INSTALLATION GUIDE /

Flipside Handspray Complete Set

Kohler Co. 1119916-X2-A
58
50
40
22.5
G1/2"
G1/2"
137
264
137
273
K-15600X
K-15599X

1119916-X2-A Kohler Co.
Install the Handshower
• Run cold and hot water through the shower outlet to ush
out dirt and debris.
• Insert the washers into the end of the inlet of the
handshower hose.
• Put the water ow restrictor into inlet of the handspray.
(only 15599X)
• Thread the handshower onto the hose until hand-tight. Do
not overtighten.
• Thread the hose onto the shower outlet.
• Wrench tighten the hose to the shower outlet. Do not
overtighten.
Installation Checkout
• Turn on the shower valve
• Check for leaks at each end of the handshower hose and
the inlet of the handshower.Make any adjustments as
needed.
• Rotate the handshower face to verify smooth operation of
the spray options.
• Turn off the shower valve.
Install the Shower Bracket
• Separate between the bracket from the bracket base.
• Position the bracket base on the wall, and mark anchoring
hole locations.
• Drill mounting holes at the marked location on the nished
wall.
• Insert the anchors into the nished wall.
• Secure the bracket base to the nished wall with screw.
• Fit the bracket over the bracket base and snap into place.
• Hang the handspray on the shower bracket.

 
 
 

 
 
 


 
 

 
 

 
 
 
 
 
 
 
Handspray
Water Flow Restrictor
Washer
Hose 22.5
Bracket Base
Bracket
Anchors
Screws
ฝกบัว
ตัวลดแรงดันนํ้า
แหวนรอง
สายฝกบัว
ฐานรองขอแขวน
ขอแขวน
สกรู
พุก

Kohler Co. 1119916-X2-A
Service Parts - 
The ideal cleaning technique is to always blot dry any water
from metal surfaces. Allowing water to evaporate on metal
will form water deposits. It is important to use a dabbing
action to dry metal using dry cloths. Do not use cleaners
containing ammonia, bleach, acid (including hydrochloric
solution) or chemicals that can damage the nishes. Use mild
soap solution, rinse and be sure to wipe the entire surfaces
dry. Use only a soft cloth or nonabrasive sponge to wipe
surfaces






Care and Cleaning

No. Description K-15599X K-15600X
   
1 1119917** Handspray       
2 1120863** Handspray     
3 880091 Water Flow Restrictor     
4 77420 Washer       
5 1059041** Bracket        
6 1072938** Hose       

KOHLER® FAUCET LIMITED WARRANTY
Call Center /
Tel. [phone] Fax. [phone]
[email protected]

1119916-X2-A Kohler Co.
Kohler (Thailand) Public Company Limited warrants to the original
products, which are purchased from authorized distributors and
dealers within Thailand only,
Kohler® faucet warrants limited warrantee within following terms and
conditions:
1. Warrants ceramic valve to be free from leakage and dripping of
aerator. Warrants its faucet on normal residential use for as long as
the original consumer purchase owns his or her home. Nevertheless,
if the Faucet is used commercially, Kohler (Thailand) Public
Company Limited warrants the faucet one (1) year from the date
the product is purchased.
2. Warranty does not cover the change of owner, relocation of owner,
scratch from installation and improper cleaning* and usage.
3. Warranty excludes damage caused by incorrect
installation, modication, pebbles, sand and other debris which
cause the ceramic valve to erode.
4. Warranty is not covered for labor charges, installation or other
incidental or consequential costs. If a defect is found in normal
residential use, Kohler (Thailand) Public Company Limited will at
its election, repair, provide a replacement service part or product,
or make appropriate adjustment.
Proof of purchase (Tax Invoice) must be provided to Kohler (Thailand)
Public Company Limited with all warranty claims.
To ensure continuous product quality and performance, as well as
product durability and life-time, without any damage to the product,
consumers should purchase and use only genuine service parts and
after-sales services from Kohler (Thailand) Public Company Limited
or company’s authorized service centers, distributors, or dealers only.
To obtain warranty service, please contact the authorized KOHLER
dealers or contact the KOHLER Call Center, together with proof of
purchase at:
Call Center
KOHLER (Thailand) Public Company Limited
16th Floor, Jasmine City Building
2 Soi Sukhumvit 23, Sukhumvit Road
Bangkok 10110
Tel: [phone] Fax: [phone]
Email: [email protected]
Remarks:
1. There may be variation in nished/color delity between catalog
images and actual products.
2. Kohler (Thailand) Public Company Limited reserves the right to
make changes in product characteristics, packaging, or availability
at any time without notice.
*Never use cleaners containing abrasive cleansers, ammonia, bleach,
acids, waxes, alcohol, solvents or other products not recommended for
chrome. This will void the warranty.
This is Kohler Co.’s exclusive written warranty.
