Kreg KFPCHB User manual

STEP 1:
Set Up Your Pocket-Hole Jig
Scan the QR to watch a video for this step
AUse Material Thickness Gauge / Hex Wrench to measure material thickness (¾").
BSet jig material thickness to ¾".
Note: You can use most Kreg Pocket-Hole Jigs for this project. Be sure to set up and
use your jig according to the manufacturer’s instructions, and follow this guide for
proper hole placement.
CSet drill bit stop collar to ¾" (loosen and tighten stop collar with Hex Wrench).
A B C
WOODWORKING KIT CORNHOLE BOARDS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Included in Bundle
7Pocket-Hole Jig 520PRO
8Versa-GripTM Clamp - 24"
92" Classic Face Clamp
10 Material Thickness Gauge
11 #2 Driver Bit
12 Easy-Set Drill Bit and Stop Collar
13 2 1/2" Pocket-Hole Screws
14 1 1/4" Pocket-Hole Screws
Base Kit
1 Side Rail
2Cross Brace
3Top
4Leg Brace
5Leg
6Cornhole Board Hardware
BEFORE YOU
GET STARTED
We want to make sure
have you the guidance
and resources you
need to be successful
with this project.
Simply scan the QR
code below for tips and
tricks on setting up
your jig, drilling pocket
holes, and more.
WARNING:
!
Drilling, sawing, sanding or machining wood products can expose you to wood dust, a substance known to the State of
California to cause cancer. Avoid inhaling wood dust or use a dust mask or other safeguards for personal protection. For more information
go to www.P65Warnings.ca.gov/wood.
WARNING:
!
Improper assembly or excessive weight applied to the nished product could result in injury. Follow all instructions provided
for assembly. Kreg is not responsible for injuries as a result of improper assembly or use.
WARNING:
!
Always wear personal protective equipment certied as such, including safety glasses, hearing protection, and respiratory
protection. When using a power tool, always follow the manufacturer’s personal protection equipment requirements. Gloves are
recommended for handling unnished wood products.

STEP 2:
Drill Pocket-Holes in Cross Braces (x8)
Scan the QR to watch a video for this step
STEP 3:
Drill Pocket-Holes in Leg Braces (x2)
Scan the QR to watch a video for this step
BA
A
C
B
D
E F
C
AClamp Cross Brace so it is centered in the jig.
BDrill two pocket holes using the outside drill guides.
CFlip Cross Brace 180° in the jig and repeat steps A-B on the
other end of the Cross Brace.
DAlign outside edge of jig to inside edge of existing pocket
holes, ensuring end stop and drill pocket hole. Repeat on the
other end of the Cross Brace.
EAlign jig so one drill guide hole is centered on Cross Brace
and drill one pocket hole.
FRepeat steps A-E for remaining Cross Braces.
AClamp Leg Brace in jig so outside drill guides are
approximately 1" from outside edges of board.
BDrill two pocket holes using the outside drill guides.
CFlip Leg Brace 180° in the jig.
DRepeat A-B on the other end of the Leg Brace.
ERepeat A-D for second Leg Brace.

STEP 4:
Assemble Frame
Scan the QR to watch a video for this step
A
H
B C D
E F
AOptional: Workpiece edges and pocket holes can be sanded
prior to assembly.
B AlignedgeofrstCrossBracewithguidelinesofboth
Side Rails. Important: Ensure all pocket holes are facing the
correct direction, as indicated in photo B.
C ClampsiderailstorstCrossBrace,checkingtomakesure
alignment with guide line is consistent.
Important: Position pieces so that pocket-holes point in
toward the center.
DUse #2 driver bit to drive 1 ¼" pocket-hole screws into
Cross Brace.
Tip: Adjust drill clutch for driving screws. Do NOT use an
impact driver, as this may lead to over-driven screws or
stripped screw heads.
EPlace second Cross Brace so it aligns with next guide line
indicated on Side Rails.
FUse #2 driver bit to drive 1 ¼" pocket-hole screws into the
Cross Brace.
GPlace remaining Cross Braces so they align with remaining
guide lines and attach with #2 driver bit and 1 ¼" pocket-
hole screws.
HEnsure assembled frame matches photo H.
IRepeat A - H for second Frame Assembly.
G
APlace Frame Assembly on Top and position so that corners
of Frame Assembly align with guide lines located at each
corner of Top.
BClamp the Top and Frame Assembly to the work surface.
CUse #2 driver bit to drive 1 ¼" pocket-hole screws into Cross
Braces.
Tip: Adjust drill clutch for driving screws. Do NOT use an
impact driver, as this may lead to over-driven screws or
stripped screw heads.
DAttach the Cross Braces by driving 1 ¼" pocket-hole screws,
starting with the pocket holes in one corner then moving
to the opposite corner. After all four corners are attached,
attach remaining Cross Braces with pocket-hole screws.
ERepeat A - D for second Top and Frame Assembly.
STEP 5:
Attach Top to Frame (x2)
Scan the QR to watch a video for this step
A B C D

STEP 6:
Assemble and Attach Legs (x4)
Scan the QR to watch a video for this step
ABCD
E
AAlign edge of Leg Brace with guide line on Leg as shown in
photo A.
BUse #2 driver bit to drive 1 ¼" pocket-hole screws into Leg
Brace.
Tip: Adjust drill clutch for driving screws. Do NOT use an
impact driver, as this may lead to over-driven screws or
stripped screw heads.
CRepate A - B for second Leg.
DArrange included Bolt, Washers, and Nut as shown
in photo D.
EInsert the rounded end of Leg Brace into Frame and line
up the hole in the Frame with the hole in the Leg. Slide bolt
through bolt hole and secure using the washers and nut.
Note: Place one washer between the bolt head and Side Rail,
Side Rail and Leg, and the nut and Leg. Tighten nut using a
pair of combination or adjustable wrenches.
Tip: Avoid under- or over-tightening the nut, so the Leg
Assembly moves freely but stays in place when folded up.
FRepeat steps for second assembly.
STEP 7:
Customize it!
Scan the QR to watch a video for this step
A Onceyou’renishedaddingyourowndecorativetouches,
take a photo and post it with the #builtwithkreg hashtag to
show your work and see what others are building with Kreg.
NOTE: For best results, seal top and edges of cornhole boards.
The material used is a composite that can be vulnerable to
water damage if not properly sealed. For tips on how to apply
sealer to edges, please visit: https://learn.kregtool.com/learn/
make-painted-plywood-edges-look-great/.
