KDS-EN6, KDS-DEC6 –Introduction
2
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and affordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Overview
This document describes the commands that can be used for KDS-6 console for managing
USB. KDS-6 uses Linux OS and the console is operated by a BusyBox shell. API supports
KDS-6 firmware versions 7.2 and above.
Defaults:
•Telnet port: 24.
•User name: "admin"
•Password: “admin” to log in.
Terms
•Commands starting with "$" –Console commands executed under the Linux shell
console. The default value of multicast IP (multicast_ip) is 225.0.10x.xxx. Please use this
multicast_ip value.
•The ‘ast_send_event -1 xxx’ command has a new shortcut named ‘e’. All of the
following ‘ast_send_evnt -1 xxx’ commands can be replaced with the shortcut command
like ‘e xxx’. They are exactly the same.
•USBoIP (USB over IP) extension function.
A ‘transparent’ type of ‘USB over IP’ extension function. Comparing to ‘KMoIP’ which is
‘emulation’ type.
•KMoIP (Keyboard/Mouse over IP) extension function.
A USB extension, but uses ‘emulation’ technology instead of ‘transparent’ USBoIP,
optimized for USB Interrupt mode of work, guarantee quick responses.
•Host - KDS-EN6
•Client –KDS-DEC6

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Introduction
3
Command Syntax Conventions
Following table describes the syntax used with the commands in this document.
Convention
Description
boldface
Commands and keywords.
italic
Command input that is supplied by you.
[x]
Keywords or parameters that appear within square brackets are optional.
{x}
Keywords or parameters within braces must be entered.
x|y
Keywords or parameters separated by a vertical bar require you to choose one option.
x||y
Keywords or parameters separated by a double vertical bar allow you to choose any or
all the options.
All commands and parameters are case sensitive.
“/ # “ in a command example refers to a command prompt and is not part of the command.
To access the console using Telnet
Every KDS-6 host/client FW has Telnet and a Telnet client built in. A developer can use KDS-
6's Telnet client to connect to any other KDS-6 board or write their own program using Telnet
protocol to connect to any KDS-6 board through the Ethernet network.
•Default is Telnet port 24.
•Use "root" to log in.
•No password is required.
Astparam APIs Overview
KDS-6 series firmware includes many firmware features that are configurable. Most of the
configuration is done by the “Configuration APIs” (called “Astparam”). Astparam is the console
command to access these system configurations. We also name these system configuration
as Astparam.
Astparam can be saved in flash ROM. So that system configuration is not lost after a system
power failure.
The Astparam format is simply a key=value string pair. Both the “key” and “value” are ANSI
strings and case sensitive. The firmware decides how to use it. The firmware does not
validate the Astparam, so any typed error could cause unexpected results.
All configuration modifications are saved in RAM until astparam save command is called.

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Accessing Astparam
4
Accessing Astparam
The most fundamental and powerful way to access Astparam is through the Astparam
Console API command. Most alternative approaches are just a wrap of Astparam commands.
To learn more about Console API commands and how to use console APIs, see Console
APIs on page 5) or reference the “Console APIs v2” document.
To use Astparam:
$ astparam OPTIONS [KEY] [VALUE]
OPTIONS:
•g: read from RW partition cache file. [KEY] is required.
•s: write to RW partition cache file (not saved to flash ROM yet). [KEY] and [VALUE] are
required. If [VALUE] is empty the [KEY] is removed.
•flush: clear all settings in RW partition cache file including random generated MAC
address. "./astparam save" is needed to clear all settings in flash ROM.
•dump: dump all parameters in RW partition cache file.
•save: save all parameters in RW partition cache file into flash ROM.
Start/Stop KMoIP [KDS-DEC6]
In order to manage KMoIP use np_kmoip Astparam:
Key
Description
Value (bold is FW default)
Decoder/Encoder
no_kmoip
Enable/disable KMoIP function.
y: disable KMoIP
n: enable KMoIP
Decoder/Encoder
Syntax [Start]
>>astparam s no_kmoip n
Syntax [Stop]
>>astparam s no_kmoip y
Usage Information:
•This command is for KMoIP.
•This command is used for runtime control.

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Console APIs
5
Console APIs
Switch Channel [KDS-DEC6]
Command client to connect to a specified channel. For API backward compatibility and easier
usage, this command has 3 syntax formats. Channel can be specified by channel number (ch-
select) or host’s ip address (host-ip-addr).
Syntax [legacy, refresh current connection] e e_reconnect
Syntax [specify channel, apply to all services] e e_reconnect:: {ch-select|host-ip-addr}
Parameters
•ch-select:
▪Enter 4 digit decimal number from 0000 to 9999. It must be in 4 digit format
prepending with 0.
Example: 0000, 0001, 0100, 1000, 3456, 1342, 8888, 9999….
▪Default value: Determined from on-board 4-bits DIP switch. Since it is 4-bits 0 or 1, it
can only represent 16 channels in total. They are 0000, 0001, 0010, 0011, 0100,
0101,..., 1111. Default values are also interpreted as decimal number instead of
binary value.
•host-ip-addr:
▪Enter an IP address in dotted decimal format. Used to specify the host’s IP address
to connect to.
Example: 169.254.11.22
▪{{Z}|{v||u||a| }}:
Used to specify which function to apply.
v: video over IP
u: USB over IP
a: Audio over IP
Z: all features except video over IP
Usage Information
•Command supports ch-select from 0000 to 9999, which means there are maximum
10000 host channels can be used.
•To simplify configuration process, FW will automatically map
•‘channel’ to ‘multicast IP’. Users don’t have to specify ‘multicast IP’.
•For a trick to improve video switching time, please see Ex5 in following examples
section.

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Console APIs
6
Version History
FW >= A7.0.0
Examples
Ex1: Start connect all services to ‘current’ channel. ‘current’ channel is by default got from on-
board 4-bits DIP switch. Only this command triggers FW to re-read 4-bits DIP switch value.
/ # e e_reconnect
/ #
Ex2: Start connect all services to channel ‘9810’.
/#e e_reconnect::9810
/ #
Ex3: Above command equals to following command:
/#e e_reconnect::9810::Z
/ #
Ex4: Start connect ‘video over IP’ to channel ‘9810’. The others use ‘current’ channel.
/#e e_reconnect::9810::v
/ #
Ex5: Use following command (without specifying ‘functions’) can switch video under only 1
second.
/#e e_reconnect::1222
/ #
Ex8: Connect ‘USB over IP’ to ‘169.254.2.3’
/ # e e_reconnect::169.254.2.3::u
/ #
"Switchto X", where X=Channel number command is a legacy command being used for
switch channel. It is still being supported but we strongly encourage to use e_reconnect
command instead. Its support will be discontinued in the next KDS-6 major release.

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Console APIs
7
Stop Link [KDS-DEC6]
Used to stop services.
Syntax [stop all] e e_stop_link
Usage Information
•All services will be stopped.
•Client’s ‘e_stop_link’ state will NOT persist between client reboot.
Version History
FW >= A7.0.0
Examples
Ex1: Stop services.
/#e e_stop_link
/ #
Get Video Manager State
Syntax lmparam g STATE
Result
•Encoder
▪s_init: System is under initialization.
▪s_idle: System is idle. Services are stopped.
▪s_attaching: Services are started, but no client attached or no video source.
▪s_srv_on: Services are started.
▪s_error: Fatal error.
•Decoder
▪s_init: System is under initialization.
▪s_idle: System is idle. Services are stopped.
▪s_srv_on: Services are started.
▪s_error: fatal error.
Example
Ex1: Get video manager current state.
/# lmparam g STATE
s_srv_on
/#

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Console APIs
8
Get Attached Client IP [KDS-EN6]
Syntax lmparam g USB_CLIENT_IP
Result
•xxx.xxx.xxx.xxx: Return the IP address of last requested USBoIP client. If there is no one
requested, it returns ‘0.0.0.0’.
Usage Information
Version History
FW >= A7.0.0
Examples
Ex1: Get current USBoIP status. Current requested client’s IP is ‘169.254.10.167’.
/#lmparam g USB_CLIENT_IP
169.254.10.167/ #

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Example
9
Example

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Astparam APIs
10
Astparam APIs
Generic
Key
Description
Value
Host/
Client
multicast_on
Configure casting mode
y: Multicast mode
n: Unicast mode (default)
H/C
pwr_led_type
share_usb: (default)
H/C
en_log
‘y’ show debug message on debug
console.
y: Display (default)
n: Hide
H/C
ui_show_text
‘y’ to display diagnostic information on
the bottom of GUI. ‘n’ to hide it.
y: Display (default)
n: Hide
C
IP Network Setting
Key
Description
Value
Host/
Client
ip_mode
static:
dhcp:
autoip: (default)
H/C
ipaddr
H/C
netmask
H/C
gatewayip
H/C
hostname_prefix
H/C
hostnamebydipswitch
Use default hostname_id based on 4-
bits DIP switch.
When “hostnamebydipswitch” is “y”,
“hostname_id”’s default value is the
value of “ch_select” where default get
from on-board 4-bits DIP switch.
y: (host default)
n: (client default)
H/C
hostname_id
Overwrite “hostnamebydipswitch”.
[FW >= A7.0.0] In FW < A7.0.0, client
maps ch_select to host’s hostname in
order to find and connect to host. In
FW
Use new approach to discover host’s
IP address and host’s hostname is no
more bonded to channel resolution
process. Which means host’s
Astparam, hostname_id, can be any
value as user’s wish in FW >= 7.2.
However, FW by default will still
update hostname based on ch_select.
To set hostname_id other than
ch_select, please set
‘hostnamebydipswitch’ to ‘n’.
H/C

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Astparam APIs
11
Key
Description
Value
Host/
Client
hostname_tx_middle
[FW >= 7.2] The default host name of
a host is ‘ast3-gatewayXXXX’. This
parameter is used to change the ‘-
gateway’ part.
Both host and client need the
same setting.
Gateway (default)
H/C
hostname_rx_middle
[FW >= 7.2] The default host name of
a host is ‘ast3-
clientXXXXXXXXXXXX’. This
parameter is used to change the ‘-
client’ part.
Both host and client need the
same setting.
Client (default)
H/C
ch_select
Default channel value. Default value
from on-board 4-bits DIP switch.
[FW >= 7.2][client] Due to the support
of free routing, this value is only used
as the default value of following
‘ch_select_x’ parameters:
ch_select_v: video
ch_select_u: USB
ch_select_a: audio
ch_select_r: IR
ch_select_s: Serial
ch_select_p: GPIO/Push Button
[FW >= 7.2]
ch_select_c: CEC
Change ‘ch_select’ won’t affect
anything if ‘ch_select_x’ is already
specified.
H/C
ch_select_v
ch_select_u
ch_select_a
ch_select_r
ch_select_s
ch_select_p
ch_select_c
Like ‘ch_select’ but for specific
services.
Default value from ‘ch_select’:
ch_select_v: video
ch_select_u: USB
ch_select_a: audio
ch_select_r: IR
ch_select_s: Serial
ch_select_p: GPIO/Push Button
ch_select_c: CEC
C
multicast_leave_force
[FW >= 7.2] Auto send IGMP leave
packet when received multicast
packets that are not interested in.
Specify a value higher than 0 will
enable this feature. However, DO NOT
use a value that is too small. The
smaller the value the higher load
Ethernet switch may impact. Just use
default value should be good to go.
The specified time interval is used to
specify the minimum interval of
sending IGMP leave packet.
8000: Enable with 8000 ms
interval (default)
0: Disable
H/C

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Astparam APIs
12
Video over IP
Key
Description
Value
Host/
Client
v_output_timing_convert
Force specific video output timing.
Examples:
00000000: Pass-Through
80000010: Full HD 1080p60
8000001F: Full HD 1080p50
8000005F: Ultra HD 2160p30
8000005E: Ultra HD 2160p25
80000004: HD 720p60
81004048: WXGA 1366x768@60
81004021: WXGA+ 1440x900@60
81004032: WUXGA 1920x1200@60
8100401D: SXGA+ 1400x1050@60
0: Pass-Through (default)
C
v_src_unavailable_timeout
Wait for a v_src_unavailable_timeout
ms before entering power save. Set to
‘-1’ means never timeout.
10000: 10 seconds (default)
-1: never timeout
C
v_hdmi_hdr_mode
0: HDR passthrough (default)
1: Force HDR off
C
v_frame_rate
Used to control frame rate of video
encode.
Default set to ‘0’ means ‘no limitation’
use best effort. Set to other value will
limit the maximum video encode frame
rate. Valid range: 0,1,2,...,60.
Frame rate = (v_frame_rate / 60) *
input refresh rate For example, set to
‘30’ under 1080p60Hz: Frame rate =
(30/60) * 60 = 30 FPS
0: Best effort (default)
H
v_hdmi_force_rgb_output
‘v_hdmi_force_rgb_output’ is used to
change this behavior.
Default is ‘5’. You can use
‘osd_pic_on.sh’ under 2160p video
source.
Set to ‘1’ to use YUV format under
2160p case. Which can get better
picture quality but can’t use
‘osd_pic_on.sh’ under 2160p.
Set to ‘0’ means ‘pass-through’. Client
will output the same color format as
Host input. Note that doing this will
break features like ‘video fast
switching’ and ‘osd_pic_on.sh’.
5: all output RGB (default)
1: non-4K RGB, 4K YUV
0: pass-through
C

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Astparam APIs
13
Video Wall
Key
Description
Value
Host/
Client
en_video_wall
Enable video wall feature. Please also
check the value of Astparam,
web_ui_cfg, for the video wall Web UI.
y: enable
n: disable (default)
H/C
vw_rotate
Clock-wise rotate output picture.
Console API:
echo 3 >
/sys/devices/platform/display/vw_rotate
0: No rotate (default)
3: 180 degree
6: 270 degree
C
vw_stretch_type
Video wall stretching type:
1: Stretch out
2: Fit in
1: Stretch out
2: Fit in (default)
vw_ver
Specify video wall control APIs
version:
1: Default. Specify monitor layout and
auto calculate coordinate.
2: Manually specify coordinate. Easier
for mosaic style video wall
configuration.
Following Astparam will be used when
‘vw_ver’ is ‘2’:
•vw_v2_x1
•vw_v2_y1
•vw_v2_x2
1: Default
2: v2. Specify coordinate
C
HDCP
Key
Description
Value
Host/
Client
hdcp_always_on
Always enable HDCP 1.4
y: enable
n: disable (default)
H/C
hdcp_always_on_22
Always enable HDCP 2.2
y: enable
n: disable (default)
H/C
v_reject_hdcp
Don’t accept HDCP video source.
y: enable
n: disable (default)
H

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Astparam APIs
14
Audio
Key
Description
Value
Host/
Client
a_analog_in_vol
Set analog audio’s input volume.
Range from 0 to 100 %.
Default value ‘-1’ means use driver
built in default value.
This setting requires system reset to
take effect. To runtime change the
volume, please use following
command:
echo [value] >
/sys/devices/platform/150
0_i2s/analog_in_vol
-1,0,1,2 ~100
H/C
a_analog_out_vol
Set analog audio’s output volume.
Range from 0 to 100 %.
Default value ‘-1’ means use driver
builtin default value.
This setting requires system reset to
take effect. To runtime change the
volume, please use following
command:
echo [value] >
/sys/devices/platform/150
0_i2s/analog_out_vol
-1,0,1,2 ~100
H/C
IR over IP
Key
Description
Value
Host/
Client
no_ir
This is a global IR over IP
enable/disable setting.
y: Disable IRoIP
n: Enable IRoIP (default)
H/C
ir_guest_on
Enable IR guest mode feature
y: Enable (default)
n: Disable
H/C
ir_sw_decode
Enable IR software decode feature
y: Enable
n: Disable (default)
H/C
ir_sw_decode_nec_cfg
NEC remote control configuration of IR
software decode feature
The format is:
[device address]_[code for 0]_[code
for 1]_[code for 2]_.._[code for
8]_[code for 9]
each variable is decimal number and
valid device address is 0~65535
If device address is 65535 (default), IR
software decode function only displays
decoded NEC result includes device
address and button code. This is for
remote control learning purpose.
65535_0_1_2_3_4_5_6_7_8_9
C

Kramer Electronics Ltd.
KDS-EN6, KDS-DEC6 –Astparam APIs
15
Serial over IP
Key
Description
Value
Host/
Client
no_soip
y: Disable SoIP (default)
n: Enable SoIP
H/C
soip_type2 [FW < 7.2]
soip_type [FW >= 7.2]
Specify Serial over IP operating type.
[ FW >= 7.2] Introduced new
‘soip_type’. It will overwrite
‘soip_type2’’s setting if defined.
Otherwise, ‘soip_type’’s default value
comes from the setting of ‘soip_type2’.
y: Use type 2 (default)
n: Use type 1
H/C
1: Use type 1
2: Use type 2 (default)
3: Use type 3
H/C
soip_guest_on
y:
n: (default)
H/C
s0_baudrate
115200-8n1
H/C
soip_type2_token_timeout
soip_token_timeout
For type 2 only.
1,2,3... seconds
H/C
For type 2 and type 3. Default value
from ‘soip_type2_token_timeout’.
H/C
ch_select_soip2
ch_select_s
Default value from from ‘ch_select’.
N/A
C
Default SoIP channel.
CEC over IP
Key
Description
Value
Host/
Client
no_cec
This is a global CEC over IP
enable/disable setting.
CEC extension and guest mode are
both activated if CECoIP is enabled.
y: Disable CECoIP
n: Enable CECoIP (default)
H/C
cec_drv_option
32bits bitmap CEC driver options to
tweak driver behavior.
Default value is 0.
0x00000001: Disable CEC extension
0: (default)
H/C
All brand names, product names, and trademarks are the property of their respective owners.
