram
does not automatically retract, the crimp is not
complete.
Failure to observe these warnings could result in
severe injury or death.

4
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
IMPORTANT SAFETY INFORMATION
Pinch points:
Remove battery before changing•
dies, adapters, or jaws.
Keep hands away from the crimp-•
ing tool head when crimping.
Failure to observe these warnings
could result in severe injury or death.
Do not dispose of batteries in a fire. They will vent
fumes and may explode.
Failure to observe this warning could result in severe
injury from harmful fumes or burns from flying
debris.
Inspect tool and dies before use. Replace any
worn or damaged parts. A damaged or improp-
erly assembled tool can break and strike nearby
personnel.
Failure to observe this warning could result in severe
injury or death.
Do not use this tool for continuous use. After 30 to•
40 cycles, allow the tool to cool for 15 minutes.
Do not secure this tool in a vise. This tool is•
designed for hand-held operation.
This tool may be used in damp or wet environ-•
ments; however, air-drying is recommended before
use if the tool becomes soaked. Damage may
result when the tool is operated prior to thorough
drying when electrical components are soaked.
Use this tool for the manufacturer’s intended•
purpose only.
Failure to observe these precautions may result in
injury or property damage.
Do not allow anything to contact the battery
terminals.
Do not immerse the batteries in liquid. Liquid may•
create a short circuit and damage the battery.
If batteries are immersed, contact your service
center for proper handling.
Do not place the battery into a pocket, tool pouch,•
or tool box with conductive objects. Conductive
objects may create a short circuit and damage the
battery.
Do not place a battery on moist ground or grass.•
Moisture may create a short circuit and damage
the battery.
Failure to observe these precautions may result in
injury or property damage.
Do not store the battery at more than 122 °F•
(50 °C) or less than 10.4 °F (–12 °C). Damage to
the battery can result.
Do not use another manufacturer’s charger. Other•
manufacturers’ chargers may overcharge and
damage the battery.
Do not attempt to open the battery. It contains no•
user-serviceable parts.
Failure to observe these precautions may result in
injury or property damage.
Do not perform any service or maintenance other
than as described in this manual. Injury or damage
to the tool may result.
Failure to observe this precaution may result in injury
and property damage.
Note: Keep all decals clean and legible, and replace
when necessary.

5
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
Identification
Crimping Tool
Length .....................................................19.5" (495.3 mm)
Width .........................................................3.00" (76.2 mm)
Height (with battery)..............................12.25" (311.2 mm)
Mass/Weight (with battery) .....................21.25 lb (9.63 kg)
Crimping Force ........................................ 15 tons (135 kN)
Hydraulic Oil....... 52057878 biodegradable hydraulic fluid
Recommended Operating
Temperature Range..........5 °F to 122 °F (–15 °C to 50 °C)
Battery Charger
Read the instructions supplied with the battery charger
Specifications
1. LED Work Light (white)
2. Die Release Button
3. Crimping Head
4. Lanyard Ring
5. Housing
6. Retract Button
7. LED Indictor (red)
8. Battery
9. Trigger
Crimping Capacities
Maximum Crimping Capacity
Aluminum..................................................... 1250 kcmil
Copper......................................................... 1500 kcmil
*With PH14 Dies (no Adapter Kit needed):
1027 kcmil 48/7 ACSR
*With 48824 Die Holder Kit for PH2 Dies:
477 26/27 ACSR tension,
terminals through 1033 kcmil
With 48788 Die Holder Kit for TBM 15 Dies:
1000 kcmil copper and aluminum fittings
With 48820 Die Holder Kit for Y46 Dies:
1250 kcmil aluminum and
1500 kcmil copper fittings
With 48802 Die Holder Kit for 12-ton “U” Dies:
500 kcmil copper splices,
750 kcmil copper terminals,
350 kcmil aluminum splices,
750 kcmil aluminum terminals
* Do not use non-butting dies (crimps controlled by
tonnage) in this tool, as damage could occur to
connectors and/or conductors.
98
2
3
4
76
5
1
52047087 120 VAC corded adapter
52047088 230 VAC corded adapter
52049189 18 V, 3 Ah lithium-ion battery
52049201 120 VAC, 18 V charger
52049202 230 VAC, 18 V charger
52049204 12 VDC, 18 V charger
52054992 Li (18 V) to NiCd, NiMH (12 V) charger adapter
50122746 Carrying strap

6
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
Procedure for Using Kearney PH14 Dies
1. No die holder assemblies are needed. Dies fit
directly into tool.
2. Select proper die set for fitting to be crimped.
Note: Do not use non-butting dies (crimps con-
trolled by tonnage) in this tool, as damage could
occur to connectors and/or conductors.
3. Install upper die in hole in top of “C” head. Snap in
place with top die retaining plunger (6).
4. Install lower die in hole in end of piston. Snap in
place with bottom die retaining plungers (6).
Adapter Kits
Procedure for Using Kearney PH2 Dies;
48824 Die Holder Kit
1. Install 48823 PH2 die spacer assembly into hole
in top of “C” head. Snap in place with retaining
spring plunger (6).
2. Install upper 48825 die holder assembly into hole in
die spacer assembly. Lock in place with die spacer
retaining screw.
3. Install lower 48825 die holder assembly in hole in
end of piston. Snap in place with bottom die holder
retaining spring plungers (6).
4. Select proper die set for fitting to be crimped.
Note: Do not use non-butting dies (crimps con-
trolled by tonnage) in this tool, as damage could
occur to connectors and/or conductors.
5. Slide die into place in top die holder tight against
shoulder. Detent screw will snap into groove of
die. Lock in place with top die retaining cap screw.
Repeat operation for other die entry.
PH2 Die Holder Kit 48824 contains:
(1) 48823 and (2) 48825 Die Holders
PH14 DIES
BOTTOM DIE
RETAINING SPRING
PLUNGERS (6)
TOP DIE HOLDER
RETAINING SPRING PLUNGER (6) TOP DIE HOLDER
RETAINING SPRING PLUNGER (6)
48823 PH2
DIE SPACER
ASSEMBLY DETENT SCREWS
TOP DIE
RETAINING SCREW
48825 PH2
DIE HOLDER ASSEMBLIES
BOTTOM DIE
RETAINING SCREW
TOP DIE HOLDER
RETAINING SCREW
BOTTOM DIE HOLDER
RETAINING SPRING PLUNGERS (6)

7
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
Adapter Kits (cont’d)
Procedure for Using Thomas & Betts TBM15 Dies;
48788 Die Holder Kit
1. Install the upper 48789 die holder assembly in hole
in top of “C” head. Snap in place with top die holder
retaining spring plunger (6).
2. Install lower 48789 die holder assembly in hole in
end of piston. Snap in place with bottom die holder
retaining spring plungers (6).
3. Select proper die set for fitting to be crimped.
4. Slide top die into place in die holder while depress-
ing die retainer button. Release die button while it
snaps into place, locking die into position. Repeat
operation for other die entry.
Procedure for Using Burndy Y46 Dies;
48820 Die Holder Kit
1. Install the upper 48822 die holder assembly in hole
in top of “C” head. Snap in place with top die holder
retaining spring plunger (6).
2. Install lower 48821 die holder assembly in hole in
end of piston. Snap in place with bottom die holder
retaining spring plungers (6).
3. Select proper die set for fitting to be crimped.
4. Slide top die into place in die holder while simulta-
neously squeezing both retainer buttons. Release
buttons and allow them to snap into place. Repeat
operation for other die entry.
48788 Die Holder Kit contains:
(2) 48789 Die Holders
48820 Die Holder Kit contains (1) each:
48822 Upper Die Holder and 48821 Lower Die Holder
48789 TBM15 DIE
HOLDER ASSEMBLIES
BOTTOM DIE
HOLDER RETAINING
SPRING PLUNGERS (6)
TOP DIE
HOLDER
RETAINING
SPRING
PLUNGER (6)
BOTTOM DIE
RETAINING MECHANISM
TOP DIE
RETAINING
MECHANISM
48822 Y46 DIE
HOLDER ASSEMBLY
BOTTOM DIE
HOLDER RETAINING
SPRING PLUNGERS (6)
BOTTOM DIE
RETAINING
MECHANISM (2)
TOP DIE
RETAINING
MECHANISM (2)
TOP DIE HOLDER
RETAINING SPRING PLUNGER (6)

8
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
Adapter Kits (cont’d)
Procedure for Using 12-Ton “U” Dies;
48802 Die Holder Kit
1. Install the upper 48803 die holder assembly in hole
in top of “C” head. Snap in place with top die holder
retaining spring plunger (6).
2. Install lower 48803 die holder assembly in hole in
end of piston. Snap in place with bottom die holder
retaining spring plungers (6).
3. Select proper die set for connector to be crimped.
4. Slide die into place in die holder while depress-
ing die retainer button. Release die button while it
snaps into place, locking die into position. Repeat
operation for other die entry.
12-Ton “U” Die Holder Kit 48802 contains:
(2) 48803 Die Holders
TOP DIE HOLDER
RETAINING SPRING
PLUNGER (6)
48803 12-TON “U”
DIE HOLDER ASSEMBLIES BOTTOM DIE HOLDER
RETAINING SPRING
PLUNGERS (6)
DIE RETAINING MECHANISMS
Setup
1. Select the die set that corresponds to the size, type,
and manufacturer of connector to be crimped.
2. Select proper die holders set for type of dies to be
used. Install the die holders and/or dies according
to procedures under “Adapter Kits”.
Kearney PH14 dies—no holders required•
Kearney PH2 dies—48824 Die Holder Kit•
12-ton “U” dies—48802 Die Holder Kit•
T&B TBM 15 dies—48788 Die Holder Kit•
Burndy Y46 type “P” dies—48820 Die Holder Kit•
3. Install proper size crimping dies in crimping head.
Be sure die seat area is clear of debris.
4. Connect the hydraulic hose from the power source
to the tool.
5. In cold weather, allow the power source to run
(idle) for a few minutes to warm the hydraulic fluid.
Actuating the tool intermittently will reduce the time
required to warm the fluid to an efficient operating
temperature.

9
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
Operation
Inspect tool and dies before use. Replace any
worn or damaged parts. A damaged or improp-
erly assembled tool can break and strike nearby
personnel.
Failure to observe this warning could result in severe
injury or death.
Electric shock hazard:
This tool is not insulated. When
using this unit on or near energized
electrical lines, use proper personal
protective equipment.
Failure to observe this warning
could result in severe injury or death.
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection could
result in serious eye injury from
flying debris or hydraulic oil.
Pinch points:
Remove battery before changing•
dies, adapters, or jaws.
Keep hands away from the crimp-•
ing tool head when crimping.
Failure to observe these warnings
could result in severe injury or death.
Do not use this tool for continuous use. After 30 to•
40 cycles, allow the tool to cool for 15 minutes.
Do not secure this tool in a vise. This tool is•
designed for hand-held operation.
This tool may be used in damp or wet environ-•
ments; however, air-drying is recommended before
use if the tool becomes soaked. Damage may
result when the tool is operated prior to thorough
drying when electrical components are soaked.
Use this tool for the manufacturer’s intended•
purpose only.
Failure to observe these precautions may result in
injury or property damage.
Charging the Battery
Read the instructions supplied with the battery charger.
LED Work Light (white)
This LED automatically turns on when the trigger is
pulled. It remains on for 10 seconds after the trigger is
released.
LED Indicator (red)
This tool is equipped with a special circuit board incor-
porating several important features to inform the user
about the current status of the unit. The LED signals in
the following cases:
What happens Signal What it means
Flashing light for 2 seconds Battery is inserted in tool
Constant light for 20 seconds
at end of cycle
Battery charge is below
17 V at beginning of cycle
Tool will not start, and
constant light for 20 seconds
when trigger is released
Battery charge is below
16 V at beginning of cycle
Tool will stop, and constant
light for 20 seconds after
trigger is released
Battery voltage drops
below 13 V during cycle
Tool will stop, and flashing
light for 20 seconds when
trigger is released
Motor current exceeds
20 A during cycle
Circuit has become too hot
Pressure Sensor
This tool is equipped with a pressure sensor that alerts
the user of an incomplete crimp.
If the tool is manually retracted before completion of a•
crimp, the red LED and an audible beep will be active
for 2 seconds.
If the tool is unable to reach the required crimp force,•
the red LED, work light, and an audible beep will pulse
until after the trigger is released.

10
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
Operation (cont’d)
For a cUL or UL classified crimp, see the connector
table in this instruction manual.
Preparation
Note: When using KC12-type dies, complete the
number of crimps listed on the “Connector Selection”
chart in this manual. For other dies, complete the
number of crimps specified by the manufacturer.
1. Select a proper size and type of connector to
correspond with the wire or cable.
2. Strip the cable to an appropriate length. Follow the
connector manufacturer’s instructions.
Note: Apply an oxide inhibitor, if required.
See the connector manufacturer’s instructions.
3. Clean the die seat area.
Crimping
1. Insert the cable fully into the connector.
2. Align the connector between the crimping dies as
shown below.
3. For a UL or cUL classified crimp, complete the
number of crimps specified under “Connector
Selection”.
4. For a single crimp, position the connector so the
crimp will be located at the center of the barrel.
For a double crimp, position the connector so two
crimps will be evenly spaced between the connec-
tor marks.
5. Depress the trigger to advance the piston. Hold the
trigger down until the piston automatically begins to
retract.
Notes: If the crimping tool does not automatically
retract, the crimp is incomplete.
It is normal for the battery load display to light at
both the beginning and near the end of the crimping
cycle.
6. Release the trigger until the piston retracts
completely.
7. To stop the ram from returning fully, activate the
trigger for a brief moment. This activation will close
the retraction valve and stop the retraction motion.
Note: if it is necessary to retract the piston before
a crimp cycle is complete, push the retract button.
Pushing the retract button will result in complete
retraction of the piston.
After completing the last crimp on an aluminum
connector, wipe off the excess oxide inhibitor.
An incomplete crimp can cause a fire.
Use proper die, connector, and cable combina-•
tions. Improper combinations can result in an
incomplete crimp.
The relief valve sounds and the ram automatically•
retracts to indicate a completed crimp. If you do
not hear the sound of the relieve valve or the ram
does not automatically retract, the crimp is not
complete.
Failure to observe these warnings could result in
severe injury or death.

11
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
Connector Selection
Tool Range: 8 AWG to 750 kcmil
When used with KC12-type dies, this tool is cUL and UL classified for use with the following connector brands:
When used with KA12-type dies, this tool is cUL and UL classified for use with the following connector brands:
Short
Long
Short
Long
BARREL
TYPE
8 AWG to
250 kcmil:
1 crimp
300 to
750 kcmil:
2 crimps
NUMBER
OF CRIMPS*
VHSS
VHS
VHCS
VHCL
ANDERSON
CSP
CU
CTL-2/CTL
CTL-L/LCN
BLACKBURN®
YS-L
YS
YA-2LN/
YA-L/YA-2L;
YA/YA-L-TC/
YA-L-2TC
YA/YAZ
YA-2N/YA-2TC
YAZ-2N/YAZ-2TC
BURNDY
CT
CTL
CSW
CRA/CRB
CRC
CLN, CLW
CRA-L/CRB-L
CRA-2/CRB-2L
CRC-2L
ILSCO
SCSS
SCS
SCL
SCH
LCAS
LCA
LCD
LCAN
LCB
LCC
PANDUIT
54504 to
54523-TB
54804 to
54823
54104 to
54123-TB;
54204 to
54223
54930BE to
54923BE;
54850BE to
54880BE
T&B
BCU
BBCU
BLU
BBLU
PENN-
UNION
CONNECTOR
TYPE
Copper
Splices
Copper
Lugs
8 to
1/0 AWG:
1 crimp
2/0 AWG to
350 kcmil:
2 crimps
400 to
750 kcmil:
3 crimps
NUMBER
OF CRIMPS*
ANDERSON
VACS
VACL
BLACKBURN®
ASP
ATL
BURNDY
YS-A
YA-A
YA-ATN
ILSCO
AS
ACL/ACN
2ACL/2ACN
PANDUIT
SA
LAA
LAB
T&B
60501 to
60578
60101 to
60176;
60230 to
60278
PENN-
UNION
PIK
BLUA
CONNECTOR
TYPE
Dual-rated
Aluminum
Splices
Dual-rated
Aluminum
Lugs
* Use the number of
crimps listed in this
column instead of the
number provided with
the connector.
Die Selection
Refer to “Connector Selection” for brand names and model numbers of appropriate lugs as well as crimping instructions.
Crimps made with this tool and KC12-type or KA12-type dies are cUL and UL classified when used with the appropriate conductor
and connectors listed below.
Dies for Copper Connectors
Catalog
No.
UPC
No.
Cable
Size
Color
Code
No. of
Crimps
KC12-8 10996 8 AWG Red 1
KC12-6 10997 6 AWG Blue 1
KC12-4 10998 4 AWG Gray 1
KC12-2 10999 2 AWG Brown 1
KC12-1 11003 1 AWG Green 1
KC12-1/0 11004 1/0 AWG Pink 1
KC12-2/0 11007 2/0 AWG Black 1
KC12-3/0 11010 3/0 AWG Orange 1
KC12-4/0 11011 4/0 AWG Purple 1
KC12-250 11012 250 kcmil Yellow 1
KC12-300 11013 300 kcmil White 2
KC12-350 11014 350 kcmil Red 2
KC12-400 11015 400 kcmil Blue 2
KC12-500 11016 500 kcmil Brown 2
KC12-600 11018 600 kcmil Green 2
KC12-750 11020 750 kcmil Black 2
Dies for Aluminum Connectors
Catalog
No.
UPC
No.
Cable
Size
Color
Code
No. of
Crimps
KA12-8 22084 8 AWG Blue 1
KA12-6 22085 6 AWG Gray 1
KA12-4 22086 4 AWG Green 1
KA12-2 22087 2 AWG Pink 1
KA12-1 22088 1 AWG Gold 1
KA12-1/0 22089 1/0 AWG Tan 1
KA12-2/0 22090 2/0 AWG Olive 2
KA12-3/0 22121 3/0 AWG Ruby 2
KA12-4/0 22122 4/0 AWG White 2
KA12-250 22123 250 kcmil Red 2
KA12-300 22124 300 kcmil Blue 2
KA12-350 22125 350 kcmil Brown 2
KA12-400 22126 400 kcmil Green 3
KA12-500 22127 500 kcmil Pink 3
KA12-600 22128 600 kcmil Black 3
KA12-750 22129 750 kcmil Yellow 3

12
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
Maintenance
Wear eye protection when operating
or servicing this tool.
Failure to wear eye protection could
result in serious eye injury from
flying debris or hydraulic oil.
Skin injection hazard:
Do not use hands to check for oil
leaks. Oil under pressure easily
punctures skin. If injured, seek
medical attention immediately to
remove oil.
Failure to observe this warning
could result in serious injury, gan-
grene, or death.
Do not use solvents or flammable
liquids to clean the tool body.
Solvents or flammable liquids could
ignite and cause serious injury or
property damage.
Pinch points:
Remove battery before changing•
dies, adapters, or jaws.
Keep hands away from the crimp-•
ing tool head when crimping.
Failure to observe these warnings
could result in severe injury or death.
Relief valve adjustments must be done by an
authorized service center.
Daily
Before use:
1. Inspect the tool for wear or damage, such as cracks,
gouges, or chips.
2. Inspect the tool for damage or leaks.
3. Inspect the rotation of the head assembly. Fully
retract the ram. The head should rotate no more
than 360°. If damage is detected, send the tool to a
Klauke Authorized Service Center for inspection.
After use:
1. Use a damp cloth and mild detergent to clean the
housing. Allow the housing to dry.
2. Fully retract the ram. Place the tool in the carrying
case and store in a cool, dry place.
3. If necessary, recharge the batteries. Refer to the
instructions supplied with the battery charger.
Monthly
1. Thoroughly clean all surfaces.
2. Check the oil level.
Annually or After 10,000 Crimps
1. Replace the hydraulic oil.
2. Send the tool to a Klauke Authorized Service Center
for inspection.
Checking the Oil Level
1. Remove the screws holding the housing cover
together.
2. Point the crimping head downward and remove the
oil reservoir plug. Fill reservoir if necessary.
3. Replace the oil plug and housing cover.

13
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
Problem Possible Cause Probable Remedy
Tool is inoperative. Dirt, contaminants, etc., in ram area
of tool.
Clean tool.
Tool battery contacts damaged. Reform contacts.
Tool components worn or damaged. Return tool to a Klauke Authorized
Service Center.
Motor is inoperative. Low or uncharged battery. Try known charged battery. Inoperative
battery may be discharged or may have
reached life expectancy.
Broken switch components. Return tool to a Klauke Authorized
Service Center.
Motor runs but tool will not
complete a cycle.
Oil level low. Return tool to a Klauke Authorized
Service Center.
Air in hydraulic system. Pull trigger and hold retract button
simultaneously. Run for approximately
10 seconds, and then attempt to crimp.
If unsuccessful, return tool to a Klauke
Authorized Service Center.
Cold oil. Pull trigger and hold retract button
simultaneously to warm oil. Store tool
in warm area.
Dies stop during operation. Oil level low. Return tool to a Klauke Authorized
Service Center.
Air in hydraulic system. Pull trigger and hold retract button
simultaneously. Hold for approximately
10 seconds.
LED glows for 20 seconds. Battery charge low. Charge or replace battery.
Tool loses oil. Damaged internal seal. Return tool to a Klauke Authorized
Service Center.
Troubleshooting
Before You Begin
1. Make sure that the battery is charged. Recheck
the battery after several minutes to make sure the
battery is holding its charge.
2. Use a nonflammable contact cleaner or pencil
eraser to clean the electrical contacts on the battery
and tool.
3. Reinstall the battery and check the tool again.

14
Instruction manual
EK 135L
HE.13451_A © 01/2013 R&D-2
Gustav Klauke GmbH • Auf dem Knapp 46 • D-42855 Remscheid
Telefon ++49 [phone] • Telefax ++49 [phone] • www.klauke.com
Handgeführtes Elektrowerkzeug Typ EK 135L
(D) CE-´13 - Konformitätserklärung. Wir erklären in alleiniger Verantwortlich-
keit, daß dieses Produkt mit den folgenden Normen oder normativen Doku-
menten übereinstimmt:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 gemäß den Be-
stimmungen der Richtlinien 2006/42/EG, 2004/108/EG, 2011/65/EU
(GB) CE-´13 - Declaration of conformity. We declare under our sole responsi-
bility that this product is in conformity with the following standards or normative
documents:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 in accordance
with the regulations of directives 2006/42/EG, 2004/108/EG, 2011/65/EU
(F) CE-´13 - Déclaration de conformité. Nous déclarons sous notre seule
reponsabilité que ce produit est en conformité avec les normes ou documents
normatifs suivants:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 conformément
aux réglementations des directives 2006/42/EG, 2004/108/EG, 2011/65/EU
(NL) CE-´13 - Konformiteitsverklaring. Wij verklaren en wij stellen ons er alleen
voor verantwoordelijk dat dit produkt voldoet aan de volgende normen of
normatieve documenten:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 overeenkomstig
de bepalingen van de richtlijnen 2006/42/EG, 2004/108/EG, 2011/65/EU
(I) CE-´13 - Dichiarazione di conformità. Dichiariamo sotto la nostra esclusiva
responsabilità che questo prodotto è conforme alle seguenti norme e docu-
menti normativi:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 conformemente
alle disposizioni delle direttive 2006/42/EG, 2004/108/EG, 2011/65/EU
(E) CE-´13 - Declaración de conformidad. Declaramos bajo nuestra sola
responsabilidad que este producto està en conformidad con las normas o
documentos normativos siguientes:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 de acuerdo con
las regulaciones de las directivas 2006/42/EG, 2004/108/EG, 2011/65/EU
(P) CE-´13 - Declaração de conformidade. Declaramos sob nossa exclusiva
responsabilidade que este producto cumpre as seguintes normas ou docu-
mentos normativos:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 conforme as
disposiçoes das directivas 2006/42/EG, 2004/108/EG, 2011/65/EU
(S) CE-´13 - Konformitetsdeklaration. Vi förklarar pá eget ansvar att denna
produkt õverenstämmer med följande normer eller normativa dokument:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 enligt bestãm-
melserna i direktiverna 2006/42/EG, 2004/108/EG, 2011/65/EU
(FIN) CE-´13 - Todistus slandardinmukaisuudesta. Asiasta vastaavana todist-
amme täten, että tämä tuote on seuraavien standardien ja standardoimisasia-
kirjojen vaatimusten mukainen:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 ja vastaa säädok-
siä 2006/42/EG, 2004/108/EG, 2011/65/EU
(N) CE-´13 - Konformitetserklæring. Vi erklærer på eget ansvarlighet at dette
produkt er i overensstemmelse med følgende standarder eller standard-
dokumenter:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 i henhold til be-
stemmelsene i direktive ne 2006/42/EØF, 2004/108/EØF, 2011/65/EU
(DK) CE-´13 - Konformitetserklæring. Vi erklærer under almindeligt ansvardt
at dette produkt er i overensstemmelse med folgende normer eller normative
dokumenter:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 i henhold til be-
stemmelseme i direktiverne 2006/42/EØF, 2004/108/EØF, 2011/65/EU
(PL) CE-´13 - Zgodnosc z dyrektywami CE. Swiadomi odpowiedzialnosci
oswiadczamy, ze niniejszy produkt jest zgodny z nastepujacymi normami lub
dokumentacja normatywna:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 zgodnie z posta-
nowieniami wytycznych 2006/42/EG, 2004/108/EG, 2011/65/EU
(GR) CE-´13 - ΔΗΛΩΣΗ ΣΥΜΜΟΡΦΩΣΗΣ Μ αναληψη συνολικης δηλωνομ⋅
οτι το πορον προιον συμϕωνι μ τα παρακατω ποοτυπα και μ τα ηροτυηα ηου
αναϕρονται στα σχπκο γγραϕα
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037 συμϕωνα μ τοχς
κονονισμους 2006/42/EG, 2004/108/EG, 2011/65/EU
(H) CE-´13 – Megfelelőségi nyilatkozat. Kéziműködtetésűelektromos kézis-
zerszámok:
Teljes felelősségel kijelentjük, hogy ezek a termékek a következőszabványok-
kal és irányelvekkel összhangban vannak: EN 60745-1, EN 12100 Teil 1 + 2,
EN ISO 13857, EN 349, EN 60204-1, EN 28662-1, EN 61000-6-3, EN 61000-
6-2, EN 60529, EN 1037; és megfelelnek a rendeltetés szerinti 2006/42/EG,
2004/108/EG, 2011/65/EU irányelveknek.
(CZ) CE-´13 – Prohlášeni o shode. Prohlašujeme na vlastni zodpovednost, ze
tyto produkty splnuji následujici normy nebo normativni listiny:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1, EN
28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037;
Ve shode se smernicemi 2006/42/EG, 2004/108/EG, 2011/65/EU
(RO) CE-´13 - Declaraţie de conformitate. Noi declarăm pe propria răspundere
căacest produs este în conformitate cu următoarele norme şi documente
normative:
EN 60745-1, EN 12100 Teil 1 + 2, EN ISO 13857, EN 349, EN 60204-1,
EN 28662-1, EN 61000-6-3, EN 61000-6-2, EN 60529, EN 1037; potrivit
dispoziţiilor directivelor 2006/42/EG, 2004/108/EG, 2011/65/EU
Remscheid, den 18.05.2013
___________________________________________
Dipl.-Ing. Joh.-Christoph Schütz, CE-Beauftragter
