Kontron CP3010-SA User manual

D R A F T — F O R I N T E R N A L U S E O N L Y
The pulse of innovation
» User Guide «
CP3010-SA
Doc. ID: 1056-1693, Rev. 1.0
Date: November 4, 2014

D R A F T — F O R I N T E R N A L U S E O N L Y
2
www.kontron.com
User Guide
CP3010-SA
Revision History
Imprint
Kontron Europe GmbH may be contacted via the following:
MAILING ADDRESS TELEPHONE AND E-MAIL
Kontron Europe GmbH +49 (0) 800-SALESKONTRON
Lise-Meitner-Straße 3-5 [email protected]
86156 Augsburg, Germany
For further information concerning other Kontron products, please visit our Internet website:
www.kontron.com.
Disclaimer
Copyright © 2014 Kontron AG. All rights reserved. All data is for information purposes only and not
guaranteed for legal purposes. Information has been carefully checked and is believed to be accurate;
however, no responsibility is assumed for inaccuracies. Kontron and the Kontron logo and all other
trademarks or registered trademarks are the property of their respective owners and are recognized.
Specifications are subject to change without notice.
Revision Brief Description of Changes Date of Issue
1.0 Initial issue 4-Nov-2014

D R A F T — F O R I N T E R N A L U S E O N L Y
3
www.kontron.com
User Guide
CP3010-SA
Contents
Revision History ..........................................................................................................2
Imprint .....................................................................................................................2
Disclaimer ..................................................................................................................2
Contents ....................................................................................................................3
Tables .......................................................................................................................7
Figures ......................................................................................................................9
Warranty .................................................................................................................. 10
Proprietary Note ........................................................................................................ 10
Trademarks .............................................................................................................. 10
Environmental Protection Statement .............................................................................. 10
1 Introduction ...................................................................................... 11
1.1 Board Overview .......................................................................................... 11
1.2 System Expansion Capabilities ....................................................................... 12
1.2.1 CP3010-HDD Extension Module (8 HP) ............................................................. 12
1.2.2 CP-RIO3-04 Rear Transition Module................................................................. 12
1.3 Board Diagrams.......................................................................................... 12
1.3.1 Functional Block Diagram ............................................................................. 13
1.3.2 Front Panel ............................................................................................... 14
1.3.3 Board Layout ............................................................................................. 15
1.4 Technical Specification ................................................................................ 16
1.5 Standards ................................................................................................. 20
1.6 Related Publications.................................................................................... 21
2 Functional Description ......................................................................... 22
2.1 Processor.................................................................................................. 22
2.1.1 Integrated Processor Graphics Controller ......................................................... 22
2.2 Memory .................................................................................................... 23
2.3 Watchdog Timer.......................................................................................... 23
2.4 Battery..................................................................................................... 23
2.5 Flash Memory............................................................................................. 23
2.5.1 SPI Boot Flash for uEFI BIOS.......................................................................... 23
2.5.2 SATA Flash ................................................................................................ 24
2.6 Trusted Platform Module 1.2.......................................................................... 24
2.7 Board Interfaces......................................................................................... 24
2.7.1 Front Panel LEDs......................................................................................... 24
2.7.1.1 System Status LEDs ..................................................................................... 24
2.7.1.2 General Purpose LEDs .................................................................................. 25
2.7.2 USB Interfaces ........................................................................................... 26
2.7.3 DisplayPort Interfaces ................................................................................. 26

D R A F T — F O R I N T E R N A L U S E O N L Y
4
www.kontron.com
User Guide
CP3010-SA
2.7.4 Serial Ports ............................................................................................... 26
2.7.5 Gigabit Ethernet ......................................................................................... 27
2.7.6 SATA Interfaces .......................................................................................... 27
2.7.7 Debug Interface ......................................................................................... 27
2.7.8 CompactPCI Interface .................................................................................. 27
2.7.8.1 Board Functionality when Installed in System Slot.............................................. 27
2.7.8.2 Board Functionality when Installed in Peripheral Slot (Passive Mode) ..................... 28
2.7.8.3 Front/Rear I/O Configuration........................................................................ 28
2.7.8.4 Board Insertion/ Replacement under Power ...................................................... 28
2.7.8.5 Power Ramping .......................................................................................... 28
2.7.8.6 ENUM# Interrupt ........................................................................................ 29
2.7.9 CompactPCI Connectors J1 and J2................................................................... 29
2.7.9.1 CompactPCI Connector Keying ....................................................................... 29
2.7.9.2 CompactPCI Connectors J1 and J2 Pinouts ........................................................ 30
2.7.9.3 Optional Rear I/O Interface........................................................................... 33
2.7.9.4 Rear I/O Pin Description............................................................................... 35
3 Configuration..................................................................................... 40
3.1 DIP Switch Configuration.............................................................................. 40
3.2 System Write Protection ............................................................................... 41
3.3 CP3010-SA-Specific Registers ........................................................................ 41
3.3.1 Write Protection Register (WPROT) .................................................................. 42
3.3.2 Reset Status Register (RSTAT) ........................................................................ 43
3.3.3 Board ID High-Byte Register (BIDH)................................................................ 44
3.3.4 Geographic Addressing Register (GEOAD) ......................................................... 44
3.3.5 Watchdog Timer Control Register (WTIM) ......................................................... 45
3.3.6 Board ID Low-Byte Register (BIDL) ................................................................. 46
3.3.7 LED Configuration Register (LCFG) .................................................................. 46
3.3.8 LED Control Register (LCTRL) ......................................................................... 47
3.3.9 General Purpose Output Register (GPOUT)......................................................... 48
3.3.10 General Purpose Input Register (GPIN)............................................................ 48
4 Power Considerations .......................................................................... 49
4.1 CP3010-SA Voltage Ranges............................................................................ 49
4.2 Power Consumption..................................................................................... 49
5 Thermal Considerations ........................................................................ 51
5.1 Operational Limits for the CP3010-SA .............................................................. 52
6 CP3010-HDD Extension Module .............................................................. 53
6.1 Overview................................................................................................... 53
6.2 Technical Specifications ............................................................................... 53
6.3 CP3010-HDD Module Functional Block Diagram .................................................. 55
6.4 Front Panel of the CP3010-SA with CP3010-HDD Module....................................... 56
6.5 CP3010-HDD Module Board Layout .................................................................. 56

D R A F T — F O R I N T E R N A L U S E O N L Y
5
www.kontron.com
User Guide
CP3010-SA
6.6 Module Interfaces (Front Panel and Onboard).................................................... 57
6.6.1 CAN Interface ............................................................................................ 57
6.6.2 Serial Port................................................................................................. 57
6.6.3 Gigabit Ethernet Interface ............................................................................ 57
6.6.4 USB Interface ............................................................................................ 57
6.6.5 Audio Interfaces......................................................................................... 57
6.6.6 SATA Interface ........................................................................................... 57
7 CP-RIO3-04 Rear Transition Module ........................................................ 58
7.1 Overview................................................................................................... 58
7.2 Technical Specifications ............................................................................... 58
7.3 CP-RIO3-04 Front Panels .............................................................................. 59
7.4 CP-RIO3-04 Rear Transition Module Layout ....................................................... 60
7.5 Module Interfaces ....................................................................................... 62
7.5.1 USB Interfaces ........................................................................................... 62
7.5.2 VGA Interface ............................................................................................ 62
7.5.3 Gigabit Ethernet Interface ............................................................................ 62
7.5.4 COM Interface ............................................................................................ 62
7.5.5 Peripheral Control Interface .......................................................................... 63
7.5.6 SATA Interfaces .......................................................................................... 63
7.5.7 Rear I/O Interface on CompactPCI Connector rJ2................................................ 64
8 Installation ....................................................................................... 66
8.1 Safety ...................................................................................................... 66
8.2 General Instructions on Usage ....................................................................... 66
8.3 Board Installation ...................................................................................... 66
8.3.1 Standard Board Insertion ............................................................................. 67
8.3.2 Standard Board Removal .............................................................................. 67
8.4 CFast Card Installation ................................................................................. 68
8.5 Rear Transition Module Installation ................................................................ 68
8.6 Battery Replacement ................................................................................... 68
9 uEFI BIOS .......................................................................................... 69
9.1 Starting the uEFI BIOS Setup Program ............................................................. 69
9.2 Setup Menus.............................................................................................. 70
9.2.1 Main Setup Menu ........................................................................................ 70
9.2.2 Advanced Setup Menu .................................................................................. 71
9.2.3 Security Setup Menu.................................................................................... 72
9.2.3.1 Remember the Password ............................................................................... 72
9.2.4 Boot Setup Menu ........................................................................................ 73
9.2.5 Exit Setup Menu ......................................................................................... 73
9.3 The uEFI Shell ............................................................................................ 74
9.3.1 Introduction, Basic Operation ....................................................................... 74
9.3.1.1 Entering the uEFI Shell ................................................................................ 74
9.3.1.2 Exiting the uEFI Shell .................................................................................. 74
9.3.2 Kontron-Specific uEFI Shell Commands ............................................................ 75

D R A F T — F O R I N T E R N A L U S E O N L Y
6
www.kontron.com
User Guide
CP3010-SA
9.4 uEFI Shell Scripting..................................................................................... 76
9.4.1 Startup Scripting ........................................................................................ 76
9.4.2 Create a Startup Script ................................................................................. 76
9.4.3 Examples of Startup Scripts........................................................................... 77
9.4.3.1 Execute Shell Script on Other Harddrive ........................................................... 77
9.4.3.2 Enable Watchdog ........................................................................................ 77
9.4.3.3 Handling the Startup Script in the SPI Boot Flash ............................................... 78
9.5 Firmware Update ........................................................................................ 79
9.5.1 Updating the uEFI BIOS................................................................................ 79
9.5.1.1 uEFI BIOS Fail-Over Mechanism ...................................................................... 79
9.5.1.2 Updating Procedure .................................................................................... 79
9.5.1.3 uEFI BIOS Recovery ..................................................................................... 79
9.5.1.4 Determining the Active Flash ......................................................................... 79

D R A F T — F O R I N T E R N A L U S E O N L Y
7
www.kontron.com
User Guide
CP3010-SA
Tables
1 CP3010-SA Main Specifications ............................................................................. 16
2 Standards ........................................................................................................ 20
3 Additional Standards for Boards Ordered with Ruggedized Service ................................. 20
4 Additional Standards for Boards with Extended Temperature Range ............................... 21
5 Related Publications ........................................................................................... 21
6 Features of the Processors Supported on the CP3010-SA ............................................. 22
7 System Status LEDs Function ................................................................................ 24
8 General Purpose LEDs Function ............................................................................. 25
9 POST Code Sequence ........................................................................................... 25
10 POST Code Example ............................................................................................. 26
11 CompactPCI Connector J1 System Slot Pinout ........................................................... 30
12 CompactPCI Connector J1 Peripheral Slot Pinout ....................................................... 31
13 CompactPCI Connector J2 Pinout (CP3010-SA Front I/O Vers.) ...................................... 32
14 Rear I/O CompactPCI Connector J2 Pinout (CP3010-SA Rear I/O Vers.) ........................... 34
15 CompactPCI Rear I/O Connector J3 Signals ............................................................... 34
16 GPIO Signal Description ....................................................................................... 35
17 COMA and COMB Signal Description ........................................................................ 35
18 GPIO Signal Description ....................................................................................... 36
19 VGA Signal Description ........................................................................................ 36
20 Gigabit Ethernet Signal Description ........................................................................ 37
21 SATA Signal Description ...................................................................................... 38
22 USB Signal Description ........................................................................................ 38
23 Power Supply and Power Management Signal Description ............................................ 39
24 DIP Switch SW1 Functionality ................................................................................ 40
25 CP3010-SA-Specific Registers ............................................................................... 41
26 Write Protection Register (WPROT) ......................................................................... 42
27 Reset Status Register (RSTAT) ............................................................................... 43
28 Board ID High-Byte Register (BIDH) ....................................................................... 44
29 Geographic Addressing Register (GEOAD) ................................................................ 44
30 Watchdog Timer Control Register (WTIM) ................................................................. 45
31 Board ID Low-Byte Register (BIDL) ........................................................................ 46
32 LED Configuration Register (LCFG) ......................................................................... 46
33 LED Control Register (LCTRL) ................................................................................ 47
34 General Purpose Output Register (GPOUT) ................................................................ 48
35 General Purpose Input Register (GPIN) .................................................................... 48
36 DC Operational Input Voltage Range ....................................................................... 49
37 CP3010-SA Power Consumption ............................................................................. 50
38 Power Consumption of CP3010-SA Accessories .......................................................... 50
39 CP3010-HDD Module Specifications ........................................................................ 53
40 Serial Port Connector J3 Pinout ............................................................................. 57
41 CP-RIO3-04 Rear Transition Module Specifications ..................................................... 58
42 Serial Port Connectors J2 (COMB) and J3 (COMA) Pinout ............................................. 62
43 Peripheral Control Connector J13 Pinout ................................................................. 63
44 Rear I/O CompactPCI Connector rJ2 Pinout .............................................................. 65
45 Rear I/O Signal Description .................................................................................. 65
46 Navigation ....................................................................................................... 69

D R A F T — F O R I N T E R N A L U S E O N L Y
8
www.kontron.com
User Guide
CP3010-SA
47 Main Setup Menu Sub-Screens and Functions ............................................................ 70
48 Advanced Setup Menu Sub-Screens and Functions ..................................................... 71
49 Security Setup Menu Functions .............................................................................. 72
50 TPM Configuration Sub-Screen .............................................................................. 72
51 Boot Priority Order ............................................................................................. 73
52 Exit Setup Menu Functions ................................................................................... 73
53 Kontron-Specific uEFI Shell Commands ................................................................... 75

D R A F T — F O R I N T E R N A L U S E O N L Y
9
www.kontron.com
User Guide
CP3010-SA
Figures
1 CP3010-SA Functional Block Diagram .................................................................... 13
2 4 HP CP3010-SA Front Panel ................................................................................ 14
3 4 HP CP3010-SA Board Layout (Top View) ............................................................... 15
4 4 HP CP3010-SA Board Layout (Bottom View) .......................................................... 15
5 CPCI Connectors J1/J2 ....................................................................................... 29
6 DIP Switch SW1 ................................................................................................ 40
7 CP3010-SA with Intel® Atom™ E3845, 1.91 GHz ....................................................... 52
8 CP3010-SA with Intel® Atom™ E3827, 1.75 GHz ....................................................... 52
9 CP3010-HDD Module Functional Block Diagram ........................................................ 55
10 Front Panel of the 8 HP CP3010-SA with CP3010-HDD Module ...................................... 56
11 CP3010-HDD Module Board Layout (Top View) ......................................................... 56
12 Serial Port Connector J3 ..................................................................................... 57
13 CP-RIO3-04 4HP and 8HP Front Panels ................................................................... 59
14 4HP CP-RIO3-04 Rear Transition Module Layout ........................................................ 60
15 8HP CP-RIO3-04 Rear Transition Module Layout ........................................................ 61
16 Rear I/O CompactPCI Connector rJ2 ....................................................................... 64

D R A F T — F O R I N T E R N A L U S E O N L Y
10
www.kontron.com
User Guide
CP3010-SA
Warranty
This Kontron product is warranted against defects in material and workmanship for the warranty period
from the date of shipment. During the warranty period, Kontron will at its discretion decide to repair
or replace defective products.
Within the warranty period, the repair of products is free of charge as long as warranty conditions are
observed.
The warranty does not apply to defects resulting from improper or inadequate maintenance or handling
by the buyer, unauthorized modification or misuse, operation outside of the product’s environmental
specifications or improper installation or maintenance.
Kontron will not be responsible for any defects or damages to other products not supplied by Kontron
that are caused by a faulty Kontron product.
Proprietary Note
This document contains information proprietary to Kontron. It may not be copied or transmitted by any
means, disclosed to others, or stored in any retrieval system or media without the prior written consent
of Kontron or one of its authorized agents.
The information contained in this document is, to the best of our knowge, entirely correct. However,
Kontron cannot accept liability for any inaccuracies or the consequences thereof, or for any liability
arising from the use or application of any circuit, product, or example shown in this document.
Kontron reserves the right to change, modify, or improve this document or the product described here-
in, as seen fit by Kontron without further notice.
Trademarks
This document may include names, company logos and trademarks, which are registered trademarks
and, therefore, proprietary to their respective owners.
Environmental Protection Statement
This product has been manufactured to satisfy environmental protection requirements where possible.
Many of the components used (structural parts, printed circuit boards, connectors, batteries, etc.) are
capable of being recyc.
Final disposition of this product after its service life must be accomplished in accordance with appli-
cable country, state, or local laws or regulations.

D R A F T — F O R I N T E R N A L U S E O N L Y
11
www.kontron.com
User Guide
CP3010-SA
1 Introduction
1.1 Board Overview
The CP3010-SA is a highly integrated, low-power, 3U CompactPCI® CPU board designed to support the
Intel® Atom™ processors E3845 and E3827 with a maximum of quad-core 1.91 GHz processing perfor-
mance. Even though the board design is based on the Atom™ technology, performance levels of former
Core™2 Duo platforms can be reached. Further, the built-in graphics core now features Intel® HD
Graphics Technology offering an outstanding increase in graphics performance compared to previous
Atom™ designs.
Memory demanding applications can make use of up to 8 GB soldered DDR3L SDRAM memory running
at 1333 MHz. For onboard data storage, the CP3010-SA offers a CFast option or a soldered SATA Flash
and, on the 8HP extension module, an HDD/SSD option. On the system side, the CP3010-SA supports a
PCI 32-bit, 33 MHz (66 MHz on request) CompactPCI® interface enabling the peripheral mode feature.
Using the latest Atom™ technology, the board offers a very low TDP (thermal design power) value. This
feature, in conjunction with the special heat sink design, makes the CP3010-SA a perfect fit for all sys-
tems and applications where cooling by fans is not desired or not possible. As a result, operation in
temperature ranges from -40°C up to +85°C is possible.
Designed with soldered processor and memory to handle even the toughest environmental conditions,
the CP3010-SA can be used in industrial and mobile applications where motion, shock and vibration
can typically be found. With respect to the transportation market, the CP3010-SA is fully EN50155-
compliant.
The CP3010-SA comes with a comprehensive I/O feature set supporting interfaces such as DisplayPort,
USB 3.0/2.0, Gigabit Ethernet, SATA, CAN, and RS-232 serial ports as well as the audio interfaces Line-
In and Line-Out. Available as 4HP or 8HP version – optionally combined with rear I/O support – the
CP3010-SA can be adapted to a wide range of application needs.
As a stable product based on Intel®‘s embedded product line, the CP3010-SA ensures long-term avail-
ability. This eliminates the risk of unplanned design changes and unexpected expensive application
modification. While minimizing deployment risks by providing a broad range of software support, the
CP3010-SA eases the process of product integration and maximizes competitive advantages to meet
time-to-market windows.
The board is offered with various Board Support Packages including Windows, VxWorks and Linux op-
erating systems. For further information concerning the operating systems available for the CP3010-
SA, please contact Kontron.

D R A F T — F O R I N T E R N A L U S E O N L Y
12
www.kontron.com
User Guide
CP3010-SA
1.2 System Expansion Capabilities
1.2.1 CP3010-HDD Extension Module (8 HP)
The CP3010-HDD extension module for the 8 HP CP3010-SA version provides onboard support for a 2.5”
HDD/SSD and various ports on the front panel, such as one USB 2.0 port, one COM port, one Gigabit
Ethernet, one CAN port, and two audio interfaces (Line-In and Line-Out). For further information on
the CP3010-HDD extension module, refer to Chapter 6.
1.2.2 CP-RIO3-04 Rear Transition Module
The CP-RIO3-04 rear transition module has been designed for use with the CP3010-SA and provides
comprehensive rear I/O functionality. For further information on the CP-RIO3-04 rear transition mod-
ule, refer to Chapter 7.
1.3 Board Diagrams
The following diagrams provide additional information concerning board functionality and component
layout.

D R A F T — F O R I N T E R N A L U S E O N L Y
13
www.kontron.com
User Guide
CP3010-SA
1.3.1 Functional Block Diagram
Figure 1: CP3010-SA Functional Block Diagram
DDR3L w/o ECC
Bank B
soldered
DDR3L w/o ECC
Bank A
soldered
COMA & COMB (TTL)
Front Panel
POST Code / Debug / Gen. Purpose LEDs
FPGA
Board
Control
CompactPCI Connector
COMA + COMB or COMA + GPIO
Debug
3.3V and 5V
Intel® Atom™
Processor
(SoC)
DDR3L DDR3L
USB3.0, USB 2.0
LPC SMBusSPI
USB
SATA
USB 3.0
type-A PCIe
2x DisplayPort
DP USB 2.0
2x SATA 3Gb/s
GbE GbE
RJ-45 RJ-45
TPM
PCIe
LPC
USB 2.0
type-A
DP A
USB
GbE
Contr.
I210
GbE
Contr.
I210
PCI PCI 32-bit / 33MHz
3.3V / 5V VIO
USB 2.0 2x USB 2.0
GbE
PCIe
PCIe x1
High-
speed
extension
connector
PCIe
HDA
PCIe x1
1x USB 2.0
VGA
VGA CRT
GbE
Watchdog / Thermal LEDs
COMA
Onboard Power Supplies
DC/DC etc.
USB
Power USB Power
GbE
Switch
GbE
Switch
Rear I/O Eth Rear I/O Eth
Rear I/O Eth
Rear I/O Eth
SFF-XDP
RTC
Battery
RTC
CFAST
socket
PCI
Bridge
PCIe x1
COMA+B
SATA
Mux
2x 2x SATA
1x SATA Ext.
(optional)
DP B
UART
VGA
USB 2.0
USB
MUX
USB Ext.
USB 2.0
1x USB 3.0
USB Ext.
SATA Ext.
USB 2.0
SATA
Flash
Up to 64GB
XBUS
XBUS
SPI Boot
Flashes
(standard/
recovery)
User
EE-PROM

D R A F T — F O R I N T E R N A L U S E O N L Y
14
www.kontron.com
User Guide
CP3010-SA
1.3.2 Front Panel
Figure 2: 4 HP CP3010-SA Front Panel
Note: For information regarding the front panel of the 8 HP CP3010-SA with a CP3010-HDD ex-
tension module, refer to Chapter 6.
CP3010
DP-A DP-B
USB 2.0 USB 3.0 WD0123TH
SPEED
ACT
SPEED
ACT
System Status LEDs
TH (red/green): Temperature Status
WD (green): Watchdog Status
General Purpose LEDs
LED3..0 (red/green/red+green): General Purpose/ POST Code
Note: If the General Purpose LEDs 3..0 are lit red during boot-up,
a failure is indicated before the uEFI BIOS has started.
Integral Ethernet LEDs
ACT (green): Ethernet Link/Activity
SPEED (orange): 1000BASE-T Ethernet Speed
SPEED (green): 100BASE-TX Ethernet Speed
SPEED (off) + ACT on: 10BASE-T Ethernet Speed

D R A F T — F O R I N T E R N A L U S E O N L Y
15
www.kontron.com
User Guide
CP3010-SA
1.3.3 Board Layout
Figure 3: 4 HP CP3010-SA Board Layout (Top View)
Figure 4: 4 HP CP3010-SA Board Layout (Bottom View)
J1
J2
Intel® Atom™
Battery
J10A
GbE A
J3
J6 J7
J4
J8
J9
Logic
DDR3L SDRAM
SPD EEPROMs with DTS
J5
CFast
(opt.)
J10B
GbE B
(SoC)
ON
SW1
TH LED
WD LED
LED0
LED1
LED2
LED3
1234
DDR3L SDRAM
SATA Flash
(opt.)
J12
J11

D R A F T — F O R I N T E R N A L U S E O N L Y
16
www.kontron.com
User Guide
CP3010-SA
1.4 Technical Specification
Table 1: CP3010-SA Main Specifications
FEATURES SPECIFICATIONS
SoC
CPU The CP3010-SA supports the following processors:
» Quad-core Intel® Atom™ E3845, 1.91 GHz, 2 MB L2 cache
» Dual-core Intel® Atom™ E3827, 1.75 GHz, 1 MB L2 cache
Graphics Controller Intel® HD Graphics integrated in the processor with support for two independent
displays
Memory
Main Memory Up to 8 GB, dual-channel DDR3L SDRAM memory without ECC running at 1333 MHz
(soldered)
Flash Memory Two 8 MB SPI boot flash chips for two separate uEFI BIOS images
SATA NAND flash (optional):
» Up to 64 GB soldered SATA NAND flash, or
» CFast card
EEPROM EEPROM with 64 kbit
Interfaces
CompactPCI CompactPCI interface:
» Compliant with CompactPCI Specification PICMG® 2.0 R 3.0
» System master operation
» 32-bit / 33 MHz master interface (66 MHz on request)
» 3.3 V or 5 V (universal PCI interface)
» Support for up to seven peripheral slots (7x REQ/GNT signals)
When installed in a peripheral slot, the CP3010-SA is isolated from the CompactPCI
bus. It receives power from the backplane and supports rear I/O.
CP3010-SA removal under power:
When installed in a peripheral slot, the CP3010-SA supports hot plugging on the
power interface through a dedicated power controller, but not on the PCI inter-
face.
Hot swapping of peripheral boards controlled by the CP3010-SA:
When installed in the system slot, the CP3010-SA supports the hot swapping of
other boards. Individual clocks for each slot and Enum signal handling are in com-
pliance with the PICMG 2.1 Hot Swap Specification.
The CP3010-SA itself, however, is not hot swappable. When installed in the system
slot, the system must be powered down in order to replace the board.
Rear I/O The following interfaces are routed to the rear I/O connector J2:
» COMA and COMB, or COMA and GPIO (all ports have 3.3V LVTTL signaling)
» General purpose signals: 5 x GPIs and 3 x GPOs
»2xUSB2.0
»1xCRTVGA
» 2 x Gigabit Ethernet
»2xSATA3Gb/s
» System management signals
» Input for 5V standby power
» System write protection

D R A F T — F O R I N T E R N A L U S E O N L Y
17
www.kontron.com
User Guide
CP3010-SA
Interfaces
DisplayPort Two DisplayPort interfaces (DVI/HDMI-capable through passive cable adapter) for
connection to monitors
Gigabit Ethernet Three 10 Base-T/100 Base-TX/1000 Base-T Gigabit Ethernet interfaces based on
three Intel® I210-IT Ethernet controllers:
» Two interfaces with Wake-on-LAN support and individually switchable to front
I/O or rear I/O
» One interface available on the high-speed I/O extension connector, J7, for
t h e C P 30 10 - HDD
USB Four USB ports:
» One USB 3.0 port on the front I/O
» One USB 2.0 port on the front I/O
» Two USB 2.0 ports on the rear I/O CompactPCI interface, one of them switch-
able to the high-speed I/O extension connector, J7, for the CP3010-HDD
Serial Two 16C550-compatible UARTs:
» COMA available either on the rear I/O or on the high-speed I/O extension con-
nector, J7, for the CP3010-HDD
» COMB or GPIO available on the rear I/O only
SATA Two SATA 3 Gb/s ports:
» One SATA port either onboard for the SATA Flash or the CFast card, or on the
rear I/O
» One SATA port either on the rear I/O or on the high-speed I/O extension con-
nector, J7, for the CP3010-HDD
I/O Extension
Interfaces
I/O extension to 8 HP board version via the CP3010-HDD extension module:
» SATA 3 Gb/s for 2.5” HDD/SSD
»USB2.0
» Gigabit Ethernet
»COMA
»AudioLineIn
»AudioLineOut
»CAN
»Resetbutton
» HDD/SSD activity LED
Sockets
Front Panel Connectors » DP: two standard DisplayPort connectors, J3 and J6
» USB 3.0: one standard 9-pin, type A connector, J8
» USB 2.0: one standard 4-pin, type A connector, J9
» Ethernet: one standard dual RJ-45 connector, J10A/B
Onboard Connectors » CompactPCI connectors, J1 and J2
» CFast socket, J5 (optional)
» 60-pin, high-speed I/O extension connector, J7, for connection to the CP3010-
HDD extension module
»JTAGconnector,J4
» XDP-SFF (debug) connector, J12
» SPI extension connector, J11
Table 1: CP3010-SA Main Specifications (Continued)
FEATURES SPECIFICATIONS

D R A F T — F O R I N T E R N A L U S E O N L Y
18
www.kontron.com
User Guide
CP3010-SA
LEDs / Switches
Front Panel LEDs System Status LEDs:
» TH (red/green): Temperature Status
» WD (green): Watchdog Status
General Purpose LEDs:
» LED3..0 (red/green/red+green): General Purpose / POST Code
Ethernet LEDs:
» ACT (green): Network / Link Activity
» SPEED (green/orange): Network Speed
DIP Switch One DIP switch, SW1, for board configuration
Timer
Real Time Clock Real-time clock with 242 Byte CMOS RAM; battery-backup available
Watchdog Timer Software-configurable, two-stage Watchdog with programmable timeout ranging
from 125 ms to 4096 s in 16 steps
Serves for generating IRQ or hardware reset
Sys. Management
Thermal Management CPU and board overtemperature protection is provided by:
» Up to four Digital Thermal Sensors (DTS), one for each core
» One DTS for the Bus Interface Unit (BIU) within the SoC
» Two DTS integrated in the SPD EEPROMs near to the DDR3L memory banks
» Specially designed heat sinks
Security
TPM Trusted Platform Module (TPM) 1.2 for enhanced hardware- and software-based
data and system security
Software
uEFI BIOS Phoenix SecureCore Tiano™ (SCT) BIOS firmware based on the uEFI Specification and
the Intel Platform Innovation Framework for EFI:
» LAN boot capability for diskless systems (standard PXE)
» Redundant image; fail-safe recovery in case of a damaged image
» Non-volatile storage of setting in the SPI boot flash (battery only required for
the RTC)
» Compatibility Support Module (CSM) providing legacy BIOS compatibility
based on Phoenix SCT3
» Command shell for diagnostics and configuration
» uEFI Shell commands executable from mass storage device in a pre-OS envi-
ronment (open interface)
Operating Systems There are various operating systems available for the CP3010-SA. For further infor-
mation, please contact Kontron.
Table 1: CP3010-SA Main Specifications (Continued)
FEATURES SPECIFICATIONS

D R A F T — F O R I N T E R N A L U S E O N L Y
19
www.kontron.com
User Guide
CP3010-SA
Note: For information regarding the front panel of the 8 HP CP3010-SA with a CP3010-HDD ex-
tension module, refer to Chapter 6.
General
Power Consumption See Chapter 4 for details.
Temperature Range Operational: 0°C to +60°C Standard (depending on the airflow in the system)
-40°C to +85°C Extended (depending on the airflow in the system)
Storage: -40°C to +85°C Without hard disk and without battery
Battery 3.0V lithium battery for RTC; Battery type: UL-recognized CR2025
Temperature ranges:
Operational (load): -20°C to +70°C typical
(refer to the battery manufacturer’s
specifications for exact range)
Storage (no load): -40°C to +70°C typical
Climatic Humidity 93% RH at 40 °C, non-condensing (acc. to IEC 60068-2-78)
Dimensions 100 mm x 160 mm
3U, 4 HP, CompactPCI-compliant form factor
Board Weight 4 HP CP3010-SA with heat sink (without CFast card): 243 grams
Table 1: CP3010-SA Main Specifications (Continued)
FEATURES SPECIFICATIONS

D R A F T — F O R I N T E R N A L U S E O N L Y
20
www.kontron.com
User Guide
CP3010-SA
1.5 Standards
This product complies with the requirements of the following standards.
Note: Customers desiring to perform further environmental testing of the CP3010-SA must con-
tact Kontron for assistance prior to performing any such testing.
Boards without conformal coating must not be exposed to a change of temperature which
can lead to condensation. Condensation may cause irreversible damage, especially when
the board is powered up again.
Kontron does not accept any responsibility for damage to products resulting from destruc-
tive environmental testing.
In addition, boards ordered with the ruggedized service comply with the following standards as well.
Table 2: Standards
TYPE ASPECT STANDARD
CE Emission EN 55011, EN 61000-6-4, EN 50155, EN 50121-3-2 (Class B)
Immunity EN 50155, EN 61000-6-2, EN 50121-3-2
Electrical Safety EN 60950-1
Mechanical Mechanical Dimensions IEEE 1101.10
Environmental Climatic Humidity IEC 60068-2-78 (see note below)
WEEE Directive 2002/96/EC
Waste electrical and electronic equipment
RoHS 2 Directive 2011/65/EU
Restriction of the use of certain hazardous substances in
electrical and electronic equipment
Table 3: Additional Standards for Boards Ordered with Ruggedized Service
TYPE ASPECT STANDARD REMARKS
Environmental Operating Vibration IEC 60068-2-6 Test parameters:
10-300 [Hz] frequency range
5 [g] acceleration
1 [oct/min] sweep rate
10 cycles/axis
3 directions
Operating Shocks IEC 60068-2-27 Test parameters:
30 [g] acceleration
12 [ms] shock duration half sine
3 shocks per direction (total: 18)
18 directions
5 [s] recovery time
Operating Bumps IEC 60068-2-27 Test parameters:
15 [g] acceleration
11 [ms] shock duration half sine
500 shocks per direction
6 directions
1 [s] recovery time
