EM-568 Series
EBX SBC with VIA CPU, VGA,
LCD, LVDS, Audio,
Ethernet, CF, PC/104
and PCI expansion
USER'S MANUAL

COPYRIGHT©
This document is a copyright of the original manufacturer, 2002. The original manufacturer reserves
the rights to make improvement and/or modification to the product described in this manual at any
time without further notice. This manual may not, in whole or in part, be photocopied, reproduced,
transcribed, translated, or transmitted in whatever form without the written consent of the
manufacturer, except for copies retained by the purchaser for backup purposes. All rights are
reserved.
TRADEMARKS
The following are trademarks or registered trademarks of their respective companies: IBM, Intel, AMD,
Cyrix, NS, Award, AMI, Microsoft, Windows, Windows NT, Novell, SCO, PC/104, PICMG, ALI, UMC, VIA,
S3, Realtek, SMC and Winbond. Products mentioned in this manual are mentioned for identification
purposes only. All names of products or services appearing in this manual are the trademarks or
registered trademarks of their respective organizations and companies.
Copyright 2003
Version: 1.0
Date: 2003/07/11

TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION.......................................................................................................................................... 1
1.1 INTRODUCTION ............................................................................................................................................................... 1
1.2 FEATURES ....................................................................................................................................................................... 1
1.3 SPECIFICATION................................................................................................................................................................ 2
1.4 UNPACK YOUR EM-568 SERIES ...................................................................................................................................... 3
1.5 BOARD LAYOUT .............................................................................................................................................................. 4
CHAPTER 2 INSTALLATION............................................................................................................................................ 5
2.1 SYSTEM MEMORY INSTALLATION ................................................................................................................................... 5
2.2 JUMPER SETTINGS AND CONNECTORS............................................................................................................................. 6
2.2.1 Board Outline....................................................................................................................................................... 6
2.2.2 Jumper Settings Summary....................................................................................................................................... 7
2.2.3 I/O Connectors Summary...................................................................................................................................... 12
CHAPTER 3 BIOS SETUP................................................................................................................................................. 27
3.1 RUNNING AWARD BIOS ............................................................................................................................................. 27
3.2 CMOS SETUP UTILITY ................................................................................................................................................. 28
3.3 STANDARD CMOS SETUP............................................................................................................................................. 30
3.4 BIOS FEATURES SETUP ................................................................................................................................................ 33
3.5 CHIPSET FEATURES SETUP ............................................................................................................................................ 35
3.6 INTEGRATED PERIPHERALS ........................................................................................................................................... 38
3.7 POWER MANAGEMENT SETUP....................................................................................................................................... 40
3.8 PNP/PCI CONFIGURATION ............................................................................................................................................ 42
3.9 PC HEALTH STATUS (OPTIONAL).................................................................................................................................. 44
3.10 LOAD OPTIMIZED DEFAULTS....................................................................................................................................... 45
3.11 SET SUPERVISOR / USER PASSWORD ........................................................................................................................... 46
3.12 SAVE & EXIT SETUP.................................................................................................................................................... 47
3.13 EXIT WITHOUT SAVING............................................................................................................................................... 48
CHAPTER 4 DRIVERS SUPPORT................................................................................................................................... 49
4.1 USE YOUR DRIVER CD-ROM....................................................................................................................................... 49
4.2 FILE DIRECTORY ........................................................................................................................................................ 49
APPENDIX A. WATCH-DOG TIMER.............................................................................................................................. 50
APPENDIX B. DIGITAL I/O.............................................................................................................................................. 50
APPENDIX C. BRIGHTNESS CONTROL...................................................................................................................... 50
RMA SERVICE REQUEST FORM .................................................................................................................................. 52

Chapter 1 Introduction
1
User’s Manual
Chapter 1 Introduction
1.1 Introduction
EM-568 offers multi computing power options. VIA Eden-533MHz is designed especially for fan-less
requirement to enable better MTBF. As an x86 architecture, the platform supports prevail operating
systems such as Windows 95/98SE/XP/2000/NT and Linux. Your previous investment on these operating
systems is, thus, protected in the following 4 years. With 64KB internal L2 cache integrated in the CPU,
your applications are able to benefit more execution speed from this mechanism.
VIA Twister-T chipset supports 2D/3D Video Accelerator by integrating S3 Pro Savage 4. It also supports
36-bit TTL LCD and 2 channels (2x18-bit) LVDS. EM-568 is able to compatible with the most coming
bigger size industrial and commercial LCDs. By enabling VRAM, the system can further cut its cost and
while maintains its speed. EM-568 uses SODIMM to limit its board height and supports PC 133/PC 100.
There are two storage options in EM-568 design. One is EIDE, and the other one is CF II. EIDE supports
four IDE devices. EM-568 offers 2 IDE box header to fulfill flexible hard disk placement in system design.
Regarding to CF II socket, system can further cut its whole size when using popular large volume CF II
form factor SSD.
EM-568 embodies the following I/O: 1 x LAN, 1 x FDD, 4 x COM, 1 x LPT, Keyboard & Mouse, 4 x USB, 1
x IrDA and 4 x DIO. Expansion slots include PC/104 and PCI. Power supply complies with AT and ATX.
Watchdog timer is 16-level.
As an industrial PC embedded board, EM-568’s operating temperature is ranging from 0°C to 60°C. All
these numerous features provide an ideal price/performance solution for commercial and industrial
applications where stability and reliability are essential.
1.2 Features
z VIA Eden-533MHz Fanless or C3 800MHz/ FSB 133MHz
z VIA VT8606 North Bridge and VT82C686B South Bridge
z Award BIOS
z S3 Pro Savage 4 2D/3D Video Accelerator
z VGA, 36-bit TTL LCD and 2°18-bit LVDS
z LCD Brightness Control via GPIO
z AC 97 Audio
z Realtek RTL 8100B
z CF Type II Socket
z PCI and PC/104 expansion slots
z 1 x LAN, 1 x FDD, 4 x COM, 1 x LPT, Keyboard & Mouse, 4 x USB, 1 x IrDA and 4 x DIO
z Watchdog Timer
z AT/ATX Power Connector

Chapter 1 Introduction
2 User’s Manual
1.3 Specification
EM-568 Series
Processor VIA low power CPU 400/ 533/ 733/800M/1G on board
Default: Eden-533M (EM-568A) & C3-800M (EM-568B)
FSB 133 MHz
L2 Cache 64K on CPU
Chipset VIA VT8606 (North) & VT686B (South)
BIOS 256KB Award license BIOS
System Memory SODIMM socket up to 512MB PC133 / PC100 SDRAM
VGA & LCD 1〉Chip: VT8606 integrated S3 ProSavage 4, AGP 4X Graphics support 36 bit TFT/
DSTN/ STN LCD & 2 channels of 18 bit (2x18) LVDS
1-1〉Connector: a〉VGA: 2x6x2.54 mm pin header
b〉TFT LCD: 2x25x1.0 mm box header
c〉LVDS LCD: 2x15x1.0 mm box header (2x18 bit)
2〉Chip: Thine THC63LVDF83A or Compatible Support one channel 24 bit LVDS
LCD(optional)
2-1〉Connector: LVDS LCD:1x20x1.25 mm right angle box header (24 bit)
(optional)
3〉VRAM: Support 8/ 16/ 32MB memory (shared)
Audio Chip: VIA VT1612A AC 97 Codec & NS LM1877 Amp for 2W per channel
Connector: 2x8x2.0 mm pin header (Mic-in, Line-in, CD-in, Line-out & Speaker-out)
Ethernet Chip: Realtek RTL8100B (10/100 BaseT)
Connector: RJ-45 Vertical type
Solid State Disk Connector: 50-pin socket for type I/II Compact Flash
PC/104 Connector: PC104 connector (ISA)
Expansion Bus PCI slot
Serial Port (FOUR)
Chip: VT686B & Winbond W83877TF COM Setting: COM 1, 3 & 4 is RS-232, COM 2 is RS-232/422/485 setting by jumper
COM Power: 4 COMs pin 9 all with +5V & +12V selector
Connector: 2x20x2.54 mm pin header
Parallel Port Multi-mode (SPP/ EPP/ ECP)
Connector: 2x13x2.54 mm pin header
IDE (TWO) Connector: 2x20x2.54 mm & 2x22x2.0 mm pin header
FDD Connector: 2x17x2.54 mm pin header
USB V1.1 (FOUR) Connector: 2* 2x5x2.54 mm pin header
PS/2 Keyboard &
Mouse Connector: 2x4x2.54 mm pin header
IRDA Shared with COM 2
Connector: 1x5x2.54 mm pin header
RTC 3V Li battery in holder
LCD Inverter Port Connector: 1x5x2.54 mm wafer
System Indicator H/W Reset, Power LED, HDD LED & System alarm speaker
Connector: 1x11x2.54 mm pin header
Watchdog Timer 16 levels timer intervals
Digital I/O 4 * In & 4 * Out
Connector: 2x5x2.54 mm pin header
Hardware Monitoring Chip: VT686B (South)
Power Management Support power saving modes, normal/ standby/ suspend; APM 1.2 compliant
Power Input AT or ATX select by adapter cable & Jumper setting
Connector: 1x7x2.54 mm wafer
OS Support WIN 98, 2000, XP & WIN NT4.0; Linux Red Hat 7.2 or later version
Temperature Operating: 0 degree C ~ 60 degree C
Storage: - 10 degree C ~ 70 degree C
Humidity 5% ~ 95% relative humidity, non-condensing
Dimension 5.75” x 8.0” EBX form factor

Chapter 1 Introduction
3
User’s Manual
1.4 Unpack your EM-568 Series
Before you begin to install your card, please make sure that you received the following materials as listed
below:
Standard Packing:
zEM-568 x 1 pc Embedded Single Board Computer
zDriver Utility CD-ROM x 1 pc Drivers & Utilities
zUser's Manual x 1 pc This User's Manual
Note
：
：：
：
All Option Kits are to be purchased separately
Option
：
：：
：
EM-568CB
zLPT cable x 1 pc 0800100250001 25P D-SUB TO 26P P26 with Key
zFDC cable x 1 pc 0800100340002 34P TO 34P P4 with Key
zIDE cable x 1 pc 0800100400004 ATA100 40P 80 Impendence P20 with Key
zUSB Y cable x 1 pc 080019F100001 2°5P 2.54mm with P9
zVGA cable x 1 pc 080029F020001 2°6 2.54mm with P8 TO D-SUB 15 Female
zAT power cable x 1 pc 0800800120002 EBX (7PIN) TO AT P8 / P9 (12PIN)
zATX power cable x 1 pc 080089D000001 20P ATX TO 7P EBX+4P HEADER°2
zPS2 cable x 1 pc 0801895080001 Keyboard / Mouse Y cable 8P Header-PS2
zSOUND cable x 1 pc 080199D160002 16P TO 5P PhoneJack°4 with Key
zCOMPORT cable x 1 pc 080279D400001 40P TO 9P D-SUB Male°4 P40 with Key
zIDE cable x 1 pc 080019D440001 IDE 40P°2 TO 44P P20 with Key

Chapter 1 Introduction
4 User’s Manual
1.5 Board Layout

Chapter 3 BIOS Setup
5
User’s Manual
Chapter 2 Installation
2.1 System Memory Installation
Step 1: Insert the RAM module into the SODIMM socket
Step 2: Press Module down till clip hold.

Chapter 3 BIOS Setup
6 User’s Manual
2.2 Jumper Settings and Connectors
2.2.1 Board Outline
FAN1
1 3
CONB1
CONA1
SCF1
1
3
CMOS1
1
3
PLRS1
1
INVER1
1 4
CDIN1
SLCDA1
USBA1
USBA2
CPU1
1
1
A B
D C
2
1 10
9
DIOA1
2
1 10
9
1
LCD1
2
49 50
LVDSD1
1
20
1
5
LVDSC1
1 2
29 30
VGAB1
11
12
2
1
V
LCD1
1 3
2
1
8
7
IRDA1
1 5
LPTA1
1
2
26
25
2 8
1 7
PKMB1
FDCA1
IDEA1
COMD1
1 7
PS7M1
PSW1
1
ATXC1
1
PS4W1
1SBVA1
1 5
LANH1
SOUNA1
2
116
15
2
140
39
2
1
34
33
2
144
43
IDEB1
2
140
30
SRIV1
SRIV2 SC2T1
SC2T2
1 1
1
1
LEDD1
2 4
1 3
1 3
JFA1
2
1 10
9

Chapter 3 BIOS Setup
7
User’s Manual
SC2T2
2.2.2 Jumper Settings Summary
LOCATION FUNCTION
CMOS1 Clear CMOS Data
SC2T1/SC2T2 Select COM2 Type
SRIV1/SRIV2 Select COM port pin 9 Type
VLCD1 Select Panel Voltage
SBVA1 Select AT/ATX Power
SCF1 Master/Slave Select
JFA1 Factory Setting
SLCDA1 Select Panel Type
z CMOS1 : Clear CMOS Data
Description CMOS1
Normal (Default) 1-2
Clear CMOS 2-3
zSC2T1/SC2T2: Select COM2 Type
COM1 TYPE SC2T1 SC2T2
RS-232 (Default) 1-2 1-5,2-6,3-7,4-8
RS-422 3-4 5-9,6-10,7-11,8-12
RS-485 5-6 5-9,6-10,7-11,8-12
CMOS1
1
2
3
SC2T1
1 5
2 6
1 4
9 12
RS-232
RS-422
RS-485
CMOS1
SC2T1
SC2T2

Chapter 3 BIOS Setup
8 User’s Manual
z
zz
zSRIV1, SRIV2: Select COM port pin 9 Type
Default: RI
z VLCD1: Select Panel Voltage
Panel Voltage VLCD1
+3.3V (Default) 1-2
+5V 2-3
Pin 9 Type SRIV1 SRIV2
RI 1-5,2-6,3-7,4-8 1-2
+5V 5-9,6-10,7-11,8-12 1-2
+12V 5-9,6-10,7-11,8-12 2-3
VLCD1
3.3V (Default) VLCD1
5V
Default: VLCD1
1 2 3
1 2 3
1 2 3
1 2 3
1 2 3
SRIV2SRIV1
1 2 3 4
9 10 11 12
V
LCD1
SRIV1
SRIV2

Chapter 3 BIOS Setup
9
User’s Manual
zSBVA1: Select AT/ATX power (2x3 Pin 2.54mm)
Power Type SBVA1
AT 1-3,2-4 (Default)
ATX 3-5,4-6
zSCF1: Master/Slave Select
Compact Flash Card ATA Disk Chip SCF1
Master Slave 1-2
Slave Master 2-3 (Default)
Default:
SBVA1
1
3
SCF1
2 4 6
1 3 5
SBVA1
SCF1

Chapter 3 BIOS Setup
10 User’s Manual
zJFA1: Factory Setting
Defaut: 1-2
Pin No. Description
1 3VSB
2 Pin A14
3 -GNT1
JFA1
1 3
JFA1

Chapter 3 BIOS Setup
11
User’s Manual
zSLCDA1: Select Panel Type (2x4 Pin)
Note: Different type of LCD panel with the same resolution will have different jumper setting
for selection.
Panel Type SLCD1
640 x 480 TFT 1-2,3-4,5-6,7-8
800 x 600 TFT 3-4,5-6,7-8
1024 x 768 TFT 2pixel/Clk at 32MHZ 1-2,5-6,7-8
1280 x 1024 TFT 5-6,7-8
640 x 480 DSTN 1-2,3-4,7-8
800 x 600 DSTN 3-4,7-8
1024 x 768 DSTN 1-2,7-8
1024 x 768 TFT 1pixel/Clk at 65MHZ 7-8
640 x 480 TFT 1-2,3-4,5-6
800 x 600 TFT 3-4,5-6
1024 x 768 TFT 1-2,5-6
1280 x 1024 TFT 5-6
1400 x 1050 TFT 2pixel/Clk at 54MHZ 1-2,3-4
800 x 600 DSTN 3-4
1024 x 768 DSTN 1-2
1280 x 1024 DSTN OFF
Default
All OFF:
SLCDA1
1 3 5 7
2468
SLCD1A1
640X480 TFT
800 x 600 TFT
1024 x 768 TFT 2pixel/Clk at 32MHZ
1280 x 1024 TFT
640 x 480 DSTN
800 x 600 DSTN
1024 x 768 DSTN
1024x768 TFT/ pixel/ Clk at 65MHZ
640 x 480 TFT
800 x 600 TFT
1024 x 768 TFT1280 x 1024 TFT
1400 x 1050 TFT 2pixel/Clk at 54MHZ800 x 600 DSTN
1024x1024 DSTN1280x1024 DSTN
1 3 5 7
2 4 6 8
SLCDA1

Chapter 3 BIOS Setup
12 User’s Manual
2.2.3 I/O Connectors Summary
zDIOA1: Digital Input/ Digital Output Ports(2x5 Pin 2.54mm Header)
Pin No. Description Pin No. Description
1 IN0 2 OUT0
3 IN1 4 OUT1
5 IN2 6 OUT2
7 IN3 8 OUT3
9 Ground 10 Ground
LOCATION FUNCTION
DIOA1 Digital Input/ Digital Output Ports (2°5 Pin 2.54mm Header)
PLRS1 Power LED, HD, LED, Reset, Speaker Connector (11Pin 2.54mm)
FAN1 3 Pin FAN Connector
CONA1 /CONB1 PC/104 Connector (8 bit/16 bit)
LANH1 RJ-45 180°LAN Connector
LEDD1 2°2 Pin Lan Link & Active LED
IRDA1 IRDA1 Connector
INVER1 LCD Inverter Connector
CF1 Compact Flash Connector
USBA1 USB Port #1 &#2 Connector 2°5 Pin 2.54mm
USBA2 USB Port #3 &#4 Connector 2°5 Pin 2.54mm
PKMB1 PS/2 Keyboard & Mouse Connector (2°4 Header 2.54mm)
VGAB1 External VGA Connector (12 Pin Header)
IDEA1 IDE Interface Connector (44Pin 2.0mm Pitch Header)
IDEB1 IDE Interface Connector (40Pin 2.54mm Pitch Header)
SOUNA1 Sound Connector 2°8 Header 2.00mm
FDCA1 Floppy Interface Connector (34 Pin Header)
CDIN1 CD_IN Connector (2.54mm Pitch 180°)
LPTA1 Parallel Connector (26 Pin 2.54mm Pitch Header)
LVDSC1 LVDS Panel Connector(2°15P 1.0mm)
COMD1 COM1, COM2, COM3, COM4 Connector
LCD1 Panel LCD Connector (50 Pin 1.0mm JST Header)
PS7M1 7 Pin Power Connector
PS4W1 4-Pin Power Connector (WAFER 4P 2.00mm)
ATXC1 For ATX Function
PSW1 For ATX Power Button
LVDSD1 LVDS Connector (20Pin 1.27mm Pitch)
1
2
9
10
DIOA1
DIOA1

Chapter 3 BIOS Setup
13
User’s Manual
zPLRS1: Power LED, HD LED, Reset, Speaker Connector (11 Pin 2.54mm)
Pin No. Description
1 Power LED +
2 Power LED +
3 GND
4 HDD LED +
5 HDD LED -
6 RESET SW +
7 RESET SW – (GND)
8 External Speaker -
9 Internal Buzzer -
10 NC
11 External Speaker +
z
zz
zFAN1: 3-Pin FAN Connector (For EM-568B only)
Pin No. Description
1 Ground
2 +5V
3 FAN Status
Default :
8-9 (ON) Internal Buzzer 11
1
PLRS1
FAN1
1 2 3
FAN1
PLRS1

Chapter 3 BIOS Setup
14 User’s Manual
z
zz
zCONA1:PC/104 Connector（
（（
（8 bit）
））
）
z
zz
zCONB1:PC/104 Connector（
（（
（16 bit）
））
）
Description
CONA1 CONB1
Pin No.
Row A Row B Row C Row D
1 IOCHCK# Ground Ground Ground
2 SD7 RSTDRV SBHE# MEMMCS16#
3 SD6 +5V LA23 IOCS16#
4 SD5 IRQ9 LA22 IRQ10
5 SD4 -5V LA21 IRQ11
6 SD3 DRQ2 LA20 IRQ12
7 SD2 -12V LA19 IRQ15
8 SD1 0 WS# LA18 IRQ14
9 SD0 +12V LA17 DACK0#
10 IOCHRDY NC MEMR# DRQ0
11 AEN SMEMW# MEMW# DACK5#
12 SA19 SMEMR# SD8 DRQ5
13 SA18 IOW# SD9 DACK6#
14 SA17 IOR# SD10 DRQ6
15 SA16 DACK3# SD11 DACK7#
16 SA15 DRQ3 SD12 DRQ7
17 SA14 DACK1# SD13 +5V
18 SA13 DRQ1 SD14 MASTER#
19 SA12 REFRESH# SD15 Ground
20 SA11 SYSCLK NC Ground
21 SA10 IRQ7 --- ---
22 SA9 IRQ6 --- ---
23 SA8 IRQ5 --- ---
24 SA7 IRQ4 --- ---
25 SA6 IRQ3 --- ---
26 SA5 DACK2# --- ---
27 SA4 TC --- ---
28 SA3 BALE --- ---
29 SA2 +5V --- ---
30 SA1 OSC --- ---
31 SA0 Ground --- ---
32 Ground Ground --- ---
CONA1/
CONB1
B A
1
C D1
CONA1 CONB1
20
32

Chapter 3 BIOS Setup
15
User’s Manual
z
zz
zLANH1 : RJ-45 180º LAN Connector
Description
Pin No. Fast E-Net
1 TX+
2 TX-
3 RX+
4 T45
5 T45
6 RX-
7 T78
8 T78
z
zz
zLEDD1: 2x2 Pin Lan Link & Active LED
Pin No. Signal Pin No. Signal
1 3VSB 2 LINK LED-
3 3VSB 4 ACTIVE LED-
2
1
4
3
LEDD1
LEDD1
LANH1

Chapter 3 BIOS Setup
16 User’s Manual
z
zz
zIRDA1: IRDA Connector
Pin No. Description
1 VCC
2 KEY
3 IRRX
4 GND
5 IRTX
z
zz
zINVER1: LCD INVERTER Connector
Pin No. Description
1 GND
2 +5V
3 +12V
4 ENAVEE
5 Bright
ÚRegular pin 5 (bright) output is 1.8V. But output can be adjusted by below software tools.
E568LAWD.EXE for output: 0 ~ 3.3V
Brightness Adjust Operation:
Power-on by DOS booting disk, execute software tool and push "+" bottom to increase voltage or push
"-" bottom to decrease voltage.
IRDA1
5
1
INVER1
1
2
3
4
5
IRDA1
INVER1
