Kwikset Halo Touch User manual

Quick Start and Troubleshooting Guide
66856
Rev 01 English

Welcome to the Kwikset family!
This guide will get you up and running
with your new Halo Touch Fingerprint Smart Lock.
If you have any issues, please visit our
support center: kwikset.com/halo-touch
or call us at 1-800-327-5625.

Getting started
For an interactive version of this installation guide,
please download the Kwikset app:
kwikset.com/app
1

Parts in the box ................................................4
Required tools ..................................................5
Installation...........................................................7
Download the app.........................................17
Reference guide .............................................19
Frequently Asked Questions ...................33
Table of contents
3

Parts in the box
Exterior assembly
Latch
Strike
Battery pack Interior assembly Interior cover
1
Step
2
Step
actual
size
03809
46780 actual
size
4

Required
tools
Mounting
plate
Keys
Batteries SmartKey™
tool
Phillips head
screwdriver
3
Step 4
Step
5
Step
actual
size
actual
size
actual
size
actual
size
64844
49191
64109
68611
No electric drills
5

Installation

If drilling a new door, use
the supplied template and
instructions available at:
kwikset.com/doorprep
Remove your existing deadbolt
!
7
1-3/4” to 2”
(44mm - 51mm)
2-1/8”
(54mm)

C
B
A
*Use the longer
screws if the holes
are worn out.
You will have two
extra screws.
Extend the latch bolt.
UP is on top.
If the D-shaped hole
is not centered in the
door hole, rotate the
latch face to extend
the latch.
03809*
(2X)
If your door requires
a drive-in latch,
please contact
Kwikset at
1-800-327-5625.
1Install the latch
[OUTSIDE]
8

DOOR
JAMB
*Install the longer screws
closest to the door jamb.
1" (25 mm)
hole depth
46780*
(4X)
2Install the strike
9

A
Install the exterior assembly
3
[OUTSIDE]
Cable goes under the latch.
10

C
B
Install the exterior assembly
[INSIDE]
Route the cable
through the center
hole, then push into
the bottom hole.
Insert the key and
test the latch. If the
latch does not extend
or retract smoothly,
adjust the screws.
Tighten the screws evenly.
DO NOT over-tighten.
Keep parallel to
the door edge
64844
(2X)
11

B
A
Install the interior assembly
4
Remove the interior
cover from the
interior assembly.
Make sure the turnpiece
shaft is pointing up as
shown below.
Incorrect:
If the turnpiece shaft
is not pointing up, put
the cover back on and
rotate the turnpiece
until you hear a click.
12

E
D
C
align
Secure the interior
assembly onto the
mounting plate.
49191
(2X)
Connect the cable.
Ensure a tight cable
connection.
Lay cable flat inside the
bottom of the interior
housing.
Ensure the spindle
fully engages with the
turnpiece shaft.
[INSIDE]
13

Perform the door handing process
5
With the door open, install
the battery pack to initiate
auto-handing. NOTE: Lock
must be installed on the door
before installing the battery.
Install 4 AA batteries into the
battery pack.
The latch will retract and extend to
learn the orientation of the door.
Then the status LED will indicate
success or failure.
GREEN: Successful. Proceed to the
next step.
RED: Unsuccessful. Make sure the
lock interior and batteries are
correctly installed. Perform
step 5 again. If your second
attempt is still unsuccessful,
follow the Manual Door
Handing instructions. [INSIDE]
14
Status
LED

Secure the interior
cover onto the
interior assembly.
You may need to rotate the
turnpiece to align with the
turnpiece shaft.
For additional security, you may
choose to lock the window by
installing the security screw.
When the window is locked, you
will need to remove the entire
cover to access the battery pack
and buttons.
64109
(3X)
68611
(1X)
[INSIDE]
15

Download the app
& create an account

Create your account
kwikset.com/app
The Kwikset app is needed to use this lock. If this
lock was professionally installed (or installed by
someone other than the homeowner), make sure
this step is performed by the homeowner.
Follow the setup instructions in the Kwikset app
to create your account:
17
