Kontron ThinkIO-P User manual

™
29867.01_01.VC.051017/132414
ThinkIO™ - P
Premium DIN Rail PC
for Fieldbus and IO Systems
Manual ID: 29867.01, Rev. Index 01
17 October, 2005
The product described in this manual is
in compliance with all applied CE stan-
dards.
QUICK START GUIDE

Preface QUICK START GUIDE ThinkIO™ - P
© 2005 Kontron Modular Computers GmbH ID 29867.01, Rev. 01
29867.01_01.VC.051017/132414
Page ii
Revision History
Imprint
Kontron Modular Computers GmbH may be contacted via the following:
MAILING ADDRESS TELEPHONE AND E-MAIL
Kontron Modular Computers GmbH +49 (0) 800-SALESKONTRON
Sudetenstraße 7 [email protected]
D - 87600 Kaufbeuren Germany
For further information about other Kontron Modular Computers products, please visit our In-
ternet web site: www.kontron.com
Copyright
Copyright © 2005 Kontron Modular Computers GmbH. All rights reserved. This manual may
not be copied, photocopied, reproduced, translated or converted to any electronic or machine-
readable form in whole or in part without prior written approval of Kontron Modular Computers.
GmbH.
Publication Title: ThinkIO™ - P: Quick Start Guide
ID Number: 29867.01
Rev.
Index Brief Description of Changes Date of Issue
01 Initial issue 17 Oct, 2005
Disclaimer:
Kontron Modular Computers GmbH rejects any liability for the correctness and
completeness of this manual as well as its suitability for any particular purpose.

ThinkIO™ - P QUICK START GUIDE Preface
29867.01_01.VC.051017/132415
ID 29867.01, Rev. 01 © 2005 Kontron Modular Computers GmbH Page iii
Table of Contents
Revision History .........................................................................................................ii
Imprint ........................................................................................................................ii
Copyright ....................................................................................................................ii
Table of Contents ...................................................................................................... iii
Proprietary Note ........................................................................................................iv
Trademarks ...............................................................................................................iv
Explanation of Symbols .............................................................................................v
For Your Safety .........................................................................................................vi
Temperature and High Voltage Safety Instructions ..............................................vi
Special Handling and Unpacking Instructions ......................................................vi
1. General ............................................................................................................. 1
1.1 About This Guide ......................................................................................... 1
1.2 Requirements ............................................................................................... 1
1.3 The ThinkIO-P .............................................................................................. 1
1.4 The WAGO Interface and I/O Modules ........................................................ 2
1.5 Unpacking the ThinkIO-P ............................................................................. 2
1.6 Mounting ...................................................................................................... 2
1.7 Software and Documentation ....................................................................... 2
2. Pre-Operation ................................................................................................... 3
2.1 System Configuration ................................................................................... 3
2.2 Power Requirements .................................................................................... 4
2.3 Installation of the ThinkIO-P ......................................................................... 4
3. Initial Operation ................................................................................................ 5
3.1 Power On ..................................................................................................... 5
3.2 System Operation Verification ...................................................................... 5

Preface QUICK START GUIDE ThinkIO™ - P
29867.01_01.VC.051017/132415
© 2005 Kontron Modular Computers GmbH ID 29867.01, Rev. 01Page iv
Proprietary Note
This document contains information proprietary to Kontron Modular Computers GmbH. It may
not be copied or transmitted by any means, disclosed to others, or stored in any retrieval sys-
tem or media without the prior written consent of Kontron Modular Computers GmbH or one of
its authorized agents.
The information contained in this document is, to the best of our knowledge, entirely correct.
However, Kontron Modular Computers GmbH cannot accept liability for any inaccuracies or the
consequences thereof, or for any liability arising from the use or application of any circuit, prod-
uct, or example shown in this document.
Kontron Modular Computers GmbH reserves the right to change, modify, or improve this doc-
ument or the product described herein, as seen fit by Kontron Modular Computers GmbH with-
out further notice.
Trademarks
Kontron Modular Computers GmbH, the PEP logo and, if occurring in this manual, “CXM” are
trademarks owned by Kontron Modular Computers GmbH, Kaufbeuren (Germany). In addition,
this document may include names, company logos and trademarks, which are registered trade-
marks and, therefore, proprietary to their respective owners.

ThinkIO™ - P QUICK START GUIDE Preface
29867.01_01.VC.051017/132415
ID 29867.01, Rev. 01 © 2005 Kontron Modular Computers GmbH Page v
Explanation of Symbols
CE Conformity
This symbol indicates that the product described in this manual is in
compliance with all applied CE standards. Please refer also to the
section “Applied Standards” in the ThinkIO-P Hardware Reference
Guide.
Caution, Electric Shock!
This symbol and title warn of hazards due to electrical shocks (> 60V)
when touching products or parts of them. Failure to observe the pre-
cautions indicated and/or prescribed by the law may endanger your
life/health and/or result in damage to your material.
Please refer also to the section “High Voltage Safety Instructions” on
the following page.
Warning, ESD Sensitive Device!
This symbol and title inform that electronic boards and their compo-
nents are sensitive to static electricity. Therefore, care must be taken
during all handling operations and inspections of this product, in
order to ensure product integrity at all times.
Please read also the section “Special Handling and Unpacking
Instructions” on the following page.
Warning!
This symbol and title emphasize points which, if not fully understood
and taken into consideration by the reader, may endanger your health
and/or result in damage to your material.
Note ...
This symbol and title emphasize aspects the reader should read
through carefully for his or her own advantage.

Preface QUICK START GUIDE ThinkIO™ - P
29867.01_01.VC.051017/132415
© 2005 Kontron Modular Computers GmbH ID 29867.01, Rev. 01Page vi
For Your Safety
Your new Kontron product was developed and tested carefully to provide all features necessary
to ensure its compliance with electrical safety requirements. It was also designed for a long
fault-free life. However, the life expectancy of your product can be drastically reduced by im-
proper treatment during unpacking and installation. Therefore, in the interest of your own safety
and of the correct operation of your Kontron product, compliance with the following guidelines
is imperative.
Temperature and High Voltage Safety Instructions
Special Handling and Unpacking Instructions
• Do not handle this product out of its protective enclosure while it is not used for opera-
tional purposes unless it is otherwise protected.
• Whenever possible, unpack or pack this product only at EOS/ESD safe work stations.
Where a safe work station is not guaranteed, it is important for the user to be electrically
discharged before touching the product with his/her hands or tools. This is most easily
done by touching a metal part of your system housing.
• It is particularly important to observe standard anti-static precautions when changing pig-
gybacks, ROM devices, jumper settings etc. If the product contains batteries for RTC or
memory backup, ensure that the product is not placed on conductive surfaces, including
anti-static plastics or sponges. They can cause short circuits and damage the batteries
or conductive circuits on the board.
Warning!
All operations on this device must be carried out by sufficiently skilled
personnel only.
During operation the ThinkIO-P heats up and some parts of the enclosure
may get hot enough to cause light burns if touched for a period of time longer
than 1 to 2 seconds. Exercise care when handling a ThinkIO-P that has just
been operated. If necessary, cool down the ThinkIO-P before handling it.
Caution, Electric Shock!
Before installing your new Kontron product into a system always
ensure that your mains power is switched off. This applies also to the
installation of piggybacks.
Serious electrical shock hazards can exist during all installation,
repair and maintenance operations with this product. Therefore,
always unplug the power cable and any other cables which provide
external voltages before performing work.
ESD Sensitive Device!
Electronic boards and their components are sensitive to static elec-
tricity. Therefore, care must be taken during all handling operations
and inspections of this product, in order to ensure product integrity at
all times.

ID 29867.01, Rev. 01 © 2005 Kontron Modular Computers GmbH
29867.01_01.VC.051017/132415
GeneralThinkIO™ - P QUICK START GUIDE
Page 1
1. General
1.1 About This Guide
This Quick Start Guide is designed to provide information necessary to quickly install and begin
operations with the ThinkIO-P. It begins with unpacking and ends with the ThinkIO-P being
ready for operation in an application development environment. It includes not only the
ThinkIO-P, but also, where applicable, makes references to optionally available WAGO-I/O-
SYSTEM-750/753 I/O modules. Operating system or application software descriptions are not
part of this guide. Refer to the appropriate programming guide or application documentation for
further information concerning software.
The use of this guide requires that all applicable safety requirements are complied with in order
to prevent bodily harm or damage to the equipment involved.
This guide is designed to be read sequentially and is, as such, a procedure in itself. Do not skip
over subjects unless they have been previously read and understood.
The information and all of the instructions and procedures provided in this guide must be taken
into account or complied with to avoid improper operation or damage to the equipment.
1.2 Requirements
This guide assumes that the ThinkIO-P application requirements and system configuration
have been defined and that this information and all other required elements of the application
are available to the integrator at the time the procedures of this guide are applied.
1.3 The ThinkIO-P
The ThinkIO-P is an industrial PC packaged in an assembly, 224 x 70 x 100 mm, for mounting
on a DIN rail. It can be complemented with WAGO-I/O-SYSTEM-750/753 input and output
modules using the optional WAGO interface module (K-Bus) for controlling of the I/O modules.
The following figure demonstrates this configuration.
Figure 1-1: ThinkIO-P with the WAGO Interface Module (K-Bus) Assembled on the Right
C
D
B
A
--
++
X4 Power
RST
X7 DVI
X5 I/O
X6 RS232
X10 USB0 X8 ETH0
X11 USB1
X9 ETH1
ACT/LNK ACT/LNK SpeedSpeed
Run
Stop
Diag:
SP:

QUICK START GUIDE ThinkIO™ - P
29867.01_01.VC.051017/132416
General QUICK START GUIDE ThinkIO™ - PQUICK START GUIDE ThinkIO™ - P
© 2005 Kontron Modular Computers GmbH ID 29867.01, Rev. 01Page 2
1.4 The WAGO Interface and I/O Modules
The WAGO-I/O-SYSTEM-750/753 families of industrial input and output modules is option-
ally available for usage with the ThinkIO-P. This option requires the WAGO interface module
(K-Bus) for interfacing between the ThinkIO-P and the WAGO I/O modules. Through the
WAGO interface module (K-Bus) access is gained to a wide variety of industrial digital and
analog input/output devices as well as special encoders and counters.
1.5 Unpacking the ThinkIO-P
The ThinkIO-P is shipped in appropriate packaging material. This packaging material should
be retained for future use if it is necessary to return the product for servicing.
To unpack the ThinkIO-P proceed as follows:
1. Observing ESD requirements, carefully open the packaging and remove its contents.
2. Verify that the contents are as described in the delivery document(s) and are not dam-
aged.
If anything is missing, damaged, or not as described by the packing list, contact Kontron
for further instructions. Do not proceed until notified by Kontron.
3. Dispose of the packaging material as appropriate.
1.6 Mounting
The ThinkIO-P is designed to be mounted on a securely fixed, grounded, top-hat DIN rail for
operation. If for any reason that this is not possible, it must be ensured that the ThinkIO-P is
placed on a secure, flat, level surface with ESD protection before being operated.
Kontron assumes no liability for any damage whatsoever resulting from the operation of an un-
securely fixed ThinkIO-P.
1.7 Software and Documentation
The ThinkIO-P is delivered initially with pre-installed software. This is to ensure that it may be
operated for application installation or development. In addition, software and product docu-
mentation are provided on accompanying CD-ROMs.
Warning!
The ThinkIO-P itself is delivered as a closed unit and must not be opened.
In particular, if the ThinkIO-P is provided with a WAGO interface module
(K-Bus) attached to it, the interface module is not removable. Except for
the backup battery which is accessible from the front, there are no user servi-
cable parts within the ThinkIO-P or WAGO interface module (K-Bus). Open-
ing or removing of any attached components except for the battery will void
the product warranty.

ID 29867.01, Rev. 01 © 2005 Kontron Modular Computers GmbH
29867.01_01.VC.051017/132416
Pre-OperationThinkIO™ - P QUICK START GUIDE
Page 3
2. Pre-Operation
2.1 System Configuration
Basically, a ThinkIO-P application is comprised of the ThinkIO-P hardware, the ThinkIO-P soft-
ware, interfacing cabling, and, as an option, a WAGO interface module (K-Bus) and, as re-
quired, optional WAGO-I/O-SYSTEM 750/753 modules.
Figure 2-1: ThinkIO-P and K-Bus Cabling Diagram
* both main power inputs may be
from the same power source
Signals
5 VDC
Signals
5 VDC
LEDs
X1 CF-Card
X4 Power
ThinkIO-P
X11 USB1
X10 USB0
X9 ETH1
X8 ETH0
X7 DVI (CRT)
X6 RS232
X5 I/O
X3 Profibus/CAN
X2 DeviceNet
Run
/
Stop
24 VDC * 24 VDC *
K
-
B
U
S
W
A
G
O
I
O
W
A
G
O
I
O
W
A
G
O
I
O

QUICK START GUIDE ThinkIO™ - P
29867.01_01.VC.051017/132416
Pre-Operation QUICK START GUIDE ThinkIO™ - PQUICK START GUIDE ThinkIO™ - P
© 2005 Kontron Modular Computers GmbH ID 29867.01, Rev. 01Page 4
Before applying power to the ThinkIO-P, all interfacing cabling must be connected and, if re-
quired, the WAGO-I/O-SYSTEM 750/753 modules must be installed and their interfacing ca-
bling connected.
2.2 Power Requirements
The ThinkIO-P itself requires 24 V DC for operation. This is supplied via the X4 connector.
The optional WAGO-I/O-SYSTEM 750/753 modules have their own power input connections.
Refer to appropriate WAGO module documentation for the exact power and wiring connection
requirements.
Availability of appropriate power sources must be ensured prior to installation.
2.3 Installation of the ThinkIO-P
Using the application requirements as a guide, assemble the ThinkIO-P and the associated ap-
plication components. To achieve this, perform the following:
1. Mount the ThinkIO-P on the DIN rail or place on an appropriate surface.
2. If WAGO I/O modules are to be installed, refer to WAGO documentation for their assem-
bly.
3. Ensuring that no power is applied, connect all interfacing cables.
4. Verify the physical configuration with the application requirements. Resolve any anoma-
lies before proceeding.
Warning!
If the ThinkIO-P is to be operated with a CompactFlash card installed, it must
be installed before applying power to the system. The CompactFlash inter-
face is not a “hot plug” interface. In addition, do not remove the Compact-
Flash card with power applied to the system.
Failure to comply with this directive can result in damage to the Compact-
Flash card, and will result in improper operation of the system.
Note...
The ThinkIO-P provides 5 VDC internal system power for the WAGO I/O
modules (excluding the WAGO interface module (K-Bus)) up to a maximum
of 1 A of current. If more power is required for I/O modules, one or more
WAGO Internal System Supply modules (750-613) must be added as appro-
priate to provide additional module power.
Note...
If any connector protection caps were removed to install interfacing cables,
retain these caps for future use. They are special ESD protection devices for
the connectors on which they were installed, and they are required to be
installed if the connector is not used.

ID 29867.01, Rev. 01 © 2005 Kontron Modular Computers GmbH
29867.01_01.VC.051017/132416
Initial OperationThinkIO™ - P QUICK START GUIDE
Page 5
3. Initial Operation
3.1 Power On
As stated previously, the ThinkIO-P is delivered with pre-configured software for initial opera-
tions. This software allows the ThinkIO-P to initialize itself and to boot the operating system.
Once the system has booted it is ready either for application development or the installation of
an application.
What transpires now depends on the system configuration and the application requirements.
Three possibilities exist: performance of a simple system operation verification; establishment
of the basis for application development or the installation of an application. The following chap-
ter provides only information and procedures to perform a system operational verification. For
assistance concerning application development refer to the appropriate ThinkIO-P Program-
ming Assistance Guides.
3.2 System Operation Verification
When power is applied to the ThinkIO-P the system initializes itself and then boots the operat-
ing system. At completion of the boot process, control of the system is available to an operator.
To proceed, perform the following:
1. Ensure that all interfacing cabling is properly connected.
2. Ensure that the main input power to the ThinkIO-P is correct: + 24 V DC.
3. If applicable, ensure that the input power to the WAGO interface module (K-Bus) and
the I/O modules is of the correct type and voltage.
4. Apply power to the system.
Note ...
The ThinkIO-P now initializes itself and boots the operating system. This can
take several minutes to be accomplished. At the end of this process, either an
operating system command prompt will appear on the display indicating that
the operator now has control or an appropriate graphic user interface (GUI) is
displayed allowing operator control of the system. Refer to the appropriate
software documentation for further information.
The operator can now determine the operational status of the system and also
make changes to the system software configuration such as setting the IP ad-
dress of the ThinkIO-P or deactivating the BootP server if required.

QUICK START GUIDE ThinkIO™ - P
29867.01_01.VC.051017/132416
Initial Operation QUICK START GUIDE ThinkIO™ - PQUICK START GUIDE ThinkIO™ - P
© 2005 Kontron Modular Computers GmbH ID 29867.01, Rev. 01Page 6
5. Verify the system operational status.
6. Upon completion of the system status verification either remove all power from the sys-
tem and dispose of the system as required or proceed with application development or
installation. For application development or installation, refer to the appropriate
ThinkIO-P guides.
Note ...
At this time there are several possibilities to assess the operational status of
the ThinkIO-P.
For example, during bootup the status LEDs are operated in accordance with
pre-programmed functionality. This information is contained in the Hardware
Reference Guide for the ThinkIO-P.
If access is available to the operating system, various configuration informa-
tion is available via OS functions. Refer to the appropriate Programming As-
sistance Guide for more information.
