KLAY-INSTRUMENTS 2000 Series User manual

Manufactured by:Nijverheidsweg 5 7991 CZ DWINGELOO
P.O. Box 13 7990 AA DWINGELOO
Tel: [phone] The Netherlands
www.klay-instruments.com Fax: [phone] E-Mail: [email protected]
INSTRUCTION MANUAL
"INTELLIGENT"
PRESSURE- AND LEVEL TRANSMITTERS
SERIES 2000-SAN
SERIES 2000
SERIES CER-2000
SERIES 2000-HYDROBAR
SERIES 2000 SERIES 2000-SAN SERIES CER-2000
WARNING
Read this manual before working with the product. For personal and system safety and for optimum product
performance, make sure you thoroughly understand the contents before installing, using, or maintaining the
Series 2000, Series 2000-SAN, Series CER-2000 and the Series 2000-Hydrobar. Read the precautions and
warnings on the last page.

H/US/2000-HART/05-2021/06 KLAY INSTRUMENTS B.V.
CONTENTS
SECTION PAGE
1 Introduction 3
1.1 Description Series 2000-SAN 3
1.2 Description Series 2000 3
1.3 Description Series CER-2000 3
1.4 Description Series 2000-Hydrobar 3
1.5 Barometric reference 3
2 Dimensions 4
2.1 Dimensions Series 2000-SAN 4
2.2 Dimensions Series 2000 4
2.3 Dimensions Series CER-2000 4
2.4 Dimensions Series 2000-Hydrobar 5
2.5 Dimensions Series 2000-Hydrobar Junction box (G59) 5
3 Installing Transmitter 6
3.1 Installing Weld-on adaptor 6
3.2 Installing Series 2000-SAN 6
3.3 Installing Series 2000 6
3.4 Installing Series CER-2000 7
3.5 Mounting position 7
3.6 Mounting position effect 7
3.7 Installing Series 2000-Hydrobar 7
3.8 Calibration 7
3.9 Wiring 7
4 Remaining 8
4.1 Digital Local indicator 8
4.2 CE / EMC - Rules 8
4.3 External load 8
4.4 Intrinsically safe and Non Sparking (Ex) 9/10
4.5 Functional safety - SIL 10
4.6 Traceability year of manufacturing 10
4.7 Software revision 11
5 Push buttons functions 11
6 Programming points (P101 - P114) 12
7 Reading on display 12
8 Explanation of programming points 13
P101 Zero adjustment (4 mA) 13
P102 Span adjustment (20 mA) 13
P103 Cancel mounting position effect 13
P104 Pressure unit on display 14
P105 Output: 4-20 mA or 20-4 mA 14
P106 Damping adjustment 14
P107 Process Temperature indication 15
P108 Temperature °F or °C 15
P109 Readout on Display 15
P110 Simulation of current (4-20 mA) 15/16
P111 Linearization 16/18
P112 Density 18
P113 Write protection 18/19
P114 Response time from push buttons 19
P115 Service-menu 19
P116 Service-menu 19
9 Programming of the Series 2000 20
9.1 Programming with Hand Held Terminal 20
9.2 Programming with DTM 20
9.3 Programming with PDM 20
10 Specifications 21
11 Precautions and warnings 22
Attachment: EU-Declaration of Conformity 23

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 3
1 INTRODUCTION
The Series 2000 and Series 2000-SAN are solid-state pressure- and level transmitters based upon a bridge
resistive silicon sensor, with a very high burst pressure. The sensor element is mounted in a stainless steel
foot. A very strong stainless steel "flush" diaphragm protects the sensor from the process medium. Special
oil fills the chamber surrounding the sensor and transfers pressure from the flush mounted diaphragm to the
sensor.
Pressure on the sensor element creates a very small deflection of the silicon substrate and bridge network.
The resulting strain in the silicon resistors causes a change in the bridge resistance proportional to the
pressure applied. The transmitter electronics detects this change in bridge resistance and converts it into
4-20 mA. The amplifier system is based on a single Integrated Circuit, which ensures a perfect linearity in the
4-20 mA output. Together with the Klay flush diaphragm technology the long term stability is perfect.
The Series CER-2000 are "All Stainless Steel" pressure transmitters based on a ceramic pressure cell, with
very high burst pressure. These transmitters do not have oil filling.
The Series 2000, 2000-SAN and CER 2000 are available as SIL2, proven in use (Option G200).
1.1 DESCRIPTION SERIES 2000-SAN
The Series 2000-SAN are specially designed with a flush mounted diaphragm so they fully meet the needs
of the food, pharma and chemical industries. The Series 2000-SAN is available as 3-A version (Sanitary
Standard - Option G153) and EHEDG (Sanitary standard –Option G150). Standard the wetted parts are
made of AISI 316, other materials are available, like Hastelloy C. Various process connections can be
delivered, such as Tri-Clamp (1.5”, 2” and 3”), SMS (1.5” and 2”), dairy milk couplings (DN 25, 40 and 50),
flanges (DIN and ANSI) and sanitary weld-on adaptors (ø 1.89, 2.44 and 3.34 inch)
1.2 DESCRIPTION SERIES 2000
The Series 2000 is specially designed for the pulp and paper or similar industries, where clogging is a
problem. The very compact construction of the Series 2000 permits flush installation with the tank or pipe
wall. Standard the wetted parts are made of AISI 316, a lot of other materials are available.
All transmitters are fully temperature compensated, which means that various process temperatures have
nearly no effect on the accuracy of the output signal. When a failure occurs, the transmitter is repairable.
However, for optimum accuracy the transmitter has to be send back to the factory.
1.3 DESCRIPTION PERAMIC "S" (SERIES CER-2000)
The Series CER-2000 is a pressure transmitters based on a ceramic pressure cell, which can be used for
all gauge and absolute pressure measurement on steam, liquids and gases. These transmitters do not
have oil filling.
1.4 DESCRIPTION (SERIES 2000-HYDROBAR)
The Series 2000-Hydrobar is a complete range of submersible level transmitter for top mounting. The 2000-
Hydrobar can be used in fluids like waste water, mud, pulp and chemicals. As standard the cable material is
polyethylene. The connections for the wetted parts from the 2000-Hydrobar to the cable are from Viton® FKM.
1.5 BAROMETRIC REFERENCE
The Series 2000 is in basic a so called Relative Transmitter which means that barometric changes will not
affect the zero (4 mA). The venting (4) is placed in the cover of the housing and is the barometric reference
to atmospheric pressure. The venting must be kept clean.

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 4
2 DIMENSIONAL DRAWINGS
2.1 SERIES 2000-SAN (CODE W) PARTS MATERIAL
1. Cover AISI 304
2. Pushbutton + Display
3. Cover with venting AISI 304
4. Venting PA
5. PG Cable gland
6. O-Ring (2 pcs) EPDM
7. Electronics housing AISI 304
8. Foot AISI 316
9. Lock ring AISI 304
10. Weld-on Adaptor AISI 316 L
11. Packing PTFE
12. Diaphragm AISI 316 L
2.2 SERIES 2000 PARTS MATERIAL
1. Cover AISI 304
2. Pushbuttons + Display
3. Cover met venting AISI 304
4. Venting PA
5. PG Cable gland
6. O-Ring (2 pcs) EPDM
7. Electronics Housing AISI 304
8. Foot with cooling fins AISI 316
9. O-Ring Viton
10. O-Ring Viton
11. M8 bolt AISI 316
12. Diaphragm and ring AISI 316
13. Weldon adaptor AISI 316 L
Ø 1.3 inch
2.3 SERIES 2000 PARTS MATERIAL
1. Cover AISI 304
2. Pushbuttons + Display
3. Cover with venting AISI 304
4. Venting PA
5. PG Cable gland
6. O-Ring (2 pcs) EPDM
7. Electronics Housing AISI 304
8. Foot with cooling fins AISI 316
9. Ceramic sensor Al2O3
10. Process connection AISI 316
½ " NPT
A "Viton" O-Ring is used as standard for sealing the
ceramic sensor. Other O-Ring materials are available on
request. This depends on the process medium.

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 5
2.4 SERIES 2000-HYDROBAR PARTS MATERIAL
1. Cover AISI 304
2. Pushbuttons + Display
3. Cover met Venting AISI 304
4. Venting PA
5. PG Cable gland
6. O-Ring (2 pcs) EPDM
7. Electronics Housing AISI 304
8. Connection to Cable AISI 316
9. Cable with Venting PE
10. Sensor foot AISI 316
11. Diaphragm protection cap PE
12. Diaphragm AISI 316 L
13. Mounting bracket AISI 304
(2 holes Ø 0.26”)
The wetted parts of the 2000-Hydrobar are sealed with an
O-Ring (Viton). Other materials can be applied (on request).
2.5 SERIES 2000-HYDROBAR (JUNCTION BOX - G59)
PARTS MATERIAL
8. Connection to Cable AISI 316
9. Cable with Venting PE
10. Sensor foot AISI 316
11. Diaphragm protection cap PE
12. Diaphragm AISI 316L
13. Junction Box AISI 316L
14. Mounting bracket AISI 304
The wetted parts of the 2000-Hydrobar are sealed with an
O-Ring (Viton). Other materials can be applied (on request).

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 6
3 INSTALLING TRANSMITTER
The diaphragm of the transmitter is protected with a special protection cap. Protect the diaphragm until
installation takes place. DO NOT DAMAGE THE DIAPHRAGM
3.1 INSTALLING WELD-ON ADAPTOR
A certified welder should perform installation of the weld-on adaptor.
Weld with Argon, MIG or TIG. The smallest welding pin should be used.
1. Cut a hole in the process vessel/pipe to accept the weld-on adaptor. The hole should produce a
tight fit when coupled with the weld-on adaptor.
2. Prepare the hole by beveling the edge to accept filler material.
3. Remove the weld-on Adaptor from the transmitter.
4. Remove the PTFE packing of the SERIES 2000-SAN.
5. Remove the gasket and O-Ring out of the weld-on adaptor!
WARNING
Improper installation may result in distortion of the weld-on adaptor.
Excessive heat will distort the weld-on adaptor. Weld in sections as
shown in the figure left. Allow adequate cooling between passes.
To reduce the chances of distortion to the weld-on adaptor,
use a mandrel.
Series 2000-SAN Part.no. 1019
Series 2000 Part.no. 1016
Determine (before welding) the position of the electronic housing, so
that the cable entry and the venting are in the right position. After
welding these positions are fixed.
6. Position the weld-on adaptor in the vessel hole and tack six places.
The weld sequence is shown in the figure above.
7. Weld the weld-on adaptor in place using 0.03 to 0.045 inch. (0.762 to 1.143 mm) stainless rod
as filler material in the beveled area. Adjust amperage for penetration.
8. Remove the mandrel after the welding operation.
3.2 INSTALLING TRANSMITTER SERIES 2000-SAN
1. Make sure to correctly locate the packing within the weld-on adaptor.
2. Improper installation of the packing can cause a process leak.
3. Position the transmitter into the weld-on adaptor and begin engaging threads.
4. The transmitter can be rotated prior to seating enabling the user to optimize access to
calibration adjustments, cable entry, and local indicator.
5. Once the Lock ring (9) has been hand tightened, it must be tightened with an additional turn
with adjustable pliers (± 1/8").
3.3 INSTALLING TRANSMITTER SERIES 2000
1. After welding, clean up edges, and take care of the inside adaptor wall.
2. Make sure the O-Ring (10) and (11) are properly located.
Improper installation at the O-Ring can cause a process leak.
3. Apply silicone grease to the O-Ring (10), diaphragm ring and the hole inside wall of the weld-on
adaptor, this prevents galvanic cell corrosion between transmitter and Adaptor inside.
4. Install the transmitter and fix it with the AISI M8 bolt.

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 7
3.4 INSTALLING TRANSMITTER SERIES CER-2000
The position of the electronic housing is depending on the welding position of the weld-on adaptor. Before
welding, locate the weld-on adaptor so that the cable entry and the venting are in the right direction.
DO NOT DAMAGE THE THREAD.
3.5 MOUNTING POSITION
When the transmitter is mounted horizontally, the cable gland must be pointed downwards.
3.6 MOUNTING POSITION EFFECT (Series 2000 and Series 2000-SAN)
All transmitters are calibrated in vertical position. If the transmitter is mounted in another position, there can
be a little zero shift. (4.02 mA instead of 4.00 mA). If the transmitter is mounted down, there is a zero shift
(For example 3.98 mA instead of 4.00 mA). After installation of the transmitter the zero must be set to 4.00
mA with P103 in the programming mode. This will not affect the span.
3.7 INSTALLING TRANSMITTER SERIES 2000-Hydrobar
The diaphragms are protected by a special protection cap (PE). Do not remove this cap. When clogging is a
problem, please contact Klay Instruments. Do not damage the diaphragm.
3.8 CALIBRATION
All transmitters are fully calibrated at the factory, to customer specified range. If calibration is not specified,
the transmitter will be calibrated at the maximum span.
3.9 WIRING
Under the cover (3) you will find the terminal board.
The push buttons "Zero", "Span" and "Prog" are
under the other cover (1). External loads must be
placed in the negative side of the 2-wire loop.
The figure left shows the wiring connection of the
transmitter. The 2-wires must be connected to 3 (-)
and 4 (+) of the terminal board.
The screw terminal tightening torque range needs to be: minimum 1.0 Nm (8.85 in-lb); max. 1,2 Nm
(10.62 in-lb).
Remove approx. 5 cm (2 in) of the cable mantle, strip approx. 1 cm (0.4 in) of insulation from the ends
of the individual wires. When using stranded cable apply the correct end sleeves for the wires and
make sure these are connected properly underneath the screw terminals.
The field wire conductor cross-section needs to be: minimum 0,2 mm2(24 AWG) and maximum 1,5
mm2(16 AWG). The transmitter must always be connected to
earth. The transmitter must be connected with
standard two-wire shielded cable. Do not run signal
wiring in open trays with power wiring, or near heavy
electrical equipment (Frequency controller or heavy
pumps). Shielding must always be connected at the
side of the power supply. In case the process
connection is already connected to ground (e.g. via
the tank or pipe line) Do not connect the instrument
to ground. Please ensure that the instrument is
not connected to ground twice to prevent an
'earth loop'. In applications with synthetic process
connections, the enclosure (internal or external)
must be connected to ground.
The CER-2000 with a synthetic process connection must be
connected to earth. Reversing the polarity will not damage the
transmitter, but the transmitter will not function
until the + and –are properly connected.

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 8
4. REMAINING
4.1 DIGITAL LOCAL INDICATOR
All transmitters from the Series 2000 are standard equipped with a digital display. As standard transmitters
are delivered with closed covers. The three push buttons and the display are behind the cover (1). As
an option a Transparent cover can be delivered to achieve the display can be used as a local display in the
process. The display can be set to any value between 0000 and 9999 (4 digit). (Option: "I" extra price).
4.2 CE / EMC - RULES
All Klay transmitters are manufactured in accordance with the RFI/EMC directives and comply with the CE
standard. All transmitters are fitted with RFI filters, which provide optimum, trouble-free operation. Our
products are in conformitywith EMC-Directive 2014/30/EU based ontest results using harmonized standards.
4.3 EXTERNAL LOAD
The minimum power supply is based on the total circuit
resistance. The maximum permissible load (Ri max.) in
case of 24 Vdc is 600 Ω (Ohm).
By increasing the power supply, the external load can be
increased to 1200 Ohm / 36 Vdc.
(see figure left).
RI max = Power Supply - 12 Vdc
20 mA
With a loop resistance of 250 Ω a power supply of at least 17 Vdc must be used.
0
200
400
600
800
1000
1200
1400
12 24 36

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 9
4.4 INTRINSICALLY SAFE and NON SPARKING (Ex version)
The Series 2000, Series 2000-SAN, Series CER-2000 and Series 2000-Hydrobar-cable are also available
for intrinsically safe (Zone 0). The Series 2000, Series 2000-SAN, Series 2000-Cable and Series 2000-
SAN-Cable are also available for Non-Sparking (Zone 2).
ATEX –DEKRA 20ATEX0025 X
IECEx –DEK 14.0079X
II 1G Ex ia IIC T4 Ga
Ex ia IIC T4 Ga
II 2D Ex ib IIIC T100°C Db (option G100, extra price)
ATEX –DEKRA 20ATEX0026 X
Ex ib IIIC T100°C Db (option G100, extra price)
Ex ec IIC T4 Gc (option G180, extra price)
II 3G Ex ec IIC T4 Gc (option G180, extra price)
For detailed explanation see “EU-Declaration of conformity”on the last page of this manual.
The transmitters with EPL Gc (option G180) shall only be used in an area of at least pollution degree
2, as defined in IEC 60664-1.
For use in a non-sparking area, the transmitter can be installed without the use of a (intrinsic safe) barrier.
The transmitter can be connected with the following nominal value’s:
UN= 12…26.5 Vdc; IN= 4…20 mA; PN= 0,28 W.
For use in an intrinsically safe area, use a certified power supply from 12 - 26,5 Vdc.
Installation of this device has to be carried out by a certified mechanic / installer.
Transmitter type and options
Equipment category
Ambient temperature range
Pressure / Level Transmitter
Series 2000, Series 2000-SAN, Series 2000-Cable,
Series 2000-SAN-Cable, Series CER-2000,
Series 2000-Hydrobar-Cable and
Series 2000-Hydrobar-EXTD
With transparent indicator cover (Option I)
II 1G
-20 °C to +70 °C
Process temperature range:
-20 °C to +100 °C
Pressure / Level Transmitter
Series 2000, Series 2000-SAN, Series 2000-Cable
and Series 2000-SAN-Cable.
With closed covers, Option G180
ll 3G
-20 °C to +70 °C
Process temperature range:
-20 °C to +100 °C
Pressure / Level Transmitter
Series 2000, Series 2000-SAN, Series 2000-Cable,
Series 2000-SAN-Cable, Series CER-2000,
Series 2000-Hydrobar-Cable, Series 2000-Hydrobar-
EXTD and Temperature Transmitter Type TT-2000
With closed covers, Option G100
II 1G
and
II 2D
-20 °C to +70 °C
Process temperature range:
-20 °C to +100 °C
The maximum surface temperature of lP6x enclosure T100 °C is based on a maximum ambient
temperature of 70 °C and maximum process temperature of 100 °C. This temperature is
determined with a dust layer of maximum 5 mm.
Electrical Data
Pressure / Level Transmitter Series 2000, Series 2000-SAN, Series 2000-Cable,
Series 2000-SAN-Cable, Series CER-2000, Series 2000-Hydrobar-Cable,
Series 2000-Hydrobar-EXTD and Temperature Transmitter Type TT-2000:
Supply/output circuit (terminals 3 ‘-’ and 4 ‘+’): in type of protection intrinsic safety Ex ia IIC, or Ex ia lllC only
for connection to a certified intrinsically safe circuit, with the following maximum values: Ui= 26,5 Vdc; Ii=
110 mA; Pi= 0,9 W (linear source); Li= 1,4 mH; Ci= 63 nF (without cable between terminals 3 ‘-’ and 4 ‘+’).

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 10
Cable length
The maximum length of the cable for the Series 2000-Cable, 2000-SAN-Cable and 2000-Hydrobar-Cable is
100 m. Electrostatic charging of the cable and the protection cap by the flow of non-conductive media (for
example in stirring vessels or pipes) shall be avoided.
Special conditions for Safe use in Zone 0 and Zone 1
As category 1G equipment may be applied directly in the process, electrostatic discharge from the cable and
the protection cap of Pressure / Level Transmitter Series 2000-Hydrobar-Cable by the flow of non-conductive
media (for example in stirring vessels or pipes) should be avoided.
Special Instructions for Safe use in Zone 2
For use in non-sparking areas (Zone 2), the following should be taken into consideration:
As standard the transmitter is supplied without a certified cable gland. The cable entry is fitted with
a PE blanking plug for protection during transport. Remove the blanking plug after installing the
transmitter. When using a gland make sure it is certified and complying with applicable protection
level of the transmitter.
Always use the covers supplied by Klay Instruments B.V.
All transmitters from Klay Instrument are designed to last for at least 10 years under normal
process and environmental conditions. The gaskets and seals for the Series 2000 are successfully
tested according to IEC 60079-0 for temperature endurance (heat and cold), resistance to impact
and ingress protection by DEKRA Certification. In harsh process and environmental conditions, the
lifetime of gaskets and seals may be reduced. Klay Instruments strongly advises to inspect these
yearly and replace them when necessary.
For use in a potentially explosive atmosphere caused by air/dust mixtures the following should be taken
into consideration:
The dust layer may not exceed a thickness of 5 mm.
as standard a transmitter is supplied with a certified cable gland (PG). When using a different gland
make sure it is certified and complying with applicable protection level of the transmitter.
Always use the covers supplied by Klay Instruments B.V.
All certifications are in compliance with IECEx scheme rules, and the International Standards:
EN IEC 60079-0:2012, EN 60079-11:2012, IEC 60079-7:2015/ A1:2017, IEC 60079-11:2011 and
IEC 17050-1:2010. The transmitters are certified for use in hazardous areas by DEKRA Certification.
DO NOT REMOVE THE SCREW COVER(S) WHEN AN EXPLOSIVE ATMOSPHERE MAY BE PRESENT.
4.5 FUNCTIONAL SAFETY - SIL
The device is certified as “Proven in use” for a functional safety environment of SIL2 according
to IEC-61511 and SIL1 according to IEC-61508.
Note: Option SIL (Proven in use) is valid on transmitters with a serial number > 4309036, and only applicable with
software version V9.17.
When ordered as a SIL (Proven in use) transmitter, the safety manual will be supplied. (Option G200).
Detailed information can be found in the Safety manual of the instrument. The most recent version of the
Safety manual is available on: www.klay-instruments.com under section Downloads.
4.6 TRACEBILITY YEAR OF MANUFACTURING
The year of manufacturing of the transmitter can be traced as follows: take the first two numbers from the
serial number that is engraved in the transmitter and add 1970 to it.
For example: if the serial number is 4309036. The year of manufacturing is 1970 + 43 = 2013.

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 11
4.7 SOFTWARE REVISIONS
Due to the improvements on the Series 2000, there are several software versions (revisions).
For this reason it is possible the transmitter you are working with does not support some options,
which are discussed in this manual. This instruction is applicable from software version V9.17 and higher.
After powering up, the transmitter will show the software version on the display.
5 PUSH BUTTONS FUNCTIONS
The Series 2000 can be programmed easily by use of the 3 front
panel pushbuttons. The display can show engineering units of:
mH2O, inH2O, bar and PSI.
The functions of the three pushbuttons will be explained below.
This button has 2 functions:
It can be directly used for adjusting the zero (4 mA), with or without a test pressure.When
the zero (4 mA) must be adjusted at 0 (atmospheric pressure), the button must be held
until the word "Zero" appears on the display. The transmitter is now set to 4 mA.
This button must be used for stepping down in the menu or to decrease a value (-).
For canceling the mounting position effect you have to use P103.
This button has 2 functions:
It can be directly used for adjusting the span (20 mA), when using a test pressure (air).
When a test pressure (e.g. 2 bar) is supplied to the transmitter, the button must be held
until the word "SPAN" appears on the display. The transmitter is adjusted at 20 mA now.
The span can also be adjusted without test pressure (see P102).
This button must be used for stepping up in the menu or to increase a value (+).
This button has 2 functions:
It is used to adjust the Programming Points (P101 till P114). Push it once and P100 is
displayed, use the [] (SPAN) to step to P101.
This button must also be used for confirming the adjustments (enter).
For example, if you want to change the adjustment in psi (P104),
the following steps must be taken:
1. Push on [PROG] till "100" appears on the display.
2. Push on [SPAN] 4 times to go to point "P104" (adjustment pressure unit).
3. Push [PROG] to confirm this.
4. Push several times on [] (SPAN) to reach 3 (= bar). (Conversion table page 11).
5. 1 = mWC, 3 = bar, 5 = PSI, 11 = inch WC
6. Confirm this by pushing once at [PROG].
7. The transmitter is now adjusted to read in psi.

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 12
6. PROGRAMMING POINTS (P101 –P114)
The following points can be adjusted with the three
push buttons. For an explanation of these points see
the following pages of this manual.
To change one of these points you have to push on
[PROG] until "100" appears on the display.
To go from a lower program (P101) to a higher one
(P102), push on button [] (SPAN). To confirm the
adjustments, you always have to press on [PROG].
*) Standard adjustments ex works.
Programming points
P101
Zero adjustment (4 mA)
P102
Span adjustment (20 mA)
P103
Cancel mounting position effect
P104
Adjustment pressure unit
(See Conversion table)
P105
4-20 mA *)
20-4 mA (Reverse output)
P106
Adjustment damping (0 to 25 sec)
P107
Indication of process temp. (Read out on
display)
P108
0 = °C (*)
1 = °F
P109
Read out on display:
Curr (0) = Current (4 - 20 mA) (*)
Unit (1) = Pressure unit (conversion table)
PerC (2) = Percentage
TenP (3) = Temperature
Hect (4) = Hectoliters
CBn (5) = Cubic meters
Ltr (6) = Liters
P110
Simulation of current
P111
Linearization
0 = No Linearization (*)
1 = Cylindrical tank
2 = Vertical tank with cone
3 = Vertical tank with spherical cone
P112
Density
P113
Write Protection
P114
Response time from push buttons
7. READING ON THE DISPLAY
On the standard built-in display several values can be
shown. When the transmitter is in the process the display
gives all the information of the process pressure or
temperature. On the display the following units are available:
mH2O, inH2O, bar and PSI (see P104 and P109).
The standard transmitter is supplied with two "closed" covers protecting the buttons and the display. As an option an "open" cover
(IP 66) can be fitted. The display can then be used as a local process display. (Option: "I" extra price). The full scale can be set
between -9999 and 9999 (4 digit).

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 13
8. EXPLANATION PROGRAMMING POINTS P101 to P114
ZERO ADJUSTMENT (4 mA)
The transmitter as standard is adjusted to 4.00 mA at atmospheric pressure.
It is also possible to adjust a zero-suppression or elevation.
For example: Zero elevation of 1.45 psi.
1. Push at [PROG] until "100" is shown on the display.
2. Push once at [] / SPAN till "101".
3. Confirm this by pushing [PROG].
4. Now the display will show 0.00 mH2O. Push at [] till 1.45 psi is on the display.
5. Confirm with [PROG].
6. The output of the transmitter will be lower than 4 mA. The output at atmospheric
pressure will be for example 3.68 mA. When a pressure of 1.45 psi is applied on the
diaphragm the output will be 4.00 mA.
The elevation can be canceled by pushing at [] till zero disappears out of the display. The transmitter is
now adjusted at 4 mA at atmospheric pressure.
SPAN ADJUSTMENT (20 mA) WITHOUT TEST PRESSURE
Before adjusting the span take care the right pressure unit is selected.
(See also P104 and P109).
Example: Adjustment of the span at 0 - 29 psi.
First off all, the pressure unit must be adjusted at psi. (See P104).
1. Push [PROG] till "100" is shown on the display.
2. Push twice at [] / SPAN until "102" appears on the display.
3. Confirm this by pushing [PROG].
4. Push [SPAN] (+) or [ZERO] (-) to select the measuring range that is required.
5. Confirm by pushing [PROG].
The transmitter is adjusted now.
P102 is the adjustment of the total span.
When a compound range must be adjusted (for example -14.5 till +43.5 psi), a span of 58 psi must be programmed.
The Zero (P101) must be set at -14.5 psi. The transmitter is adjusted at - 14.5 psi = Zero and +43.5 psi = Span.
If the process temperature at -14.5 psi is above 20 °C, another filling oil must be applied inside the transmitter (Option G26).
If the process temperature at -7.25 psi is above 60 °C, another filling oil must be applied inside the transmitter (Option G26).
CANCEL MOUNTING POSITION EFFECT
All transmitters are calibrated vertically. When a transmitter of the Series 2000 or 2000-SAN is
installed horizontally, there will be a small "mounting effect" on the zero (4 mA). For example, the
transmitter shows 4.03 mA instead of 4.00 mA. This can be easily canceled with P103. In P103
there are three options:
ESC Nothing will be changed. Leave without doing anything. (confirm with PROG).
RESET Use this option when you are not sure if P103/SET has been done in a proper
way. (confirm with PROG). When using this option, the original factory setting
will be valid.
SET Canceling mounting position effect. (confirm with PROG). When SET selected
the transmitter is automatically adjusted at 4.00 mA. Span will not be affected.
Do not apply pressure while executing "cancel mounting position effect"
P101
P102
i
P103

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 14
ADJUSTMENT PRESSURE UNIT ON DISPLAY (See Conversion table)
Several engineering units can be shown on the display by using a conversion factor.
(See conversion table below). As standard the pressure unit of the transmitter is set to bar. Four
engineering units can be used for displaying the applied pressure on the display (mH2O,
inH2O, bar and PSI).
1. Press [PROG] until "100" appears on the display.
2. Push 4x []to get to point P104 (pressure unit setting).
3. Now press [PROG] to confirm this.
4. Now press []or []and set it to the correct pressure unit. See also the
conversion table below. The number in brackets, see Display column,
represents the menu options of transmitters with other software. Example:
3 = bar
5. Then press [PROG] again to confirm. The transmitter is now set to read in
"bar".
Conversion table:
DISPLAY:
CONVERSIE FACTOR:
mH2O (mWK) * (1)
1.000
mmH2O (mm WK) (2)
1000
bar * (3)
0.09806
Mbar (4)
98.0665
PSI * (5)
1.4223
Atm (6)
0.0967
KPa (7)
9.80665
MPa (8)
0.009807
Kgf/cm2 (9)
0.1
mm HG (10)
73.556
inH20 ("WK) * (11)
39.37
"HG (12)
2.895906
To show one of the engineering units, P109 must be adjusted at 1 (= Pressure unit).
*) Pressure units that can be shown on the display. When the value of the highest range is larger
than 9999, "NA" will appear in the display (Not Applicable). Another unit must be chosen.
REVERSE OUTPUT (20 - 4 mA)
The transmitter as standard is adjusted to 4-20 mA output.
Push on [PROG] and go to P105.
Push once at [] to change the output to 20-4 mA (Reverse output).
Push at [PROG] to confirm this.
Now the transmitter will give 20 mA at atmospheric pressure.
ADJUSTMENT DAMPING (0 … 25 sec)
In P106 an electronic damping can be adjusted between 0 and 25 seconds.
This can be done with the push buttons [] (up) and [] (down).
Always confirm by pushing once at [PROG].
INDICATION OF PROCESS TEMPERATURE (READ OUT ON DISPLAY)
1. Push [PROG] until "100" is shown on the display.
2. Push 7 times at [], go to [P107].
P104
P105
P106
P107

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 15
3. Push [PROG] to confirm this. Now the process temperature appears on the display
(Indication: +/-2C).
This will remain on the display. To get the actual pressure back on the display you have to
push again on P107 until the actual pressure appears on the display again.
TEMPERATURE IN °F OR °C
The temperature of the transmitter is standard adjusted at °F (FAHR). When pushing at [] in
P108, this will change into °C (CELC). Always confirm by pushing once at [PROG].
READ OUT ON DISPLAY
Curr (0) = current (4 - 20 mA)
Unit (1) = pressure unit (See conversion table)
PErC (2) = percentages (0 - 100%)
TEnP (3) = temperature (°F of °C) Indication of process temperature, accuracy depending on sensor position.
hECt (4) = hectoliter (only in combination with P111)
Cb n (5) = Cubic meter (only in combination with P111)
Ltr (6) = Liters (only in combination with P111)
As standard the transmitter read out is in mA (0).To change this, follow the next steps:
1. Push [PROG] until "100" is shown on the display.
2. Push 9 times at [] / SPAN till "109" appears on the display.
3. Confirm with [PROG].
4. Push once at [].
5. Push [PROG] to confirm this.
The transmitter will now read mH2O (mWC).
The pressure unit can be changed with the conversion table in P104.
1 = mH2O (=mWC), 3 = bar, 5 = psi, 11 = inchH2O (inchWC).
The read out can also be in 0 - 100%. Select P109, option PErC (2).
SIMULATION OF CURRENT (4-20 mA)
The transmitter can be used as a simulator of a current between 4 - 20 mA.
This can be done in P110 with the push buttons [] and [].
The user can perform a current simulation (Curr) or a pressure simulation (Unit).
Current-simulation (Curr)
To perform a current-simulation follow the next steps:
1. Push [PROG] until "100" is shown on the display.
2. Push 10 times at [] / SPAN till "110" appears on the display.
3. Confirm with [PROG].
4. The display will readout 'Curr'
5. Confirm with [PROG].
6. The display shows '4.00'. Push [PROG] and the output changes to 4.00 mA.
7. By pushing [] / SPAN or [] / ZERO, you can change the value on the display. The
output value will change as soon as the [] / SPAN OR [] / ZERO button is released.
8. Pressing the [PROG]-button again will exit the simulation.
Pressure-simulation (Unit)
To perform a pressure-simulation follow the next steps:
1. Push [PROG] until "100" is shown on the display.
P108
P109
P110

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 16
2. Push 10 times at [] / SPAN till "110" appears on the display.
3. Confirm with [PROG].
4. The display will readout 'Curr'
5. Press [] / SPAN once
6. The display will readout 'Unit'.
7. Confirm with [PROG].
8. The display shows a pressure value. Push [PROG] and the output changes to a mA-
output corresponding with the range entered in menu P101 and P102.
9. By pushing [] / SPAN or [] / ZERO, you can change the value on the display. The
output value will change as soon as the [] / SPAN OR [] / ZERO button is released.
10. Pressing the [PROG] button again will exit the simulation.
The values that can be entered using the pressure-simulation are related to the adjustments in
menu P101 and P102. These values are also the minimum and maximum values.
HART: This menu will not work when the device is operating in multi-drop mode.
LINEARIZATION
nLin (0) = No Linearization
hCil (1) = Cylindrical tank (horizontal)
ConU (2) = Tank with bottom cone
SPHE (3) = Tank with spherical bottom
Not possible in combination with Ex, G100, G180, G104 and G200.
As standard the transmitter is delivered without Linearization nLin (= 0). However, for a
horizontal tank or a tank with a bottom cone, a linearization can be applied to achieve the
current signal (mA) is equal to the level in the tank. All values must be programmed in meters.
Linearization horizontal tank (Cylindrical)
1. Push [PROG] until "100" is shown on the display.
2. Push 11 x at [] / SPAN till "111" appears. (Confirm with [PROG])
3. Push [] once. (Confirm with [PROG])
4. Enter the height (H1) of the tank in meters. (Confirm with [PROG])
5. Enter the same height (H2) of the tank in meters. (Confirm with [PROG])
6. Enter the length (L) of the tank. For a "ball" or cone shaped tank, take the cylindrical
length plus the length of 1 "ball" cone. (Confirm with [PROG])
7. Enter H3 in meters if the transmitter is installed like in the left picture. Enter 0m when the
transmitter is installed like in the right picture.
8. Enter the percentage of the actual "full" level (for example 80%).
(Confirm with [PROG]).
P111
Cylindrical horizontal tank Cylindrical tank with cone-shaped ends

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 17
Linearization horizontal tank (Elliptic)
1. Push [PROG] until "100" is shown on the display.
2. Push 11 x at [] / SPAN till "111" appears. (Confirm with [PROG])
3. Push [] once. (Confirm with [PROG])
4. Enter the height (H1) of the tank in meters. (Confirm with [PROG])
5. Enter the height (H2) of the tank in meters. (Confirm with [PROG])
6. Enter the length (L) of the tank. For a "ball" or cone shaped tank, take the cylindrical
length plus the length of 1 "ball" cone. (Confirm with [PROG])
7. Enter H3 in meters if the transmitter is installed like in the left picture. Enter 0m when the
transmitter is installed like the right picture.
8. Enter the percentage of the actual "full" level (for example 80%).
(Confirm with [PROG]).
If the height (H) of the tank is 1 meter and the maximum level in the tank is 0.8 meter the percentage (point 8)
must be set at 80%.The calibration at P102 must be adjusted at: 1 meter (if specific gravity equals 1).
Linearization vertical tank with cone
1. Push [PROG] till "100" appears on the display.
2. Push 11 times at [] till "111" appears.
3. (Confirm with [PROG])
4. Push twice at []. (Confirm with [PROG])
5. Enter height (H1) of the tank (= actual level).
(Confirm with [PROG]).
6. Enter diameter (D) of tank. (Confirm with [PROG])
7. Enter height (H2) of cone. (Confirm with [PROG])
8. Enter the height (H3) from the bottom of the tank to
the topside of the diaphragm (or weld-on adaptor).
(Confirm with [PROG]).
9. Enter the percentage of the actual "full" level (for
example 80%).(Confirm with [PROG]).
Cylindrical horizontal tank Cylindrical tank with cone-shaped ends

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 18
Linearization vertical tank with spherical cone
1. Push [PROG] till "100" appears on the display.
2. Push 11 times at [] till "111" appears.
3. (Confirm with [PROG])
4. Push three times at []. (Confirm with [PROG])
5. Enter height (H1) of the tank (= actual level).
(Confirm with [PROG]).
6. Enter diameter (D) of tank. (Confirm with [PROG])
7. Enter height (H2) of cone. (Confirm with [PROG])
8. Enter the height (H3) from the bottom of the tank
to the topside of the diaphragm (or weld-on
adaptor) (Confirm with [PROG]).
9. Enter the percentage of the actual "full" level (for
example 80%).(Confirm with [PROG]).
When the specific gravity of the fluid is unequal to 1 and you do not want to use option P112, you must take care of
defining of the calibration of the transmitter. Calibration (see P102) = Height of the level x Specific Gravity.
DENSITY MEDIUM
If the specific gravity of the medium differs from 1 kg/dm3, you can enter the real density of the medium in
option P112. Before this option is used, in menu P102 the 'true' height of the tank must be entered first.
WRITE PROTECTION
The Series 2000 with HART-Protocol can be protected for adjustment (Write Protection). This is
possible for two kinds of adjustments:
Local changes with pushbuttons and display (L.Pro = Local Protection).
Changes by external HART configuration software (Handheld terminal or PC).
(C.Pro. = Communication Protection).
As standard, the transmitter is set to no-write protection.
Adjustment Local Protection
1. Push [PROG] till "100" appears on the display.
2. Push [] / SPAN 13 times till "113" appears on the display.
3. Push [PROG] to confirm. ("L.Pro." appears on the display).
4. Push []/[] for adjusting to "ON" or "OFF".
5. Push [PROG] to confirm.
Adjustment Communication Protection
1. Push [PROG] till "100" appears on the display.
2. Push [] / SPAN 13 times till "113" appears on the display.
3. Push [PROG] to confirm. ("Lo.Pr." appears on the display).
4. Push once more at [PROG]. ("Co.Pr." appears on the display).
5. Push []/[] for adjusting to "ON" or "OFF".
6. Push [PROG] to confirm.
When Lo.Pr. is set to ON, the display shows PROT for program point: 104, 105, 107, 108, 109 and 111. Both
protections can be adjusted at the same time, independent from each other.
P112
P113

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 19
RESPONSE TIME FROM PUSH BUTTONS
The response time from the push buttons can be adjusted from 0.0 till 5.0 seconds. The
reaction time is set to 0.5 seconds from the factory.
PROGRAMMAPUNT P115 & P116: SERVICE MENU
Please consult manufacturer before using.
9. PROGRAMMING THE SERIES 2000
When using HART®or a Hand Held Terminal (HHT), a minimum resistance of 250 ohms must be
present in the loop of the 2-wire system. This is necessary for proper communication (see drawing
below). A power supply of at least 17 Vdc must be used.
9.1 PROGRAMMING WITH THE HAND HELD TERMINAL
The Series 2000 can be easily programmed with the Hand Held Terminal (HHT) from the "HART
Foundation" or the HHT from "Rosemount" (type 275 or 375 Hart Communicator).
Option 1: HART ®Handheld terminal connected across the transmitter.
Option 2: HART ®Handheld terminal connected across the loop resistor.
9.2 PROGRAMMING WITH DTM
An instruction manual is available which is a guide for installing and using the Klay Series 2000 HART DTM.
This DTM is developed to make configuration changes of Klay Series 2000 HART transmitters easy. This
DTM can be used with almost every FDT-container. The most recent version of the DTM file (zip file) is
available on: www.klay-instruments.com under section “Downloads”.
Unzip the file and run the installation.
17 –36 Vdc
Power
Supply
+
-
250 Ω
ΩΩΩ
Ω
17 –36 Vdc
Power
Supply
+
-
HHT
HHT
250 Ω
ΩΩΩ
Ω
P114

Instruction Manual Series 2000 HART Klay Instruments
H/US/2000-HART/05-2021/07
Page 20
9.3 PROGRAMMING WITH PDM
There is also a Device Description (DD) available for the Series 2000 HART. This DD can be used for
configuring a Series 2000 HART transmitter using Simatic PDM. The most recent version of the DD file
(zip file) is available on: www.klay-instruments.com under section “Downloads”. Unzip
KLAY_PDM_HART_REV8.zip and run DeviceInstall.exe.
10. SPECIFICATIONS
Manufacturer
Klay Instruments
Instrument
Series 2000, Series 2000-SAN,
Series CER-2000 and 2000-Hydrobar
Output
4-20 mA
Optional: HART®Protocol
Power Supply
Standard :12 –36 Vdc
Ex : 12 –26.5 Vdc
HART®:17 –36 Vdc (Standard) min. 250 Ω
17 –26.5 Vdc (Ex) min. 250 Ω
Accuracy
0.1% of adjusted span
Ranges 1
Code
Adjustable span ranges
Max.
overpressure
Series 2000
1
0 - 1.45psi
0 - 5.8 psi
93 psi
2
0 - 4.35 psi
0 - 17.4 psi
150 psi
3
0 - 14.5 psi
0 - 145 psi
435 psi
4
0 - 72.5 psi
0 - 435 psi
1450 psi
5
0 - 290 psi
0 - 1450 psi
2900 psi
Series 2000 (SAN)/2000-Hydrobar
1
0 - 0.58psi
0 - 5.8 psi
93 psi
2
0 - 1.74 psi
0 - 17.4 psi
150 psi
3
0 - 14.5 psi
0 - 145 psi
435 psi
4
0 - 72.5 psi
0 - 435 psi
1450 psi
5
0 - 290 psi
0 - 1450 psi
2900 psi
1
0 - 2.9 psi
0 - 5.8 psi
93 psi
2
0 - 11.6 psi
0 - 17.4 psi
150 psi
Series CER 2000
3
0 - 29 psi
0 - 145 psi
435 psi
4
0 - 145 psi
0 - 435 psi
1450 psi
5
0 - 580 psi
0 - 1450 psi
2900 psi
6
0 - 2175 psi
0 - 5800 psi
8700 psi
Series 2000
2
High pressure
(Option G83)
˃ 8700 psi
Process Temperature 3
Series 2000
-4 F to 176 F
Series 2000 (SAN)
-4 F to 212 F
Series CER-2000
-4 F to 212 F (only gases)
Series 2000-Hydrobar
+10 F to 160 F
Ambient Temperature
-4 °F to 158 °F
Damping
0.0 sec. till 25 sec.
Standard damping: 0.0 sec.
Protection grade
IP66
IP68 (2000-Hydrobar-Cable ‘submersed parts’)
Material
Housing
AISI 304 (Optional AISI 316)
wetted parts
AISI 316 L (Other materials on request)
1
For vacuum applications/compound ranges in combination with higher process temperatures a special oil filling must be applied (Option G26).
2
For pressures higher than order code 6, Contact Klay Instruments for information.
3
For higher temperatures use other kind of pressure transmitters. Contact Klay Instruments for information.
