KODAK Multiloader
SERVICE BULLETIN NO. 240 MAY 1996
3053 KODAK MULTILOADER 700 / MULTILOADER 700 Plus
Adjusting the CASSETTE OPENER
This procedure is a replacement for the procedure in the Service Manual for the Kodak MULTILOADER 700,
Publication No. SM3053.
Important
Check that the OPENER SHOVEL is the correct length. If the OPENER SHOVEL was replaced or the length was
changed, do “LENGTH ADJUSTMENT”, adjustment 3.18.1, in SM3053, 4/1990.

-2-
Figure 1
[1] Manually insert a CASSETTE and place in the centered position. Check that the CASSETTE is tight against
the STOP at the CASSETTE END SWITCH.
[2] Rotate the CASSETTE OPENER BRACKET fully up to the position in the illustration.
[3] Check that the 2 EXIT DOOR BRACKET CAMS are parallel and in the same position as shown in Figure 1on
the EXIT DOOR BRACKET.
H070_0150DC
CASSETTE
STOP
CASSETTE
END SWITCH
CASSETTE
ROLLERS
PRESSURE
BOLTS
CASSETTE
OPENER
BRACKET
2 EXIT DOOR
BRACKET CAMS
H070_0150DCA

-3-
Figure 2
Caution
The WASHERS prevent the PRESSURE BOLTS from pressing excessively on the CASSETTE and causing the
MOTOR to stall.
[4] Manually move the CASSETTE OPENER BRACKET down and toward the PROCESSOR until you see the
E-RING lift from each WASHER.
Note
If the CASSETTE lifts from the BELT, adjust the CASSETTE SUPPORT. See the SERVICE MANUAL.
H070_0151DC
E-RING
H070_0151DCA
SHAFT
SWITCHING
BELT
BOLTS
PRESSURE
CASSETTE
ROLLERS
WASHERS

-4-
Figure 3 [5] Move the CASSETTE OPENER BRACKET to
the horizontal position.
Important
For Step 6 to Step 11, see Figure 4.
[6] Now move the CASSETTE OPENER BRACKET down until
• the PRESSURE BOLTS press onto the CASSETTE LID
• the pressure on the PRESSURE BOLTS is released
• the PRESSURE BOLTS touch the CASSETTE LID again without pressure
[7] Check that the CASSETTE rests tightly at the STOP and the PRESSURE BOLTS rest on the CASSETTE LID.
[8] Use a 2mm Allen WRENCH to check the clearance between the edge of the OPENER SHOVEL and the
CASSETTE LATCH.
[9] If the clearance is not correct, loosen the 2 SCREWS of the CASSETTE OPENER BRACKET and move the
OPENER SHOVEL to a distance of 2 mm (0.08 in.) from the CASSETTE LATCH.
[10] Tighten the 2 SCREWS of the CASSETTE OPENER BRACKET.
[11] Check the clearance again.
H070_0152AC
H070_0152ACA
BRACKET
OPENER
CASSETTE

-5-
Figure 4
2 mm (0.08 in.)
H070_0153EC
STOP
LID
CASSETTE
LATCH
CASSETTE
BOLT
PRESSURE
SHOVEL
OPENER
BRACKET
OPENER
CASSETTE
2 SCREWS
H070_0153ECA

-6-
Figure 5
[12] Move the CASSETTE OPENER BRACKET up fully and toward the front of the MULTILOADER.
[13] Remove the CASSETTE.
[14] Check the alignment of the edges of the ENTRANCE DOOR CAM and the BALL BEARING. If necessary:
• Loosen the 2 SETSCREWS.
• Adjust the 2 ENTRANCE DOOR CAMS.
• Tighten the 2 SETSCREWS.
• Check again.
H070_0154DC
ENTRANCE DOOR CAM
ENTRANCE DOOR CAM
BALL BEARING
2 SETSCREWS
H070_0154DCA
