BEFORE YOU BEGINBEFORE YOU BEGIN
INSTALLATION INSTRUCTIONS
WASHBASIN CABINETS
K-15227T/K-15228T
SLIM
·
·
·
·
·
·
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation. This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning, and
warranty information-
Turn off the water supply.
The pluming installation must comply with Water Supply
Regulations/Bye-laws, Building Regulations or any
particular regulations and practices, specified by the local
water company or water undertakers. The installation
should be carried out by a plumber.
Before installation carefully inspect the new fixture for any
signs of damage.
please leave instructions for the
consumer.
SLIM bathroom cabinet adopts E1 grade wood-based
panel of high quality, and with further processing, its
harmful emissions will be less than 1.5mg/L.
·
·
·
·
·
·
·
-
E1
1.5mg/L
ORDERING INFORMATION
This installation covers the following products in the SLIM
range:
SLIM 790mm Washbasin Cabinet......................K-15227T
SLIM 990mm Washbasin Cabinet......................K-15228T
790mm .............................................K-15227T
990mm .............................................K-15228T
SAFETY: WARNINGS
Kohler products are precision-engineered and should give
continued superior and safe performance, provided:
1. They are installed, commissioned, operated and
maintained in accordance with the recommendations given
in this Manual.
2. Periodic attention is given, as necessary, to maintain the
product in good functional order. Recommended
guidelines are given in the section.
Carefully inspect the new fixture for any signs of damage.
When installing Kohler Products, manufacturers guidelines for
power tool safety should be followed.
MAINTENANCE
1.
2.
215500
, 2010
Copyright Kohler China Ltd., 2010
1144955-T01-A

Fig.2
2
ROUGHING-IN
INSTALLATION
-2-
UNIT : mm
K-15228T
990mm Washbasin Cabinet
990mm
A. Install Washbasin Cabinet
Install the services.
Hot (H) and Cold (C) inlets must be connected to the correct
inlet pipes.
Install the drain in accordance with the manufacturer s
instructions.
Use P-trap drain. Connect P-trap pipe with washbasin drain.
Make sure a watertight seal exisits on all
washbasin drain connections.
Provide access to the plumbing connections
for future plumbing maintenance.
The hot and cold water supplies must be installed with
isolating valves.
Caution!
Caution!
A.
(H) (C)
P
K-15227T
790mm Washbasin Cabinet
790mm
460
Fig.1
1
460
395
395
790
990
1144955-T01-A

-3-
Fig.3
3
UNIT : mm
1.
1. Mark the position of hanged bracket according to
dimensions as illustrated, and loosen the suspension hook
of washbasin cabinet.
Avoid the cables and pipes inner set when
drilling in the wall.
Different types of bolts are required for different
decoration boards. Please apply suitable bolts and plugs.
Caution!
Note:
20
20
790
616
460
340
20 20
990
616
Wall Bracket
Wall Bracket
2.
3.
2. Drill holes for fixing the bracket. Using a level, ensure that
the hanged bracket is level.
3. Use suitable plugs and bolts, and fix the hanged bracket on
the wall.
Fig.4
4
MAX1
2
1
34
Caution: Do not exert external force on
this bar during transportation to
avoid damage to the cabinet.
1144955-T01-A

-4-
4.
5.
4
4. Hang the washbasin cabinet on the wall, and position the
suspension on the hanged bracket.
5. Set the washbasin cabinet onto the wall bracket. Be sure
the cabinet adjusted level and the back board of cabinet
appressed to the wall by adjusting the screws of wall clips.
See Fig.4.
6. Mark the wall through two holes at the corresponding
positions as illustrated in Fig 5.
7. Dismount the washbasin cabinet and put aside. Drill holes
at the marked position.
8. Insert the plugs into the wall.
9. Set the washbasin cabinet onto the brackets. Be sure the
cabinet adjusted level and the back board of cabinet
appressed to the wall by adjusting the screws of wall clips.
Caution!
Note:
Avoid the cables and pipes inner set when
drilling in the wall.
Different types of bolts are required for different
decoration boards. Please apply suitable bolts and plugs.
6. 5
7.
8.
9.
8
Fig.5
5
(P )
/
Connect Drainage
Inwall drainage (P-Trap)
Please install the drain assembly and faucet as shown.
Please set the water supply and drainage position according
to the suppliers instructions. You can adjust the height of
shelf to fit the drain assembly.
Faucet
Supply Lines
Shut-off Valve
Drain Assembly
Back Board
Sliding doors
Fig.6
6
1144955-T01-A

-5-
1.
2.
3.
4.
5.
6.
7.
USER MAINTENANCEUSER MAINTENANCE
Warn! Risk of product damage.
1.
2.
3.
4.
5.
6. Please do not sit, lean or step on the basin cabinet.
7. If any fixtures caused by abnormal reasons, Kohler China
can supply paid replacement for service parts caused by
abnormal reasons as shown in Service Parts Page in the
limited duration of warranty.
Many cleansers contain abrasive and chemical substance
which is not suitable for cleaning stainless steel, enamel,
plating or plastic products. You may use mild cleansers or
soaps to clean the surfaces. Wipe any splashes of cleaner
solutions from the surface with clean soft cloth.
Maintain ventilation in the bathroom, and separate the dry
area from the damp one if conditions permit. Try to open
the door and windows of the bathroom and maintain good
ventilation.
Kohler bathroom cabinet are dealt with strict procedures
for damp-proof, whose good damp-proof function ensures
good performance even in bathroom of huge humidity. Yet
do not splash and pour water directly on the bathroom
cabinet. Make sure that the bathroom is not over damp
and wipe any splashes from surfaces immediately.
Maintenance of door board: Clean and wipe door board
regularly, and wipe the condensation vapor with dry and
soft cloth.
Ensure that electrical connections for appliances such as
head lamp is insulated wipe mirror surface with chamois
regularly to guarantee the persistent excellent performance.
