KOKEN LM-110 User manual

Gynecological
Examination
Simulator
LM-110
Instruction Manual
Thank you for purchasing the Gynecological Examination Simulator.
Please read this instruction manual carefully to ensure correct use of the product,
and store it in a safe place for easy access.
KOKEN CO., LTD.
1-4-14 Koraku, Bunkyo-ku, Tokyo 112-0004 JAPAN
URL:http://www.kokenmpc.co.jp
E-mail:[email protected]
© 2016-2020 KOKEN CO.,LTD. C-1-1026-1-01-04

1
Handling and Safety Precautions
These precautions should be strictly observed in order to ensure safe,
long-term use of the product.
The following precautions should be observed particularly strictly:
1. This model is made from special materials so that it closely resembles the feel of a living body,
so please handle this product gently as you would do so with a living body. Applying excessive
force, such as by pulling or dropping the model, can damage the product.
2. The materials of this model have a distinct odor. It is not harmful to the human body, and does
not a󱐯ect the product’s quality. The distinct odor will recede over time. Since the product is
coated with baby powder during manufacturing, there may be a trace smell of baby powder.
3. Please use glycerin as a lubricant. Please apply some glycerin before use during a practical. The
manufacturer is not liable for product deterioration or damage caused by the use of lubricant
other than glycerin.
*This product does not come with glycerin. Please purchase glycerin separately.
4. Please do not use oily lubricant (baby oil, olive oil etc.), alcohol lubricant, and lubricant containing
organic solvent. These may cause breakage of the model.
5. In caring for the model, do not use rubbing alcohol, thinners, or benzin or other organic solvents
on the model, as doing so may cause damage.
6. Never draw on the model with oil-based ink, pencil, chalk, or paint as it will stain the product
permanently.
7. Placing an object directly on the product or placing the product on an uneven surface may
change the shape of the product.
8. If the model was cleaned with water to reduce stickiness or after use in a practical, apply baby
powder over the entire model to reduce friction.
9. The genital unit may change shape over long-term use. Please check after about 3 years from
purchase. If the changed shape a󱐯ects the functioning of the model, please consider replacing
the genital unit.
10. There may be air bubbles or patterns on the model created during manufacturing. It will not
a󱐯ect the strength of the model, as it is made from a material that is resistant to tearing.

2
1. The contents of this instruction manual are subject to change without notice.
2. This instruction manual may not be reproduced in part or in its entirety without permission.
3. Please contact the manufacturer in the event that any errors or omissions are found in the contents of
this instruction manual.
4. This product should be used only as described in this instruction manual. In particular, the product
should not be used in any way that contravenes the precautions noted in the instruction manual.
11. The model may warp if stored in a very cold or very hot environment for an extended period
of time. The materials may also deteriorate, warp, or discolor if exposed to direct sunlight or UV.
Please store the product in an environment with a temperature of 0°C to 50°C, away from
direct sunlight and UV.
12. Please wear disposable gloves during a practical.
13. Please beware that the ovarian cysts and the hydrosalpinx may rupture if pumped with too
much air.
14. This product is intended for use in standard operating environments. Do not use it in heavy
industrial settings.
15. This model uses urethane foam for some of its parts, and may be susceptible to damage from
pests that are attracted to urethane foam (such as insects in the ant family).
When storing this model, ensure that thorough measures are taken to prevent pest damage
before storing. The company will not be involved with or held liable for pest damage that occurs
during storage.
16. There may be some indentations on the bottom or sides (i.e. the surfaces that make contact with
the main body) of the genital unit (see photograph below). However, they will not a󱐯ect the
product's quality or function. This is an unavoidable result of the characteristics of the material
used on these surfaces.

3
Table of Contents
1. Outline and characteristics
2. Structure and components
3. Handling instructions
3-1. Instructions for use
3-2. Adjustment of ovarian cysts and hydrosalpinx
3-3. Possible examinations and procedures
3-4. Removal of the genital unit
4. Care instructions
5. Specications

4
1. Outline and characteristics
Outline
This model enables practical training in basic gynecological examination. It is best suited for the
education of doctors-in-training and medical students, including general practice.
Characteristics
1. Soft, special material used for the external genital piece and abdominal piece impart a feel
to the model during bimanual examination (internal and external examination) and rectal
examination that closely resembles that of a living body.
2. All uteri are right-and-left adjustable, which enables the product to recreate realistic
examination of conditions such as cervical motion tenderness.
3. Internal reproductive organs such as the uterus and ovaries have normal and abnormal
states and the examination of their respective disease states (intramuscularis hysteromyoma,
subserous myoma, ovarian cyst, hydrosalpinx, etc.) can be practiced by changing the uterus.
The uterus can be changed easily.
4. The size of ovarian cysts and hydrosalpinx can be adjusted by pumping in air to achieve the
size and texture that closely resembles a living body.
5. The product can be used for the practical training of vaginoscopy, probing, and cytology
such as collection of intimal smears.
6. The genital unit can be detached easily for simple care and replacement.

5
2. Structure and components
Component Number of component
Main body 1
Genital unit 1
Fixing screw 2
Normal uterus 1
Early pregnancy uterus 1
Hysteromyoma 1 (in tunica muscularis) 1
Hysteromyoma 2 (under endometrium) 1
Ovarian cyst 1 (ping-pong ball size) 1
Ovarian cyst 2 (tennis ball size) 1
Hydrosalpinx 1
Air pump 1
Storage case 1
Abdominal wall protective sheet 1
Baby powder 1
Instruction Manual (this document) 1
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬
⑭

6
3. Handling instructions
3-1. Instructions for use
1. Remove the abdominal wall protective sheet from the storage case, and take out the main
body.
*If the genital unit feels sticky, apply the enclosed baby powder over the entire surface.
2. Peel open the abdominal wall
3. Apply glycerin to the hole for attaching the uterus
6
6
6
Storage case
Abdominal wall
protective sheet

7
4. Apply glycerin to the stopper ring on the uterus
5. Insert the uterus into the hole for attaching the uterus.
*On the inside of the hole for attaching the uterus is a groove into which the stopper ring will
t. Insert the uterus so that the stopper ring ts into this groove.
Picture is of the
normal uterus
Stopper ring
Cross section of the insertion site
Set correctly
Insert the ovaries of the normal uterus into
their respective compartments as shown
in the photograph.
*When practicing with a diseased uterus,
use without inserting the ovaries into their
compartments.
External
genitals
Uterus

8
6. Cover the main body with the abdominal wall and secure it with the hook and loop fasteners.
7. When removing the uterus, pull it out of the hole for attaching the uterus.
○ Do this also when changing to another uterus.
3-2 Adjustment of ovarian cysts and hydrosalpinx
○ The size of the ovarian cysts and the hydrosalpinx can be adjusted by injecting air with the
air pump.
1. Insert the ovarian cyst or hydrosalpinx uterus into the hole for attaching the uterus, and
attach the air pump connector to the straight stopcock.
*If the abdominal wall around the ilium is
not aligned properly, adjust to align it.
The straight stopcock is combined with
a luer-lock style connector. Attach and
turn to connect the air pump.

9
2. Open the handle on the straight stopcock and close the air pump valve before pumping in air.
*If you want to reduce the amount of air, loosen the air pump valve to release the air.
*Beware that pumping in too much air may cause the uterus to rupture.
3. Once the amount of air has been adjusted, close the handle on the straight stopcock and
detach the air pump connector.
4. Lay the straight stopcock on the underside of the uterus so it does not get in the way of the
examination.
Close
Open
Close
Detach

10
5. Cover the main body with the abdominal wall, and secure it with the hook and loop fasteners.

11
3-3 Possible examinations and procedures
○ The product is designed to accommodate practice of the following procedures. In addition,
the uterus may be changed to recreate the conditions of a normal uterus or uteri of various
abnormal states.
Internal examination Bimanual examination
Rectal examination Vaginoscopy
Probing Collection of intimal smears
*Before a practical, apply glycerin to the genitals, vaginal cavity and rectum of the model before
use. If using an endoscope for vaginoscopy, apply glycerin to the endoscope before use as well.

12
3-4 Removal of the genital unit
○ The genital unit is removable. To care for or replace the unit (for instance, if the genital part
has split), unscrew the xing screws (in 2 locations) and unfasten the hook and loop fasteners
around the leg (in 2 locations) to remove it.
○ Perform these procedures in reverse to assemble.
Peel o󱐯 while
holding the faster
on the unit side.

13
4. Care instructions
1. After use, wipe off dirt and the glycerin applied during the practical. Use water or neutral
detergent diluted with water, and wipe with a wet cloth or gauze. Wipe o󱐯 the moisture with
a dry, soft cloth such as gauze, and apply baby powder over the entire model.
*Never use organic solvents such as disinfecting alcohol, paint thinners, or benzenes to clean
this product.
*If left on, moisture and glycerin can cause mold. Please wipe them o󱐯 thoroughly.
2. This model can warp if stored for an extended period of time in a very cold or very hot
environment. The materials may also deteriorate, warp, or discolor if exposed to direct sunlight
or UV. When storing this product, store the model in an environment with a temperature of
0°C to 50°C, away from direct sunlight and UV.
3. This model may release oil residues. When storing this product, wrap the model in the
attached abdominal wall protective sheet and store in the storage case.
4. The uterus models can be rinsed in water. After rinsing in water, wipe off the moisture
thoroughly with a dry, soft cloth such as gauze.
5. Specication
Length Width Height Weight
GynecologicalExamination
SimulatorMainbody
Storagecase
Product
Approx.39cm Approx.41cm Approx.19cm Approx.4.7kg
 Approx.47cm Approx.54cm Approx.26cm Approx.5kg
