Krone Fortima F 1250 MC User manual
Original operating instructions
Round baler
Fortima F 1250 (MC)
Fortima F 1600 (MC) Fortima V 1500 (MC)
Fortima V 1800 (MC)
(from serial no.: 976 393)
Order no.: 150 000 135 10 en
01.02.2018
Table of Contents
2
Pos: 1 /BA/Konfor mitätserklärungen/ Rundballenpressen/For tima F 1250 (MC), F1600 (MC), V1500 (MC), V1800 (MC) @ 506\m od_1499767662812_78.doc x @ 3479896 @ @ 1
CV0
EC Declaration of Conformity
We
Maschinenfabrik Krone Beteiligungs-GmbH
Heinrich-Krone-Str. 10, D-48480 Spelle
hereby declare as manufacturer of the product named below, on our sole responsibility,
that the Machine: Round Baler
Type: Fortima F 1250, Fortima F 1250 MC
Fortima F 1600, Fortima F 1600 MC
Fortima V 1500, Fortima V 1500 MC
Fortima V 1800, Fortima V 1800 MC
to which this declaration refers is in compliance with the following relevant provisions of:
• EC Directive 2006/42/CE (machines),
• EU Directive 2014/30/EU (EMC). Within the meaning of the Directive the
harmonised standard EN ISO 14982:2009 was taken as a basis.
The signing Managing Director is authorised to compile the technical documents.
Spelle, 01.08.2017
Dr.-Ing. Josef Horstmann
(Managing Director, Design & Development)
Year of manufacture: Machine no.:
