Landoll 1230 Series User manual

MODEL 1230 SERIES
COULTER CHISEL
OPERATOR’S MANUAL
1900 NORTH STREET
MARYSVILLE, KANSAS 66508
[phone]
F-319-0501 05/01

WARRANTY
MANUFACTURER’S GUARANTEE POLICY
LANDOLL CORPORATION WARRANTY
LANDOLL warrants each new and unused LANDOLL machine, when
properly assembled, adjusted, and operated, to be free of defects in
material and workmanship, in normal use and when properly serviced,
for a period of twelve (12) months after date of delivery by the Dealer to
the original retail purchaser. LANDOLL shall repair or replace, at its op-
tion, freight on board (f.o.b.) at its factory or designated DEALER loca-
tion, any part or parts of such new and unused machine which shall
have been reported in writing to LANDOLL within thirty (30) days from
date of failure thereof and which LANDOLL inspection shall disclose to
have been defective. Defective parts must be returned to the LANDOLL
factory, freight prepaid. LANDOLL will not be liable for labor, transpor-
tation, or any other charges resulting from replacement of a defective
part. This warranty is void if any part not supplied by LANDOLL is used
in assembly or repair, or if the machine has been altered, abused, or
neglected. LANDOLL repair parts are warranted for ninety (90) days
from date of replacement or for the unexpired warranty period of the
applicable LANDOLL machine, whichever period is longer. LANDOLL
makes no warranty, whatsoever, as to purchased component parts and
other trade accessories, except to the extent that such items are war-
ranted by the manufacturer thereof. THIS WARRANTY IS EXCLUSIVE
AND IN LIEU OF ALL OTHER WARRANTIES, WHETHER EXPRESSED,
IMPLIED, OR STATUTORY (INCLUDING WARRANTIES OF MERCHANT-
ABILITY AND FITNESS FOR PURPOSE), AND LANDOLL SHALL NOT BE
LIABLE FOR SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND
ON ACCOUNT OF ANY LANDOLL PRODUCT.
NO EMPLOYEE OR REPRESENTATIVE IS AUTHORIZED TO CHANGE
THIS WARRANTY, VERBALLY OR IN WRITING, OR GRANT ANY OTHER
WARRANTY.
LANDOLL CORPORATION, WHOSE POLICY IS ONE OF CONTINUOUS
IMPROVEMENT, RESERVES THE RIGHT TO MAKE CHANGES WITHOUT
OBLIGATION TO MODIFY PREVIOUSLY PRODUCED EQUIPMENT.

MODEL 1230 SERIES
COULTER CHISEL
OPERATOR’S MANUAL
PURCHASED FROM: DATE / /
ADDRESS:
PHONE NO.: SERIAL NO.:
i

TABLE OF CONTENTS
SECTION DESCRIPTION PAGE NO.
1 INTRODUCTION 1-1
2 STANDARD SPECIFICATIONS 2-1
3 ASSEMBLY INSTRUCTIONS 3-1
3-1 ASSEMBLY - SAFETY .................................3-1
3-2 AFTER ASSEMBLY - SAFETY ...........................3-3
3-3 ASSEMBLY INSTRUCTIONS ............................3-3
3-4 MAIN FRAME AND HITCH ..............................3-4
3-5 MAIN FRAME ROCKSHAFT.............................3-5
3-6 SINGLE WHEELS ....................................3-6
3-7 WALKING BEAMS....................................3-6
3-8 LOCKUP AND LIFT CYLINDER ..........................3-7
3-9 FRAME EXTENSIONS .................................3-7
3-10 CUTTER FRAME AND CUTTERS.........................3-8
3-11 SHOVELS ..........................................3-9
3-12 SHANK HOLDERS....................................3-9
3-13 WING HINGES ......................................3-10
3-14 WING FRAME CYLINDER ANCHOR......................3-10
3-15 CUTTER FRAME CYLINDER ANCHOR ...................3-10
3-16 WING ROCKSHAFTS - 21’ & 23’ MODELS.................3-11
3-17 CUTTER FRAME ....................................3-11
3-18 GAUGE WHEELS ...................................3-12
3-19 HYDRAULIC SYSTEM ASSEMBLY ......................3-13
3-20 WARNING LIGHTS INSTALLATION ......................3-23
4 OPERATION AND MAINTENANCE 4-1
4-1 DECALS ...........................................4-5
4-2 ROCKSHAFT LOCKUP OPERATION ......................4-6
4-3 TRACTOR PREPARATION .............................4-7
4-4 CHISEL PLOW PREPARATION ..........................4-7
4-5 ATTACHING TO TRACTOR .............................4-8
4-6 PURGING THE HYDRAULIC SYSTEM .....................4-9
4-7 UNHITCHING FROM TRACTOR .........................4-10
4-8 FOLDING AND UNFOLDING WINGS .....................4-11
4-9 DEPTH CONTROL (ALL MODELS - MAIN
AND CUTTER FRAMES) ..............................4-11
4-10 LIFT CYLINDER OPERATION (FOLDING MODELS) ..........4-12
4-11 CHISEL PLOWING...................................4-12
4-12 DISC CUTTER OPERATION............................4-12
4-13 MEASURING CROP RESIDUE (LINE-TRANSECT METHOD) . . . 4-13
4-14 LEVELING THE CHISEL PLOW .........................4-14
4-15 GAUGE WHEELS ...................................4-15
4-16 DISC CUTTERS .....................................4-16
4-17 SPRING CUSHION CLAMPS (STANDARD SHANKS) .........4-16
4-18 AUTO-RESET CLAMPS (DEEP-TILL SHANKS) .............4-16
4-19 GENERAL MAINTENANCE ............................4-17
4-20 LUBRICATION ......................................4-18
4-21 BOLT TORQUE CHECKING INTERVALS ..................4-20
ii

4-22 COULTER CUTTERS .................................4-22
4-23 LEVELING BAR .....................................4-22
4-24 DEEP-TILL SHANKS .................................4-22
4-25 DEPTH CONTROL SYSTEM............................4-23
4-26 POINTS FOR SHANKS ...............................4-23
4-28 REAR BAR SHANK EXTENSIONS .......................4-24
5 TROUBLESHOOTING GUIDE 5-1
iii

SAFETY PRECAUTIONS
THIS IS THE SAFETY ALERT SYMBOL. IT IS USED TO ALERT YOU
TO POTENTIAL INJURY HAZARDS. OBEY ALL SAFETY MESSAGES
THAT FOLLOW THIS SYMBOL TO AVOID POSSIBLE INJURY OR
DEATH.
DANGER DANGER INDICATES AN IMMINENTLY HAZARDOUS SITUA-
TION WHICH, IF NOT AVOIDED, WILL RESULT IN DEATH OR
SERIOUS INJURY.
WARNING WARNING INDICATES A POTENTIALLY HAZARDOUS SITUA-
TION WHICH, IF NOT AVOIDED, COULD RESULT IN DEATH OR
SERIOUS INJURY.
CAUTION CAUTION INDICATES A POTENTIALLY HAZARDOUS SITUA-
TION WHICH, IF NOT AVOIDED, MAY RESULT IN MINOR OR
MODERATE INJURY.
CAUTION CAUTION USED WITHOUT THE SAFETY ALERT SYMBOL INDI-
CATES A POTENTIALLY HAZARDOUS SITUATION WHICH, IF
NOT AVOIDED, MAY RESULT IN PROPERTY DAMAGE.
iv

1INTRODUCTION
The Landoll 1230 Series Coulter Chisel is a quality product designed to give years of trouble free per-
formance. By following each section of this manual, your system will perform as designed for you and your
operation.
SECTION 1 gives basic instructions on the use of this manual.
SECTION 2 gives product specifications. These specifications supply lengths and measures for your
equipment. A Standard Bolt Torque Table is provided to give guidelines for bolt torques
to be used when servicing this product.
SECTION 3 contains assembly instructions for your 1230 Series Coulter Chisel. When these proce-
dures are correctly followed, your equipment should provide you years of trouble-free
operation and service.
SECTION 4 instructs how to operate your equipment before using it, and describes adjustments
needed. It also gives practical advice for the care and maintenance of your Landoll
equipment. Drawings in this section locate adjustment points on the equipment.
NOTE: IF THE EQUIPMENT IS IMPROPERLY ASSEMBLED OR MAINTAINED, THE
WARRANTY IS VOID. IF YOU HAVE ANY QUESTIONS CONTACT:
LANDOLL CORPORATION
1900 NORTH STREET
MARYSVILLE, KANSAS 66508
or phone:
[phone] or
[phone]
or FAX:
[phone]
SECTION 5 is a troubleshooting guide to aid in diagnosing and solving problems with the equip-
ment.
PARTS LIST is a separate manual showing the various assemblies, subassemblies, and systems.
Refer to that manual when ordering Landoll replacement parts. Order parts from your
Landoll dealer.
WARRANTY The Warranty Registration form is included with the product documents. Fill it out and
mail it within 15 days of purchase. The Warranty is printed inside the front cover.
NOTE: IMPROPER ASSEMBLY, MODIFICATION, OR MAINTENANCE OF YOUR
LANDOLL EQUIPMENT CAN VOID YOUR WARRANTY.
COMMENTS Address comments or questions regarding this publication to:
LANDOLL CORPORATION
1900 NORTH STREET
MARYSVILLE, KANSAS 66508
ATTENTION: PUBLICATIONS -DEPT. 55
1-1

2STANDARD SPECIFICATIONS
MODEL TYPE
OF
FOLD
WORKING
WIDTH
NO. OF
SHANKS
TOTAL/REAR
NO. OF
CUTTERS
TRANS.
WIDTH
TRANS.
HEIGHT
12317 Rigid
7’-0” 7/3 6 9’-8” 6’-3”
12337 Rigid
8’-7” 7/3 6 9’-8” 6’-3”
12319 Rigid
9’-0” 9/3 8 9’-8” 6’-3”
12339 Rigid
11’-1” 9/5* 8 10’-9” 6’-3”
123111 Rigid
11’-0” 11/3 10 10’-9” 6’-3”
123311 Rigid
13’-9” 11/6 10 15’-7” 6’-3”
123113 Rigid
13’-0” 13/5* 12 12’-9” 6’-3”
123213 Rigid
13’-0” 13/5 12 15’-7” 6’-3”
123313 Rigid
16’-3” 13/6 12 15’-7” 6’-3”
123215 Rigid
15’-0” 15/5 14 15’-7” 6’-3”
123315 Rigid
18’-6” 15/8* 14 17’-7” 6’-3”
123217 Rigid
17’-0” 17/5 16 16’-10” 6’-3”
123419 Flat Fold
19’-0” 19/7 18 13’-11” 9’-0”
123421 Flat Fold
21’-0” 21/7 20 13’-11” 9’-0”
123423 Flat Fold
23’-0” 23/7 22 13’-11” 9’-0”
* 2 Standard Shanks on Rear Extensions
IMPORTANT! Deep till shanks are for installation on rear frame of rigid models only. do not install on
frame extensions.
2-1

2-2
LANDOLL CORPORATION
GENERAL TORQUE SPECIFICATIONS (REV. 4/97)
THIS CHART PROVIDES TIGHTENING TORQUES FOR GENERAL PURPOSE APPLICATIONS WHEN SPECIAL TORQUES ARE NOT SPECIFIED
ON PROCESS OR DRAWING.
ASSEMBLY TORQUES APPLY TO PLATED NUTS AND CAPSCREWS ASSEMBLED WITHOUT SUPPLEMENTAL LUBRICATION (AS RECEIVED
CONDITION). THEY DO NOT APPLY IF SPECIAL GRAPHITE MOLY-DISULFIDE OR OTHER EXTREME PRESSURE LUBRICANTS ARE USED.
WHEN FASTENERS ARE DRY (SOLVENT CLEANED), ADD 33% TO AS RECEIVED CONDITION TORQUE.
BOLT HEAD IDENTIFICATION MARKS INDICATE GRADE AND MAY VARY FROM MANUFACTURER TO MANUFACTURER.
THICK NUTS MUST BE USED ON GRADE 8 CAPSCREWS.
USE VALUE IN [ ] IF USING PREVAILING TORQUE NUTS.
TORQUE IS SPECIFIED IN FOOT POUNDS
UNC
Size
SAE Grade
2
SAE Grade
5
SAE Grade
8
UNF
Size
SAE Grade
2
SAE Grade
5
SAE Grade
8
1/4-20 4 [5] 6 [7] 9 [11] 1/4-28 5 [6] 7 [9] 10 [12]
5/16-18 8 [10] 13 [16] 18 [22] 5/16-24 9 [11] 14 [17] 20 [25]
3/8-16 15 [19] 23 [29] 35 [43] 3/8-24 17 [21] 25 [31] 35 [44]
7/16-14 24 [30] 35 [43] 55 [62] 7/16-20 27 [34] 40 [50] 60 [75]
1/2-13 35 [43] 55 [62] 80 [100] 1/2-20 40 [50] 65 [81] 90 [112]
9/16-12 55 [62] 80 [100] 110 [137] 9/16-18 60 [75] 90 [112] 130 [162]
5/8-11 75 [94] 110 [137] 170 [212] 5/8-18 85 [106] 130 [162] 180 [225]
3/4-10 130 [162] 200 [250] 280 [350] 3/4-16 150 [188] 220 [275] 320 [400]
7/8-9 125 [156] 320 [400] 460 [575] 7/8-14 140 [175] 360 [450] 500 [625]
1-8 190 [237] 408 [506] 680 [850] 1-14 210 [263] 540 [675] 760 [950]
1-1/8-7 270 [337] 600 [750] 960 [1200] 1-1/8-12 300 [375] 660 [825] 1080 [1350]
1-1/4-7 380 [475] 840 [1050] 1426 [1782] 1-1/4-12 420 [525] 920 [1150] 1500 [1875]
1-3/8-6 490 [612] 110 [1375] 1780 [2225] 1-3/8-12 560 [700] 1260 [1575] 2010 [2512]
1/1-2-6 650 [812] 1460 [1825] 2360 [2950] 1/1-2-12 730 [912] 1640 [2050] 2660 [3325]
METRIC
COARSE THREAD METRIC CLASS 10.9 FASTENERS AND CLASS 10.0 NUTS AND THROUGH HARDENED FLAT WASHERS, PHOSPHATE
COATED, ROCKWELL C 38-45.
USE VALUE IN [ ] IF USING PREVAILING TORQUE NUTS.
Nominal
Thread
Diameter
mm
Standard Torque Nominal
Thread
Diameter
mm
Standard Torque
Newton-
Meters
Foot-
Pounds
Newton-
Meters
Foot-
Pounds
6
10 [14] 7 [10]
20
385 [450] 290 [335]
7
16 [22] 12 [16]
24
670 [775] 500 [625]
8
23 [32] 17 [24]
27
980 [1105] 730 [825]
10
46 [60] 34 [47]
30
1330 [1470] 990 [1090]
12
80 [101] 60 [75]
33
1790 [1950] 1340 [1450]
14
125 [155] 90 [115]
36
2325 [2515] 1730 [1870]
16
200 [240] 150 [180]
39
3010 [3210] 2240 [2380]
18
275 [330] 205 [245]
Table 2-1 General Torque Specifications

2-3
LANDOLL CORPORATION
HYDRAULIC FITTING TORQUE SPECIFICATIONS
37oJIC, ORS, & ORB (REV. 10/97)
THIS CHART PROVIDES TIGHTENING TORQUES FOR HYDRAULIC FITTING APPLICATIONS WHEN SPECIAL TORQUES ARE NOT SPECIFIED
ON PROCESS OR DRAWING.
ASSEMBLY TORQUES APPLY TO PLATED CARBON STEEL AND STAINLESS STEEL FITTINGS ASSEMBLED WITHOUT SUPPLEMENTAL
LUBRICATION (AS RECEIVED CONDITION). THEY DO NOT APPLY IF SPECIAL GRAPHITE MOLY-DISULFIDE OR OTHER EXTREME PRESSURE
LUBRICANTS ARE USED.
BRASS FITTINGS AND ADAPTERS - 65% OF THE TORQUE VALUE FOR STEEL. STAINLESS STEEL, ALUMINUM AND MONEL - THREADS ARE
TO BE LUBRICATED
.
TORQUE IS SPECIFIED IN FOOT POUNDS
PARKER BRAND FITTINGS
Dash
Size
37 Degree
JIC
O-Ring
(ORS)
O-Ring Boss
(ORB)
-4 11-13 15-17 13-15
-5 14-16 — 21-23
-6 20-22 34-36 25-29
-8 43-47 58-62 40-44
-10 55-65 100-110 57.5-62.5
-12 80-90 134-146 75-85
-16 115-125 202-218 109-121
-20 160-180 248-272 213-237
-24 185-215 303-327 238-262
-32 250-290 — 310-340
LANDOLL CORPORATION
HYDRAULIC FITTING TORQUE SPECIFICATIONS
37oJIC, ORS & ORB (REV. 10/97)
THIS CHART PROVIDES TIGHTENING TORQUES FOR HYDRAULIC FITTING APPLICATIONS WHEN SPECIAL TORQUES ARE NOT SPECIFIED
ON PROCESS OR DRAWING.
ASSEMBLY TORQUES APPLY TO PLATED CARBON STEEL AND STAINLESS STEEL FITTINGS ASSEMBLED WITHOUT SUPPLEMENTAL
LUBRICATION (AS RECEIVED CONDITION). THEY DO NOT APPLY IF SPECIAL GRAPHITE MOLY-DISULFIDE OR OTHER EXTREME PRESSURE
LUBRICANTS ARE USED.
BRASS FITTINGS AND ADAPTERS - 65% OF THE TORQUE VALUE FOR STEEL.
TORQUE IS SPECIFIED IN FOOT POUNDS.
AEROQUIP BRAND FITTINGS
Dash
Size
37 Degree
JIC
O-Ring
(ORS)
O-Ring Boss
(ORB)
-4 11-12 10-12 14-16
-5 15-16 — 18-20
-6 18-20 18-20 24-26
-8 38-42 32-35 50-60
-10 57-62 46-50 72-80
-12 79-87 65-70 125-135
-14 — — 160-180
-16 108-113 92-100 200-220
-20 127-133 125-140 210-280
-24 158-167 150-165 270-360
-32 245-258 — —
Table 2-2 Hydraulic Fitting Torque Specifications

NOTES:
2-4

3ASSEMBLY INSTRUCTIONS
3-1 ASSEMBLY - SAFETY
It is very important that your new 1230 Series
Coulter Chisel be properly assembled, adjusted
and lubricated before use. Illustrations in this sec-
tion show proper assembly procedures. Remove
paint from grease fittings. Replace any grease fit-
tings that are damaged or missing. Be sure to re-
turn screws, clips, etc., to their original locations.
To insure alignment of assemblies, leave the
nuts loose until completion of final assembly.
Use lock washers or flat washers as specified.
Spread all cotter pins.
After completion of final assembly, tighten all
nuts evenly to prevent misalignment, distortion or
binding. Tighten all screws and nuts to the recom-
mended torques shown in Tables 2-1 and 2-2.
CAUTION
1. THE PERSON OR PERSONS WHO
ASSEMBLE THIS MACHINE MUST
HAVE THE ABILITY TO READ, UNDER-
STAND AND FOLLOW THE STEP BY
STEP ASSEMBLY PROCEDURES AND
SAFETY INSTRUCTION OUTLINED
HEREIN.
2. ASSEMBLY AREA SHOULD BE
LEVEL, CLEAN AND FREE OF DEBRIS
TO PREVENT ASSEMBLY PERSON-
NEL FROM TRIPPING OR FALLING.
3. INSPECT ALL PARTS FOR SHARP
EDGES, GREASE, OIL OR DIRT WHICH
MIGHT CAUSE INJURY DURING AS-
SEMBLY.
3-1

WARNING
1. USE LIFT CRANE, JACK, TACKLE
OR FORK LIFT TRUCK TO LIFT HEAVY
PARTS AND ASSEMBLIES.
2. KEEP CLEAR OF PARTS WHICH
MAY MOVE OR DROP WHEN REMOV-
ING SHIPPING STRAPS OR BRACK-
ETS.
3. IF MACHINE REQUIRES BLOCKING
UP, USE BLOCKING MATERIAL OF
ADEQUATE STRENGTH AND IN GOOD
CONDITION. BLOCKS MUST BE ON A
SMOOTH DRY SURFACE.
4. NEVER PLACE ANY PART OF YOUR
BODY UNDER BLOCKED-UP ASSEM-
BLIES.
5. IF WELDING OR FLAME-CUTTING IS
REQUIRED, BE SURE NO FLAMMABLE
MATERIALS ARE IN THE AREA. ALSO,
CLEAR BYSTANDERS FROM AREA.
WARNING
1. WEAR PERSONAL PROTECTIVE
EQUIPMENT (PPE) SUCH AS, BUT NOT
LIMITED TO, PROTECTION FOR EYES,
LUNGS, EARS, HEAD, HANDS AND
FEET WHEN OPERATING, SERVICING
OR REPAIRING EQUIPMENT.
2. NEVER USE YOUR HANDS TO LO-
CATE A HYDRAULIC LEAK. USE A
PIECE OF WOOD OR CARDBOARD.
HYDRAULIC FLUID ESCAPING UNDER
PRESSURE CAN PENETRATE THE
SKIN CAUSING SERIOUS INJURY.
3. OPENINGS IN THE SKIN AND MINOR
CUTS ARE SUSCEPTIBLE TO INFEC-
TION FROM HYDRAULIC FLUID. IF IN-
JURED BY ESCAPING FLUID, SEE A
DOCTOR AT ONCE. WITHOUT IMMEDI-
ATE MEDICAL TREATMENT, SERIOUS
INFECTION CAN OCCUR.
3-2
Figure 3-1 Hydraulic Leak Detection

3-2 AFTER ASSEMBLY - SAFETY
WARNING
1. BE SURE ALL NUTS, BOLTS,
OTHER FASTENERS AND HYDRAULIC
FITTINGS ARE PROPERLY TIGHT-
ENED. REFER TO THE BOLT TORQUE
CHART.
2. BE SURE ALL SAFETY GUARDS
AND SAFETY LOCKING DEVICES ARE
IN PLACE AND FUNCTION PROPERLY.
CAUTION
BEFORE OPERATING THE MACHINE,
BE SURE TO READ THE SAFETY AND
OPERATION SECTIONS OF THE OP-
ERATOR’S MANUAL.
CAUTION
BEFORE DELIVERING THE MACHINE,
REVIEW MACHINE MAINTENANCE,
OPERATION AND SAFETY WITH THE
CUSTOMER.
3-3 ASSEMBLY INSTRUCTIONS
3-3.1 The terms “right” and “left”, “front” and
“rear”, refer to the machine as viewed by fac-
ing in the direction of forward travel.
3-3.2 Open all bundles. Do not mix parts of one
bundle with those of another. Place all bun-
dles where they will be easy to access.
3-3.3 Neatly arrange parts and tools within easy
reach of work area.
3-3.4 Use the correct grade of bolt in the proper
locations as indicated. Refer to the bolt
torque chart for descriptive markings on bolt
heads.
3-3.5 After completing each assembly step, re-
view next step in procedure before proceed-
ing with that step.
3-3

3-4 MAIN FRAME AND HITCH
3-4.1 Place main frame on suitable stands at
least 30" (76 cm) high.
3-4.2 Determine center of main frame and insert
hitch tube under frame (See Figure 3-2).
3-4.3 Attach front of hitch tube to frame with
mounting plates and four 3/4" x 8-1/2" cap
screws, lock washers, and nuts.
3-4.4 Attach rear of tube to lift cylinder anchor
with mounting plate and four 3/4" x 14" cap
screws, lock washers and nuts.
3-4.5 Attach jack to hitch and extend to floor
(See Figure 3-3).
3-4.6 Install right and left diagonal hitch braces
to frame with four 3/4" x 5-5/8" U-bolts, lock
washers and nuts (See Figure 3-4) .
3-4.7 Install attaching plate) and cylinder anchor
to hitch and diagonal braces with eight 5/8" x
8" cap screws, lock washers, nuts (See Fig-
ure 3-4).
3-4.8 Install plastic grommet around holes (See
Figure 3-3) for hydraulic hoses.
Note: See Figures 3-38 - 3-45 for assembly lay-
outs for various machine widths.
3-4
Figure 3-2 - Attaching Hitch to Frame
Figure 3-3 - Hitch and Jack
Figure 3-4 - Attaching Diagonal Braces

3-5 MAIN FRAME ROCKSHAFT
3-5.1 Lay rockshaft (See Figure 3-5) on frame
with wheel spindle holes in rockshaft lift arm
toward front of frame.
3-5.2 Lubricate inside of rockshaft bearings and
upper reinforcement bar surfaces.
Notes:
10’-10” frame requires four bearings: Two inner
and two outer.
9’-6” frame only requires two inner bearings.
3-5.3 Both Frames: Install rockshaft bearings
with a reinforcement bar under frame at each
bearing location.
10’-10” Frame: Also install one reinforcement
bar between rockshaft and frame at each
outer bearing location.
3-5.4 Attach all bearings and bars to frame with
3/4” x 8-1/2” cap screws, lock washers, nuts.
Note: Position grease fittings toward rear.
3-5
Figure 3-5 Rockshaft Installation

3-6 SINGLE WHEELS
3-6.1 Slide tube adapter (2-1/4" dia. x 7-1/2"
long) over hub spindle (See Figure 3-6).
3-6.2 Align inner hole in adapter with hole in
spindle and install 3/8" x 2" roll pin.
3-6.3 Insert spindle and adapter into lift arm,
align holes and install 3/8" x 3-1/2" cap
screw, locknut (See Figure 3-7).
3-6.4 Attach wheels to hubs with wheel bolts
shipped in hubs. Tighten to 80 ft-lb (108
N×m).
3-7 WALKING BEAMS
3-7.1 Insert wheel spindles into walking beam .
Align holes and install 3/8" x 2-1/2" roll pin,
one in each wheel spindle (See Figure 3-8).
Note: Use hole “A” for normal tire clearance or
hole “B” for additional clearance.
3-7.2 Insert walking beam into rockshaft lift arm
with beam toward outside of frame. Align
holes and install 3/8" x 3-1/2" cap screw,
locknut (See Figure 3-9).
3-7.3 Attach wheels to hubs with wheel bolts
shipped in hubs. Tighten to 80 ft-lb (108
N×m).
3-6
Figure 3-6 - Wheel Spindle and Adapter Figure 3-7 - Single Wheel Installation
Figure 3-8 - Walking Beam and Hubs Figure 3-9 - Attaching Walking Beam

3-8 LOCKUP AND LIFT CYLINDER
3-8.1 Install lockup hook with 1" diameter. L-pin
and clip pin (See Figure 3-10).
3-8.2 Install lift cylinder linkage arm with 3/4" x
3" cap screw and locknut (See Figure 3-11).
Note: Holes in arm are offset. Install arm with
holes closest to edge toward front of imple-
ment.
3-8.3 Attach base end of frame lift hydraulic cyl-
inder to frame cylinder anchor.
Lift Cylinder Sizes:
- All Rigid and 19’ Folding: 3” x 12”
- 21’’and 23’ Folding: 4” x 12”
Note: Do not connect cylinder rod until after
hydraulic system is purged of air (p. 15).
3-9 FRAME EXTENSIONS
3-9.1 Two types of frame extensions are used:
a. Short (stub) extensions, 8" & 19-1/2" (See
Figure 3-12 ).
b. Main frame extensions, 24" (See Figure
3-13).
3-9.2 The short extensions are attached with U-
bolts or bolts, depending upon location.
3-9.3 The main frame extensions are installed on
each side of certain 10’-10" frame models.
Use eight 5/8" x 2" cap screws, lock washers
and nuts to attach each extension.
Note: See Figures 3-38 - 3-45 for assembly lay-
outs to install extensions.
3-7
Figure 3-10 - Lockup in Lockup Position Figure 3-11 - Main Frame Lift Cylinder
Figure 3-12 - Short Extension
Figure 3-13 - Main Frame Extension

3-10 CUTTER FRAME AND CUTTERS
3-10.1 Attach pivoting support brackets on main
frame front bar with 3/4" x 5-5/8" U-bolts,
lock washers and nuts (See Figures 3-14,
3-15, & 3-16) .
Notes:
See Figures 3-38 - 3-45 for assembly layouts.
Rigid frame models use two brackets; folding
frames use six.
Brackets must pivot freely on pivot bolts. If not,
loosen bolts to provide 1/16" clearance.
3-10.2 Attach cutter frame to support brackets
with disc cutter support at same location.
Use four 3/4" x 8" cap screws, lock washers,
nuts (See Figure 3-15).
Note: Install RH cutter supports on right and
LH cutter support on left. See next step.
3-10.3 Install disc cutter supports (See Figure
3-16):
- RH cutter supports (hubs toward right side
of implement) on RH side.
- LH cutter supports (hubs toward left side of
implement) on LH side.
Use 3/4" x 7-7/8" U-bolts (5), lock washers,
nuts.
CAUTION
TO PREVENT POSSIBLE PERSONAL
INJURY, BE CAREFUL WHEN HAN-
DLING DISC BLADES AND COULTERS.
BLADES AND ARE SHARP!
3-10.4 Attach disc or coulter blades to hubs with
1/2" x 1-1/2" carriage bolts, lock washers,
nuts.
3-10.5 Install cutter frame lift cylinder anchor (See
Figure 3-25).
3-8
Figure 3-14 Pivoting Support Bracket for Cutter Frame
Figure 3-15 Pivot Bracket Installation Figure 3-16 RH Wing Cutter Frame
