Krone COMPRIMAF F 125 Installation instructions

Round Baler
COMPRIMAF F 125 /COMPRIMAF F 125 XC
COMPRIMAF F 155 /COMPRIMAF F 1551 XC
COMPRIMAF V 150 /COMPRIMAF V 1501 XC
COMPRIMAF V 180 /COMPRIMAF V 1801 XC
Original operating manual
150 000 126 02 EN
(from machine no. 791 259)

Dear Customer:
You have now received operating instructions for the KRONE
product which you have purchased.
These operating instructions contain important information for
the proper use and safe operation of the machine.
If these operating instructions should for any reason become
wholly or partially unusable, you can obtain replacement
operating instructions for your machine by stating the number
given on the other side.
EC Declaration of Conformity
We,
hereby declare as manufacturer of the product named below, on our sole responsibility,
that the
Machine: Krone Round Baler
Type / Types: COMPRIMA F 125 / COMPRIMA F 125 XC
COMPRIMA F 155 / COMPRIMA F 155 XC
COMPRIMA V 150 / COMPRIMA V 150 XC
COMPRIMA V 180 / COMPRIMA V 180 XC
to which this declaration refers is in compliance with the relevant provisions of
EC Directive 2006/42/EC (Machinery) and EC Directive 2004/108/EC (EMC)
The signing Managing Director is authorised to compile the technical documents.
Spelle, 19.04.10
Dr.-Ing. Josef Horstmann
(Managing Director, Design and Development)
Maschinenfabrik Bernard Krone GmbH
Heinrich-Krone-Str. 10, D-48480 Spelle
Year of manufacture: Machine No.:

Contents
1
Contents
1 General Aspects.................................................................................. I -1
1.1 Intended Use ........................................................................................................... I -1
1.2 Technical Data ......................................................................................................... I -1
1.2.1 General Aspects ...................................................................................................... I -1
1.2.2 Manufacturer’s Address ........................................................................................... I -1
1.2.3 Declaration .............................................................................................................. I -1
1.2.4 Identification ............................................................................................................ I -1
1.2.5 Data Required for Questions and Orders ................................................................ I -1
1.2.6 Operation in Accordance with Intended Use ........................................................... I -2
1.2.7 General Technical Data ........................................................................................... I -2
1.2.8 Technical Data - COMPRIMA F 125/ COMPRIMA F 125 XC .................................. I -3
1.2.9 Technical Data - COMPRIMA F 155/ COMPRIMA F 155 XC .................................. I -4
1.2.10 Technical Data - COMPRIMA V 150 / COMPRIMA V 150 XC................................. I -5
1.2.11 Technical Data - COMPRIMA V 180 / COMPRIMA V 180 XC................................. I -6
2 Safety .................................................................................................. II -1
2.1 Identifying important Information in the Operating Instructions ............................. II -1
2.2 Safety Instructions and Accident Prevention Regulations ...................................... II -1
2.2.1 Personnel Qualification and Training....................................................................... II -1
2.2.2 Dangers in the Case of Non-Compliance with the Safety iInstructions .................. II -1
2.2.3 Safety-Conscious Working ...................................................................................... II -1
2.2.4 Safety Instructions and Accident Prevention Regulations ...................................... II -2
2.2.5 Hitched Implements................................................................................................ II -3
2.2.6 PTO Operation ....................................................................................................... II -3
2.2.7 Hydraulic System.................................................................................................... II -3
2.2.8 Tyres ....................................................................................................................... II -4
2.2.9 Maintenance ........................................................................................................... II -4
2.2.10 Unauthorised Modifications and Spare Parts Production ....................................... II -4
2.2.11 Prohibited Modes of Operation............................................................................... II -4
2.3 Introduction ............................................................................................................ II -5
2.3.1 Location of Safety Stickers on the Machine
(COMPRIMA F 125 ; COMPRIMA F155) ............................................................... II -5
2.3.2 Location of General Information Labels on the Machine
(COMPRIMA F 125 ; COMPRIMA F155) ............................................................... II -8
2.3.3 Location of Safety Stickers on the Machine
(COMPRIMA V 150; COMPRIMA V 180) ............................................................. II -10
2.3.4 Location of General Information Labels on the Machine
(COMPRIMA V 150; COMPRIMA V 180) ............................................................. II -14
3 Before and After Use ........................................................................ III -1
3.1 Commissioning ...................................................................................................... III -1
3.2 Hitching.................................................................................................................. III -2
3.2.1 Connecting the Hydraulic Hoses
(COMPRIMA F 125; F 155) .................................................................................. III -2
3.2.2 Connecting the Hydraulic Hoses
(COMPRIMA V150; V 180) ................................................................................... III -3

Contents
2
3.2.3 PTO Shaft.............................................................................................................. III -3
3.2.4 Electrical Supply .................................................................................................... III -4
3.2.5 Use Safety Chain................................................................................................... III -4
3.2.6 Compressed Air Connections for the Air Brake ..................................................... III -4
3.2.7 Hydraulic brake (Export) ....................................................................................... III -5
3.2.8 Hydraulic brake (auxiliary brake) ........................................................................... III -5
3.2.9 Net brake ............................................................................................................... III -5
3.2.10 Running-in Period .................................................................................................. III -6
3.3 Road Driving .......................................................................................................... III -7
3.4 Unhitching.............................................................................................................. III -8
4 Use ..................................................................................................... IV -1
4.1 Adjustments before starting Work ......................................................................... IV -1
4.2 Forward Speed and PTO Speed............................................................................ IV -2
4.3 Filling the Bale Chamber ....................................................................................... IV -3
4.3.1 Pressure on the side walls..................................................................................... IV -3
4.4 Wrapping and Depositing Bales ............................................................................ IV -4
4.5 Driving with bale ejector COMPRIMA V 150/V 180 /V150 XC/V 180 XC............... IV -5
4.6 Before pressing
(COMPRIMA V 150, V 180)................................................................................... IV -5
4.6.1 After pressing
(COMPRIMA V 150, V 180)................................................................................... IV -5
4.7 Overload Protection for Drives .............................................................................. IV -6
4.7.1 Drive chain for wide pick-up with cam-type ........................................................... IV -6
5 Basic Settings and Operation ...........................................................V -1
5.1 Special Safety Instructions ..................................................................................... V -1
5.2 Pick-up ................................................................................................................... V -1
5.2.1 Roll-type crop guard (Special Equipment) .............................................................. V -1
5.2.2 Bearing Pressure Relief of the Pick-up................................................................... V -2
5.3 Cutting System ....................................................................................................... V -3
5.3.1 Special Safety Instructions ..................................................................................... V -3
5.3.2 General Aspects ..................................................................................................... V -3
5.3.3 Adjusting the Cutting Length .................................................................................. V -3
5.3.4 Clogging of the Cutting System .............................................................................. V -5
5.3.5 Changing Cutters.................................................................................................... V -6
5.4 Compression Pressure Setting
(COMPRIMA F 125; F 155) .................................................................................... V -9
5.4.1 Setting the Bale Diameter
(COMPRIMA F 155) ............................................................................................... V -9
5.5 Adjusting baling diameter
(COMPRIMA V 150 ,V 180)
(Medium) .............................................................................................................. V -10
5.5.1 Compression pressure setting
(COMPRIMA V 150 ,V 180) ................................................................................. V -11
5.5.2 Setting bale diameter indicator
(COMPRIMA V 150 ,V 180)(Medium) .................................................................. V -12
5.6 Setting the Rear Flap Locking Mechanism (Medium)........................................... V -14

Contents
3
5.7 Setting of the Bale Firmness Indicator (Medium) ................................................. V -14
5.8 Net Wrapping........................................................................................................ V -15
5.8.1 Special Safety Instructions ................................................................................... V -15
5.8.2 Components ......................................................................................................... V -15
5.8.3 General Aspects ................................................................................................... V -15
5.8.4 Inserting the Netting Roll ...................................................................................... V -16
5.8.4.1 Feed the net ......................................................................................................... V -17
5.8.5 Setting the Net Brake ........................................................................................... V -18
5.8.6 Adjusting the Cut-off Position ............................................................................... V -20
5.8.7 Adjusting the Feed Position .................................................................................. V -20
5.8.8 Tying position ........................................................................................................ V -21
5.8.9 Setting the Number of Net Winds ......................................................................... V -21
5.9 Adjusting Belt Motion for the Rear Floor Conveyor (COMPRIMA V 150 / V180).. V -22
5.10 Bale Counter ........................................................................................................ V -23
5.11 Clamping the Floor Conveyor (COMPRIMA F 125) ............................................. V -23
5.12 Adjusting soft core ................................................................................................ V -24
5.13 Central Chain Lubrication
(Special Equipment) ............................................................................................. V -26
5.13.1 Oil flow rate setting (cam pump) .......................................................................... V -27
5.13.2 "Central chain lubrication" diagram ....................................................................... V -27
7 Medium Control Unit ........................................................................ VII -1
7.1 General Description .............................................................................................. VII -1
7.2 Mounting............................................................................................................... VII -2
7.3 Control Unit ..........................................................................................................VII -3
7.4 Operational Readiness ......................................................................................... VII -4
7.4.1 Setting Net Winds ................................................................................................. VII -4
7.5 Baling pressure display (COMPRIMA F 125; F155) or bale diameter (COMPRIMA V
150; V 180) ........................................................................................................... VII -5
7.5.1 Operation of Tying (Manual Mode) ....................................................................... VII -5
7.5.2 Operation of Tying (Automatic Mode) ................................................................... VII -6
7.6 Settings and Diagnostics ...................................................................................... VII -6
7.6.1 Automatic Blocking Time Setting .......................................................................... VII -6
7.6.2 Motor Position Setting (Net) .................................................................................VII -7
7.6.2.1 Setting the feed position ....................................................................................... VII -7
7.6.2.2 Setting the cut-off position.................................................................................... VII -7
7.6.2.3 Approaching the Tying Position ............................................................................. VII -8
7.6.3 Sensor Test / Digital.............................................................................................. VII -8
7.6.4 Sensor Test / Analog ............................................................................................ VII -9
7.6.5 Show version number ........................................................................................... VII -9
7.6.6 Acoustic Signals and their Meaning.................................................................... VII -10
7.6.6.1 Special Safety Instructions .................................................................................VII -10
8 Comfort Control Unit ...................................................................... VIII -1
8.1 General Description ............................................................................................. VIII -1
8.2 Attaching ............................................................................................................. VIII -2
8.3 Control Unit .........................................................................................................VIII -3
8.4 Operational Readiness ........................................................................................VIII -4

Contents
4
8.5 Manual Mode.......................................................................................................VIII -5
8.5.1 Basic Screen for Manual Mode ...........................................................................VIII -5
8.6 Automatic Mode ..................................................................................................VIII -7
8.7 Messages ............................................................................................................VIII -8
8.8 Menu Level ..........................................................................................................VIII -9
8.8.1 Bringing up a Menu Level ....................................................................................VIII -9
8.9 Main Menu 1 "Settings" ..................................................................................... VIII -10
8.9.1 Menu 1-1 "Contrast" ..........................................................................................VIII -11
8.9.2 Menu 1-2 "Bale diameter"
(only for F 155) ................................................................................................. VIII -12
8.9.3 Menu 1-3 "Number of net winds".......................................................................VIII -13
8.9.4 Menu 1-4 "Sensitivity of direction display" ......................................................... VIII -14
8.9.5 Menu 1-5 "Pre-signalling" .................................................................................. VIII -15
8.9.6 Menu 1-6 "Filling correction" ..............................................................................VIII -16
8.9.7 Menu 1-9 "Tying start pulses"............................................................................ VIII -17
8.10 Main Menu 2 "Counters" ...................................................................................VIII -18
8.10.1 Menu 2-1 "Customer counters" .........................................................................VIII -18
8.10.2 Menu 2-2 "Total bale counters" ......................................................................... VIII -20
8.11 Main Menu 3 „Manual Operation“ ..................................................................... VIII -20
8.12 Main Menu 4 "Service" ...................................................................................... VIII -22
8.12.1 Menu 4-2 "Manual sensor test" ......................................................................... VIII -22
8.12.2 Menu 4-4 "Manual actuator test" .......................................................................VIII -27
8.12.3 Menu 4-7 "Position Motor" .................................................................................VIII -29
8.13 Main Menu 5 "Info" ............................................................................................VIII -30
8.13.1 Main Menu 6 "Technician" .................................................................................VIII -30
8.14 Alarm messages................................................................................................ VIII -31
8.14.1 Warnings and Messages ...................................................................................VIII -31
8.14.2 Physical alarm messages ..................................................................................VIII -32
8.14.3 General alarm messages ..................................................................................VIII -33
8.14.4 Acoustic warnings..............................................................................................VIII -33
9 Maintenance ...................................................................................... IX -1
9.1 Adjustments........................................................................................................... IX -1
9.1.1 Special Safety Instructions .................................................................................... IX -1
9.1.2 Adjusting the Scraper Bar In Relation to the Upper Spiral Roller .......................... IX -1
9.1.3 Releasing the tension on the floor conveyor (COMPRIMA F 155) ........................ IX -2
9.2 Position of the Sensors (right side of the machine COMPRIMA F 125/ F 155) ... IX -3
9.2.1 Position of the Sensors (Left side of the machine COMPRIMA F 125/ F 155) .... IX -4
9.2.2 Position of the Sensors (right side of the machine COMPRIMA V 150 / V 180) .. IX -5
9.2.3 Position of the Sensors (Left side of the machine COMPRIMA V 150 / V 180) ... IX -6
9.2.4 Adjusting the sensors ............................................................................................ IX -7
9.3 Maintenance Tasks ................................................................................................ IX -8
9.3.1 Special Safety Instructions .................................................................................... IX -8
9.3.2 General Information............................................................................................... IX -8
9.3.3 Maintenance at specified intervals ........................................................................ IX -9
9.3.4 Checking the brake settings ................................................................................ IX -10
9.3.5 Setting the brakes with ordinary brake lever ....................................................... IX -10

Contents
5
9.3.6 Setting the brakes with manual linkage setter ..................................................... IX -11
9.3.7 Tandem axle ........................................................................................................ IX -13
9.3.8 Tyres .................................................................................................................... IX -14
9.3.9 Tyre air pressure ................................................................................................. IX -14
9.3.10 Drawbar ............................................................................................................... IX -15
9.3.11 Screw connections on front and rear floor conveyors ......................................... IX -15
9.3.12 Novo Grip belt on floor conveyor ......................................................................... IX -15
9.3.13 Checking the safety rollers of single blade locking device ................................... IX -15
9.3.14 Main Drive Gear Box........................................................................................... IX -16
9.4 Drive Chains ........................................................................................................ IX -16
9.4.1 Special Safety Instructions .................................................................................. IX -16
9.4.2 General Information............................................................................................. IX -16
9.4.3 Tensioning the Drive Chains ................................................................................ IX -17
9.4.3.1 Front Floor Conveyor Drive................................................................................. IX -17
9.4.3.2 Rear Floor Conveyor Drive
(COMPRIMA V150, V180) ................................................................................. IX -17
9.4.3.3 Roller Drive .......................................................................................................... IX -18
9.4.3.4 Cutting Roller, Feed Rotor, Pick-up ..................................................................... IX -19
9.4.3.5 Main Pick-up Drive / Pick-up Drive ...................................................................... IX -20
9.4.3.6 Left Auger Conveyor Drive.................................................................................. IX -20
9.5 Hydraulic System................................................................................................. IX -21
9.5.1 Special Safety Instructions .................................................................................. IX -21
9.5.2 General Information............................................................................................. IX -21
9.5.3 Solenoid Valves ................................................................................................... IX -22
9.5.4 Replacing the Hydraulic Fluid Filter (COMPRIMA V150/180) .............................. IX -23
9.5.5 Hydraulic Circuit Diagram (COMPRIMA F125, F155) ......................................... IX -24
9.5.6 Hydraulic Circuit Diagram (COMPRIMA V 150, V 180) ....................................... IX -25
9.6 Drawbar Ring Hitch ............................................................................................. IX -26
9.7 Sharpen Cutting System Blades ......................................................................... IX -26
9.8 Maintaining the Compressed Air Brake System (Special Equipment) ................. IX -26
9.8.1 Service Line Hose Couplers
(Non-Reversible).................................................................................................. IX -26
9.8.2 Air Filter for Piping ............................................................................................... IX -27
9.8.3 Compressed Air Reservoir .................................................................................. IX -27
9.8.4 Drain Valve (Manually Operated)......................................................................... IX -27
9.9 Lubrication ........................................................................................................... IX -28
9.9.1 Special Safety Instructions .................................................................................. IX -28
9.9.2 PTO Shaft ............................................................................................................ IX -28
9.9.3 Lubricating points (COMPRIMA F 125, F155) ..................................................... IX -29
9.9.4 Lubricating points (COMPRIMA V150, V180) ..................................................... IX -30
10 Winter Storage ...................................................................................X -1
10.1 General Information................................................................................................ X -1
11 Return to Service .............................................................................. XI -1
11.1 General Information............................................................................................... XI -1

Contents
6
12 Faults – Causes and Remedy .......................................................... XII -1
12.1 General Faults, Causes and Remedy................................................................... XII -1
12.2 Faults, Causes and Remedy in the Central Chain Lubrication Device.................. XII -4
12.3 Error Messages for the Comfort Controls ............................................................ XII -4
A1 Commissioning ................................................................................. A -1
A1.1 Preparing for Commissioning ................................................................................. A -1
A1.2 Assembling the Bale Ejector ................................................................................... A -4
A1.3 Adjusting Drawbar Height ....................................................................................... A -8
A1.4 Attaching the PTO Shaft......................................................................................... A -9
A1.4.1 Length Adjustment ................................................................................................. A -9
A1.4.2 Installing the PTO Shaft ....................................................................................... A -10
A1.5 Attaching the Hose Bracket .................................................................................. A -11
A1.6 Lighting System .................................................................................................... A -12
A2 Electrical Circuit Diagram ............................................................... A -13
A2.1 Electrical Circuit Diagram - Medium ..................................................................... A -13
A2.2 Electrical Circuit Diagram - Comfort ..................................................................... A -17

I - 1
General Aspects
1 General Aspects
These operating instructions contain basic
instructions to follow for assembly, operation and
maintenance. For this reason, these operating
instructions must be read by operating personnel
before commissioning and use, and need to be
available for easy reference.
Follow both the general safety instructions contained
in the section about safety and the specific safety
instructions contained in the other sections.
1.1 Intended Use
The round balers are pick-up balers with baling
chamber. They compact agricultural material, such as
hay, straw or grass silage, into round bales.
1.2 Technical Data
1.2.1 General Aspects
These operating instructions are applicable for the
roundbalers:
COMPRIMA F 125 ; COMPRIMA F 125 XC
COMPRIMA F 155 ; COMPRIMA F 155 XC
COMPRIMA V 150 ; COMPRIMA V 150 XC
COMPRIMA V 180 ; COMPRIMA V 180 XC
1.2.2 Manufacturer’s Address
MaschinenfabrikBernard Krone GmbH
Heinrich-Krone-Strasse10
D-48480Spelle (Germany)
Telephone: [phone]
Fax.: [phone]
Email: [email protected]
1.2.3 Declaration
EC Declaration of Conformity
corresponding to the EC Directive
See reverse side of title page
1.2.4 Identification
Type
Year of
construction
Vehicle
ID No.
The entire identification plate
represents a legal document and
should not be altered or rendered
illegible!
1.2.5 Data Required for Questions and
Orders
When making questions concerning the machine or
ordering replacement parts, be sure to provide type
designation, vehicle ID number and year of construction.
Genuine replacement parts and
accessories authorized by the
manufacturer ensure safe use. Use of
other parts may void liability for
damage which results.
The machine data are located on a type plate (1) which
is located on the right-hand side of the machine below
the twine compartment.
Maschinenfabrik Bernard Krone GmbH
Heinrich-Krone-Str. 10 D-48480 Spelle
Made in
Germany

I - 2
General Aspects
1.2.6 Operation in Accordance with
Intended Use
The Round Pack are designed solely for normal
agricultural use (operation in accordance with intended
use).
Any use of the machine for other purposes is deemed
not to be in accordance with intended use. The
manufacturer is not liable for damage resulting from this,
the user alone bears the risk for this.
Operation in accordance with intended use also includes
observing the operating, maintenance and service
instructions specified by the manufacturer.
Permissible baling material:
grass fodder such as hay, stray and silage.
The collection and baling of other
materials is permitted only with the
prior approval of the manufacturer.
The basic requirements in any case
are swath form loading of the baling
material and automatic lifting by the
pick-up.
1.2.7 General Technical Data
• Road driving is permitted only when the bale chamber
is empty and closed.
• Permissible top speed: 40 km/h (30 km/h)
• For machines which have no brakes, the pulling
tractor’s tare weight must correspond to the permitted
operating specifications, or at least have a weight
which corresponds to the baler’s tare weight.
• For machines which have an operating permit, follow
the conditions contained therein!
• When operating the baler in the field, a supporting
load of 600 kg (on the ring hitch) should not be
exceeded.
• Switch off the electrical operating control when driving
on roads!
The rear flap must only be operated if the
baler is attached correctly to the tractor. If
this is not respected there is a risk of
tipping to the rear.
