Lattice Semiconductor ASC Bridge Board User manual

ASC Bridge Board
Evaluation Board User Guide
FPGA-EB-02025-2.0
September 2018

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
2 FPGA-EB-02025-2.0
Contents
Acronyms in This Document.................................................................................................................................................4
1. Introduction...................................................................................................................................................................5
2. Features.........................................................................................................................................................................6
3. Setting Up the Board .....................................................................................................................................................7
4. Applying Power to the Board.........................................................................................................................................7
5. System Clock..................................................................................................................................................................7
6. Electrical, Mechanical, and Environmental Specifications ............................................................................................8
7. J2 and J3 Female Header ...............................................................................................................................................8
8. J6, J7 and J13 D-SUB25 Connector.................................................................................................................................8
9. J1 Male Header............................................................................................................................................................11
10. J16 Fan 1 Header .........................................................................................................................................................12
11. J21 Fan 2 Header .........................................................................................................................................................12
12. J19 Fan 3 Header .........................................................................................................................................................12
13. Push Buttons................................................................................................................................................................13
14. LED Indicators..............................................................................................................................................................13
15. Demonstration Design.................................................................................................................................................13
References ..........................................................................................................................................................................14
Ordering Information..........................................................................................................................................................14
Technical Support Assistance .............................................................................................................................................14
Appendix A. Board Schematics ...........................................................................................................................................15
Appendix B. Bill of Materials...............................................................................................................................................19
Appendix C. MachXO3 9400 Development Board and ASC Bridge Board Signals and Connections. .................................20
Appendix D. ECP5 Versa Development Board and ASC Bridge Board Signals and Connections.........................................22
RevisionHistory...................................................................................................................................................................24
Figures
Figure 1.1. ASC Bridge Board, Top Side ................................................................................................................................5
Figure 2.1. MachXO3-9400 Evaluation Board Connected to the Three ASC Breakout Boards.............................................6
Figure A.1. ASC Bridge Board Block Diagram......................................................................................................................15
Figure A.2. ECP5 Connection ..............................................................................................................................................16
Figure A.3. ASC Connection ................................................................................................................................................17
Figure A.4. Fan Connectors.................................................................................................................................................18

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02025-2.0 3
Tables
Table 5.1. ASC0 ASCCLK Jumper Setting...............................................................................................................................7
Table 8.1. J6 D-SUB 25 Connection.......................................................................................................................................8
Table 8.2. J13 D-SUB 25 Connection.....................................................................................................................................9
Table 8.3. J7 D-SUB 25 Connection.....................................................................................................................................10
Table 9.1. J1 Male Header Connections for use with MachXO3-9400 or ECP5 Versa Develpment Board.........................11
Table 10.1. Fan 1 Header Connection.................................................................................................................................12
Table 11.1. Fan 2 Header Connection.................................................................................................................................12
Table 12.1. Fan 3 Header Connection.................................................................................................................................12
Table 13.1. Momentary Push-Buttons................................................................................................................................13
Table C.1. ASC1 (J4) –MachXO3-9400 Development Board and ASC Bridge Board Connections......................................20
Table C.2. ASC2 (J13) –MachXO3-9400 Development Board and ASC Bridge Board Connections....................................20
Table C.3. ASC3 (J7) –MachXO3-9400 Development Board and ASC Bridge Board Connections ctions...........................20
Table C.4. Miscellaneous –MachXO3-9400 Development Board and ASC Bridge Board Connections .............................21
Table D.1. ASC0 (J4) –ECP5 Versa Development Board and ASC Bridge Board Connections.............................................22
Table D.2. ASC1 (J13) –ECP5 Versa Development Board and ASC Bridge Board Connections ..........................................22
Table D.3. ASC2 (J7) –ECP5 Versa Development Board and ASC Bridge Board Connections ............................................22
Table D.4. Miscellaneous –ECP5 Versa Development Board and ASC Bridge Board Connections....................................23

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
4 FPGA-EB-02025-2.0
Acronyms in This Document
A list of acronyms used in this document.
Acronym
Definition
ASC
Analog Sense and Control
FPGA
Field Programmable Gate Array
GPIO
General Purpose Input/Output
I2C
Inter-Integrated Circuit
PWM
Pulse Width Modulation

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02025-2.0 5
1. Introduction
This guide describes the ASC Bridge Board, an interface board that connects up to three ASC Breakout Boards to
either the MachXO3™-9400 Development Board or the ECP5™Versa Development board for rapid prototyping
and testing platform and hardware management applications. Throughout this document, the phrase ASC
Breakout Board refers to a Platform Manager 2 evaluation board that is known by several names. The silkscreen
on the board itself is PM2 ASC EVAL BOARD, the ordering part number is LPTM-ASC-B-EVN, and on the Lattice web
site, the product name is L-ASC10 Breakout Board. The ASC Bridge Board does not contain any programmable
logic nor does it have a USB connector for power or programming. The ASC Bridge Board is primarily an
interconnect between the ASC Breakout Boards and either the MachXO3-9400 Development Board or the ECP5
Versa Development Board.
The content of this user guide includes descriptions of on-board jumper settings, tables detailing the inter-board
connections, a complete set of schematics and the bill of materials for the ASC Bridge Board.
Complete descriptions of the MachXO3 FPGA, ECP5 FPGA, and L-ASC10 devices are found in the MachXO3 Family Data
Sheet (FPGA-DS-02032), ECP5 and ECP5-5G Family Data Sheet (FPGA-DS-02012), and L-ASC10 Data Sheet (FPGA-DS-
02038).
For full descriptions of the MachXO3-9400 Development Board, ECP5 Versa Development Board and L-ASC10 Breakout
Board, see the MachXO3-9400 Development Board User Guide (FPGA-EB-02004), ECP5 Versa Development Board User
Guide (FPGA-EB-02021), and ASC Breakout Board User Guide (FPGA-EB-02023).
Figure 1.1. ASC Bridge Board, Top Side

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
6 FPGA-EB-02025-2.0
2. Features
The ASC Bridge Board features the following on board components and circuits:
0.1-inch pitch through hole prototype area
Three fan connectors with PWM (pulse width modulation) drive circuitry
Two tactile push buttons
Connectors for up to three ASC Breakout Boards
Expansion header for additional FPGA I/Os
Versa connectors to mate with either the MachXO3-9400 Development Board or the ECP5 Versa Development
Board.
ASC1
Rail LEDs
ASC0 DC-DC 4
ASC0 DC-DC 3
ASC1
POT1 (VMON 7)
and
POT2 (VMON 8)
ASC2
Rail LEDs
ASC2
POT1 (VMON 7)
and
POT2 (VMON 8)
ASC3
Rail LEDs
ASC3
POT1 (VMON 7)
and
POT2 (VMON 8)
Push Button SW1
Push Button SW2
ASC0 POT1
(VMON 7)
ASC0
ASC3 Push Button SW2
ASC2 Push Button SW2
ASC1 Push Button SW2
SW3 – I2C Select
Figure 2.1. MachXO3-9400 Evaluation Board Connected to the Three ASC Breakout Boards

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02025-2.0 7
3. Setting Up the Board
To set up the board:
Attach four of the included nylon standoffs to the ASC Bridge Board (only one standoff is needed at the narrow
edge of the board).
Attach two of the included nylon standoffs to the outside edge of each ASC Breakout Board.
Connect the ASC Bridge Board using the Versa connectors (J2 and J3) to either the MachXO3-9400 Development
Board or the ECP5 Versa Development Board.
Connect the ASC Breakout Board(s) using J6, J7 and J13 as shown in Figure 2.1. The number of ASC Breakout Boards
to install is based on the design requirement.
Slide SW3 to the MachXO3 position if the MachXO3-9400 Development Board is connected.
Note: SW3 can also remain in the MachXO3 position for new ECP5 designs as long as the I2C pins are mapped
according to Table D.4 in Appendix D. SW3 only needs to be in the ECP5 position to support a legacy demo design.
SW3 swaps the SDA and SCL signals on the ASC Bridge Board (see Figure A.2 in Appendix A).
4. Applying Power to the Board
The 3.3 V system power is supplied by either the MachXO3-9400 Development Board or the ECP5 Versa Development
Board. Depending on your design requirement, the 5 V and 12 V power can be applied through the ASC Breakout Board
(after the Hot Swap and/or Trim circuits have been populated).
Refer to the either the MachXO3-9400 Development Board User Guide (FPGA-EB-02004) or the ECP5 Versa
Development Board User Guide (FPGA-EB-02021), and ASC Breakout Board User Guide (FPGA-EB-02023) on how to
connect these power supplies. When using the 5 V and 12 V power supply, only one ASC Breakout Board is needed to
connect to the power source. By shorting jumpers J8, J9, and J14, the 5 V supply connects to the other ASC Breakout
Boards. Jumpers J4, J5, and J12 will do the same for the 12 V supply.
Note: The ASC Breakout Board may be populated with user supplied 3.3 V voltage regulator (DCDC5). When setting up
the platform, be sure that only one board is supplying the 3.3 V power to prevent power supply contention.
5. System Clock
The 8 MHz system source clock comes from the ASC0 device. When using the MachXO3-9400 Development Board, no
clock jumpers need to be installed on the ASC Bridge Board; the ASC0 device is located on the MachXO3-9400
Development Board and the clock signal is hard-wired to the MachXO3.
When using the ECP5 Versa Development board, the ASC0 device can be plugged-in to any of the ASC connectors.
Shorting one of the jumpers, J10, J11, J15, enables the ASC0 ASCCLK to connect to ECP5 device. It is recommended to
connect only one jumper.
Table 5.1. ASC0 ASCCLK Jumper Setting
ASC Connector
ASC0 Clock Jumper
ASC0 Connector
J10
ASC1 Connector
J15
ASC2 Connector
J11

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
8 FPGA-EB-02025-2.0
6. Electrical, Mechanical, and Environmental Specifications
The nominal board dimensions are 3.875 inches by 11.5 inches. Five 0.125 inch plated through holes are provided to
allow installation of plastic or metal spacers to lift the board off the desktop to a uniform height.
Operation temperature: 0°C to 55°C
Storage temperature: –40°C to 75°C
Humidity: <95% without condensation
7. J2 and J3 Female Header
J2 and J3 are 40-pin female headers that connect the signals from either the MachXO3-9400 Development Board or the
ECP5 Versa Development Board to the ASC Bridge Board. The female header carries both signal and power. The
connections for J2 and J3 are listed in Appendix C and Appendix D.
Note: The connections referenced in this document refer to the LFE5UM-45F-8BG381C device.
8. J6, J7 and J13 D-SUB25 Connector
The L-ASC10 Evaluation Board is connected to the ASC Bridge Board through D-SUB 25-pin connectors. These
connectors carry both signal and power.
Table 8.1 through Table 8.3 show the connections between the D-SUB connectors to J2 and J3 connectors.
Table 8.1. J6 D-SUB 25 Connection
J6 Header
Pin Number
ASC Pin Function
Header Connection
Header Pin Number
1
GND
—
—
2
WDAT
J3
13
3
RDAT
J3
9
4
WRCLK
J3
10
5
MANDATORY_RESET
J2
28
6
GND
—
—
7
I2C_WRITE_EN
J2
32
8
ASC_CLK
J3
5
9
3.3 V
—
—
10
N.C.
—
—
11
12 V
—
—
12
5 V
—
—
13
GND
—
—
14
ASC_12V_OC_SHUTDOWN
J3
14
15
ASC_12V_OC_SENSE
J3
12
16
GND
—
—
17
ASC_RESET
J3
7
18
I2C_SCL
J2
18
19
I2C_SDA
J2
16
20
ASC_5V_OC_SHUTDOWN
J3
8
21
ASC_5V_OC_SENSE
J3
6
22
ASC_BOARD_SENSE
J3
4
23
12 V
—
—
24
5 V
—
—
25
5 V
—
—

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02025-2.0 9
Table 8.2. J13 D-SUB 25 Connection
J13 Header
Pin Number
ASC Pin Function
Header Connection
Header Pin Number
1
GND
—
—
2
WDAT
J2
11
3
RDAT
J2
9
4
WRCLK
J2
10
5
MANDATORY_RESET
J2
28
6
GND
—
—
7
I2C_WRITE_EN
J2
32
8
ASC_CLK
J2
13
9
3.3 V
—
—
10
N.C.
—
—
11
12 V
—
—
12
5 V
—
—
13
GND
—
—
14
ASC_12V_OC_SHUTDOWN
J2
14
15
ASC_12V_OC_SENSE
J2
12
16
GND
—
—
17
ASC_RESET
J2
7
18
I2C_SCL
J2
18
19
I2C_SDA
J2
16
20
ASC_5V_OC_SHUTDOWN
J2
8
21
ASC_5V_OC_SENSE
J2
6
22
ASC_BOARD_SENSE
J2
4
23
12 V
—
—
24
5 V
—
—
25
5 V
—
—

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
10 FPGA-EB-02025-2.0
Table 8.3. J7 D-SUB 25 Connection
J7 Header
Pin Number
ASC Pin Function
Header Connection
Header Pin Number
1
GND
—
—
2
WDAT
J2
27
3
RDAT
J2
31
4
WRCLK
J2
33
5
MANDATORY_RESET
J2
28
6
GND
—
—
7
I2C_WRITE_EN
J2
32
8
ASC_CLK
J3
5
9
3.3 V
—
—
10
N.C.
—
—
11
12 V
—
—
12
5 V
—
—
13
GND
—
—
14
ASC_12V_OC_SHUTDOWN
J2
25
15
ASC_12V_OC_SENSE
J2
29
16
GND
—
—
17
ASC_RESET
J2
35
18
I2C_SCL
J2
18
19
I2C_SDA
J2
16
20
ASC_5V_OC_SHUTDOWN
J2
37
21
ASC_5V_OC_SENSE
J2
39
22
ASC_BOARD_SENSE
J2
36
23
12 V
—
—
24
5 V
—
—
25
5 V
—
—

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02025-2.0 11
9. J1 Male Header
The J1 male header provides power pins and additional I/Os from either the MachXO3-9400 Development Board or the
ECP5 Versa Development Board’s expansion connector which are not connected to the ASC Breakout Board
connectors.
Table 9.1. J1 Male Header Connections for use with MachXO3-9400 or ECP5 Versa Develpment Board
J1 Pin
Number
Silkscreen
Name
MachXO3-9400
ECP5-45
FPGA Board
Signal Name
Ball
Port
Ball
Port
1
+3.3 V
––
––
––
2
+2.5 V
––
––
––
3
N.C.
––
––
––
4
EXPCON_OSC
(Note)1
(Note)2
EXPCON_OSC
5
EXPCON_CLKIN
A10
PT23B
A10
PT36A
EXPCON_CLKIN
6
EXPCON_CLKOUT
A21
PT44A
E11
PT42B
EXPCON_CLKOUT
7
HPE_RESOUT#
G9
PT21D
A8
PT18B
HPE_RESOUT#
8
EXPCON_IO0
F8
PT11C
A12
PT49A
EXPCON_IO0
9
EXPCON_IO2
F9
PT21C
B13
PT51A
EXPCON_IO2
10
EXPCON_IO14
C6
PT14C
A9
PT33A
EXPCON_IO12
11
EXPCON_IO17
D8
PT15B
B15
PT69A
EXPCON_IO16
12
CARDSEL#
C13
PT29C
A7
PT18A
CARDSEL#
13
GND
––
––
GND
14
GND
––
––
GND
15
GND
––
––
GND
16
GND
––
––
GND
17
GND
––
––
GND
18
GND
––
––
GND
19
GND
––
––
GND
20
GND
––
––
GND
21
GND
––
––
GND
22
GND
––
––
GND
23
GND
––
––
GND
24
GND
––
––
GND
Notes:
When using the MachXO3-9400 Development Board the J1 pin 4 signal EXPCON_OSC comes from either the on-board oscillator
Y2 or from an off-board source using J10.
When using the ECP5 Versa Development Board the J1 pin 4 signal EXPCON_OSC comes from the on-board Lattice
ispClock5406D device.

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
12 FPGA-EB-02025-2.0
10. J16 Fan 1 Header
This fan connector supports either a 3-wire low-side drive fan or 4-wire fan.
Table 10.1. Fan 1 Header Connection
J16 Pin
Number
Description
MachXO3-9400
ECP5-45
FPGA Board
Signal Name
Ball
Pad
Ball
Pad
1
GND
––
––
––
2
PWM Switch to GND*
G15
PT42D
C7
PT11B
EXPCON_IO44
3
PWM
G15
PT42D
C7
PT11B
EXPCON_IO44
4
Fan Tachometer
G12
PT28A
C6
PT11A
EXPCON_IO45
5
+5 V
––
––
––
6
+12 V
––
––
––
*Note: J16 pin 2 is buffered and inverted from the signal FAN1_PWM. See Figure A.4 in the Appendix A. Board Schematics section
for additional details.
11. J21 Fan 2 Header
This fan connector supports a 3-wire low-side drive fan. The power pin on this connector is selectable between 5 V and
12 V through jumper J20. Shorting the jumper to the 1-2 location selects the 12 V option. The 5 V option is selected
when the jumper in on the 2-3 location.
Table 11.1. Fan 2 Header Connection
J21 Pin
Number
Description
MachXO3-9400
ECP5-45
FPGA Board
Signal Name
Ball
Pad
Ball
Pad
1
PWM Switch to GND*
G15
PT42D
D8
PT13B
EXPCON_IO42
2
Fan Power
––
––
––
3
Fan Tachometer
F15
PT42C
E8
PT13A
EXPCON_IO43
*Note: J21 pin 1 is buffered and inverted from the signal FAN2_PWM. See Figure A.4 in the Appendix A. Board Schematics
section for additional details.
12. J19 Fan 3 Header
This fan connector supports a 3-wire high side drive fan. The power for this fan connector is selectable between 5 V
and 12 V through jumper J17. Shorting the jumper to the 1-2 location selects the 12 V option. The 5 V option is selected
when the jumper in on the 2-3 location. A hold-up capacitor is inserted in parallel with the fan to guarantee proper
under speed detection. The ASC Bridge Board has a set of pre-populated capacitors connected through jumper J18. For
fan PWM frequency less than 10 kHz, connect J18 to the 1-2 location. Connect J18 to the 2-3 location for fan PWM
frequency between 10 kHz to 26.7 kHz. If the fan PWM frequency is greater than 40 kHz, leave J18 unconnected. For
more information about fan control, please refer to TN1278, Temperature Monitoring and Fan Control with Platform
Manager 2.
Table 12.1. Fan 3 Header Connection
J19 Pin
Number
Description
MachXO3-9400
ECP5-45
FPGA Board
Signal Name
Ball
Pad
Ball
Pad
1
GND
––
––
––
2
PWM Switch to Power*
E16
PT40C
B8
PT15B
EXPCON_IO40
3
Fan Tachometer
E13
PT28C
C8
PT15A
EXPCON_IO41
*Note: J19 pin 2 is buffered from the signal FAN3_PWM. See Figure A.4 in the Appendix A. Board Schematics section for additional
details.

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02025-2.0 13
13. Push Buttons
Two push-button switches are connected to FPGA I/O with a 10 kΩpull-up resistor tied to the 3.3 V supply. Depressing
the button drives a logic level “0” to the device.
Table 13.1. Momentary Push-Buttons
Push Button SW
MachXO3-9400
ECP5-45
FPGA Board
Signal Name
Ball
Pad
Ball
Pad
SW1
C6
PT14C
A9
PT33A
EXPCON_IO12
SW2
D8
PT15B
B15
PT69A
EXPCON_IO16
14. LED Indicators
The D1 blue LED illuminates when 3.3 V power is applied to the ASC Bridge Board. The red LEDs, D2, D3, and D4
illuminate when the corresponding ASC Breakout Boards are installed on the ASC0, ASC1 or ASC2 connectors.
15. Demonstration Design
For all the latest demo designs and documentation, please see the Lattice web page for the ASC Bridge Board.

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
14 FPGA-EB-02025-2.0
References
For more information, refer to
ECP5 and ECP5-5G Family Data Sheet (FPGA-DS-02012)
L-ASC10 Data Sheet (FPGA-DS-02038)
MachXO3-9400 Development Board User Guide (FPGA-EB-02004)
ECP5 Versa Development Board User Guide (FPGA-EB-02021)
ASC Breakout Board User Guide (FPGA-EB-02023)
Temperature Monitoring and Fan Control with Platform Manager 2 (FPGA-TN-02080)
Adding Scalable Power and Thermal Management to MachXO2 and MachXO3 Using L-ASC10 (AN6094)
Adding Scalable Power and Thermal Management to ECP5 Using L-ASC10 (AN6095)
Ordering Information
Description
Ordering Part Number
China RoHS Environment-Friendly Use
Period (EFUP)
ASC Bridge Evaluation Board
LFE5-BRIDGE-EVN
Technical Support Assistance
Submit a technical support case through www.latticesemi.com/techsupport.

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-020Ϯϱ-2.0 15
Appendix A. Board Schematics
Figure A.1. ASC Bridge Board Block Diagram
5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
ASC0 Connector
ECP5 Versa Board /
MachXO3 - 9400
Development Board
Expansion Port
+12V in
+5V in
5V
12V
3.3V
ASC1 Connector
ASC2 Connector
Fan Connector
Prototype Area
+3.3V in
+12V in
+5V in
+12V in
+5V in
* Use 4-layer routing including 3.3V and GND plane.
* 12V and 5V supply distribution use thick trace
* All component should be placed on top except 40-pin femail header J2 and J3
Title Size
Project
Rev.
Date: Sheet of
Lattice Semiconductor Corporation
5555 N.E. Moore Court
Hillsboro, Oregon. 97124
Designer:
ASC Bridge Board
B
Block Diagram
B
1 5Tuesday, July 11, 2017
Title Size
Project
Rev.
Date: Sheet of
Lattice Semiconductor Corporation
5555 N.E. Moore Court
Hillsboro, Oregon. 97124
Designer:
ASC Bridge Board
B
Block Diagram
B
1 5Tuesday, July 11, 2017
Title Size
Project
Rev.
Date: Sheet of
Lattice Semiconductor Corporation
5555 N.E. Moore Court
Hillsboro, Oregon. 97124
Designer:
ASC Bridge Board
B
Block Diagram
B
1 5Tuesday, July 11, 2017

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
16 FPGA-EB-020Ϯϱ-2.0
Figure A.2. ECP5 Connection
5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
Prototype Area
Note: Use 0.1" pictch spacing. Each connection use plated through hole for layout
ECP5 Connectors
Note: Place J2 and J3 connector on the bottom side of PCB. The silkscreen should be placed on top side.
Silkscreen : XO3
Silkscreen : ECP5
+3.3V +3.3V+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+12V
+5V
+3.3V
ASC0_BOARD_SENSE_O {3}
ASC0_5V_OC_SENSE {3}
ASC0_5V_OC_SHUTDOWN {3}
ASC0_12V_OC_SENSE {3}
ASC0_12V_OC_SHUTDOWN {3}
FAN3_TACH {4}
FAN2_TACH {4}
FAN1_TACH {4}
ASC0_CLK_O{3} ASC0_RESET{3} ASC0_RDAT{3} ASC2_CLK_O{3}
ASC1_BOARD_SENSE_O {3}
ASC1_5V_OC_SENSE {3}
ASC1_5V_OC_SHUTDOWN {3}
ASC1_12V_OC_SENSE {3}
ASC1_12V_OC_SHUTDOWN {3}
MANDATORY_RESET {3}
ASC2_RESET{3} ASC2_5V_OC_SHUTDOWN{3} ASC2_5V_OC_SENSE{3}
ASC2_RDAT{3} ASC2_12V_OC_SENSE{3}
ASC2_12V_OC_SHUTDOWN{3}
ASC1_CLK_O{3}
ASC1_RDAT{3} ASC1_RESET{3}
ASC2_BOARD_SENSE_O {3}
ASC0_WRCLK {3}
ASC0_WDAT{3} FAN3_PWM{4} FAN2_PWM{4} FAN1_PWM{4}
ASC1_WRCLK {3}
I2C_SDA_1 {2}
I2C_SCL_1 {2}
I2C_WRITE_EN {3}
ASC1_WDAT{3}
ASC2_WDAT{3}
ASC2_WRCLK{3}
I2C_SDA_1{2}
I2C_SCL_1{2}
I2C_SDA {3}
I2C_SCL {3}
Title Size
Project
Rev.
Date: Sheet of
Lattice Semiconductor Corporation
5555 N.E. Moore Court
Hillsboro, Oregon. 97124
Designer:
ASC Bridge Board
B
ECP5 / XO3 Connection
B
2 5Tuesday, July 11, 2017
Title Size
Project
Rev.
Date: Sheet of
Lattice Semiconductor Corporation
5555 N.E. Moore Court
Hillsboro, Oregon. 97124
Designer:
ASC Bridge Board
B
ECP5 / XO3 Connection
B
2 5Tuesday, July 11, 2017
Title Size
Project
Rev.
Date: Sheet of
Lattice Semiconductor Corporation
5555 N.E. Moore Court
Hillsboro, Oregon. 97124
Designer:
ASC Bridge Board
B
ECP5 / XO3 Connection
B
2 5Tuesday, July 11, 2017
AA12
AD3
AJ10
AF2
AG5
AF12AH12
AC7
AK2
AG12
SW3
JS202011SCQN
2
1
3
5
4
6
AK9
AD12
AB1
J3
40-Pin Header F
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
23 24
25 26
27 28
29 30
31 32
33 34
35 36
37 38
39 40
AF9
AB7
AA10
AD4
AJ11
AF1
AE6
AE11
AC5
AJ3
AH5
AK1
J2
40-Pin Header F
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
23 24
25 26
27 28
29 30
31 32
33 34
35 36
37 38
39 40
AF3
AK8
AA2
J1
24-Pin Header M
1
2
3
4
5
6
7
8
9
10
11
1213
14
15
16
17
18
19
20
21
22
23
24
AF8 AB8
AA11
R3
100
AK3
AD5
AE2
AE5 AA4
AC8
AJ4
AJ2
AH6
AG3
AA1
AF7
AB10
AG9
AD6
AJ12
AE1
AG6 AA5AJ5 AC6
AJ1
AH8
AK11
AG4
SW1
Switch
1 23
4
AG8 AB9
AE12
AD7
R5
0
AK5
AD2
AF6
R6
10K
AA7AJ7
AC9
AH7
AH2
AE3
AE10 AB11
AH3
AK4
AD8
AD1
AG7
AB3
AK12
AA6
AC12
AJ6
AH1
AH9
AF4
AF10
AB12
AG10
AK6
AD10
AC2
AE7
R2
2.2k
AB5
AA8AJ8
AC10
AG2
AE4 AA3 AC4
AH10 AG11
AD9
AK7
D1
Blue
AC1
AE8
AB4
AA9AJ9
AC11
AG1
R1
2.2k
AF5
R7
0
AF11AH11
AC3
AH4
R4
10K
AK10 AD11
AB2
SW2
Switch
1 23
4
AE9
AB6
EXPCON_IO2
PB2
EXPCON_IO0
EXPCON_IO17
EXPCON_IO14
HPE_RESOUT#
CARDSEL#
EXPCON_2V5
EXPCON_OSC
EXPCON_CLKIN
EXPCON_CLKOUT
SW1 SW2
A4
EXPCON_CLKOUT
EXPCON_2V5
EXPCON_OSC
EXPCON_CLKIN
HPE_RESOUT#
EXPCON_IO0
EXPCON_IO2
EXPCON_IO14
EXPCON_IO17
CARDSEL#
PB1

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-020Ϯϱ-2.0 17
Figure A.3. ASC Connection
5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
ASC0
ASC1
ASC2
ASC0_12V
J4
J8
ASC0_5V
J10
ASC0_CLK
ASC2_12V
J5
J9
ASC2_5V
J11
ASC2_CLK
ASC1_12V
J12
J14
ASC1_5V
J15
ASC1_CLK
+12V +5V+3.3V
+3.3V +12V +5V
+3.3V +12V +5V
ASC0_WDAT {2}
ASC0_WRCLK {2}
I2C_WRITE_EN {2,3}
I2C_SCL{2,3}
I2C_SDA{2,3}
ASC1_WDAT {2}
ASC1_WRCLK {2}
I2C_WRITE_EN {2,3}
ASC2_WDAT {2}
ASC2_WRCLK {2}
I2C_WRITE_EN {2,3}
ASC0_CLK_O {2}
ASC0_RDAT {2}
MANDATORY_RESET {2,3}
ASC0_BOARD_SENSE_O{2}
ASC0_5V_OC_SENSE{2}
ASC0_5V_OC_SHUTDOWN{2}
ASC0_12V_OC_SENSE{2}
ASC0_12V_OC_SHUTDOWN{2}
ASC0_RESET{2}
ASC2_CLK_O {2}
ASC2_BOARD_SENSE_O{2}
ASC2_5V_OC_SENSE{2}
ASC2_5V_OC_SHUTDOWN{2}
I2C_SCL{2,3}
I2C_SDA{2,3}
ASC2_12V_OC_SENSE{2}
ASC2_12V_OC_SHUTDOWN{2}
ASC2_RESET{2}
ASC2_RDAT {2}
MANDATORY_RESET {2,3}
ASC1_BOARD_SENSE_O{2}
ASC1_5V_OC_SENSE{2}
ASC1_5V_OC_SHUTDOWN{2}
I2C_SCL{2,3}
I2C_SDA{2,3}
ASC1_12V_OC_SENSE{2}
ASC1_12V_OC_SHUTDOWN{2}
ASC1_RESET{2}
ASC1_CLK_O {2}
ASC1_RDAT {2}
MANDATORY_RESET {2,3}
Title Size
Project
Rev.
Date: Sheet of
Lattice Semiconductor Corporation
5555 N.E. Moore Court
Hillsboro, Oregon. 97124
Designer:
ASC Bridge Board
B
ASC Connection
B
3 5Tuesday, July 11, 2017
Title Size
Project
Rev.
Date: Sheet of
Lattice Semiconductor Corporation
5555 N.E. Moore Court
Hillsboro, Oregon. 97124
Designer:
ASC Bridge Board
B
ASC Connection
B
3 5Tuesday, July 11, 2017
Title Size
Project
Rev.
Date: Sheet of
Lattice Semiconductor Corporation
5555 N.E. Moore Court
Hillsboro, Oregon. 97124
Designer:
ASC Bridge Board
B
ASC Connection
B
3 5Tuesday, July 11, 2017
J11
2-Pin Header M
1 2
R16 0
R12 0
R15 2.2k
J14
2-Pin Header M
1 2
J5
2-Pin Header M
1 2
R8 2.2k D3
Red
R9 2.2k
J6
CONN DSUB 25-PIN M
1
14 2
15 3
16 4
17 5
18 6
19 7
20 8
21 9
22 10
23 11
24 12
25 13
J13
CONN DSUB 25-PIN M
1
14 2
15 3
16 4
17 5
18 6
19 7
20 8
21 9
22 10
23 11
24 12
25 13
J10
2-Pin Header M
1 2
R14 2.2k
D2
Red
J9
2-Pin Header M
1 2
J15
2-Pin Header M
1 2
D4
Red
R10 2.2k
J4
2-Pin Header M
1 2
R13 0
J12
2-Pin Header M
1 2
R11 2.2k
J7
CONN DSUB 25-PIN M
1
14 2
15 3
16 4
17 5
18 6
19 7
20 8
21 9
22 10
23 11
24 12
25 13
J8
2-Pin Header M
1 2
ASC0_CLK
ASC0_5V
ASC0_12V
A0
ASC0_BOARD_SENSE
A1
ASC1_BOARD_SENSE
ASC1_CLK
ASC1_5V
ASC1_12V
A2
ASC2_BOARD_SENSE
ASC2_CLK
ASC2_5V
ASC2_12V

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
18 FPGA-EB-020Ϯϱ-2.0
Figure A.4. Fan Connectors
5
5
4
4
3
3
2
2
1
1
D D
C C
B B
A A
For Fan PWM frequencies of 40 kHz or greater: No jumper on J18.
For Fan PWM frequencies from 10 kHz up to 26.7 kHz: Jumper pins 2-3 on J18.
For Fan PWM frequencies less than 10 kHz: Jumper pins 1-2 on J18.
FAN3 (3 WIRE HIGH SIDE DRIVE)
FAN2 (3 WIRE LOW SIDE DRIVE)
FAN1 (4 WIRE or 3 WIRE LOW SIDE DRIVE)
+12V
+5V
TACH
PWM
SW_GND
GND
+12V
PWR
+5V
PWM
PWR
TACH
+12V
PWR
+5V
GND
PWM
TACH
10uF
FILTER
2.2uF
J16 FAN1
J20 FAN2 Voltage Select
J21 FAN2
J17 FAN3 Voltage Select
J19 FAN3
J18 FAN3 Filter Select
+3.3V +12V+5V
+3.3V +12V+5V
+12V+5V
+3.3V
FAN1_PWM{2}
FAN2_PWM{2}
FAN3_PWM{2}
FAN1_TACH{2}
FAN2_TACH{2}
FAN3_TACH{2}
Title Size
Project
Rev.
Date: Sheet of
Lattice Semiconductor Corporation
5555 N.E. Moore Court
Hillsboro, Oregon. 97124
Designer:
ASC Bridge Board
B
Fan Connectors
B
4 5Tuesday, July 11, 2017
Title Size
Project
Rev.
Date: Sheet of
Lattice Semiconductor Corporation
5555 N.E. Moore Court
Hillsboro, Oregon. 97124
Designer:
ASC Bridge Board
B
Fan Connectors
B
4 5Tuesday, July 11, 2017
Title Size
Project
Rev.
Date: Sheet of
Lattice Semiconductor Corporation
5555 N.E. Moore Court
Hillsboro, Oregon. 97124
Designer:
ASC Bridge Board
B
Fan Connectors
B
4 5Tuesday, July 11, 2017
R18
1K
R23
10K
R21
10K
J20
FAN2 Voltage Select
1 2 3
C3
0.22uF
Q1
NDT3055LCT
R17
10K
J17
FAN3 Voltage Select
1 2 3
Q4
NDT3055LCT
C1
10uF
R24
10K
Q2
IRLML6402
C2
2.2uF
R20 1K
J21
FAN2
1
2
3
J19
FAN3
1
2
3
R22
10K
J16
FAN1
1
2
3
4
5
6
R19
10K Q3
2N3904
J18
FAN3 Filter Select
1 2 3
FAN2_V
Q1_D
Q4_B
FAN3_V
Q3_G
C1
Q2_D
Q3_S
C2

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-EB-02025-2.0 19
Appendix B. Bill of Materials
Item
Quantity
Reference
Value
Manufacture
Mfr Part Number
Description
1
1
C1
10 uF
Kemet
C1206C106K4PACTU
CAP CER 10 uF
16 V 10% X5R
1206
2
1
C2
2.2 uF
Kemet
C1206C225K4RACTU
CAP CER 2.2 uF
16 V 10% X7R
1206
3
1
C3
0.22 uF
Murata
GRM188R71C224KA01D
CAP CER 0.22 uF
16 V 10% X7R
0603
4
1
D1
LED_blue
Lite-On
LTST-C193TBKT-5A
LED Blue 0603
5
3
D2,D3,D4
LED_red
Lite-On
LTST-C190KRKT
LED Red 0603
6
1
J1
Header_2x12
FCI
67997-224HLF
Male Header
24POS .100”
7
2
J2,J3
Header_2x20
TE
Connectivity
2-534206-0
Female Header
40POS .100”
8
9
J4,J5,J8,J9,J10,
J11,J12,J14,J15
Header_1x2
Molex
22284024
Male Header
2POS .100”
9
3
J6,J7,J13
DSUB_25
TE
Connectivity
5747842-3
Male 25Pin
DSUB Connector
10
1
J16
Header_Fan_1x6
Molex
22272061
Male Header
6POS .100”
11
1
J17,J18,J20
Header_1x3
Molex
22284034
Male Header
3POS .100”
12
1
J19,J21
Header_Fan_1x3
Molex
22272031
Male Header
3POS .100”
13
2
Q1,Q4
NDT3055LCT
Fairchild
NDT3055L
MOSFET N-CH 60
V 4 A SOT223
14
1
Q2
IRLML6402
International
Rectifier
IRLML6402TRPBF
MOSFET P-CH 20
V 3.7ASOT-23
15
1
Q3
2N3904
Fairchild
MMBT3904
BJT NPN 40 V
0.2A SOT-23
16
8
R1,R2,R8,R9,R10,
R11,R14,R15
2.2k
Panasonic
ERJ-3EKF2201V
RES 2.2 kΩ1%
1/10 W 0603
17
1
R3
100
Panasonic
ERJ-3EKF1000V
RES 100 Ω1%
1/10 W 0603
18
8
R4,R6,R17,R19,
R21,R22,R23,R24
10K
Panasonic
ERJ-3EKF1002V
RES 10 kΩ1%
1/10 W 0603
19
5
R5,R7,R12,
R13,R16
0
Panasonic
ERJ-3GEY0R00V
RES 0.0 Ω1/10
W 0603
20
1
R18
1K
Rohm
ESR03EZPJ102
RES 1 kΩ5% 1/4
W 0603
21
1
R20
1K
Panasonic
ERJ-3EKF1001V
RES 1 kΩ1%
1/10 W 0603
22
2
SW1,SW2
Switch
Panasonic
EVQ-Q2K03W
Tactile Switch 15
V 20 mA
23
10
bag
#4-40 by 1"
Keystone
1902E
Nylon Hex
Standoff
24
10
bag
#4-40 by 1/4"
Essentra
NSP-4-40-01
Nylon Phillips
Machine Screw

ASC Bridge Board
Evaluation Board User Guide
© 2015-2018 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
20 FPGA-EB-02025-2.0
Appendix C. MachXO3 9400 Development Board and ASC Bridge
Board Signals and Connections.
Table C.1. ASC1 (J4) –MachXO3-9400 Development Board and ASC Bridge Board Connections
Bridge Board Signal Name
Bridge
Board
J3 Pin
MachXO3
Board
X2 Pin
MachXO3 Board
Signal Name
MachXO3 Ball
Platform Designer
Signal Name
ASC0_CLK_0
5
EXPCON_IO30
D14
N / A
ASC0_RESET
7
EXPCON_IO32
C17
ASC1_RSTN_I
ASC0_RDAT
9
EXPCON_IO34
C18
rdat_1
ASC0_WDAT
13
EXPCON_IO38
D18
wdat_1
ASC0_WRCLK
10
EXPCON_IO35
D16
wrclk_1
ASC0_BOARD_SENSE
4
EXPCON_IO29
E12
User Defined
ASC0_5V_OC_SENSE
6
EXPCON_IO31
C15
User Defined
ASC0_5V_OC_SHUTDOWN
8
EXPCON_IO33
D15
User Defined
ASC0_12V_OC_SENSE
12
EXPCON_IO37
D17
User Defined
ASC0_12V_OC_SHUTDOWN
14
EXPCON_IO39
C20
User Defined
Table C.2. ASC2 (J13) –MachXO3-9400 Development Board and ASC Bridge Board Connections
Bridge Board Signal Name
Bridge
Board
J2 Pin
MachXO3
Board
X3 Pin
MachXO3 Board
Signal Name
MachXO3 Ball
Platform Designer
Signal Name
ASC1_CLK_0
13
EXPCON_IO10
F10
N / A
ASC1_RESET
7
EXPCON_IO4
E7
ASC2_RSTN_I
ASC1_RDAT
9
EXPCON_IO6
D5
rdat_2
ASC1_WDAT
11
EXPCON_IO8
D6
wdat_2
ASC1_WRCLK
10
EXPCON_IO7
C3
wrclk_2
ASC1_BOARD_SENSE
4
EXPCON_IO1
G8
User Defined
ASC1_5V_OC_SENSE
6
EXPCON_IO3
F7
User Defined
ASC1_5V_OC_SHUTDOWN
8
EXPCON_IO5
E6
User Defined
ASC1_12V_OC_SENSE
12
EXPCON_IO9
C4
User Defined
ASC1_12V_OC_SHUTDOWN
14
EXPCON_IO11
C5
User Defined
Table C.3. ASC3 (J7) –MachXO3-9400 Development Board and ASC Bridge Board Connections ctions
Bridge Board Signal Name
J2 Pin
X3 Pin
J3 Pin
X2 Pin
MachXO3 Board
Signal Name
MachXO3 Ball
Project Designer
Signal Name
ASC2_CLK_0
—
11
EXPCON_IO36
C19
N / A
ASC2_RESET
35
—
EXPCON_IO25
D12
ASC3_RSTN_I
ASC2_RDAT
31
—
EXPCON_IO22
E11
rdat_3
ASC2_WDAT
27
—
EXPCON_IO19
E10
wdat_3
ASC2_WRCLK
33
—
EXPCON_IO24
F11
wrclk_3
ASC2_BOARD_SENSE
36
—
EXPCON_IO26
F12
User Defined
ASC2_5V_OC_SENSE
39
—
EXPCON_IO28
C14
User Defined
ASC2_5V_OC_SHUTDOWN
37
—
EXPCON_IO27
D13
User Defined
ASC2_12V_OC_SENSE
29
—
EXPCON_IO21
G11
User Defined
ASC2_12V_OC_SHUTDOWN
25
—
EXPCON_IO18
D9
User Defined
