Kozyard Apollo User manual

10’x12’ Apollo Hardtop Gazebo
With Double Roof
Assembly Manual
Kozyard LLC Products
www.kozyard.com
© Copyright 2016 - 2023 Kozyard LLC. | All Rights Reserved.
Version:20231006

6.77 in. 12 in.
12 in.
111.43 in.
ø0.31in.
136.88 in.
2+
Safetyglasses
• Please read and follow this assembly and operation guide to reduce the risk of personal injury
and damage to your gazebo.
• Do not discard any of the packaging until you have checked that you have all the parts in place.
The maximum weight capacity of this gazebo roof is 2500 pounds.
• Sidewalls and nettings should be off or in the opened position and tied to poles when winds are
over 30 MPH to avoid damage.
• Some parts may have sharp edges or corners. To ensure your safety, follow basic safety precau-
tions to reduce the risk of injury. Please note that this item contains small parts which could be
swallowed by children. Keep it out of reach of children under 3 years old and pets during installa-
tion.
Warnings and Cautions
Two or more people are required
for aseembly and disassembly.
Pre-assembly
Tools that may be required.(Not included in boxes)
Note: Tools are not shown to actual size and scale.
Do not fully tighten screw prior to
complete assembly.
10’x12’ Anchor Blueprint
Anchoring poles into concrete is strongly recommended.
Ensure the gazebo is positioned on level ground

page 110’x12’ assembly manual
Attn: Prior to assembly, verify all parts and and pieces are included to ensure an
efficient installation process.
BOX 1
J1 x4 J2 x4
B1 x2
B2 x2
C1 x2
C2 x2
B61 x2
B62 x2
C61 x2
C62 x2
M x4
N x4
Q x2
T x2
T1 x2
U0 x4
U x4
Z4 x4
Z3 x4
Z x56+2
Z2 x4
Z1 x4
G x4
S x104+2
H2 x1
H1 x4
R x8
U4 x4
U3 x4
H3 x1
ITEM DESCRIPTION QTY
B1
B2
C1
C2
2
2
2
2
Joint Bar
Sidewall Track
Jointer Bar
Sidewall Track
B61
B62
2
2
Jointer Bar
Sidewall Track
C61
C62
2
2
Jointer Bar
Sidewall Track
J1
J2
4
4
Corner Solidifying Bar
Corner Solidifying Bar
M
N
4
4
Corner Roof Bar
Roof Bar
T
T1
Q 2
2
2Finishing Bar
Finishing Bar
Finishing Bar
U0
U
4
4
Solidifying Bar
Solidifying Bar
Z
Z1
Z2
Z3
Z4
56+2
4
4
4
4
Bracket
Bracket
Bracket
Bracket
Bracket
G
H1
H2
H3
4
4
1
1
Corner Cover
Joint Cover
Silcone Rubber
Double-sided adhesive tape
S
R
U3
U4
8
104+2
4
4
Spacer
Finishing End
Iron Angle
Iron Angle

BOX 2
BOX 3
ITEM DESCRIPTION QTY
ITEM DESCRIPTION QTY
C
B 2
2
Beam
Beam
page 210’x12’ assembly manual
A x4
R2 x8 A Pole 4
R2 8Corner bracket
L x4
H x4
B x2
C x2
B6 x2
C6 x2
P1 x2
Q2 x4
Wrench
Allen key
#5 x64+3
#6 x8+1
#7 x28+2
#9 x24+2
#10 x4+1
#11 x8+1
#1 x218+4
#4 x 52+2
#2 x16+2
#3 x16+2
φ12x20+M6x12
#8 x16+2
M5x15
B6
C6
H
L
2
2
4
4
Beam
Beam
Joint Cover
Plate
P1
Q2
2
4Net Frame
Allen key
Wrench
Net Frame
#1
#2
#3
#4
#5
#6
#7
#9
#8
#10
#11
218+4
16+2
16+2
52+2
64+3
8+1
28+2
4+1
8+1
1
1
24+2
16+2
Hook
Screws
Screws
Screws
Screws
Screws
Screws
Screws
Screws
Screws
Screws

BOX 4
BOX 5
P x2
ITEM DESCRIPTION QTY
ITEM DESCRIPTION QTY
page 310’x12’ assembly manual
K x1
K1 x1
F x4
Y1 x2
Y2 x2
V1 x2 V2 x2
V6 x2V5 x2V4 x2V3 x2 W3 x2 W4 x2W1 x2 W6 x2
W5 x2
W2 x2
X4 x2
X1 x2 X2 x2 X3 x2
X5 x2 X7 x2 X8 x2
X6 x2
F
K
K1
4
1
1
Union Bar
Inside Roof Connector
Outside Roof Connector
P 2Finishing Bar
2
Y1 Mosquito Net
Mosquito Net 2
Y2
V1
V2
V3
V4
V5
V6
W1
W2
W3
W4
W5
W6
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
X1
X2
X7
X6
X4
X5
X8
X3

10’x12’ assembly manual page 4
A x4
L x4
#1
x12
#8 x16
R2 R2
Parts Required:
AA
L
X12
3 inches
3/8
inches
M6
(Not included)
R2 x8
#1
#1
#1
A
L
R2
(Inclined Plane)
R2
#8
#8
#8
#8
Step 1: Set up Poles
Set up Poles (Part A) with Bracket (Part R2) and Stand Plates (Part L) using
screws #8 and #1 as shown in the diagram.
Reference for anchoring gazebo:
• If the ground is concrete and its depth is over 3 inches, you can purchase 3/8" diameter x 3" length
sleeve anchors.
• Only anchor after finishing all the assembly.
After assembly, we strongly recommend anchoring the gazebo to your deck or concrete as
shown above. Damage resulting from wind or improper anchoring is not covered under warranty.

page 510’x12’ assembly manual
B6
C6
F
X2
X2
B6 B6
F
#1
#1
#1
#1
#1
X24
C x2 B x2
C6 x2
F x4
B
B
C
C
C
C6
C6
B
F
F
#1
#1
#1
#1
Parts Required：
X2
X2
B6 x2
Long Beam Overall:
Short Beam Overall:
Step 2: Connect the Beams
1. Connect Beams (Part C and B) into one beam using Union Bar (Part F) with
screws 1# as shown in the diagram.
2. Connect Beams (Part C6 and B6) into one beam using Union Bar (Part F) with screws
1# as shown in the diagram.

page 610’x12’ assembly manual
B2 x2
B1 x2
C61 x2
C62 x2
C1 x2
C2 x2
B
C
C6 B6
B1
C2
B61
B62
C61
C62
B2
C1
B61 x2
B62 x2
#1 x80
Parts Required:
X2
X2
Tip:
1. Connect Joint Bars (part C1,C61) and
Tracks (Part C2,C62) to Beams (Part C ,C6)
using #1 screws as shown in the diagram.
10 ft overall:
12 ft overall:
STEP 3: Connect Joint Bars and Tracks with Beams
Place parts on carpet or rug to
avoid scratches during assembly.
X2
C,C6
#1
#1
C2,C62
C1,C61
B,B6
#1
#1
B2,B62
B1,B61
X2
Tip:
Do not tighten all screws on the
Jointer bars (Part C1, C61, B1, B61)
until the screws of the roof panels
are aligned in place.
2. Replicate the same steps for Joint Bars
(Part B1 and B61), Tracks (Part B2 and B62),
attaching them to Beams (Part B and B6)
using screws #1 as shown in the diagram.
2. Connect Beams (Part C6 and B6) into one beam using Union Bar (Part F) with screws
1# as shown in the diagram.

10’x12’ assembly manual page 7
A
A
A
A
B
B
B
C
C
C
B
C
B6
B6
C6
C6
B6
C6
Parts Required：
#2
x16
#3
x16
3+
A
A
B
C
X2
X2
STEP 4: Set up Poles and Beams
3 people suggested for
this step.
Tip:
#2
#2
#3 #3
X8
X8
Use screws #3 first, then use screw #2 to connect Poles and
Beams together as shown in the diagram.
Tip:
Place parts on carpet or rug
to avoid scratches during
assembly.

J2
J2
J2
J2
J1
J1
J1
J1
J2 x4J1 x4 #1
x32
page 810’x12’ assembly manual
Parts Required:
Affix the frame with Corner Solidifying Bars (Parts J1, J2) using #1 screws as shown in
the diagram.
Diagonal 1
Diagonal 2
Diagonal 1 = Diagonal 2
J2
J1
#1
#1 #1
X4
STEP 5: Connect Solidifying Bars with Beams and Poles
Tip:
Measure (DIAGONALLY) from posts to posts to
assure alignment so all materials fit as planned.

H x4
G x4
page 910’x12’ assembly manual
Parts Required: #9
x24
# 9
#9
#9
G
H
1. Finish Connecting Beams using Corner
Covers (Part G) and #9 screws as
shown in diagram.
STEP 6: Cover the connections
2. Affix middle beams using Joint
Covers (Part H) with #9 screws as
shown in diagram.
X4X4

page 1010’x12’ assembly manual
Parts Required:
X4
H2 x1
STEP 7: Seal seams
1. After finishing Step 6, apply silicone rubber to the seams to ensure they're watertight.
2. If the screws are correctly attached through Spacer part S on the roof panels, sealing the cap
screws with silicone rubber isn't necessary.

X2 X2
X4
page 1110’x12’ assembly manual
Parts Required:
H1 x4
#4 x52
#1
#4
#4
H1
#4
#4
x6
x6
x7 x7
C2
CC6 B6 B
H1 H1
B2 C62 B62
Put 6Hooks into each slot of
Sidewall Track (part C2 ,B2).
Put 7Hooks into each slot of
Sidewall Track (part C62, B62).
Note the
amount of
hooks for
each slot
as noted
below:
H
#1
x4
#4
STEP 8: Install Hooks
After finishing Hooks (Part #4) into the
tracks, then put Joint Cover (Part H1) to
lock them.

page 12
Parts Required: M x4
K x1
#1
x12
N
10’x12’ assembly manual
MM
M
M
K
2
2
2
2
M
M M
K
M
#1
#1 #1
Upward View
#1
2
M
A
#1
X4
Step 9: Set up Corner Roof Bar
M
M
M
M
X4
#1
K
1. Connect the inside Roof Connector (Part K)
with the Corner Roof Bar (Part M)
using #1 screws.
2. Attach Corner Roof Bar (Part M) to
Poles (Part A ) using #1 screws as shown
in diagram.

N
N
NN
2
22
2
N x4
#1
x12
page 13
Parts Required:
N
10’x12’ assembly manual
X4
2. Attach Roof Bar (Part N) to Beams using
#1 screws as shown in diagram.
X4
N
2
#1
N
N
N N
K
Upward View
#1
#1
#1 #1
1. Connect Roof Bar (Part N) to Inside Roof
Connector (Part K)using #1 screws as
shown in diagram.
#1
Step 10: Set up Roof Bar

P x2
R x4
Q x2
#1
x4
Q
P
page 14
Parts Required:
N
10’x12’ assembly manual
Attach Finishing Bar (Part P, Q) with
Finish End (Part R) using #1 screws to Corner
Roof Bar (Part M) as shown in the diagram.
Step 11: Set up Finishing Bar
PP
Q
Q
K
Upward View
X4
P
#1
Q
R
M

V3
V1 V2
V4 V5 V6
page 1510’x12’ assembly manual
Parts Required:
V1 V2 V3 V4
ZX8
Z1 X4
X4
Z2
V5 V6
X2
H3 x1
Z
Z1
Z2
STEP 12:Snap Brackets
Snap Bracket (Part Z, Z1, Z2) to roof panel edges as shown in the diagram.
(with snaps facing upwards)
Tips:
1. Wearing protective gloves is recommended.
2. To prevent Z-Clips (plastic brackets) from sliding off prior to assembly, apply
double-sided adhesive tape (Part H3) to the underside (bottom) edge of the roof
panels where the brackets (Part Z, Z1, Z2) are supposed to attach.
3. You can use super glue (not included) to attach the brackets to the roof panel if
the double-sided tape doesn't work for you.

page 16
10’x12’ assembly manual
Parts Required:
R x4
T x2
T1 x2
#1
x8
#1
#1
#1
V3
V1
V1
V2
V4 V5 V6
V6
R
RR
R
T1
T
T
T1
V2
V5 V4 V3
R#1 #1
#1
T1
T
V1 V2 V3 V4 V5 V6
STEP 13: Assemble Roof Panels
1. Insert Roof Panels (Part v1, v2, v3, v4, v5, v6) to upper roof as shown in diagram.
2. Attach Finishing Bars (Part T, T1) to upper roof with Finish End (Part R) using #1 screws as shown
in diagram.

page 1710’x12’ assembly manual
Parts Required:
K1 x1 #1
x2
Upward View
K
K1
#1#1
STEP 14: Connect Outside Roof Connector
Connect Outside Roof Connector (Part K1) to Inside Roof (Part K) using #1 screws
as shown in the diagram.

page 18
10’x12’ assembly manual
Parts Required: #1
x24
U x4
U0 x4
U4 x4
U3 x4
是
U0
U0
U0
U0
U
U
U
U
U3
U4
#1 #1
X4 X4
STEP 15: Connect Solidifying Bars
Attach Solidifying Bars ( Part U0,U) to roof bar or corner roof bar using Iron Angle (Part U3, U4) and
#1 screws as shown in the diagram.
NOTE:
If the holes on Solidifying Bar (part U0, U) and the
hole of the roof panel cannot be aligned, adjust or
loosen #1 screws until the screws of the roof panel
fall in place.
