Kodak DirectView CR 825 Guide

© EASTMAN KODAK COMPANY, 2005 HEALTH GROUP
Confidential
Restricted
Information
{Adjust/Replace}{Production}{Health Group}{ExternalAndInternal} Publication No. AR4825-1
10DEC05
Supersedes AR4825-1
21JUL04
ADJUSTMENTS AND REPLACEMENTS
for the
Kodak DirectView CR 825/850 SYSTEMS
Service Codes: 5634, 4825
Important
Qualified service personnel must do these procedures.
H177_0500AC

ADJUSTMENTS AND REPLACEMENTS
10DEC05
AR4825-1
Page
2 of 160
PLEASE NOTE The information contained herein is based on the experience and knowledge relating to the
subject matter gained by Eastman Kodak Company prior to publication.
No patent license is granted by this information.
Eastman Kodak Company reserves the right to change this information without notice, and
makes no warranty, express or implied, with respect to this information. Kodak shall not be
liable for any loss or damage, including consequential or special damages, resulting from any
use of this information, even if loss or damage is caused by Kodak’s negligence or other fault.
This equipment includes parts and assemblies sensitive to damage from electrostatic
discharge. Use caution to prevent damage during all service procedures.
Description Page
Table of Contents
Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
INTERLOCK SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
TOP COVER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
GALVO BOARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
GALVO ROTATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
FOLD MIRROR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
COLLECTOR AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
INTERMEDIATE PLATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
CAM SENSOR BOARD A8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
CAM MOTOR AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
SLED CAM FOLLOWER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
CLAMP BAR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
CASSETTE END STOP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
REAR CASSETTE SENSOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
EXTRACTION BAR HOME POSITION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
PLATE POSITIONING AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
RIGHT and LEFT PLUSH AY - Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
LEFT PLUSH AY - Vertical Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
INTERNAL BAR CODE READER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
CASSETTE LOAD CRADLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Replacements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
GALVO and BLOCK AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
OPTICS MODULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
PMT/DAS BOARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
PMTs and COLLECTOR AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

ADJUSTMENTS AND REPLACEMENTS
10DEC05
AR4825-1
Page
3 of 160
FOLD MIRROR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
CASSETTE HANDLING AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
CAM MOTOR AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
HOOK YOKE AY and HOOK YOKE BEARING. . . . . . . . . . . . . . . . . . . . . . . . . . . 103
IDLER ROLLER AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
CASSETTE DRIVE AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
CASSETTE DRIVE ROLLERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
CASSETTE DRIVE MOTOR AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
LEFT PLUSH AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
RIGHT PLUSH AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
EXTRACTION BAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
SLOW SCAN AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
EXTRACTION BAR REFERENCE SENSOR S9 . . . . . . . . . . . . . . . . . . . . . . . . . . 119
PLATE PRESENT SENSOR S5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
COIL BOARD A7, ENCODER and SLOW SCAN ROTOR . . . . . . . . . . . . . . . . . . 122
PLATE POSITIONING AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
ERASE LAMP AY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
CPU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
HARD DRIVE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Additional Service Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Opening and Removing COVERS and PANELS . . . . . . . . . . . . . . . . . . . . . . . . . 139
Restoring the Purchased Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Restoring the Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Setting the Laser Calibration Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Calibration for the CR 825/850 SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
4 of 160 Section 1: Adjustments
INTERLOCK SWITCH
Adjustment Specification
Prerequisites:
None
To Check:
Caution
Dangerous Voltage
1Open the FRONT DOOR.
2Close the FRONT DOOR and observe
the INTERLOCK ACTUATOR entering
the INTERLOCK SWITCH.
3Check that the INTERLOCK
ACTUATOR enters the center of the
INTERLOCK SWITCH.
Purpose: To place the INTERLOCK ACTUATOR in the correct position.
Specification: The INTERLOCK ACTUATOR enters the center of the INTERLOCK
SWITCH when you close the FRONT DOOR.
Special Tools: None
H194_0043AC
FRONT DOOR
ACTUATOR
INTERLOCK
SWITCH
INTERLOCK
H194_0043ACA

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
5 of 160
To Adjust:
1Open the FRONT DOOR.
2Loosen the 2 SCREWS.
3Move the INTERLOCK ACTUATOR up
or down to the correct position.
4Tighten the 2 SCREWS.
Postrequisites:
None
H194_0043AC
H194_0043ACB
INTERLOCK
ACTUATOR
FRONT DOOR
2 SCREWS

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
6 of 160
TOP COVER
Adjustment Specification
Prerequisites:
1Adjust the INTERLOCK SWITCH.
To Check:
1Open the FRONT DOOR.
2Open the TOP COVER.
3Close the TOP COVER slowly and
observe the 2 PINS entering the holes
in the CROSSBRACE.
4Check that the 2 PINS seat into the
center of the holes in the
CROSSBRACE.
Purpose: To place the TOP COVER in the correct position.
Specification: When the TOP COVER is closed, the 2 PINS seat into the center of the
holes in the CROSSBRACE.
Special Tools: None
H194_0044AC holes
CROSSBRACE
TOP COVER
2 PINS
H194_0044ACA

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
7 of 160
To Adjust:
1Open the TOP COVER.
2Loosen the 5 LOWER SCREWS until
the TOP COVER can be moved with a
small force.
3Close the TOP COVER.
4Move the TOP COVER left or right until
the 2 PINS seat into the center of the
holes of the CROSSBRACE.
5Can you make the adjustment?
6Remove the REAR PANEL.
7Loosen the 3 SCREWS.
8Move the TOP COVER left or right until
the 2 PINS seat into the center of the
holes of the CROSSBRACE.
9Tighten the 3 SCREWS.
Important
Do not move the TOP COVER left or right
10 Carefully lift the TOP COVER.
11 Tighten the 5 LOWER SCREWS.
Postrequisites:
None
H194_0044AC
5 LOWER SCREWS
holes
CROSSBRACE
TOP COVER
2 PINS
H194_0044ACB
H194_0051AC
3 SCREWS
H194_0051ACA
No Yes
Continue with
Step 6.Advance to Step 10.

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
8 of 160
GALVO BOARD
Adjustment Specification
Prerequisites:
1Do Setting the Laser Calibration Voltage.
To Check:
Caution
Dangerous Voltage
1Energize the system.
Important
You must have a “Session ID” for access to “Service Functions” and “Diagnostics”. See
SERVICE BULLETIN 843.
Purpose: To set the AUTOMATIC GAIN CONTROL (AGC), and the “Velocity Profile”.
Specification: •The AGC voltage on the “Galvo Plot” screen is 8.2 V DC - 11.9 V DC
with the correct “Velocity Profile”.
•No “Ringing” in the “Wave Form”.
Special Tools: •TOOL TL-5726
•DIGITAL VOLTAGE METER (DVM) TL-3386

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
9 of 160
2At the main menu, touch:
•[Service Functions]
•[Diagnostics]
•[Galvo Plot]
•[Start Galvo Plot]
•[35 x 43]
Correct

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
10 of 160
Not Correct
Important
The GALVO stops after 500 cycles. If necessary to start again, select “Start Galvo Plot”.
3Check:
•no “Ringing” in the “Wave Form”
•“AGC” is at 8.2 V DC - 11.9 V DC

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
11 of 160
To Adjust:
Laser Warning
This equipment uses a visible red laser. Prevent direct exposure to the beam from the laser.
1Do Step 1 - Step 8 of the GALVO ROTATION procedure.
2Remove the REAR PANEL.
3On the GALVO BOARD, use the DVM TL-3386 set to V DC and connect the (+) end of
the DVM to TP13 and the (-) end of the DVM to TP1.
4Is the GALVO BOARD new?
Yes No
Adjust R2 until the voltage on the
DVM is 10 ± 0.02 V DC. Check that the voltage on the DVM is between 8.2 V DC and 11.9 V DC.
R2
R112
C55
TP12
TP13
TP7
TP1
TP2
TP3
TP5
TP14 TP15
TP9
TP6
TP10
TP4
TP11 R1
R112
TP17 TP16
61
H194_1408BC
H194_1408BCB
GALVO
BOARD
4 SCREWS

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
12 of 160
5Touch:
•[Start Galvo Plot]
•[35 x 43]
6Adjust R1 until the “hook” or “ringing” is just visible on the GALVO SWEEP PROFILE.
7Adjust R1 until the “hook” or “ringing” just disappears on the GALVO SWEEP PROFILE.
8Touch:
•[Back]
•[Galvo Test]
•[Start Galvo Plot]
•[35 x 43]
9Is the “Wave Form” correct?
10 Touch:
•[Back]
•[Galvo Test]
•[Start Galvo]
Yes No
Advance to Step 16. Continue with Step 10.

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
13 of 160
11 Set the “Amplitude” to “3000”.
12 Use the DVM TL-3386 set to V AC and
connect the (+) end of the DVM to
TP13 and the (-) end of the DVM to
TP1.
Important
•The GALVO must be “sweeping” when
you adjust R112.
•The lowest value is normally 10 - 25 mV
AC.
13 Adjust R112 until the voltage on the
DVM is at the lowest value.
16
TP16
TP17
R112
R1TP11
TP4
TP10
TP6
TP9
TP15
TP14
TP5
TP3
TP2
TP1
TP7
TP13
TP12
C55
H194_0045AC
R112
R2
GALVO BOARD
H194_0045ACA
TP13
TP1
R1
R112 R2

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
14 of 160
14 Touch:
•[Stop Galvo]
•[Back]
•[Galvo Plot]
•[Start Galvo Plot]
•[35 x 43]
15 Is the “Wave Form” correct?
Yes No
Continue with Step 16.DoStep 3 - Step 15 again.

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
15 of 160
16 Lift the TOP COVER.
17 Remove:
•5 SCREWS
•PMT COVER
•FOLD MIRROR COVER
•6 SCREWS
•COVER
18 Install the TOOL TL-5726.
Class3BLaserradiationwhen
openandinterlocksdefeated.
Avoidexposuretobeam.
3.17 mm
(0.125 in.)
H194_1418HC
GALVO
SCREW
laser beam
CLIPPERS
2 BEAM
TOOL TL-5726
COVER
6 SCREWS
COVER
MIRROR
FOLD
PMT COVER
5 SCREWS
H194_1418HCA

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
16 of 160
19 Touch [Laser On].
20 Is the laser beam 3.17 mm (.125 in.) on the 2 BEAM CLIPPERS?
21 Touch:
•[Stop Galvo]
•[Back]
•[Galvo Plot]
•[Start Galvo Plot]
22 Check that the “Velocity Profile” is
correct for all sizes of CASSETTE.
Yes No
Continue with
Step 21.Important
•Rotating the GALVO centers the laser beam.
•Adjusting R2 makes the laser beam shorter or longer.
a. Loosen the SCREW.
b. Rotate the GALVO until the laser beam is in the center.
c. Tighten the SCREW.
d. Adjust R2 on the GALVO BOARD until the laser beam is
3.17 mm (.125 in.) on the 2 BEAM CLIPPERS.
e. Continue with Step 21.

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
17 of 160
23 Is the “Velocity Profile” correct?
24 Do GALVO ROTATION.
25 Install:
•REAR PANEL
•FOLD MIRROR COVER
•PMT COVER
•5 SCREWS
•COVER
•6 SCREWS
Postrequisites:
1Adjust the FOLD MIRROR.
Yes No
Continue with
Step 25.a. Adjust R1 until the “Velocity Profile” is correct.
b. Do Step 19 - Step 23, or use
diagnostics to solve the problem.

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
18 of 160
GALVO ROTATION
Adjustment Specification
Prerequisites:
1Do Setting the Laser Calibration Voltage.
2Adjust the GALVO BOARD.
To Check:
Press the Escape key to dismiss the video after viewing.
Laser Warning
•This equipment uses a visible red laser. Prevent direct exposure to the beam from the
laser.
•Dangerous Voltage
1De-energize the system.
2Remove the FRONT DOOR and RIGHT PANEL.
Purpose: To set the GALVO home position.
Specification: The laser beam displays on the wide RING of the F-THETA LENS.
Special Tools: None

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
19 of 160 Caution
Do not cause damage to the OPTICAL AY.
3Remove:
•6 SCREWS
•COVER
4Loosen the THUMBSCREW.
5Move the LASER FILTER into the
service position.
6Tighten the THUMBSCREW.
Caution
Dangerous Voltage
7Energize the system.
8Install the INTERLOCK KEY.
Important
You must have a “Session ID” for access to
“Service Functions” and “Diagnostics”. See
SERVICE BULLETIN 843.
9At the main menu, touch:
•[Service Functions]
•[Diagnostics]
•[Galvo Test]
•[Laser on]
H194_1412GC
Avoid exposure to beam.
open and interlocks defeated.
Class 3B Laser radiation when
Avoidexposure to beam.
openand interlocks defeated.
Class3B Laser radiation when
OPTICAL AY
COVER
6 SCREWS
H194_1412GCA
THUMBSCREW
LASER FILTER
service
position
H194_0049AC
H194_0049ACA
INTERLOCK KEY

ADJUSTMENTS AND REPLACEMENTS Adjustments
10DEC05
AR4825-1
Page
20 of 160
10 Check that the laser beam displays on
the wide RING of the F-THETA LENS
and the reflected light just touches the
upper RING of the F-THETA LENS.
To Adjust:
Press the Escape key to dismiss the video after viewing.
H196_2700GC
Avoid exposure to beam.
open and interlocks defeated.
Class 3B Laser radiation when
CORRECT NOT CORRECT
H196_2700GCA
F-THETA LENS laser
beam
F-THETA LENS
beam
laser
wide
RING
WALL
