L.L.Bean Lakeside Spooled End Table User manual

We have found it helpful to have a second person present in at least one step
of the assembly.
Lakeside Spooled End Table
Thank you for purchasing our Lakeside Spooled End Table. Assembly of this
product requires a screwdriver.
1 of 4 0RKL5162602

Step 1
Step 2
Remove all parts and hardware from packing material. Wooden pieces should be placed on a
nonabrasive surface (like the carton or carpet) to prevent damage to the finish.
Step 3
Remove Drawer from Top Unit (A).
Note: The legs are matched diagonally as a
set, so right front matches left back and left
front matches right back.
Lay Top Unit (A) upside down.
Attach Left Posts (C) and (B) to Top Unit (A) with
4 Hexagonal Bolts (H), tighten firmly.
PARTS
Read through these instructions.
A
C
B
C
D
E
MINIFIX
CONNECTION
BOLTS
MINIFIX CAM
E1
BOTTOM SHELF
2
1
D
C
B2
FRONT LEFT POST &
BACK RIGHT POST
1
TOP UNIT
QTY
DESCRIPTION
DRAWING
NO.
A
MIDDLE SHELF
FRONT RIGHT POST &
BACK LEFT POST
2 of 4 0RKL5162602

Step 4
Put Minifix Connection Bolts (F) into inserts in the bottom
Left Posts (B) and (C), tighten firmly with Phillips
screwdriver.
Lay the assembly on its back.
Step 5
Place Bottom Shelf (E) over the 2 Minifix Connector
Bolts (F) in the Left Posts (B) and (C) using the
holes in the corner of the Bottom Shelf. Make
sure that the holes for the Minifix Cam (G) are
facing the bottom.
Attach 2 Minifix Cam (G) to Minifix Connector
Bolts (F) in underside of Bottom Shelf (E),
tighten with Phillips Screwdriver.
This step will require assistance of second person.
Step 6
Put Minifix Connection Bolts (F) into inserts in the
bottom of Right Posts (C) and (B), like step 4 and
tighten firmly with Phillips screwdriver.
Attach Back Right Post (B) to Top Unit (A) with 2
Hexagonal Bolts (H), tighten firmly. Make sure
that Minifix Connector Bolt in bottom of posts is
inserted into the Bottom Shelf (E). Attach
Bottom Shelf (E) with 1 Minifix Cam (G), tighten
firmly with Phillips screwdriver.
This step will require assistance of second person.
3 of 4 0RKL5162602

Step 7
Slide Middle Shelf (D) into place on three posts.
Attach Front Right Post (C) to Top Unit (A) with two Hexagonal Bolts
(H), tighten firmly. Make sure to line up Middle and Bottom Shelf.
Attach Minifix Cam (G) to Minifix Connector Bolt (F) in Bottom Shelf
(E), tighten with Phillips screwdriver.
This step will require assistance of second person.
Step 8
Re-insert Drawer into Top Unit (A).
Attach Knob (J) to Drawer with
Knob Screw (K).
CARE
Clean with mild soap and wipe dry.
www.llbean.com
Product Support 1 800 341 4341
D
C
G
4 of 4 0RKL5162602
