Larzep EM03012 User manual

COLUMN PRESS 30 Tn
WITH HAND PUMP
“EM03012”
LARZEP,S.A. LARZEPAUSTRALIAPTY.LTD. LARZEPGBLTD.
AvenidaUrtiaga,6 104WedgewoodRoad, 3CommerceWay‐LeightonBuzzard
48269MALLABIA,SPAIN HALLAM,VIC.3803AUSTRALIA BEDSLU74RWUNITEDKINGDOM
Tel.+34943171200 Tel.+61(3)97963744 Tel.+441525377819
Fax.+34943174166 Fax.+61(3)97965964 Fax.+441525851990
www.larzep.com www.larzep.com.au www.larzep.co.uk

2
INSTRUCTION MANUAL
Column Press with Hand Pump
INDEX
1. BEFORE USING THE EQUIPMENT......................................2
2. TECHNICAL FEATURES ........................................................3
3. ESSENTIAL SAFETY REQUIREMENTS..............................3-4
3.1 GENERAL CONSIDERATIONS
3.2 SECURITY IN COMMANDS
3.3 SAFETY PREVENTION ACTIONS AGAINST MECHANICAL RISKS
3.4 SAFETY PREVENTION ACTIONS AGAINST OTHER RISKS
3.5 SECURITY IN MAINTENANCE
3.6 INDICATIONS
4. TRANSPORT AND INSTALLATION.....................................4
5. MAINTENANCE ........................................................................4-5
6. PROBLEMS, DAMAGES AND SOLUTIONS........................5
7. WARRANTY...............................................................................5
8. DECLARATION OF CONFORMITY .....................................6
ANNEX
•GENERAL DRAWING
1. BEFORE USING THE EQUIPMENT.
Upon removing the protective packaging from the crane, carefully inspect it. Check for:
1- Oil leaks.
2- Signs of corrosion.
3- Damage to the hydraulic cylinder and hydraulic line.
4- Cracks or dents on the frame and the hydraulic cylinder’s attachments to the frame.
5- Loose or damaged screws or joints.
6- Damaged or incorrectly assembled accessories.
If you find any damage or fault with the product, clearly label it and place it in a location where it will not be available for use until an authorized service dealer has
repaired the fault.
Familiarize yourself and your co-workers with the equipment. Before you begin using the jack, carefully read and observe all instructions and recommendations
enclosed in the packaging.
Your negligence in this matter may cause personal injury or material damage.
Do not operate hydraulic equipment near open flame, explosives, sources of intense heat or any other hazard, which could cause a fire or the damage equipment. The
hydraulic equipment should not be exposed to temperatures grater than 60ºC when in use or when stored.
When choosing a place for the press, ensure that it will be located over firm, level ground such that the entire base of the press contacts the ground. If any doubt exists
as to whether the ground will able to support the press and the additional weight it will see when in use, distribute the weight over a larger area by placing rigid steel
beams or planks under the base of the press.
Store the press with the cylinder’s piston fully retracted.
We recommend you wrap the cylinder in a protective plastic or place it in a location free of dirt, dust, steel shavings and other foreign matter, which can enter into the
cylinder and damage its components.
Never use hydraulic equipment that is damaged or suspected to be in poor condition.
Do not loose the instruction manual.
Do no store or leave the press where is can be accessed by the children.
If purchasing just a cylinder or pump for use in a press, ensure that you are using the proper combination of pump, cylinder and press frame before
assembling the unit. We recommend you seek professional advise on the matter.

3
INSTRUCTION MANUAL
Column Press with Hand Pump
2. TECHNICAL FEATURES.
HYDRAULIC CYLINDER
MODEL EM03012
•Capacity (Tn.) 30 Tn
•Maximum pressure (Kg/cm²) 700 Kg/ cm²
•Stroke (mm.) 125 mm
•Effective area (cm²) 44.16 cm²
•Oil capacity (cm²) 552 cm²
•Free advance speed (mm/sg) 3 mm/sg
•Maximum pressure advance speed 0.5 mm/sg
•Cylinder SM03012
HAND PUMP
MODEL W00807
•Tank capacity (cc) 800 cc
•Maximum pressure (Kg/cm²) 725 Kg/ cm²
FRAME : MECHANIZED-WELDED
MODEL EM03012
•
Working height (mm.) 930 mm
•
Working width (mm.) 500 mm
•
Total weight of the machine (Kg.) 120 Kg
3. ESSENTIAL SAFETY REQUIREMENTS.
3.1 GENERAL CONSIDERATIONS
DANGEROUS AREA
The speed of the hydraulic cylinder during its extension is less than 30 mm/second. Therefore then machine should be considered by the application of ANNEX V of
the Declaration of CE Conformity.
Operators standing in the dangerous area around the machine should protect their feet, faces and hands from metal pieces being ejected during pressing.
Feet protection Face protection Hands protection
Used materials and components are not for the health and safety of operators. The hand pump contains LARZEP hydraulic oil ISO: HV46.
3.2 SECURITY IN COMMANDS
The cylinder advances when we act the lever of the pump.
The pump is provided with two positions, advance and return.
In order to start the equipment is necessary to connect the pump to the cylinder.
To stop the cylinder advance, stop handling the lever of the pump. For a new start up, it will be necessary act the lever again.
3.3 SAFETY PREVENTION ACTIONS AGAINST MECHANICAL RISK
The construction of machine has been calculated to bear without any breaking under conditions of foreseen utilization and for the whole life of the machine.
The hydraulic components have been designed and calculated in compliance with the ANSI B30.1, and have been proved to 875Kg./cm²of pressing.
The frame of the machine does not cause to be dangerous in that sense.
Due to the FUNCTIONAL REASONS it is considered to be the space between the columns, the bed and the hydraulic cylinder piston.
Due to the MATERIAL PRESSED it is supposed to be surrounding area to the machine in case of metal parts being ejected during pressing.
HIDRAULIC OIL IS TOXIC IF IT ENTERS THE BLOODS STREAM. NEVER PLACE A FINGER OVER ANY ORIFICE OR LEAK, WHICH
COULD BE PRESSURIZED, SUCH AS THE HYDRAULIC LINE, AS THIS COULD CAUSE OIL TO BE INJECTED INTO BLOOD STREAM.

4
INSTRUCTION MANUAL
Column Press with Hand Pump
3.4 SAFETY PREVENTION ACTIONS AGAINST OTHERS RISKS
RISKS DUE TO HYDRAULIC ENERGY
The hydraulic pump is equipped with an internal security valve in the tank, out of operator’s control and rated at 700 Kg./ cm²
3.5 SECURITY IN MAINTENANCE
All the maintenance operations must be performed while the machine is stopped avoiding this way any potentially dangerous situation. A poor maintenance
program of the press does not increase the risk, but obviously will revert in a lower performance.
The hydraulic pump is mounted out of the frame and access is very easy. To disassemble the pump unscrew the cover screws. In order to disassemble the
cylinder it is required first to disassemble the hoses and this from the frame.
ISOLATION OF THE POWER SUPPLY
Disconnect the rapid coupler from the pump.
3.6 INDICATIONS
INFORMATION DEVICES
In the pump: Oil level and oil filling tap
In the cylinder: A gauge in order to know the operating pressure anytime.
The press, the cylinder and the pump have their corresponding serial numbers marked on them. In addition to it, you can find a sticker label showing the commercial
reference, capacity, working pressure, name and address of the manufacturer.
4. TRANSPORT AND INSTALLATION.
The machine is delivered properly packed in a wooden ballet. For it’s handling, it is recommended to use a forklift truck or a crane. In the last case, it is necessary to
make the slings trespass the arc of the frame. When doing this operation, you should be cautious and prevent the flexible hoses and couplings from any damage.
HYDRAULIC CONNECTION
Unscrew the rapid coupler site in the cylinder, and connect the hose, screwing the rapid coupler to the limit with the hand.
INSTALLING THE GAUGE
1-Replace the threaded tap in the top of the cylinder by the gauge, which is supplied separately.
2-Tighten the gauge cone to the gauge adaptor seat by using a flan wrench size 22.
3-Hold the gauge screen by hand during threading process and after reaching a comfortable reading position set the gauge screen free so that it turns the last quarter
solidarily with the thread.
CHECKING THE RIGHT OPERATION OF ALL DEVICES AND MECHANISM
1º- Select the working maximum pressure. In manual presses 700 Kg./cm².
2º- Put the hand in the lever.
3º- Push the lever several times.
4º- Check the cylinder advances.
5º- Check that the cylinder piston goes back pushed by the internal spring. In both cases, to maintain the movement is necessary let the lever without movement.
6º- Without put anything in the press, repeat the advance movement, until reaching the cylinder full stroke. In that moment the pressure will start to be increased and
we can observe it now in the gauge. This pressure will go on increasing until reaching the installation maximum pressure, previously chosen. In this stage, the cylinder
maintains the reached pressure, (the gauge maintains the reading). Check there are no leaks in the installation (gauge intake, couple, etc.)
7º- To retract the cylinder and eliminate the installation pressure open the washer turning it to the left. The piston retracts pushed by the internal spring. The return may
be slower at the end of the backstroke.
8º- Put the material to be treated in the press. 5. MAINTENANCE.
The hydraulic circuit of the press is closed, so in normal conditions no oil leakage should be coming up.
In case of oil leakage, after the proper repairing work, you should fill up the tank with hydraulic oil by LARZEP (Ref. AZ8901); the pump is equipped with an oil level
indicator to control the need quantity of oil.
As far as a non-continuous use of the press is concerned (1 hour per day), oil replacement should be done once a year.
USE ONLY LARZEP HYDRAULIC OIL
Other grades of oils or types of hydraulic fluid (such as brake fluid) may affect the performance of the equipment or cause the deterioration of the seals.
Always use the original LARZEP parts to prolong the service life of your hydraulic equipment. LARZEP S.A. or your authorized dealer can supply you with original
parts for simple maintenance work.
The machine is stable enough to operate without fixing, but if is placed in an area commonly operated by mobile machinery (cranes,
lifting equipment…) it is strongly recommended to fix it to the desired place by drilling the supporting plates.
DO NO ATTEMPT TO FILL THE PUMP WITH OIL WHILE IT IS CONNECTED TO A CYLINDER WHICH IS SUSTAINING A LOAD
BECAUSE IT MAY OVERPRESSURIZE THE RESERVOIR WHEN THE PISTON RETRACS AND CAUSE DAMAGE OR INJURY
To empty the tank, you should remove the cover and take the oil out to another container. Please, bear in mind the existing rules for waste
processing when handling the used oil. Keep greasy and lubricated the pin bearings, the piston and in general all the parts that might be in
friction

5
INSTRUCTION MANUAL
Column Press with Hand Pump
TYPE OF INSPECTION
FREQUENT: a visual inspection carried out before and after each operation.
PERIODIC: a thorough examination of the equipment, both externally and internally. The equipment is labelled with the inspection date and the date is logged in a
register.
PARTS TO INSPECT
In a FREQUENT INSPECTION, check for:
•Piston wear
•Signs of corrosion
•Wear or damage to the cylinder or pump
•Cracks, dents or any other damage to the frame, cylinder attachments, work table and its supports
•Oil leaks
•Loose or damage screws or joints
•Damaged or incorrectly assembled accessories
In a PERIODIC INSPECTION, check for the same problems as in a frequent inspection but in addition, the hydraulic equipment should be disassembled and cleaned
by an authorized service dealer so that it may be examined internally.
Periodically clean and relubricate the press’s moving parts, such as the piston, winch, pumping mechanism, etc. This is especially important when working in salty or
humid environments.
Hydraulics equipment, which is subject to the very severe environmental conditions mentioned, previously should be cleaned and relubricated after each use.
To clean the hydraulic equipment, begin by removing the pump’s oil reservoir plug and draining al the oil. Fill reservoir with kerosene and thoroughly circulate it
thorough the hydraulic equipment. After completely purging the kerosene out of the hydraulic circuit, align the pump vertically with the head down and fill the
reservoir with the new hydraulic oil until the oil level rises to the orifice
6. PROBLEMS, DAMAGES AND SOLUTIONS.
6. PROBLEMS CAUSES SOLUTIONS
1. The piston does not advance. - The pump’s relief valve is open. 1. Close the relief valve.
- Air is trapped in the hydraulic circuit. 2. Open the pump’s relief valve, align the pump vertically
with its head down, and pump the oil several times so that the
air is purged out of the hydraulic circuit.
- No oil in the reservoir. 3. With the piston fully retracted, align the pump vertically
with its head down, remove the oil reservoir plug and fill the
oil reservoir until the oil level reaches the plug’s orifice.
- Dirt has accumulated in the hydraulic circuit. 4. Clean the hydraulic circuit with kerosene as described
previously. If the problem persists, take the press to an
authorized service dealer.
- Worn or damaged check valve. 5. Take the press to an authorized service dealer.
- Improperly connected hydraulic line 6. With the piston fully retracted, ensure that the hydraulic line
is properly connected to the pump and cylinder.
2. The piston advances in spurts. - Air is entrapped in the hydraulic circuit. See Solution 2.
- Deformed piston. See Solution 5.
3. The piston will not fully extend. - Low oil level. See Solution 3.
- Deformed piston. See Solution 5.
4. the piston advances very slowly. - Air is entrapped in the hydraulic circuit. See Solution 2.
- Dirt has accumulated in the hydraulic circuit. See Solution 4.
- Worn or damaged check valve. See Solution 5.
- Improperly connected hydraulic line See Solution 6.
7. WARRANTY.
LARZEP, S.A. guarantees its products against all design and manufacturing defects for the durations of two years from the date of purchase. This guarantee does not
include the ordinary wear of both metal and non-metal parts, abuse, using the equipment beyond its rated capacity and any wear or damage incurred as a result of using
a hydraulic fluid which is not recommended by LARZEP, S.A.
Please note that if the equipment is disassembled or serviced by anyone other than an authorized service dealer or by LARZEP, S.A., this guarantee is rendered null
and void.
In the event of a warranty claim, return the equipment, to LARZEP, S.A. or the authorized dealer which sold you the hydraulic equipment, LARZEP, S.A. will repair
or replace the faulty equipment, whichever is deemed most appropriate. LARZEP, S.A. shall not be held liable for any consequential damages or losses, which may
occur as a result of faulty equipment

6
INSTRUCTION MANUAL
Column Press with Hand Pump
8. DECLARATION OF CONFORMITY.

7
INSTRUCTION MANUAL
Column Press with Hand Pump

8
INSTRUCTION MANUAL
Column Press with Hand Pump
Table of contents
Other Larzep Power Tools manuals

Larzep
Larzep ECE01113 User manual

Larzep
Larzep EE06018 User manual

Larzep
Larzep CA1014 User manual

Larzep
Larzep EE03116-CE User manual

Larzep
Larzep EE25030-CE User manual

Larzep
Larzep ECE02015-CE User manual

Larzep
Larzep EE06018-CE User manual

Larzep
Larzep ECE02013-CE User manual

Larzep
Larzep EM06018 User manual

Larzep
Larzep ECE01113-CE User manual

Larzep
Larzep EE12018-CE User manual

Larzep
Larzep ECM01113 User manual

Larzep
Larzep EE25030-CE/L User manual

Larzep
Larzep EE12018 User manual

Larzep
Larzep ECZ01113 User manual

Larzep
Larzep ECE02013 User manual

Larzep
Larzep EE03116 User manual

Larzep
Larzep ECE01115 User manual

Larzep
Larzep EZ03012 User manual
