L.L.Bean OTNQ1 User manual

1 of 4 6/27/17
Pntd Frmhs End Table
Painted Farmhouse End Table - OTNQ1 & OTNQ2
Thank you for purchasing our 1 Drawer End Table. Assembly of this product requires a phillips screwdriver. It is helpful to have a second
person availble during the assembly of this product.
2 of 4 6/27/17
Pntd Frmhs End Table
STEP 1
STEP 2
Identify and count hardware.
Lay out parts on a non-abrasive surface to avoid scratching finish.
Identify and count all parts using diagram above.
A
B
B
B
B
C
NO. DESCRIPTIONDRAWING QTY.
A
B
TOP 1
4
C1
3 of 4 6/27/17
Pntd Frmhs End Table
STEP 3
Remove Drawer from Top Assembly. Lay Top
Assembly (A) upside down on non-abrasive
surface. Attach 2 Post (B) using 4 M6 * 45MM
Bolts (D). Use Wrench (I) to install Bolts.
Do not over tighten Bolts at this time.
Assemble Loose.
STEP 4
Attach 2 additional Post (B) using 4 M6 * 45MM
Bolts (D). Use Wrench (I) to install Bolts.
Do not over tighten Bolts at this time.
Assemble Loose.
STEP 5
Position Bottom Panel (C) between the 4 Post (B).
Attach bottom panel to Post using 4 M6 * 45MM
Bolts (D). Use Wrench (I) to install and tighten all
Bolts.
At this point tighten all assembly Bolts.
A
4 of 4 6/27/17
Pntd Frmhs End Table
STEP 6
Position assembled case upright. Insert the Drawer
in to the Top Assembly. Attached Metal Knob (E)
or Wood Knob (F) using Knob Screw (G).
CARE: Clean with mild soap and wipe dry.
www.llbean.com
Product Support 1 800 341 4341

This manual suits for next models

1
