Laserworld V PRO-OEM User manual

V PRO-OEM black
User Manual
OEM housing without laser sources
Please read this manual carefully before use!

User Manual: V PRO-OEM
Stand: 03/2010
Page
2
of
8
Contents
Page
SAFE Y INS RUC IONS .........................................................................................................2
OPERA ING HE LASER .........................................................................................................3
Using the laser..........................................................................................................................3
Control panel ............................................................................................................................3
Control panel ............................................................................................................................4
ILDA mode ................................................................................................................................4
DMX mode.................................................................................................................................4
Maintenance / cleaning ...........................................................................................................5
echnical specifications...........................................................................................................5
Change scanner........................................................................................................................5
Adjustable mirror mounts .......................................................................................................5
roubleshooting .......................................................................................................................6
ILDA signal................................................................................................................................6
echnical diagram....................................................................................................................7
Please note................................................................................................................................7
EU-declaration of conformity..................................................................................................8
Checking arts
Please check if all listed parts are included, and are not damaged. Included:
1 x V PRO-OEM housing black
1 x Power cable
1 x 9-pin plug
2 x key
1 x safety cord
1 x manual
SAFETY INSTRUCTIONS
If the device has been exposed to great temperature changes, do not switch it on
immediately. Condensation water may damage your device. Leave the device
switched off until it has reached room temperature.
he laser must only be used for shows. Any operation has to be attended and
supervised by a skilled and well-trained operator.
Never leave this device running unattended and keep it away from children and
unauthorized persons.
Keep away from heaters and other heat sources. In order to safeguard sufficient
ventilation, leave 50 cm of free space around the device.
Never direct the laser beam to people or animals.
CAU ION LASER DIODE: If you open the device for
cleaning, always disconnect from mains!
-HEALTH HAZARD! Never look directly into the
light source, as sensitive ersons may suffer
an e ile tic shock!
hese lasers are considered a definite eye hazard,
particularly at the higher power levels, which WILL cause

User Manual: V PRO-OEM
Stand: 03/2010
Page
3
of
8
eye damage. So these laser series models supplied with a key switch to prevent
unauthorized use, warning labels and aperture labels affixed to the laser.
Installation safety
Prior to installation and operation of the laser, the paths of the beams and effects should be
considered, particularly with respect to how they will reach the audience. If direct audience
scanning is desired, then the laser energy in the effects needs to be considered to decide if
the effects are safe for direct viewing. Always ensure, that the maximum permissible
exposure (MPE) is not exceeded in the area accesible to the public. So install the laser in
such a way, that minimum distances and heights ensure the MPE is never exceeded in the
public area.
OPERATING THE LASER
he operator has to make sure that laser radiation – also reflected laser radiation – higher
than the maximum permissible level is avoided by technical or organisational measures.
(Especially with respect to the MPE, see above.)
Make sure to use the correct voltage
If the device is used in a flying installation, the mounting brackets and an appropriate safety-
rope must be fixed.
In some countries, the operator must notify the accidence insurance and the authority for
industrial safety, before operating a laser. For more information, contact the relevant
authorities.
Please consider that unauthorized modifications on the device are strictly forbidden due to
safety reasons!
If this device will be operated in any way differently than described in this manual, the
product may suffer damages and the guarantee becomes void. Furthermore, any other
operation may lead to dangers like short-circuit, burns, electric shock, etc.
Keep surrounding dry and clean. his unit should be keep dry, do not use in the rain or
damp and dusty environment. Projector should be put in a water-proof housing when
operated outside.
Regularly open the device (see “cleaning” further down) to check for dust inside, or if fog
fluid condenses in the housing (if so rearrange hazer and/or laser position).
Operating temperature is 10~35°C. In a new installation, check after some 15-30 minutes
whether the outlet air gets too warm. Regularly check the inside for dust deposits, especially
around the fans. Let laser cool off 10minutes after 2 hours of operation,to ensure maximum
lifetime for the diode.
Distance between laser aperture and projection screen should be not less than 1 meter.
Do not turn device on and immediately off again frequently.
Do not look into the laser beam directly, especially not with optical instruments.
Do not touch the device with wet hands.
When the laser diode becomes dim or broken, please contact your dealer timely.
When returning laser to dealer/manufacturer always use original packaging.
Maintenance should be performed every 15-day period. See “cleaning” further down.
Using the laser
Make sure the correct voltage is used. Connect mains. Connect an emergency switch to the
9-pin connector on the backside (pins 1, 2). If you do not wish to connect an emergency
switch, connect the 9-pin plug. Depending on the mode selected (see below), laser light
should come out of the opening on the front panel – be careful.
Control anel
3/4 DMX In/Out
5 Remotelock: connect emergency switch. If no

User Manual: V PRO-OEM
Stand: 03/2010
Page
4
of
8
Control anel
•MODE: select mode, or go up in menu
•ENTER: confirm changes, or go down in menu
•UP/ DOWN: change DMX address
O erating modes:
Automatic mode: built-in patterns are displayed
Music active: laser is controlled from built-in microphone
“DMXAddr“: DMX512 mode-. Here you can change the DMX address:
“Open“: change address
“Up“ & “down“: increase/decrease address
“Save“: save new address
“LCD display memory function“: save settings automatically.
Laser: On/Off, when set to Off, laser is off in Auto/DMX mode (ILDA mode only)
X/Y-Axis: mirrors projection horizontally/vertically
Upside down: Display turned upside down
ILDA mode
When an IDLA compatible interface is connected to the laser, the laser is automatically
switched to ILDA mode. Output is then controlled from a PC running software.
he laser uses pins 4 and 17 of the IDLA signal to detect the presence of an ILDA interface.
Further information can be found in the software manual.
DMX mode
Channel
DMX512
value
Func
tion
1
Red
0~255
0~100% Dimmer
2
Green
0~255
0~100% Dimmer
3
Bl
u
e
0~255
0~100% Dimmer
4 Colour
0~25
Original
colour
26~51
White
52~77
Yellow
78~103
Red
104~129
Gree
n
130~155
Cyan
156~181
Bl
u
e
182~207
Purple
208~233
Change colour
234~255
Colour flux, slow to fast
5 Pattern group
0~51
Pattern group
1
52~103
Pattern group
2
104~154
Pattern group
3
155~205
Pattern group
4
206~255
Pattern group
5
emergency switch is connected use the 9 pin plug
supplied.
6 Security switch: Laser on/off
7 ILDA connector in/out
8 Power switch: power on/off
9 Power: connect to mains.

User Manual: V PRO-OEM
Stand: 03/2010
Page
5
of
8
6
Pattern
0~255
160/5=32pcs
7
Horizontal
rotation
0~255
slow to fast
8
Vertical rotation
0~255
slow to fast
9
Rotation about Z
-
axis
0~255
slow to f
ast
10
Horizontal
movement
0~255
slow to fast
11
Verti
c
al
movement
0~255
slow to fast
12
Horizontal
size
0~255
slow to fast
13
Verti
c
al
size
0~255
slow to fast
14
Hor. and vert. size
0~255
slow to fast
15
Drawing speed
0~255
slow to fast
16
Point dr
aw
0~255
slow to fast
17
Scan
speed
0~255
slow to fast
18
Pattern size
0~1
Original
size
2~255
Size
(120=o
riginal
)
Maintenance / cleaning
Always disconnect from mains before cleaning/opening the laser. Regularly clean the interior
from dust, especially ensure operation of the fans. Use a sponge with alcohol, rather than
wet cloth or other chemical liquid, to clean the mirrors. Be careful, even light scratches
reduce the output power of the laser. Mirrors need cleaning, when a “halo” is noticeable
around the beam, or an unusual high amount of diffuse light can be seen inside the device.
Technical s ecifications
• Modes: ILDA, DMX 512, auto, music active
• ILDA: 25pin ILDA standard Sub-D shaped 25pin connector
• Galvos: 50k scanspeed
• DMX 512: 14 channels
• Patterns: 160
• Scanangle: set to ca. 40° optical (60° max)
• Beam: ca. 3mm/1mrad
• Accessories: power cable, key switch, interlock plug, manual, safety cord
• he laser comes in a flightcase.
• In ut voltage: AC 100~240V 50/60Hz
• Power consum tion: 450W
• Size: 670 x 370 x 440 mm (W x D x H)
• Weight: 30kg Laser, total: 50kg (with
flightcase)
• O erating tem erature: 10°-35°C
(below 20°C the power may be reduced)
Change scanner
1. Unscrew UK M6 screws and disconnect signal
cable.
2. Loosen M4 x 10 screw and remove galvo.
3. Insert galvo, reconnect and fix signal cable.
4. Rotate galvo to centre projection. Fix galvo.
Adjustable mirror mounts
1. Loosen setscrews, then adjust with X/Y
adjustable screws. Make sure beam is centred
on scanner mirrors.
2. Adjust Z-screw simultaneously.
3. ighten setscrews.

User Manual: V PRO-OEM
Stand: 03/2010
Page
6
of
8
4. When combining beams (RGY/RGB laser), first make sure the beams are (roughly) on
the same spot on the mirrors/dichros. hen use a test pattern (e.g. rectangle) to do
fine adjustment. For adjustments, always turn output power down (if possible).
Troubleshooting
Problem Possible reason Damaged art Re lacement
No power Fuse blown Fuse 09-00-3001-01
Power supply defective +-24V 16-03-0039-00
12V 19-03-0019-00
Music mode not working Microphone defective Microphone 16-03-0001-00
Control board defective Control board 26-2A-2009LD-00
Potentiometer defective Potentiometer 04-03-0104-01
CPU defective IC 00-89C516ED-00
X and/or Y axis no
deflection
Scanner defective Galvo 15-01-2215-00
CPU defective IC 00-89C516ED-00
Control board defective Control PCB 26-2A-2009LD-00
Power supply defective +-24V 16-03-0039-00
Scanner driver board defective Scanner driver board 26-2A-6800A-00
Laser dark or dim
Lenses / mirrors dirty Clean with alcohol
Laser diode defective Laser diode Inquire
Control board defective Control board 26-2A-2009LD-00
Configuration / wrong mode Check configuration (see
paragraph control panel)
No output
Configuration / wrong mode Check configuration (see
paragraph control panel)
Control board defective Control PCB 26-2A-2009LD-00
Power supply defective +-24V 16-03-0039-00
Display board defective Display 26-2A-YX2012DI-00
Pins 4 and 17 of the ILDA signal
not connected
See below
Laser does not switch to ILDA mode:
•he interface does not connect pins 4 and 17 (Interlock) of the IDLA signal. See interface
manual
•he cable does not connect pins 4 and 17. Use a cable that connects pins 4 and 17.
•Use an adapter that connects pins 4 and 17.
ILDA signal
Pin out of the standard ILDA signal:
1 Scanner X+ -10V..+10V 14 X- +10V..-10V
2 Scanner Y+ -10V..+10V 15 Y- +10V..-10V
3 Intensity/Blanking+ 0V..+2.5V 16 Intensity/Blanking- 0..-2.5V
4 Interlock A 17 Interlock B
5 Red+ 0..2.5V 18 Red- 0..-2.5V
6 Green+ 0..2.5V 19 Green- 0..2.5V
7 Blue+ 0..2.5V 20 Blue- 0..-2.5V
8 – 12 Not used 23-24 Not used
13 Shutter +5V, max. 20 mA 25 GND Signal ground

User Manual: V PRO-OEM
Stand: 03/2010
Page
7
of
8
Technical diagram
Please note
his device has left our premises in absolutely perfect condition. In order to maintain this
condition and to ensure a safe operation, it is absolutely necessary for the user to follow the
safety instructions and warning notes written in this user manual.
Laserworld cannot be made liable for damages caused by incorrect installations and unskilled
operation!

User Manual: V PRO-OEM
Stand: 03/2010
Page
8
of
8
EU-declaration of conformity
We hereby confirm that the following device
Laserworld V PRO-OEM black
complies with the essential safety requirements, laid down in the regulations of the
committee to assimilate the provisions of law of all participating EU states on the
electromagnetic compatibility (89/336/EWG) and with the requirements relating to the Low
Voltage Directive (LVD 2006/95/EG) was based on the following standards:
DIN EN 61000-3-2:2000 + A2: 2005
DIN EN 61000-3-3:1995 + A1: 2001
Furthermore, the device is verified in correspondence to the laser class regulations DIN EN
60825-1, if properly set up according to the upper mentioned laser safety regulation.
After installing the device, an inspection and official approval is indispensable for the overall
setup. he inspection must follow the european guidelines EN 60825-1 and corresponding
regulations for the prevention of accidents BGV-B2.
his declaration is executed on behalf of the Laserworld V PRO-OEM manufacturer
Laserworld (Switzerland) AG
Kreuzlingerstrasse 5
8574 Lengwil-Oberhofen
SCHWEIZ
Vertretungsberechtigte Personen:
Verwaltungsrat Martin Werner
Sitz des Unternehmens: 8574 Lengwil-Oberhofen / Schweiz
Firmennummer: CH-440.3.020.548-6
Handelsregister Kanton hurgau
www.laserworld.com
[e-mail]
Bevollmächtigter im Sinne des EMVG:
Cleantech Europe GmbH
Geschäftsführer: homas Schulze
Fürkhofstr. 5
81927 München / DE
