Knight Anvil Double Sided Desk User manual

knightgroup.co.nz
Tools Required: Powered Screwdriver
Assembly Instructions
Anvil Double Sided Desk

Page 1
Assembly Instructions
knightgroup.co.nz
Anvil Double Sided Desk
• To prevent possible scratches or damage, assemble
the desk upside down on a soft surface such as a
blanket, carpet or packaging.
• Attach legs to the top assembly by using bolts, spring
washer, flat washer. Tighten using the allen wrench.
Recommended
2-person Step

Page 2
Assembly Instructions
knightgroup.co.nz
Step 1
Step 3
Step 2
Step 4
Page 2
Assembly Instructions
Fix desk top with 5mm overhang over metal frame.
Where desk top butts together, make sure these are
fitted tight.
Slide centre screen pole over bracket. Carefully
remove end seal on centre screens & fit screen
between end brackets & screw self tappers to fix
screen tightly.
Assemble frames & rails together, loosely
(1 turn from tight).
Assemble screen brackets to frame, loosely (1 turn
from tight).
Anvil Double Sided Desk
Desk Top
Desk
Side Rail
Screw
5mm

Page 3
Assembly Instructions
knightgroup.co.nz
Page 3
Assembly Instructions
Step 5
Step 7
Step 6
Step 8
Attach centre screen end seal and top cap with soft
non-marking mallet.
Mark out end of return screens on desk.
Attach screens to centre pole with top slug
connectors.
Remove return screen and fix bracket in place. As an
alternative to screws, use 3M double sided tape to
fasten return screen bracket to desk top.
Anvil Double Sided Desk
Place light mark
on desktop.

Page 4
Assembly Instructions
knightgroup.co.nz
Page 4
Assembly Instructions
Step 9
Step 11
Step 10
Step 12
Remove return screen end seal, and attach screen to
bracket with self tapper screws.
Install all top caps simultaneously down all together
gently tapping with a soft non-marking mallet.
Attach return screen end seal and top cap with soft
non-marking mallet.
If for whatever reason you have to remove the top
seal, then to refit, slightly arc in the middle, placing
the 2 ends into location, & gently tap down.
Anvil Double Sided Desk

Page 5
Assembly Instructions
knightgroup.co.nz
Page 5
Assembly Instructions
Step 13
Step 15
Step 14
Completed
Fit power/data rails with screws into frame rail.
Attach cable trays with screws provided.
Fully tighten all rails to frame screws, & then screen
bracket screws.
Anvil Double Sided Desk
