JS-506 Job Separator
INSTALLATION MANUAL
A2YV-9551-00
Applied Machines: C554e/C454e/C364e/C284e/C224e/C554/C454/C364/C284/C224/C368/C308/554e/454e/364e/
284e/224e/367/287/227
COLOR MFP: 55 ppm/45 ppm/36 ppm/30 ppm/28 ppm/22 ppm
MFP: 55 ppm/45 ppm/36 ppm/28 ppm/22 ppm
Product Code: A5AY/A5C0/A5C1/A5C2/A5C4/A2XK/A4FJ/A161/A4FK/A4FM/A7PU/A7PY/A61D/A61E/A61F/A61G/
A61H/A789/A7AH/A7AK
1. Accessory parts *1 This part is used only when the Job Separator
is installed to 367/287/227.
*2 This part is used only when the Job Separator
is installed to C554e/C454e/C364e/C284e/
C224e/C554/C454/C364/C284/C224/C368/
C308/554e/454e/364e/284e/224e.
Note:
• This manual provides the illustrations of the
accessory parts and machine that may be
slightly different in shape from yours. In that
case, instead of the illustrations, use the
appearance of your machine to follow the
installation procedure. This does not cause any
significant change or problem with the proce-
dure.
• If none of the later steps instruct you to use the
parts including screw and cover that you
removed following the instructions described in
this manual, discard them.
No. Name Shape Q’ty
1. Upper tray
1
2. Sensor unit
1
3. Film
1
4. Hook*1
1
5. Regulating
plate*1
1
6. Screw A
(3 x 8 mm) 1
7. Screw B
(3 x 10 mm) 3
8. Screw C
(3 x 16 mm)*2 2
9. Screw D
(4 x 8 mm)*1 1
10. Installation
manual
1 set
Keep this bag away from babies and
children. Do not use in cribs, beds,
carriages, or playpens.
The thin film may cling to nose and
mouth and prevent breathing. This bag is
not a toy.

E-2
2. Installation procedures
<C554e/C454e/C364e/C284e/C224e/C554/C454/
C364/C284/C224/C368/C308/554e/454e/364e/284e/
224e>
(1) Turn OFF the power switch and unplug the
power cord from the power outlet.
(2) Remove protective tape and protective materials
and take out accessory parts.
Note:
When installing this option to C554e/C454e/C554/
C454/554e/454e, the following steps (3) to (9) are
performed only if the optional Output Tray OT-506
is installed.
(3) Check whether the output tray has the snap-fit
hook illustrated below or not.
< When the machine has the snap-fit hook >
Go to step (6).
< When the machine does not have the snap-fit
hook >
Go to step (4).
(4) Open the front door of the main unit.
(5) Remove the upper left cover from the main unit.
(Three screws)
<C554e/C454e/C364e/C284e/C224e/C554/C454/
C364/C284/C224/C368/C308/554e/454e/364e/
284e/224e>
Follow the installation procedures starting on page
E-2.
<367/287/227>
Follow the installation procedures starting on page
E-7.
< With the
snap-fit hook >
< Without the
snap-fit hook >

E-3
(6) Remove the output tray from the main unit.
(7) Reattach the upper left cover removed in step (5)
to the main unit. (Three screws)
(8) Close the front door of the main unit.
(9) Remove the guide from the main unit.
(10) Remove the cover from the main unit as shown
in the illustration. (Two screws)
<C554e/C454e/C364e/C284e/C224e/C554/C454/
C364/C284/C224/554e/454e/364e/284e/224e>
<C368/C308>
(11) Remove the knockout from the cover removed
in step (10) with nippers.
< With the snap-fit hook >
< Without the snap-fit hook >

E-4
(12) Remove the cover from the main unit as shown
in the illustration. (One screw)
(13) Remove the knockout from the cover removed
in step (12) with nippers.
(14) Remove the paper backing from the supplied
film and attach it to the main unit as shown in
the illustration.
Note:
• Alignment in vertical direction:
Align the lower edge of the film with the surface
of the cover in the exit section.
• Alignment in back and forth direction:
± 2 mm from both edge of the depression on
the cover of the exit section
(15) Attach the supplied sensor unit to the main unit
by fitting the two tabs into the holes.
(16) Secure the sensor unit with the supplied
screw A.
(17) Conduct the following procedure to connect the
sensor unit's connector to the main unit.
<C554e/C454e/C364e/C284e/C224e/C554/C454/
C364/C284/C224/554e/454e/364e/284e/224e>
a) Remove the connector from the wire saddle
shown in the illustration.
± 2 mm
Connector
Wire saddle

E-5
b) Connect the sensor unit’s connector to the con-
nector described in step a).
c) Route the harness through the wire saddles A,
B, and the edge cover.
Note:
Position the connector under the wire saddle A as
shown in the illustration.
<C368/C308>
a) If present, disconnect the relay connector from
the sensor unit connector.
b) Connect the sensor unit connector to the con-
nector as shown in the illustration.
c) Route the sensor unit harness through the wire
saddle and the edge cover.
(18) Reattach the cover removed in step (12) to the
main unit. (One screw removed in step (12))
Connector
Connector
Wire saddle B
Wire saddle A
Edge cover
Edge cover
Wire saddle

E-6
(19) Install the supplied upper tray into the main unit
by fitting the tab into the hole.
Note:
Fit the two protrusions on the upper tray into the
notch on the cover shown in step (18) and into the
depression on the main unit’s surface as shown in
the illustration.
(20) Secure the upper tray with three supplied
screws B.
(21) Reattach the cover removed in step (10). (Two
screws removed in step (10))
(22) Attach the job separator by fitting the three tabs
into the holes.
(23) Secure the job separator with two supplied
screws C.
(24) Remove the cover shown in the illustration from
the back of the main unit. (One screw)
Protrusion
Notch
Protrusion
Tab
Depression

E-7
(25) Plug in the two connectors of the job separator.
Fit the head of the cable tie into the mounting
hole on the main unit.
(26) Reattach the cover removed in step (24). (One
screw)
Note:
• Be careful not to pinch the harness.
• Insert two tabs A into the holes on the main unit
cover first. Then fit two tabs B into the holes.
* The installation procedure for models C554e/
C454e/C364e/C284e/C224e/C554/C454/C364/
C284/C224/C368/C308/554e/454e/364e/284e/
224e is complete.
<367/287/227>
(1) Turn OFF the power switch and unplug the
power cord from the power outlet.
(2) Remove protective tape and protective materials
and take out accessory parts.
(3) Remove the output tray from the main unit.
Connector
Cable tie
Tab B
Tab A

E-8
(4) Remove the guide from the main unit.
(5) Remove the cover from the main unit as shown
in the illustration. (One screw)
(6) Remove the knockout from the cover removed in
step (5) with nippers.
(7) Remove the cover from the main unit as shown
in the illustration.
(8) Remove the paper backing from the supplied film
and attach it to the main unit as shown in the
illustration.
Note:
• Alignment in vertical direction:
Align the lower edge of the film with the surface
of the cover in the exit section.
• Alignment in back and forth direction:
0 to 2 mm from the edge of the metal sheet
(9) Attach the supplied sensor unit to the main unit
by fitting the two tabs into the holes.
(10) Secure the sensor unit with the supplied
screw A.
0 to 2mm

E-9
(11) Conduct the following procedure to connect the
sensor unit's connector to the main unit.
a) If present, disconnect the relay connector from
the sensor unit connector.
b) Connect the sensor unit connector to the con-
nector as shown in the illustration.
c) Route the sensor unit harness through the two
wire saddles.
(12) Install the supplied upper tray into the main unit
by fitting the tab into the hole.
Note:
Fit the two protrusions on the upper tray into the
portion where the cover has been removed in step
(7) and into the depression on the main unit’s sur-
face as shown in the illustration.
(13) Secure the upper tray with three supplied
screws B.
Protrusion
Tab
Notch
Protrusion

E-10
(14) Reattach the cover removed in step (5). (One
screw removed in step (5))
(15) Mount the supplied regulating plate to the
machine at the position shown in the illustra-
tion.
(16) Remove the cover shown in the illustration from
the job separator. (Two screws)
(17) Install the supplied hook into the job separator
according to the following procedure.
a) Press the hook into the job separator.
b) Secure the hook by turning it in the direction
indicated by the arrow in the illustration.
(18) Attach the job separator by fitting the three tabs
into the holes.
Note:
Make sure that the hook installed in step (17) is
secured at the proper position.
Hook

E-11
(19) Secure the job separator with one supplied
screw D.
(20) Remove the cover shown in the illustration from
the back of the main unit. (One screw)
(21) Plug in the two connectors of the job separator.
Fit the head of the cable tie into the mounting
hole on the main unit.
(22) Reattach the cover removed in step (20). (One
screw)
Note:
Be careful not to pinch the harness.
