Konica Minolta FS-501 User manual

4684-7761-03 Printed in Japan
INSTALLATION MANUAL
FS-501
for Product Code 4036
Finisher
NOTES
•Before installing, be sure to unplug the power cord of the machine.
•Keep all packing materials out of the reach of children.

FS-501
– 1 –
■Outline of Installation Procedures for 4036 System
When installing the machine and associated options as a system, follow the order shown
on the left.
NOTE
For the detailed installation procedures for each option, follow the instructions given
in the corresponding Installation Manual and perform the procedures correctly.
✱ Electron System Options
PC-101 PC-201 DK-501
DF-601
AD-501
JS-601
FS-501
WT-501
FS-601
OC-501
PK-501/PK-4/
PK-131
Copier/Printer Machine
HD-501
EM-301
PC-401
Dehumidifier Heater 1C
EK-501 VI-501
D-103DT-105
Electron System Options
4684U057AB

FS-501
– 2 –
■Before Installing the Finisher
In order to adjust the height of the machine to the height of the finisher, the Paper Feed
Cabinet PC-101, or PC-201, or PC-401, or Desk must be installed.
■Unpacking the Finisher
1. Check that the following accessories are available in the box.
* Rail Guide A is not used when the FS-501 is mounted on the machine (product code
4036).
<Machine + Paper Feed Cabinet PC-101/PC-
201>
4684U058AA
<Machine + Paper Feed Cabinet PC-401>
4684U059AA
<Machine + Desk>
4684U060AA
1 Rail guide A............................................................................................1
2 Rail guide B............................................................................................1
3 Ground plate ..........................................................................................1
4 Rail .........................................................................................................1
5 Stabilizing pin .........................................................................................1
6 Magnet plate ..........................................................................................1
7 Horizontal transport unit .........................................................................1
8 Tray ........................................................................................................1
9 Protective guide .....................................................................................1
10 Label ......................................................................................................1
11 Screws A ................................................................................................3
12 Screws B ................................................................................................2
13 Installation manual (this manual) ...........................................................1
14 Spacer ....................................................................................................1
6 7 8
13
4698U044AA 4698U045AB 4698U046AB
4698U047AA 4698U048AA 4684U075AA
9
10 11
4684U072AA4684U076AB
12
1 4 5
14
4583U018AA
4684U070AA
2 3
4684U061AB 4684U062AA
9735U001AA

FS-501
– 3 –
2. Remove all tape and packing brackets. NOTES
•Make sure that the installation site is flat and level.
•After the Finisher has been set up, avoid moving it unless it is absolutely neces-
sary.
When the Finisher needs to be moved, perform the steps by referring to “Removing
the Rail” on p. 7.
After the Finisher has been moved, perform the steps given in “Installing the Hori-
zontal Transport Unit” on p. 5 and step 5, 6 on p. 4.
C4683U006AB
Tape
Packing
bracket
4684U074AA
NOTE
Do not remove these parts.
C4683U008AA
4643U003AA 4683U013AA
Packing bracket

FS-501
– 4 –
■Installing the Accessories
1. Peel off the seal covering the area where the
stabilizing pin and magnet plate will be
attached.
4583U016AA
2. Attach the enclosed stabilizing pin and
magnet plate with the enclosed screws A to
the left side of the machine as shown.
C4683U009AA
3. Place the Ground Plate furnished with the kit
in Rail Guide B.
4684U063AB
4. Attach the rail guide B to the left side of the
Paper Feed Unit as shown in the illustration
(two screws B furnished with the finisher).
NOTE
Fit Rail Guide B in the tab on the lower
portion of the Paper Feed Unit.
4684U064AA
5. Insert the rail into the Rail Guide B.
6. Protrude the leading edge of the rail out
about 60 mm to the right from the right end of
the machine.
NOTE
If the rail is pulled out more than necessary,
it is caught by the flat spring fitted to the
machine as it is brought back into the
original position.
7. Insert the spacer that comes with the finisher
into the rail.
NOTE
Slide out the rail to the left and check that it
does not come off the Rail Guide B.
4684U065AA
4583U017AB
8. Slide the other end of the rail installed in step
5 into the rail guide on the finisher.
NOTE
Insert the rail until it snaps into place.
At this time, the finisher should stay
attached to the machine, even if you try to
pull it away.
C4683U010AA
C4683U011AA

FS-501
– 5 –
■Unpacking the Horizontal Transport Unit
■Installing the Horizontal Transport Unit
■Adjusting the Height and Tilt of the Finisher
Remove all packing materials and tape.
C4651U023AB
Tape
1. Place the horizontal transport unit on the
paper output section of the machine, and
make sure that the plastic guide pin on the
bottom of the horizontal transport unit hooks
into the bracket on the finisher.
C4683U023AA
2. Push the horizontal transport unit in.
NOTE
Make sure that the gears on the horizontal
transport unit and on the finisher are
correctly aligned.
C4683U014AA
3. Secure the horizontal transport unit with the
lock.
NOTE
Firmly secure the Horizontal Transport Unit
and the Finisher in position using the Lock
Lever.
C4683U013AA
1. If the finisher gradually tilts toward the
machine, check the following:
•Are the stabilizing pin and the hole in the fin-
isher at the same height?
•Is the horizontal transport unit not extremely
tilted?
* If the finisher is not at the same height as the
machine, adjust the machine as follows.
4684U066AA
2. Slide the finisher away from the machine,
and then remove the lower-front cover (two
screws) of the finisher.
4643U021AB
3. Lift the finisher’s two caster covers up, and
then pull them off.
4643U020AA

FS-501
– 6 –
■Connecting the Hookup Cord
4. Without turning the adjusting bolt (lower bolt)
on the caster, loosen the securing bolt (upper
bolt), and then turn the adjusting bolt (lower
bolt) as indicated below to adjust the height
of the finisher.
<Two rear casters>
If the stabilizing pin is too high:
Turn the bolt clockwise
If the stabilizing pin is too low:
Turn the bolt counterclockwise
<Two front casters>
If the magnet plate is too high:
Turn the bolt clockwise
If the magnet plate is too low:
Turn the bolt counterclockwise
4643U022AB
Securing bolt
Adjusting
bolt
5. If the finisher tilts toward the machine, check
the following:
•Are distances a and b equal?
* If a and b are not equal, refer to step 4 above
and turn the adjusting bolt (lower bolt) as
indicated to adjust the tilt of the finisher.
4684U067AA
a
b
6. After the adjustment is finished, without
turning any of the adjusting bolts (lower
bolts), tighten the four securing bolts (upper
bolts).
7. Re-install the caster covers and the lower-
front cover (two screws).
4643U029AA
Securing bolt
Adjusting bolt
1. Remove the connector covers from the
horizontal transport unit and the machine.
2. Connect the hookup cord to the horizontal
transport unit and the machine.
4684U068AA
3. Secure the hookup cord of the Horizontal
Transport Unit using the cord clamp (large) of
the finisher.
4684U069AA

FS-501
– 7 –
■Installing the Tray and Protective Guide
■Removing the Rail
■Affixing the Labels
Affixing the enclosed operation labels.
Install the enclosed tray and protective guide at
the positions shown in the illustrations.
4643U024AA
4643U017AA
1. Pinch together the rail stoppers on the left
side of the finisher to release them.
2. Disconnect the two hookup cords.
3. Remove the horizontal transport unit from the
finisher, and then place it on top of the
machine.
4. Carefully pull the finisher away from the
machine.
5. Slide the rail under the machine, and then
remove it from the right side of the machine.
C4651U020AA
C4683U018BA
for Machine
4684U076AB
for RADF
4698U109AA
Label for Machine Label for RADF
