Kogan S900 User manual

6500 LUMENS FULL HD
WI-FI PROJECTOR
(S900)
KAS900PRRA

Read this manual fully and carefully before using the product.
• Do not look directly into the light from the projector.
• A direct burst of Intense light can harm your eyes and cause severe damage to the
eyes of infants.
• Do not use or store the projector in a damp, humid environment.
• Do not attempt to repair this product yourself. If the product or its power supply
experiences any malfunction or damage, stop using it immediately and contact
Kogan.com to arrange a repair.
• Ensure the projector is a safe distance from other heat-emitting devices or the
service life of the projector may be shortened.
• It is strongly suggested not to use the projector for more than 6 hours
consecutively.
SAFETY & WARNINGS

Projector
Remote Control
Power Cable
3-in-1 Video Cable
HDMI Cable
AAA Battery (x2)
Lens Cover
Warranty Card
User Guide
COMPONENTS

OVERVIEW
Control Panel
Focus
Keystone
IR receiver
Vent
Lens
Lens Cap

Power
Source
Down
Right Volume+
Indicator
Menu
Up
Left
Volume-
Return
Enter/OK
AV
HDMI 2
USB Port x2
VGA port
Audio output (3.5mm)
HDMI 1
IR receiver
Power

Remote Control
Power
Play/Pause
Rewind
Confirm
Mute
Fast Forward
Directional
Button
Source
Volume +
Menu
Back
Volume -

Getting Started
1. Connect the projector to a power outlet using the supplied cable, the indicator light
on will turn RED.
2. Press the power button on the projector or remote control, it starts work, the
indicator light on will turn WHITE.
3. The boot screen appears.
Image Adjustment
To achieve a clear image:
1. Adjust the keystone correction to make the picture a rectangle.
2. Adjust the focus ring to make the picture clear.
Keystone:
OPERATION
Keystone

Focus:
Connect Input Devices
Use the source button to select the desired signal source (USB/HDMI 1/HDMI 2/AV/VGA).
1. On the remote control: Press “ ” and press “ ” or “▲▼” to select the source.
To c o n f i r m press “OK”.
2. On the projector: press “S” and then press “” or “▲▼” to select the source. To
confirm press “OK”.
Focus

PC
1. Connect projector to a PC using either a VGA cable (not supplied) or HDMI cable.
2. Select either “HDMI” or “VGA” (depending on the cable you have used) on the
input select screen.
MacBook or MacBook Air
1. Connect projector to a Mac using either a Type-C to HDMI adapter to connect your
MacBook or a Mini Display to HDMI adapter to connect with your MacBook Air
(adapter not included).
2. Select “HDMI” on the input select screen.
USB
1. Insert a USB storage device into one of the USB ports on the projector.
2. Choose “USB” on the input select screen.
3. Select from: “Video, Music, Photo or Text”.
4. Confirm the file you want to play.

Soundbar
1. Use the supplied AV cable to connect to a soundbar.
2. Tu r n o n both the projector and the soundbar.
3. The projector will output all audio to the soundbar.
AV
1. Connect the projector to your AV device using supplied 3-in-1 composite AV cable
to the projector.
2. Tu r n o n both the projector and AV device.
3. Choose “AV” on the input select screen.
Amazon fire TV Stick
1. Plug the TV Stick into the HDMI port of the projector.
2. Choose “HDMI” on the input select screen.
Note: only 1080P TV Sticks are supported, not the 4K TV stick
Game Console
1. Connect the game console to HDMI port of the projector.
2. Tu r n o n b o t h t h e p r o j e c t o r a n d g a m e c o n s o l e .
3. Choose “HDMI” on the input select screen.
AV
Audio-out
AUDIO-OUT
AUDIO-OUT
Component
Component
AV
Video
Audio out(R)
Audio out
(L)
Audio Signal Line
Video Player

4. Wireless Connection (Android device only)
To a c t i v a t e t h i s f u n c t i o n , y o u r A n d ro i d d e v i c e m u s t s u p p o r t the Multi-Screen/Wireless
display.
4. Select “Mirroring” on the input source screen.
5. Ensure your Android device is connected to the internet.
6. On your Android device use the “Multi-Screen” function to search and connect to
the projector.
The fluency of screen mirroring with a wireless connection will be affected by the network
environment.
1. A bandwidth of 100Mbit or more is recommended when using screen mirroring.
2. Ensure your Android device is close to the projector when using a wireless
connection. A distance within 1 meter is recommended.

5. HDMI CEC
CEC (Consumer Electronics Control) allows users to control multiple HD devices that
support CEC with one remote control, eliminating the need to use multiple remotes to
control your devices.
1. Connect device(s) which support CEC to the projector by HDMI.
2. Choose SETTING > OPTION > HDMI CEC > Device List.
3. Search for and select the device(s).

Ceiling Mount Installation
This projector is compatible with most universal wall mounts (sold separately).
1. Remove the four rubber feet.
2. Enter MENU > PICTURE Projection Mode and select the ceiling-mounted.

Imaging System
LCD
Power
110-240V~50/60Hz
Light source
LED
Dimension
30.5 x 24.5 x 8.7cm
Colour
16.8m full colour
Resolution
Native 1920x1080 Full HD
Projection
Distance
1.5~7m
Input Interface
HDMIx2/VGA/AV/
USBx2/AUDIO IN
Projection size
50-300"
Zoom Function
100%-75%
Aspect Ratio
16:9 / 4:3
Output Interface
AUDIO OUT
Keystone
Correction
±15°Vertical
Manual
Projector Weight
= 2.5kg
Projection Size and Distance
Optimum projection distance: 3m
Distance
Screen size
1.5m
35"
1.75m
50"
2.4m
72"
3.3m
100"
3.9m
120"
5.5m
180"
7m
300"
SPECIFICATIONS

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
