Kohler LOURE 98964A User manual

All information is based on the latest product information available at the time of publication. Kohler Co.
reserves the right to make changes in product characteristics, packaging, or availability at any time without
notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove any debris.
2. An in line water filter must be used with this product.
3. Inspect the supply pipes for damage. Replace as necessary.
4. Observe local plumbing codes.
5.
Check for leaks before covering the pipes, repair as needed.
6. Recommended working pressure: 100 to 500kPa.
7. Maximum working pressure: 800kPa.
8. All installations should comply with the relevant requirements of AS/NZS 3500 and AS/NZS 6400.
BEFORE YOU BEGIN
ROUGH-IN DIMENSIONS
1
**Color code must be specified when ordering
1216028-AN2-A 08/08/2016 1216028-AN2-A 08/08/2016
4
Hand Shower with Diverter - Deck Mount
LOURE
SHOWER TAPWARE
Hand Shower with Diverter - Deck Mount
LOURE
SHOWER TAPWARE
Handshower with diverter: 98964A Handshower with diverter: 98964A
INSTALLATION INSTRUCTIONSSPARE PARTS
53x53 64x64
60
G1/2"
106
Max.32
40x40
Ø35 Ø35
100~200
G1/2"
G1/2" G1/2"
871527
O-Ring
864718
Plug
831289
Washer
3002770
Tee
831289
Washer
864149**
Nut
3002771
Seat
1245195**
Hose
1129983**
Bonnet
870205
Washer
1172476
Guide
830915
Steel Washer
864342
Nut
864909
Shank
1109501
Adapter
1109498**
Ball
1109499
Split Ring
1109500
Seal
1211617**
Handle
1211522**
Escutcheon
871132
Adapter
1054593
Hose
3002772
Fixing Bush
3004794
Valve Extension
1260687
Hose
Hose
834792
Nut
3004795
Valve
831752
Check Valve
870205
Washer
864342
Nut
830915
Steel Washer
870916
Rachet Ring
1260687
270
2824
G1/2"
9220
1158335**
Handshower

INSTALLATION - Supply tee 3). Slide the shower hose(18) (length: 2m) through the hose
guide(19), and attach to the connection hose(20) (length: 0.6m).
4). Put the washer(17) into the shower hose(18) connector and
thread the shower hose onto the handshower(16).
5). Put the fiber washer(21) into plug(22) and tighten the
plug to one of the center tee(23) ports of the spout.
6). Connect one side body(27) to the tee(4) located on the other
side body, using washers and one of the hoses provided with the
deck-mount tapware (Remove another hose and place aside).
7). Connect the tee(4) to the bottom port of the diverter with hose(26)
(length:1m) using washers.
8). Tighten the connection hose(24) to the end (with note label)
using a washer.
9). Connect the center tee(23) to another end of the diverter with
hose(25) (length:1m) using washers.
10). To ensure the water flows smoothly and the handshower can be
drawn out easily, avoid kinking or twisting of the hose.
NOTES: To make installation easier you may back off the center tee of the
spout up to 180 degree. Hoses should only be used where indicated.
INSTALLATION - Diverter
2
3
INSTALLATION CHECKOUT
1). Ensure all coupling nuts are tight. Turn on main water supply and check for leaks. Repair as required.
CLEANING INSTRUCTIONS
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with a
clean soft cloth. Many cleaners may contain such chemicals as ammonia, chlorine, toilet chemicals etc. which
could adversely affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler fittings.
1216028-AN2-A 08/08/20161216028-AN2-A 08/08/2016
1.) Insert the washer(2) into the tee nut(3).
2.) Connect the tee(4) to one side body(1) of the deck mount
tapware as shown.
1.) Remove the ratchet ring(5), escutcheon(6) and washer(7)
from the diverter body(10).
2.) Insert the diverter body with washer(8) and nut(9) through
the mounting hole in the deck.
3.) Reinstall the diverter body parts according to the following order:
washer(7), escutcheon and ratchet ring.
4.) Tighten the escutcheon, then wrench tighten the nut(9).
5.) Using handle(11), turn the diverter clockwise until it stops.
6.) Remove the handle and rotate it until the Kohler logo faces the front,
then press the handle onto the diverter body.
INSTALLATION - Handshower
1.) Remove the nut(15) and washer(14). Place the rubber washer(13)
into the groove of the escutcheon and place the shank into the
mounting hole in the deck.
2.) From the underside of the deck, install the washer(14) and nut(15)
onto to the shank and firmly tighten the nut.
1234
9
5
7
10
11
6
8
13
14
15
12
27
22 21 23 4
25
26
24
16
20
18
19
17
