Landoll Brillion WFPD23 User manual

®
LANDOLL COMPANY, LLC
1900 North Street
Marysville, Kansas 66508
[phone]
800-428-5655 ~WWW.LANDOLL.COM
‘
Wing Float Pulverizer
Models: WFPD23-37, WFPO23-37 & WFPC23-37
With Scrapers: WFPDS23-37
Operator’s Manual
F-1108-0121

Manuals for Wing Float Pulverizers 23-37
Manual Number Manual Type
F-1108 Operator’s Manual
F-1109 Parts Manual

F-1108-0121 i
Table of Contents
1 Safety Information
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Description of Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Owner Assistance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Warranty Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Understanding Safety Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Transporting Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Safety Instructions for Towing Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Attaching, Detaching and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Maintenance Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Protective Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Tire Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Chemical Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Prepare for Emergencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
High Pressure Fluid Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Safety Chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Decals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
2 Assembly
Transport Axle Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Transport Axle Linkage Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Tire and Wheel Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Center Frame Roller Assembly Installation . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Drawbar Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Drawbar Jack, Hose Support and Manual Storage Canister Installation . . 2-11
Wing Fold Cylinder Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Hydraulic Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Purging the Hydraulic System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
Wing Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
Wing Frame Roller Assembly Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
Wing Rest Installation, WFP 23-29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-24
Wing Rest Installation, WFP 31-37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-25
Warning Lamp Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
SMV Sign Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
Center Roller Scrapers - Optional. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28
Wing Roller Scrapers - Optional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-29
Acre Meter Installation - Optional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30
Float Lock Kit - Optional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
Hydraulic Top Link Kit – Optional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33

ii F-1108-0121
TABLE OF CONTENTS
3 Operation
Tractor Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Pulverizer Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Attaching to the Tractor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Hitch Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Telescoping Drawbar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Hydraulic System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
General Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Transport Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Scraper Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Electronic Acre Meter Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Transporting on a Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
4 Maintenance
General Torque Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Hydraulic Fitting Torque Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Fasteners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Lubrication Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Hydraulic System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Purging Hydraulic System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Roller Bearing Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Roller Axle Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Clamp Tightening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
LED Warning Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-11
Acre Meter Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
Maintenance Chart. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-13
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-14
5 General Reference and Specifications

F-1108-0121 1-1
TABLE OF CONTENTS Chapter 1
Safety Information
Introduction
The implement described in this manual has been
designed with care and built by skilled workers using
quality materials and processes. Proper assembly and
maintenance will provide you with satisfactory use for
seasons to come.
DANGER
DANGER
Description of Unit
The Brillion Wing Float Pulverizer is designed with a rigid
or telescoping drawbar (Size Dependent) making it
versatile to use directly behind a tractor or a companion
tool in both pre-plant and post-plant situations. By its
patented design, the wings and the center section operate
independently during field operation. The wings are
capable of floating in two planes vertically and horizontally
without altering the position of the center section. The
Wing Float Pulverizer uses a single hydraulic circuit that
lifts and folds the machine. Trunnions Bearings mount the
8" Rollers Axles with a choice of 20" Notched Ductile, 20"
Optimizer and 20" Crowfoot Wheels.
Using this Manual
This manual will familiarize you with safety, assembly,
operation, adjustment, and maintenance. Read this
manual and follow the recommendations to help ensure
safe and efficient operation.
• The information in this manual is current at time of
printing. Some parts may have changed to assure top
performance.
• Location reference: Right and Left designations in this
manual are determined by facing the direction the
implement will travel during field operation, unless
otherwise stated.
Owner Assistance
If customer service or repairs are needed, contact your
Brillion dealer. They have trained personnel, parts and
service equipment specially designed for Brillion
products. Your implement’s parts should only be replaced
with Brillion parts. If items covered in this manual are not
understood, contact your local Brillion Dealer.
Warranty Registration
Brillion Farm Equipment, by Landoll, shall have no
warranty obligation unless each product is registered
within 10 days of retail purchase, using the Landoll
Company, LLC Ag Products on-line registration process.
Please refer to the Ag Products Policy and Procedures
Manual, accessible at www.landoll.com for step by step
instructions regarding product registration.
Enter your product information below for quick reference.
MODEL NUMBER
SERIAL NUMBER
DATE OF PURCHASE
Refer to the ID plate as shown. See Figure 1-1.
a
Figure 1-1: ID Plate
Read this entire manual before attempting to
assemble, adjust or operate this implement.
Failure to comply with this warning can result in
personal injury or death, damage to the implement
or its components and inferior operation.

1-2 F-1108-0121
TABLE OF CONTENTS
Safety
NOTE
Investigation has shown that nearly 1/3 of all farm
accidents are caused by careless use of machinery. Insist
that all people working with you or for you abide by all
safety instructions.
Understanding Safety Statements
You will find various types of safety information on the
following pages and on the implement decals (signs)
attached to the implement. This section explains their
meaning.
NOTICE
CAUTION
WARNING
DANGER
DANGER
NOTE
You should read and understand the information
contained in this manual and on this implement decals
before you attempt to operate or maintain this equipment.
• Examine safety decals and be sure you have the
correct safety decals for the implement. See
Figure 1-3.
• Order replacement decals through your Brillion dealer.
• Keep these signs clean so they can be observed
readily. It is important to keep these decals cleaned
more frequently than the implement. Wash with soap
and water or a cleaning solution as required.
• Replace decals that become damaged or lost. Also, be
sure that any new implement components installed
during repair include decals which are assigned to
them by the manufacturer.
• When applying decals to the implement, be sure to
clean the surface to remove any dirt or residue. Where
possible, sign placement should protect the sign from
abrasion, damage, or obstruction from mud, dirt, oil etc.
DANGER
DANGER
Transporting Safety
IMPORTANT
It is the responsibility of the owner/operator to
comply with all state and local laws.
• When transporting the implement on a road or highway,
use adequate warning symbols, reflectors, lights and
slow moving vehicle sign as required. Slow moving
tractors and towed implements can create a hazard
when driven on public roads. They are difficult to see,
especially at night.
• Do not tow an implement that, when fully loaded,
weighs more than 1.5 times the weight of the towing
vehicle.
• Carry reflectors or flags to mark the tractor and
implement in case of breakdown on the road.
• Do not transport at speeds over 20 MPH under good
conditions. Never travel at a speed which does not
allow adequate control of steering and stopping.
Reduce speed if towed load is not equipped with
brakes
• Avoid sudden stops or turns because the weight of the
implement may cause the operator to lose control of
the tractor. Use a tractor heavier than the implement.
• Use caution when towing behind articulated steering
tractors; fast or sharp turns may cause the implement
to shift sideways.
• Keep clear of overhead power lines and other
obstructions when transporting. Know the transport
height and width of your implement. See Figures 5-1
and 5-2.
Special notice - read and thoroughly understand.
Proceed with caution. Failure to heed caution
may cause injury to person or damage product.
Proceed with caution. Failure to heed warning will
cause injury to person or damage product.
Proceed with extreme caution. Failure to heed
notice will cause injury or death to person and/or
damage product.
• Do not allow anyone to ride on the tractor or
implement. Riders could be struck by foreign
objects or thrown from the implement.
• Never allow children to operate equipment.
• Keep bystanders away from implement during
operation.

F-1108-0121 1-3
TABLE OF CONTENTS
Safety Instructions for Towing
Vehicles
The maximum travel speed is the lesser of
• The limit of the road conditions;
• The maximum specified ground speed;
— for towing operations as indicated in this manual
or SIS;
— of the towed vehicle as indicated in its operator’s
manual, SIS, or information sign;
• The maximum ground speed of the towed equipment
combination shall be limited to the lowest specified
ground speed of any of the towed machines. This
speed is the ground speed limitation.
EXAMPLE: If the tractor is capable of 25 mph, the first
implement has a SIS for 19 mph, and the last
implement’s operator’s manual states its specified
ground speed is 15 mph, the towed equipment
combination ground speed limitation is 15 mph.
Attaching, Detaching and Storage
• Do not stand between the tractor and implement when
attaching or detaching implement unless both are
blocked from moving.
• Before applying pressure to the hydraulic system, be
sure all connections are tight and that hydraulic hoses
are not damaged.
• Block implement so it will not roll when unhitched from
the tractor.
• Relieve pressure in hydraulic circuit before uncoupling
hydraulic hoses from tractor.
NOTE
To relieve hydraulic pressure: Depending on tractor
hydraulic system, some can be relieved by actuating
control lever after engine is stopped. If tractor has electric
over hydraulic controls, it may be necessary to move the
control lever to the float position. Refer to tractor’s
operator’s manual.
Wear protective gloves and safety glasses or goggles
when working with hydraulic systems.
Maintenance Safety
• Block the implement so it will not roll when working on
or under it to prevent injury.
• Do not make adjustments or lubricate the machine
while it is in motion.
• Make sure all moving parts have stopped.
• Understand the procedure before doing the work. Use
proper tools and equipment.
Protective Equipment
• Wear protective clothing & equipment appropriate for
the job. Avoid loose fitting clothing.
• Because prolonged exposure to loud noise can cause
hearing impairment or hearing loss, wear suitable
hearing protection, such as earmuffs or earplugs.
Tire Safety
Tire changing can be dangerous and should be performed
by trained personnel using correct tools and equipment.
• When inflating tires, use a clip-on chuck and extension
hose long enough to allow you to stand to one side, not
in front of or over the tire assembly. Use a safety cage
if available.
• When removing and installing wheels use
wheel-handling equipment adequate for the weight
involved.
Chemical Safety
Agricultural chemicals can be dangerous. Improper use
can seriously injure persons, animals, plants, soil &
property.
• Read chemical manufactures instructions and store or
dispose of unused chemicals as specified. Handle
chemicals with care & avoid inhaling smoke from any
type of chemical fire.
• Store or dispose of unused chemicals as specified by
the chemical manufacturer.
Prepare for Emergencies
• Keep a First Aid Kit and Fire Extinguisher handy.
• Keep emergency numbers for the doctor, ambulance,
hospital and fire department near the phone.
High Pressure Fluid Safety
Escaping fluid under pressure can be nearly invisible and
have enough force to penetrate the skin causing serious
injury. Use a piece of cardboard, rather than hands, to
search for suspected leaks.
Any fluid injected into the skin must be surgically removed
within a few hours or gangrene may result.
Avoid the hazard by relieving pressure before
disconnecting hydraulic lines.
NOTE
Relieve hydraulic pressure by shifting the control valve
lever to float.
Wear protective gloves and safety glasses or goggles
when working with hydraulic systems.

1-4 F-1108-0121
TABLE OF CONTENTS
Safety Chain
Use the safety chain to help control drawn machinery
should it separate from the tractor drawbar.
• Use a chain with a strength rating equal to or greater
than the gross weight of towed machinery, which is
21,100 pounds minimum in accordance with ASAE
S338.2 specifications. If two or more implements are
pulled in tandem, a larger chain may be required. Chain
capacity must be greater than the TOTAL weight of all
towed implements.
• A second chain should be used between each
implement.
• Attach the chain to the tractor drawbar support or
specified anchor location. Allow only enough slack in
the chain to permit turning. The distance from hitch pin
to attachment point or intermediate support point
should not exceed 9 inches. See Figure 1-2.
• Replace the chain if any links or end fittings are broken,
stretched or damaged.
• Do not use a safety chain for towing.
See Page 3-3. for Hitch Lock functionality.
Figure 1-2: Safety Chain
Hitch Lock
Hitch Lock
9" MAX
TRACTOR
DRAWBAR
DRAWBAR
Locknut,1-8
Bolt,1-8 x 2-1/4
Safety Chain
TRACTOR
DRAWBAR
Bolt,1-8 x 2-1/4
DRAWBAR
Locknut,1-8
Safety Chain
SPADE POSITION
CLEVIS POSITION

F-1108-0121 1-5
TABLE OF CONTENTS
Decals
Figure 1-3: Decals
CAUTION
1.
2.
3.
4.
5.
DO NOT ALLOW ANYONE TO RIDE ON THIS IMPLEMENT.
DO NOT TRANSPORT AT SPEEDS OVER 20 MPH.
DO NOT STAND BETWEEN TRACTOR AND IMPLEMENT WHILE TRACTOR IS MOVING.
WHEN SERVICING IN RAISED POSITION, PLACE BLOCKING UNDER ROLLERS.
WITH WINGS FOLDED AND WEIGHT ON CENTER ROLLER, THE IMPLEMENT IS
DRAWBAR LIGHT.
DANGER
BLEED THE AIR FROM WING LIFT CYLINDERS
BEFORE OPERATING. FAILURE TO DO SO WILL
ALLOW WINGS TO FREE-FALL AND MAY CAUSE
SERIOUS PERSONAL INJURY. SEE OPERATORS
MANUAL FOR CORRECT PROCEDURE.
DANGER
FALLING WINGS CAN CAUSE INJUR
Y
OR DEATH. STAND CLEAR WHEN WINGS
ARE BEING RAISED OR LOWERED.
WARNING
DO NOT GO NEAR LEAKS
High pressure oil easily punctures
skin causing serious injury,
gangrene or death.
If injured, seek emergency medical
help. Immediate surgery is
required to remove oil.
Do not use fingers or skin to
check for leaks.
Lower load or relieve hydraulic
pressure before loosening fittings.
ITEM 1
3K706
DANGER
WATCH FOR ELECTRICAL WIRES AND
OTHER OVERHEAD OBSTRUCTIONS WHEN
FOLDING WINGS.
FAILURE TOHEED THESE WARNING
MAY RESULT IN PERSONAL INJURY
OR DEATH.
9J629
ITEM 2
9J629
ITEM 3
5J859
ITEM 4
170505
ITEM 5
3J678
ITEM 6
3J675
ITEM 7
528933
ITEM 8
528938
ITEM 9
528934
ITEM 10
170510
ITEM 12
2P808
ITEM 11
170509
ITEM 13
2P151
MANUFACTURED UNDER
US PATENT NO. 8118110
170505
LANDOLL COMPANY, LLC
1900 North Street
Marysville, Kansas 66508

1-6 F-1108-0121
TABLE OF CONTENTS
Figure 1-4: Decal Placement (1 of 4)
11
9
1
11
9
1
3
2
11
2
11
9
9

F-1108-0121 1-7
TABLE OF CONTENTS
Figure 1-5: Decal Placement (2 of 4)
Center Frame Front View
Center Frame Back View
13 4
5
6
9
6
9
78687
13
6
12

1-8 F-1108-0121
TABLE OF CONTENTS
Figure 1-6: Decal Placement (2 of 4)
9
10 12
66
Wing - Left Hand

F-1108-0121 1-9
TABLE OF CONTENTS
Figure 1-7: Decal Placement (3 of 4)
6
12
6
10
9
Wing - Right Hand

1-10 F-1108-0121
TABLE OF CONTENTS
Table provided for general use.
NOTES:

F-1108-0121 2-1
TABLE OF CONTENTS Chapter 2
Assembly
CAUTION
WARNING
NOTE
Refer to the repair parts manual F-1109 for identification
of parts and for the approximate relationship of the parts
in assembly.
To ensure alignment of assemblies, leave the nuts loose
until completion of final assembly. Use lock washers or flat
washers as specified. Spread all cotter pins.
After completion of final assembly, tighten all nuts evenly
to prevent misalignment, distortion or binding. Tighten all
screws and nuts to the recommended torques.
IMPORTANT
• If pre-assembled parts or fasteners are temporarily
removed, remember where they go. It is best to keep
parts separated.
• Check that all working parts move freely, bolts are tight
and cotter pins spread.
• Refer to the Torque Table for proper torque valves.
Note the different torque requirements for Bolts with
Locknuts. See Page 4-1.
“Left” and “Right” refer to directions seen as if standing
behind the machine and facing in the direction of forward
travel.
Do not work on or under this machine unless
securely blocked and supported by a hoist or
tractor or by other sufficient means.
Do not attempt to lift heavy parts (such as the
Frame, Rockshaft, and Pull Hitch) manually. Use
a hoist or a fork lift to move these parts into
position.

2-2 F-1108-0121
TABLE OF CONTENTS
Transport Axle Installation
NOTE
The Bearing Inserts are maintenance free and require no
grease.
1. Select a smooth, level area that can be reached by a
hoist or lift truck.
2. Place the Center Frame on supports, approximately
36 inches high and rated for 2,000 lbs. or higher.
3. Place a Bearing Insert into each Bearing half and
attach Transport Axle to Center Frame, using 5/8-11
x 11 1/2" Bolts, Flat Washers, and Locknuts.
4. Install the base end of the 4 X 16 Hydraulic Cylinder
using one of the pins provided with the Cylinder. The
rod end of the Cylinder will be attached to the Lift
Linkage at the same time as the Transport Axle
Linkage. See Figure 2-2.
5. Tighten all hardware to the recommended torques.
See Page 4-1.
Figure 2-1: Transport Axle Installation
Center Frame
Bolt,5/8-11 x 11-1/2
Flat Washer,5/8
Locknut,5/8-11
Bearing Half
Bearing Insert
Transport Axle
Assembly
Bolt,5/8-11 x 11-1/2
Flat Washer,5/8
Roll Pin,5/16 x 2
Pin,1 x 5-1/2
Flat Washer,1"
Hydraulic Cylinder,
4 x 16
Bearing Half

F-1108-0121 2-3
TABLE OF CONTENTS
Table provided for general use.
NOTES:

2-4 F-1108-0121
TABLE OF CONTENTS
Transport Axle Linkage
Installation
NOTE
Linkage must be free to rotate after assembly
IMPORTANT
Clevis Pin Transport Lock must be removed when
lowering machine.
1. Assemble the Toggle Link Weldment to the Transport
Axle Assembly with 1 x 6-3/4 Pin. Secure with 3/8 x 2
Roll Pins. See Figure 2-2.
2. Place 1-1/16 x 3-1/2 Spacer between Transport Axle
Assembly Lugs. Secure with 5/8-11 x 6 Bolt and
Flange Locknut.
3. Place the Toggle Link w/Tap on the left side and the
Toggle Link on the right side of the Frame Center
Tube. Align the Toggle Links with the Frame Center
Tube Hole with spring bushing and insert 1" Pin
w/Keeper from left to right. Place 1" Flat Washer on
the end of the Pin. Secure with 3/8 x 2 Roll Pin.
4. Place the 1-3/8 x 1-1/16 Spacer between the
Hydraulic Cylinder Rod Clevis ears. Place a 1 x 2 x
1/4 Washer on each side of the Cylinder Rod Clevis.
Align Toggle Links with Cylinder Clevis and insert 1"
Pin W/Keeper from left to right. Place 1” Flat Washer
on the end of the Pin. Secure with 3/8 x 2 Roll Pin.
5. Place a 1 x 2 x 1/4 Washer on each side of the Toggle
Link Weldment. Align Toggle Links with the Toggle
Link Weldment and insert 1" Pin w/Keeper from left to
right. Place 1" Flat Washer on the end of the Pin.
Secure with 3/8 x 2 Roll Pin.
6. To prevent 1" Pins w/Keeper from rotating, secure
with 5/16-18 x 3/4 Bolts.
7. Insert 1/2 x 6 Clevis Pin into the Toggle Link, under
the Toggle Link Weldment and through the Toggle
Link w/Tap. Secure with Hair Pin Cotter. Clevis Pin is
the Transport Lock.

F-1108-0121 2-5
TABLE OF CONTENTS
Figure 2-2: Transport Axle Linkage Installation
Clevis Pin,1/2 x 6
Transport Lock,
must remove when
lowering machine
Toggle Link Weldment
Flange Locknut,5/8-11
Spacer,
1-1/16 x 3.5
Bolt,5/8-11 x 6
Roll Pin,3/8 x 2
Pin,1 x 6-3/4
Link, Toggle w/Tap
Pin,1" w/Keeper
Bolt,5/16-18 x 11/16
Roll Pin,3/8 x 2
Hair Pin Cotter
Flat Washer,1"
Toggle Link
Spacer,
1-3/8 X 1-1/16
Rod Clevis
Washer,1 x 2 x 1/4
Front
Hydraulic Cylinder
4 x 16

2-6 F-1108-0121
TABLE OF CONTENTS
Tire and Wheel Installation
WARNING
NOTE
All tire/wheel assemblies are mounted with the valve stem
facing outward from Hub and Spindle.
The Pulverizer uses 11L-15 12PLY rating tires and should
be inflated to 52 PSI.
Install Tire and Wheel Assemblies onto Hub and Spindles
with 1/2-20 x 1 Wheel Bolts. See Figure 2-4. Tighten
1/2-20 x 1 Wheel Bolts to 50 ft-lbs using the sequence in
Figure 2-3.Tighten to a full torque of 85-90 ft-lbs.
Leave supports under the frame to support the machine in
case of weight shift while adding components.
a
Figure 2-3: Stud Tightening Sequence
NOTE
Torque will drop after the first 10 hours of operation.
Check the nuts for proper torque after this interval and
re-tighten them.
Figure 2-4: Tire and Wheel Assembly
Use a torque wrench to assure proper torque.
Insufficient torque can cause stud breakage
and damage the wheel pilots. Over torque can
stress the Wheel Bolts.
%2/7





Wheel and Tire
Assembly
Hub and Spindle
Assembly
Wheel Bolt,
1/2-20 x 1
Valve Stem Outward
Transport Axle
Assembly
