Kramer VM-1110xl User manual

Kramer Electronics, Ltd.
Preliminary
USER MANUAL
Model:
VM-1110xl
Balanced Audio Distributor

Contents
i
Contents
1 Introduction 1
2 Getting Started 1
2.1 Quick Start 2
3 Overview 3
4 Your VM-1110xl Balanced Audio Distributor 3
5 Installing the VM-1110xl in a Rack 6
6 Connecting Your VM-1110xl 6
6.1 Connecting a 1:10 Mono DA 7
6.2 Connecting a 2x1:5 Mono DA 8
6.3 Connecting a 1:5 Stereo DA 9
7 Technical Specifications 10
Figures
Figure 1: VM-1110xl Balanced Audio Distributor 4
Figure 2: Connecting the VM-1110xl as a 1:10 Mono DA 7
Figure 3: Connecting the VM-1110xl as a 2x1:5 Mono DA 8
Figure 4: Connecting the VM-1110xl as a 1:5 Stereo DA 9
Tables
Table 1: VM-1110xl Balanced Audio Distributor Features 5
Table 2: VM-1110xl Balanced Audio Distributor Technical Specifications 10

Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better!
Our 1,000-plus different models now appear in 11 groups1that are clearly
defined by function.
Thank you for purchasing your Kramer VM-1110xl Balanced Audio
Distributor.
This product is ideal for the following typical applications:
Audio duplication and production studios, delivering undiminished
quality duplicates
Recording studios
Broadcast studios for on-line signal distribution
Each package includes the following items:



VM-1110xl Balanced Audio Distributor
Power cord
This user manual
2 Getting Started
We recommend that you:



Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
Review the contents of this user manual
Use Kramer high-performance high-resolution cables
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 We recommend that you use only the power cord supplied with this device

KRAMER:SIMPLECREATIVETECHNOLOGY
Getting Started
2
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.

Overview
3
3 Overview
The VM-1110xl is a high performance balanced audio DA (distribution
amplifier) using XLR connectors. It can be configured as a mono (1:10 or
2x1:5) DA or as a stereo (1:5) DA.
The VM-1110xl features:
Front panel output level trimmer controls
Active Bi-FET amplifying circuitry that ensures hum-free, full-
bandwidth operation
A high-power discrete buffering system providing excellent
performance
To achieve the best performance:
Use only good quality connection cables1to avoid interference,
deterioration in signal quality due to poor matching, and elevated
noise levels (often associated with low quality cables).
Avoid interference from neighboring electrical appliances that
may adversely influence signal quality and position your Kramer
VM-1110xl away from moisture, excessive sunlight and dust
4 Your VM-1110xl Balanced Audio Distributor
Figure 1 and Table 1 define the VM-1110xl.
1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your VM-1110xl Balanced Audio Distributor
4
Figure 1: VM-1110xl Balanced Audio Distributor

Your VM-1110xl Balanced Audio Distributor
5
Table 1: VM-1110xl Balanced Audio Distributor Features
# Feature Function
1 Power LED Lights when the unit is powered on
2 1:10 / 2x1:5 Button Pushing in selects 2x1:5
1
, releasing selects 1:10
2
3 Level B Trimmer Adjusts
3
the output signal level for OUTPUT B
4 Level A Trimmer Adjusts
3
the output signal level for OUTPUT A
5 INPUT A XLR Female Connector Connects to the source A
6 INPUT B XLR Female Connector Connects to the source B
7 OUT A XLR Male Connector Connects to the acceptor A (from 1 to 5)
8 OUT B XLR Male Connector Connects to the acceptor B (from 1 to 5)
9 Power Connector with Fuse AC connector enabling power supply to the unit
10 ON/OFF Switch Illuminated switch for powering the unit
1 Splits inputs A and B to outputs 1A-5A and 1B-5B, respectively
2 Splits input A to all 10 outputs
3 Insert a screwdriver into the small hole and carefully rotate it, trimming the OUTPUT level

KRAMER:SIMPLECREATIVETECHNOLOGY
Installing the VM-1110xl in a Rack
6
5 Installing the VM-1110xl in a Rack
This section describes how to install the VM-1110xl in a rack.
Before Installing in a rack How to Rack Mount
Before installing in a rack, be sure that the environment is
within the recommended range:
Operating temperature range +5to +45C (41to 113F)
Operating humidity range 10 to 90% RHL, non-condensing
Storage temperature range -20to +70C (-4to 158F)
Storage humidity range 5 to 95% RHL, non-condensing

CAUTION!!
When installing on a 19" rack, avoid hazards by taking
care that:
1. It is located within the recommended environmental
conditions, as the operating ambient temperature of a
closed or multi unit rack assembly may exceed the
room ambient temperature.
2. Once rack mounted, enough air will still flow around
the machine.
3. The machine is placed straight in the correct
horizontal position.
4. You do not overload the circuit(s). When connecting
the machine to the supply circuit, overloading the
circuits might have a detrimental effect on overcurrent
protection and supply wiring. Refer to the appropriate
nameplate ratings for information. For example, for
fuse replacement, see the value printed on the
product label.
5. The machine is earthed (grounded) in a reliable way
and is connected only to an electricity socket with
grounding. Pay particular attention to situations where
electricity is supplied indirectly (when the power cord
is not plugged directly into the socket in the wall), for
example, when using an extension cable or a power
strip, and that you use only the power cord that is
supplied with the machine.
To rack-mount a machine:
1. Attach both ear brackets to the
machine. To do so, remove the
screws from each side of the
machine (3 on each side), and
replace those screws through the
ear brackets.
2. Place the ears of the machine
against the rack rails, and insert the
proper screws (not provided)
through each of the four holes in the
rack ears.
Note that:
In some models, the front panel
may feature built-in rack ears
Detachable rack ears can be
removed for desktop use
Always mount the machine in the
rack before you attach any cables
or connect the machine to the
power
If you are using a Kramer rack
adapter kit (for a machine that is not
19"), see the Rack Adapters user
manual for installation instructions
(you can download it at:
http://www.kramerelectronics.com)
6 Connecting Your VM-1110xl
You can connect your VM-1110xl Balanced Audio Distributor in one of
three ways:
1:10 mono DA, see section 6.1
2x1:5 mono DA, see section 6.2
1:5 stereo DA, see section 6.3

Connecting Your VM-1110xl
7
6.1 Connecting a 1:10 Mono DA
To connect1the VM-1110xl as a 1:10 mono DA, as the example in Figure 2
illustrates, do the following:
1. Connect one mono audio source (for example, a mono audio player) to
INPUT A on the rear panel.
2. Connect up to 10 audio acceptors2to the OUT connectors on the rear panel.
3. On the front panel, release the 1:10 / 2x1:5 button.
4. Connect the power cord to the electricity supply.
5. Switch on the VM-1110xl.
The audio input is distributed to the audio outputs.
Figure 2: Connecting the VM-1110xl as a 1:10 Mono DA
1 Switch OFF the power on each device before connecting it to your VM-1110xl. After connecting your VM-1110xl, switch on
its power and then switch on the power on each device
2 Not all outputs have to be connected

KRAMER:SIMPLECREATIVETECHNOLOGY
Connecting Your VM-1110xl
8
6.2 Connecting a 2x1:5 Mono DA
To connect
1
the VM-1110xl as a 2x1:5 mono DA, as the example in Figure
3illustrates, do the following:
1. Connect mono audio source A (for example, a mono audio player) to
INPUT A on the rear panel.
2. Connect mono audio source B (for example, a mono audio player) to
INPUT B on the rear panel.
3. Connect up to 10 audio acceptors
2
to the OUT connectors on the rear
panel. The A INPUT feeds to the A OUT connectors and the B INPUT
feeds to the B OUT connectors.
4. On the front panel, press IN the 1:10 / 2x1:5 button.
5. Connect the power cord to the electricity supply.
6. Switch on the VM-1110xl.
The audio input is distributed to the audio outputs.
Figure 3: Connecting the VM-1110xl as a 2x1:5 Mono DA
1 Switch OFF the power on each device before connecting it to your VM-1110xl. After connecting your VM-1110xl, switch on
its power and then switch on the power on each device
2 Not all outputs have to be connected

Connecting Your VM-1110xl
9
6.3 Connecting a 1:5 Stereo DA
To connect1the VM-1110xl as a 1:5 stereo DA, as the example in Figure 4
illustrates, do the following:
1. Connect one stereo audio source (for example, a stereo audio player) to
INPUT A (left channel) and INPUT B (right channel) on the rear panel.
2. Connect up to 5 audio acceptors2to the OUT connectors (left channels to
OUT A and right channels to OUT B) on the rear panel.
3. On the front panel, press IN the 1:10 / 2x1:5 button.
4. Connect the power cord to the electricity supply.
5. Switch on the VM-1110xl.
The audio input is distributed to the audio outputs.
Figure 4: Connecting the VM-1110xl as a 1:5 Stereo DA
1 Switch OFF the power on each device before connecting it to your VM-1110xl. After connecting your VM-1110xl, switch on
its power and then switch on the power on each device. Not all outputs need to be connected

KRAMER:SIMPLECREATIVETECHNOLOGY
Technical Specifications
10
7 Technical Specifications
The VM-1110xl technical specifications are shown in Table 2:
Table 2: VM-1110xl Balanced Audio Distributor Technical Specifications
1
INPUTS: 2 balanced audio +4dBu/50kon XLR (F) connectors
OUTPUTS: 10 balanced audio +4dBu/50on XLR (M) connectors
MAX. OUTPUT LEVEL: 23.8Vpp
BANDWIDTH (-3dB): >100kHz
S/N RATIO: 89.3dB
CROSSTALK: -78dB
CONTROLS: Level (x2): -0.7dB to +5.1dB, mode selector switches
COUPLING: AC (input); DC (output)
AUDIO THD + NOISE: 0.081%
AUDIO 2nd HARMONIC: 0.006%
POWER SOURCE: 230V AC, (115V AC U.S.A) 6VA
DIMENSIONS: 19" x 7" x 1U W, D, H, rack mountable
WEIGHT: 2.6kg (5.7lbs) approx
ACCESSORIES: Power cord
1 Specifications are subject to change without notice

11
LIMITED WARRANTY
WHO IS PROTECTED?
WHAT IS COVERED AND WHAT IS NOT COVERED
WHAT WE WILLPAY FOR AND WHAT WE WILL NOT PAY FOR
HOW YOU CAN GET WARRANTY SERVICE
LIMITATION OF IMPLIED WARRANTIES
EXCLUSION OF DAMAGES
CAUTION!
Kramer Electronics (hereafter ) warrants this product free from defects in material and workmanship under the
following terms.
Kramer
HOW LONG IS THE WARRANTY
Labor and parts are warranted for seven years from the date of the first customer purchase.
Only the first purchase customer may enforce this warranty.
We will pay labor and material expenses for covered items. We will not pay for the following:
The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall
not be liable for:
This warranty gives you specific legal rights, and you may also have other rights, which vary from place to place.
All products returned to Kramer for service must have prior approval. Thismay be obtained from your dealer.
This equipment has been tested to determine compliance with the requirements of:
EN-50081: "Electromagnetic compatibility (EMC);
generic emission standard.
Residential, commercial and lightindustry"
EN-50082: "Electromagnetic compatibility (EMC) generic immunity standard.
Part 1: Residential, commercial and light industryenvironment".
CFR-47: FCC* Rules and Regulations:
Part 15: “Radio frequency devices
Subpart B Unintentional radiators”
Except as below, this warranty covers all defects in material or workmanship in this product. The following are not covered
by the warranty:
1. Removal or installations charges.
2. Costs of
initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are the
responsibility of the Kramer dealerfrom whom the product was purchased.
3. Shipping charges.
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of warranty
coverage, and should be included in any shipment of the product. Please also include in any mailing a contact name,
company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length of this warranty.
1. Damage to other property caused by defects inthis product, damages basedupon inconvenience, loss of use of the product, loss
of time, commercial loss; or:
2. Any other damages, whether incidental, consequential or otherwise. Some countries may not allow limitations on how long an
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations and exclusions may not apply to you.
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of the manufacturer will void user authority to operate the
equipment.
Usethe supplied DC power supply to feed power to the machine.
Please use recommended interconnection cablesto connect the machine to other components.
1. Any product which is not distributed by Kramer, or which is not purchased from an authorized Kramer dealer.
2. Any product, on which the serial number has been defaced, modified or removed, or on which the WARRANTY VOID IF
TAMPERED sticker has been torn, reattached, removed or otherwise interfered with.
3. Damage, deterioration or malfunction resulting from:
i) Accident, misuse, abuse, neglect, fire, water, lightning or other actsof nature
ii) Product modification, or failure to followinstructions supplied with the product
iii) Repair or attempted repair by anyone not authorized by Kramer
iv) Any shipment of the product (claims must be presented to the carrier)
v) Removal or installationof the product
vi) Any other cause, which does not relate to a product defect
vii) Cartons, equipment enclosures, cables or accessories used in conjunction with the product
* FCCand CE approved using STP cable(for twisted pair products)
NOTE:
Part 1:

Kramer Electronics, Ltd.
Distributed by Solid Signal
www.solidsignal.com
P/N: 2900-001030 REV 2
Caution
Safety Warning:
Disconnect the unit from the power supply before
opening/servicing.
PN:
2900- 001030 Rev:
2
