Lattice Semiconductor LatticeMico32/DSP User manual

October 2007
Revision: EB17_01.4
LatticeMico32/DSP Development Board
User’s Guide

2
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Introduction
This document describes the features and functionality of the LatticeMico32/DSP Development Board. This board
is designed as a hardware platform for design and development with the LatticeMico32 microprocessor, as well as
for the LatticeMico8 microcontroller, and for various DSP functions.
This document describes the numerous functional elements of the board. The schematics of the board can be
found in the appendix at the end of this document.
Features
• LatticeECP™ FPGA with 33,800 LUT4s, 131 kbit of embedded RAM, 4 PLLs, and 360 user I/O pins
• Lattice MachXO™ with 640 LUTs
• Serial Flash with 8 Mbit for non-volatile storage of FPGA configuration data.
• DDR SODIMM socket for DDR SDRAM modules (DDR1, 100-133MHz, 32-bit data bus)
• Parallel Flash 2x128 Mbit, organized as 8M 32-bit words
• SRAM 2x4 Mbit, organized as 256K 32-bit words
• USB 2.0 connector and integrated ispDOWNLOAD
®
cable for programming the FPGA
• Flywire connector for programming using an ispDOWNLOAD cable (available separately)
• 9-pin RS232 serial port (230 Kbps)
• 15-pin VGA (64 color encoding)
• Ethernet 10/100 M full/half duplex
• Two USB 2.0 compatible host connectors
• One USB 2.0 compatible target connector
• One USB OTG (On-the-Go) connector
• Expansion connector with 46 user I/Os
• 12x12 prototyping area for the integration of individual components (connections to the FPGA)
• 8x6 prototyping area for the integration of individual components (connections to the MachXO)
• Sigma Delta D/A converter
• Crimp connector with 5 signal pairs for high-speed data transfer
• Audio interface (line-in, line-out, and microphone) CODEC
• LCD connector for character displays, with contrast potentiometer
• 25 MHz oscillator with clock distribution buffer
• Eight LEDs with test points for each LED
• Two-character 7-segment display
• Green LED to indicate the proper operation of the 3.3V and 2.5 V power supplies
• Blue LED which shows the configuration status (“DONE”)
• Red LED to signal that the FPGA can be configured (“INIT”)
• Yellow LED indicating the FPGA PROGRAM# I/O is asserted (“PROGRAM#”)
• 3x4 key matrix

3
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
• Four DIP switches
• Single step key
• Program key to initiate the configuration sequence of the FPGA
• Reset key
• 5V power supply
• Switching regulator for the generation of the 3.3V I/O voltage, the 2.5V DDR and LVDS voltages and the 1.2V
core voltage
Getting Started
1. Unpack all components and compare them to the packaging list. All boards leave the factory fully tested.
Detailed information can be found in the Troubleshooting section of this document.
2. Place the board in front of you so that the keyboard is on the left side.
3. Take the regulated DC power supply which has been supplied with the package and connect it to the power
jack on the board. Two green power-on LEDs will illuminate to confirm that power is correctly applied to the
board (regulating 5V to 3.3V and 2.5V).
4. To check the basic functionality, please see the Troubleshooting section of this document.
A number of example and demonstration programs are available for the LatticeMico32/DSP Development board.
Check the Lattice web site at: www.latticesemi.com/boards (and navigate to the correct board) to find additional
documentation, and design and programming files.
Note: Unless described otherwise, positional statements (left, right etc.) refer to the board positioned in front of you
so that the key pad is in the bottom left corner.
Related Literature
• LatticeMico32 Development Kit User’s Guide : This guide includes a tutorial for using the LatticeMico32 Sys-
tem software with the LatticeMico32/DSP Development Board.
• LatticeMico32/DSP Demonstration : This includes a documented demonstration of a DSP example using the
LatticeMico32/DSP Development board.
These documents can be downloaded from the Lattice web site at: www.latticesemi.com/boards. Select the
FPGA/FPSC Boards -> LatticeMico32/DSP Development board and click on the User Manuals link.
Overview
The following block diagram gives you an overview of the functionality of your LatticeMico32/DSP Development
Board. Subsequent pages illustrate the position of connectors, user interfaces, and modules.

4
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Figure 1. LatticeMico32/DSP Development Board Block Diagram
Table 1. Board Defaults
Peripheral Interfaces
This section describes all peripheral interfaces of the LatticeMico32/DSP Development Board in alphabetical order.
Figure 2 shows the position of peripheral interfaces available on the board.
Item Type
Default
Status Comments
LatticeECP33 FPGA Programmed
The bitstream is based on Example PlatformA and the
LED7SegsTest project. The LED7SegsTest.mem and
LED7SegsTest.bit files are included in the LED7SegsTest
project.
Visual indications of operation are:
• Left to Right and Right to Left scanning of the 8 LEDs.
• Upcount and roll over of the 7 segment displays from 0 to 99
decimal at ~1 second intervals.
LCD Backlight (X5) Jumper Open Backlight is off.
Configuration Switch TMS Switch Off (Down) LatticeECP33 device can be programmed.
Sigma Delta DAC Converter Jumper Open
Contrast Control Reostat Varible Not set to any specific level.
4-place DIP - Logic 1 Switch Off Logic 0 on selected pins - see Table 18.
SODIMM DDR 400 Setting (X18) Jumper Shorts Pins
1 and 2 Set to below DDR400 memory use.

5
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Figure 2. Peripheral Interfaces
Audio Interface
The audio interface has two connectors for 3.5 mm stereo jacks. The upper one is for line-out, the lower for line-in.
They are connected to the audio codec TLV320AIC23BIPW from Texas Instruments.
LCD
Contrast
Potentiometer
Microphone
Input
Audio
Line In
Line Out
LCD
Connector
X6
Ethernet
10/100M
3.3V
Testpoint
2.5V
Testpoint
GND
Testpoint
1.2V
Testpoint
CLK
Testpoint
Flywire-
Connector X3
High-Speed
USB for
Configuration
DIP-Switch
for the
Configuration
X5
X13
X12 Expansion
Connector
DDR SDRAM
Socket X4
USB Host
Connector
Mini USB
OTG-Connector
Power PlugRS232
X1A
VGA
X1B
Sigma Delta
DAC Connector

6
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Table 2. Audio Codec U1001 Pin Definitions
The signal CODEC CS# has a pull-up resistor of 10 k Ω . The Signal CODEC MODE selects the interface to use for
the codec. Driving it high corresponds to SPI, low to I
2
C.
Detailed information on the audio codec can be found at the Texas Instruments web site at www.ti.com.
Clock Sources
A 25 MHz oscillator supplies the FPGA (primary clock pin A10 and PLL input V1), the MachXO (pin A8), the Ether-
net controller and the Expansion Connector (pin 29 of X12). The frequency can be measured via testpoint CLK. A
25MHz input clock is required by the Ethernet controller. To generate other clock frequencies, use the PLLs of the
FPGA.You can find detailed information for the usage of the PLLs on the Lattice web site and in the LatticeECP/EC
Family Data Sheet.
The USB controller requires a 24 MHz quartz oscillator for configuration. Another 12 MHz quartz supplies the USB
host/peripheral controller.
DDR SODIMM Socket for DDR SDRAM Modules
The board includes a standard DDR1 SODIMM socket with 200 contacts (DDR SDRAM Module is not included).
The upper four bytes of the data bus are not connected. Thus, only half of the capacity of the memory module is
available.
The DDR SODIMM socket is factory configured to provide a regulated 2.5V. DDR400 modules require a power
supply of 2.6V (±0.1V). To support DDR400, you must short-circuit pins 2 and 3 of connector X18. Position 1-2 is
used for 2.5V mode. If you have your board in front of you so that the power supply is in the upper left corner, pin 1
is the right-most one and is marked with a copper etched triangle .
Note:In bank 2, there are four DQSs. Two of them do not have the required DQ pins available. Therefore, only two
DDR interfaces are valid. So, the LatticeECP33 can have a 16-bit DDR interface .
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
3 CODEC BCLK W1 21 CODEC CS# W4
4 CODEC DIN W2 6 CODEC DOUT W3
5 CODEC LRCIN AA1 7 CODEC LRCOUT Y2
25 CODEC MCLK Y3 24 CODEC SCLK Y1
23 CODEC SDIN AA2 22 CODEC MODE V4
Table 3. DDR SODIMM Socket (X4) - Data Bus, n.c. ... Not Connected
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
11 DDR DQS0 A16 47 DDR DQS2 H18
12 DDR DM0 B15 48 DDR DM2 H19
5 DDR DQ0 A14 41 DDR DQ16 D21
7 DDR DQ1 B14 43 DDR DQ17 F20
13 DDR DQ2 A15 49 DDR DQ18 G21
17 DDR DQ3 B16 53 DDR DQ19 G20
6 DDR DQ4 A17 42 DDR DQ20 H20
8 DDR DQ5 B17 44 DDR DQ21 J19
14 DDR DQ6 A18 50 DDR DQ22 J18
18 DDR DQ7 B18 54 DDR DQ23 H17
25 DDR DQS1 D21 61 DDR DQS3 J20
26 DDR DM1 D21 62 DDR DM3 K20

7
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Table 4. DDR SODIMM Socket (X4) - Address Bus
Table 5. DDR SODIMM Socket (X4) - Other Signals
Ethernet Interface
An Intel LXT971A is included for Ethernet PHY. This is an IEEE-compliant Fast Ethernet PHY Transceiver that
directly supports both 100BASE-TX and 10BASE-T applications, full and half duplex. For more information, please
refer to the data sheet of this component.
Table 6. Ethernet Controller U0801 Pin Definition
19 DDR DQ8 B22 55 DDR DQ24 F22
23 DDR DQ9 B21 59 DDR DQ25 G22
29 DDR DQ10 C21 65 DDR DQ26 H22
31 DDR DQ11 C22 67 DDR DQ27 H21
20 DDR DQ12 E20 56 DDR DQ28 K19
24 DDR DQ13 E18 60 DDR DQ29 K18
30 DDR DQ14 F19 66 DDR DQ30 L18
32 DDR DQ15 F18 68 DDR DQ31 L19
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
112 DDR A0 D16 111 DDR A1 C16
110 DDR A2 E15 109 DDR A3 D15
108 DDR A4 C15 107 DDR A5 E14
106 DDR A6 D14 105 DDR A7 C14
102 DDR A8 E13 101 DDR A9 D13
115 DDR A10 E16 100 DDR A11 C13
99 DDR A12 B13 123 DDR A13 C17
117 DDR BA0 E17 116 DDR BA1 D17
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
35 DDR CK0+ B12 37 DDR CK0- A12
160 DDR CK1+ A20 158 DDR CK1- B19
96 DDR CKE0 A13 95 DDR CKE1 C12
118 DDR RAS# C18 119 DDR WE# D18
120 DDR CAS# A19 121 DDR S0# C19
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
4HPE RESOUT# H6 42 ETH MDIO K4
43 ETH MDC K5 45 ETH RXD3 F2
46 ETH RXD2 G3 47 ETH RXD1 G2
48 ETH RXD0 G1 49 ETH RXDV J4
52 ETH RXCLK K1 53 ETH RXER J5
54 ETH TXER J2 55 ETH TXEN J3
56 ETH TXCLK J1 57 ETH TXD0 H1
58 ETH TXD1 H2 59 ETH TXD2 H3
60 ETH TXD3 H4 62 ETH COL K2
63 ETH CRS K3 64 ETH MDINTR# F1
Table 3. DDR SODIMM Socket (X4) - Data Bus, n.c. ... Not Connected (Continued)

8
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Expansion Connector
The expansion connector provides 46 user I/Os connected to the FPGA. The remaining pins serve as power and
clock supplies for expansion boards. The expansion connector is configured as two 2x20 100mil centered pin head-
ers (X12 and X13). Tables 7 and 8 describe the connections to the FPGA.
Table 7. Expansion Connector X12
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
1 GND — 2 n.c. (coding) —
3 VCC2V5 — 4 EXPCON IO29 W21
5 EXPCON IO30 W20 6 EXPCON IO31 W19
7 EXPCON IO32 Y20 8 EXPCON IO33 AA22
9 EXPCON IO34 AA21 10 EXPCON IO35 AB21
11 EXPCON IO36 T17 12 EXPCON IO37 T14
13 EXPCON IO38 T13 14 EXPCON IO39 U14
15 EXPCON IO40 U13 16 EXPCON IO41 U12
17 EXPCON IO42 U11 18 EXPCON IO43 V14
19 EXPCON IO44 V13 20 EXPCON IO45 W13
21 VCC5V0 — 22 GND —
23 VCC2V5 — 24 GND —
25 VCC3V3 — 26 GND —
27 VCC3V3 — 28 GND —
29 EXPCON OSC — 30 GND —
31 EXPCON CLKIN — 32 GND —
33 EXPCON CLKOUT — 34 GND —
35 VCC3V3 — 36 GND —
37 VCC3V3 — 38 GND —
39 VCC3V3 — 40 GND —
Table 8. Expansion Connector X13
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
1HPE RESET# — 2 GND —
3 EXPCON IO0 K22 4 EXPCON IO01 K21
5 EXPCON IO2 L22 6 EXPCON IO03 L21
7 EXPCON IO4 L20 8 EXPCON IO05 M22
9 EXPCON IO6 M21 10 EXPCON IO07 M20
11 EXPCON IO8 M19 12 EXPCON IO09 M18
13 EXPCON IO10 N22 14 EXPCON IO11 N21
15 EXPCON IO12 N20 16 EXPCON IO13 N19
17 EXPCON IO14 N18 18 EXPCON IO15 P22
19 GND — 20 VCC3V3 —
21 EXPCON IO16 P21 22 GND —
23 EXPCON IO17 P20 24 GND —
25 EXPCON IO18 P18 26 GND —
27 EXPCON IO19 P19 28 EXPCON IO20 R22
29 EXPCON IO21 R21 30 GND —
31 EXPCON IO22 R19 32 EXPCON IO23 R18

9
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
ispDOWNLOAD Cable Connector
There are two ways to configure the programmable Lattice devices on the board. The USB connector requires a
standard USB cable, and is described later in this document. Connector X3 is available to connect a Lattice isp-
DOWNLOAD cable. An ispDOWNLOAD cable is used to program IEEE 1532 compliant programmable devices.
Lattice provides either a parallel port or a USB port download cable. The FPGA and CPLD are programmed using
the cable and ispVM
®
programming software.
DIP switch SW0302
1
controls the device to be configured: the FPGA or the MachXO. If it is on (in top position), the
MachXO is selected; if off, the FPGA is selected.
The ispVM System software can be downloaded from the Lattice web site at: www.latticesemi.com/ispvm.
Note: Do not change the switch when the configuration of a device is in progress!
Note: The board as configured from the factory, has a built-in USB ispDOWNLOAD cable. The built-in cable and an
external ispDOWNLOAD cable cannot be used at the same time.
Table 9. ispDOWNLOAD Connector X3 Pin Definition
High-Speed LVDS Connector
On the right side of the board there is a 20-pin jack for connecting crimp cables. Five LVDS signal pairs of the
FPGA are wired with the connector (see Table 10). This interface serves as a means for high-speed data transfer.
Figure 3. 20-pin DF13 Connector by Hirose
33 EXPCON IO24 R17 34 GND —
35 EXPCON IO25 T22 36 EXPCON IO26 T18
37 EXPCON IO27 U22 38 CARDSEL# V20
39 EXPCON IO28 V19 40 GND —
1. Caption on the board: CONF.
Pin Signal Name Pin Signal Name
1VCC3V3 2 JTAG_TDO
3 JTAG_TDI 4 JTAG_PROG
5 JTAG_TRST 6 JTAG_TMS
7 GND 8 JTAG_TCK
9 JTAG_DONE 10 JTAG_INIT
Table 8. Expansion Connector X13 (Continued)

10
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Table 10. High-Speed Connector X14 Pin Definition
LCD Connector (Optional)
The LCD connector is a 16-pin header with a standard pinning for LCD modules with back-light (e.g. Truly MTC-
C202DPRN-1N). In order to use an LCD module, attach it to the connector via a 16-pin ribbon cable.
Note: The LCD module is tied to a 5V supply. The LatticeECP33 to LCD interface is 3.3V.
Put a jumper on connector X5 to turn on the backlight of the LCD. The contrast of the LCD module is adjustable
with the potentiometer R0526, because different LCD modules need different voltages for the best contrast.
Figure 4. LCD Panel (Not Included)
Table 11. LCD Connector X6 Pin Definition
Serial Interface
The board includes an RS232 serial interface port. The interface provides transmit (TX), receive (RX), and hard-
ware handshaking. The MAXIM MAX3232 data sheet provides detailed information on the interface circuit. A 9-pin
female to 9-pin female null modem cable is required.
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
1HSCON DAT0- E21 2 HSCON DAT0+ D22
3 GND — 4 GND —
5 HSCON DAT1- G19 6 HSCON DAT1+ G18
7 GND — 8 GND —
9 HSCON DAT2- F21 10 HSCON DAT2+ E22
11 GND — 12 GND —
13 HSCON DAT3- J22 14 HSCON DAT3+ J21
15 GND — 16 GND —
17 HSCON DAT4- G17 18 HSCON DAT4+ F17
19 GND — 20 GND —
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
1GND — 2 VCC5V —
3 CONTRAST — 4 LCD REGSEL P3
5 LCD RW P4 6 LCD ENABLE P5
7 SEG A#/DB0 M3 8 SEG B#/DB1 M4
9 SEG C#/DB2 M5 10 SEG D#/DB3 N1
11 SEG E#/DB4 N2 12 SEG F#/DB5 N3
13 SEG G#/DB6 N4 14 SEG DP#/DB7 N5
15 BACKLIGHT — 16 GND —

11
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Table 12. Serial Interface X1C Pin Definitions
Sigma Delta D/A Converter
The board includes a low-pass filter connected to a dedicated pin of the FPGA. With this, a sigma delta converter
can be realized. Great results can be achieved by using a resolution of 8 to 10 bits. Example VHDL code is pro-
vided.
Power Supply
Four different voltages are needed: 3.3V I/O voltage, 2.5V DDR and LVDS voltages as well as 1.2V core voltage.
The 3.3V supply draws up to 1A, the 2.5V and 1.2V supplies up to 2A of current.
For more information, see the power supply information in the Components section of this document.
Test Points
In order to check the various voltage levels used, several test points are provided. There is one test point for 1.2V,
2.5V, 3.3V, one for ground, and one for accessing the 25MHz oscillator. The 25MHz clock signal can be checked
with another test point.
USB Host/Peripheral Interface
There are one USB peripheral and two USB host connectors on board. These are connected to the Cypress
CY7C67300 USB Host/Peripheral Controller U0702. This controller is compliant with the Universal Serial Bus
Specification 2.0. You can transmit and receive serial data at both full-speed (12 Mbps) and low-speed (1.5 Mbps)
data rates. For more information, please refer to the data sheet of the USB controller. U0703 and U0704 are USB
power control switches, which must be enabled by the user via the USB PWEN signals. The USB OC signal pulls
low to indicate voltage, current and thermal issues.
Table 13. USB GPIO Connections (U0702)
Signal Direction Sub-D Pin RS232 Function FPGA Pin
RS TXD LVTTL Out 3 Transmit Data L1
RS RTS LVTTL Out 7 Request to Send L2
RS RXD LVTTL In 2 Receive Data M2
RS CTS LVTTL In 8 Clear to Send M1
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
94 USB GPIO0 B7 93 USB GPIO1 C7
92 USB GPIO2 D7 91 USB GPIO3 E7
90 USB GPIO4 F7 89 USB GPIO5 A8
87 USB GPIO6 B8 86 USB GPIO7 C8
66 USB GPIO8 D8 65 USB GPIO9 E8
61 USB GPIO10 F8 60 USB GPIO11 A9
59 USB GPIO12 B9 58 USB GPIO13 C9
57 USB GPIO14 D9 56 USB GPIO15 E9
55 USB GPIO16 F9 54 USB GPIO17 G9
53 USB GPIO18 B10 52 USB GPIO19 C10
50 USB GPIO20 D10 49 USB GPIO21 E10
48 USB GPIO22 F10 47 USB GPIO23 G10
46 USB GPIO24 B11 45 USB GPIO25 C11
44 USB GPIO26 D11 43 USB GPIO27 E11
42 USB GPIO28 E12 41 USB GPIO29 pulled up

12
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Table 14. Additional USB GPIO Connections (U0702, U0704, and U0704)
USB Configuration Connector
In addition to the ispDOWNLOAD connector, the FPGA and the MachXO can also be configured by a standard
USB connection. The USB target connector is wired to the Cypress CY7C68013A device (U0301).
This programming method requires the use of the ispVM System software. This can be downloaded from the Lat-
tice web site at: www.latticesemi.com/ispvm.
This connection will appear to the ispVM System software as if a regular USB-based ispDOWNLOAD cable is con-
nected to the PC.
The CY7C68013A in combination with the MachXO CPLD acts as a built-in ispDOWNLOAD cable. The MachXO is
connected to the ispDOWNLOAD Connector X3, and can program the LatticeECP33. The LatticeECP33 can be
programmed when DIP switch SW0302 is ‘off’ (pushed down).
Note: Like the ispDOWNLOAD connector, the MachXO drives the JTAG signals when it is programmed for USB
configuration. Only use the built-in ispDOWNLOAD cable or an external ispDOWNLOAD cable exclusively. It is not
recommended to switch between cables without first power cycling the board. Failure to follow this recommenda-
tion may cause unpredictable results and may possibly damage the board.
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
U0703:1 USB PWEN0 B2 U0703:2 USB OC0# E1
U0703:4 USB PWEN1 C2 U0703:3 USB OC1# D1
U0704:1 USB PWEN2 C3 U0704:2 USB OC2# D2
U0702:85 HPE RESOUT# B3
Table 15. Connections Between the USB Controller (CY7C68013A) and the MachXO Device
Cypress Pin Signal name MachXO Pin Cypress Pin Signal Name MachXO Pin
34 GP D0 G14 35 GP D1 G13
36 GP D2 H14 37 GP D3 H13
44 GP D4 H12 45 GP D5 J13
46 GP D6 J12 47 GP D7 K14
80 GP D8 K13 81 GP D9 K12
82 GP D10 L14 83 GP D11 M13
95 GP D12 M14 96 GP D13 M12
97 GP D14 N14 98 GP D15 N13
57 GP ADR0 H1 58 GP ADR1 H2
59 GP ADR2 J1 60 GP ADR3 J3
61 GP ADR4 K1 62 GP ADR5 K2
63 GP ADR6 L1 64 GP ADR7 L3
93 GP ADR8 M1 69 GP SLOE M3
67 GP INT0 N7 68 GP INT1 M6
71 GP FIFOADR0 M4 72 GP FIFOADR1 N4
70 GP WU2 N3 73 GP PKTEND P5
74 GP SLCS# E3 79 USBCF WAKE N9
3 GP RDY0 D3 4 GP RDY1 E2
5 GP RDY2 F2 6 GP RDY3 F3
7 GP RDY4 G1 8 GP RDY5 G2
54 GP CTL0 D1 55 GP CTL1 C3

13
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
VGA Interface
The board includes a VGA connector for driving a VGA monitor. The VGA interface is connected to a 15-pin plug
socket. The pin definitions are listed in Table 16.
VGA RD0 and VGA RD1 are both connected to pin 1, but have different series resistors (see Figure 5). Thus, a 6-
bit VGA interface is realized. Figure 5 shows the connection of the RGB signals. The FPGA is responsible for gen-
erating correct HSYNC and VSYNC sweep frequencies. Understand the SYNC frequencies of the VGA monitor
being connected to the VGA plug and adjust the FPGA frequencies as required.
Table 16. VGA Connector X1B Pin Definition, n.c. ... Not Connected
Figure 5. VGA Connector
56 GP CTL2 C2 51 GP CTL3 C1
52 GP CTL4 B2 76 GP CTL5 B1
23 GP T0 M2 24 GP T1 N1
25 GP T2 P1 28 GP BKPT F12
100 USB CLK O M7 26 GP IFCLK M8
41 GP RXD0 E13 40 GP TXD0 E14
43 GP RXD1 F13 42 GP TXD1 F14
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
1VGA RD0 A3 1 VGA RD1 B4
2 VGA GR0 A4 2 VGA GR1 B5
3 VGA BL0 A5 3 VGA BL1 B6
4 n.c. — 5 n.c. —
6 GND — 7 GND —
8 GND — 9 n.c. —
10 GND — 11 n.c. —
12 n.c. — 13 VGA HSYNC A7
14 VGA VSYNC A6 15 n.c. —
Table 15. Connections Between the USB Controller (CY7C68013A) and the MachXO Device (Continued)

14
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
User Interface
Figure 6 shows the position of the user interface elements.
Figure 6. User Interface Features
2.5 VLED
(green)
3.3 VLED
(green)
FPGA Configuration
LED (blue)
FPGA Initialization
LED (red)
Single-Step
Key
Reset Key
3 x 4
Keyboard
7-Segment
Display
8LEDs with
Testpads
LCD
Connector
Program
Key
Program
LED (yellow)
4 x DIP
Switches

15
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
7-Segment Display
The 7-segment display is wired as follows:
Table 17. 7 Segment Display U0502 Pin Definition
The signals of the 7-segment display are low-active, which means that with a logic ‘0’, the segment is lit. SEG A# ...
SEG F# and SEG DP# drive not only the two 7-segment displays, but also the LCD. To write different data to these
three components, the user must drive the signals alternately to the components. This can be realized with the sig-
nals SEG CA0#, SEG CA1# and LCD ENABLE. They serve to activate the two 7-segment displays and the LCD,
respectively.
DIP Switches
There is a 4-bit DIP switch on the board. When the switch is turned to the on position, a logic ‘1’ will be seen. The
connections are in Table 18.
Table 18. DIP Switches SW0514 Connection
LEDs
Eight LEDs can be used for custom status signaling. They are low-active; with a logic ‘0’ the LED is on. You can
control the LEDs via the signals below.
Table 19. LED LD0501 ... LD0508 Connection
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
ASED_A# M3 E SED_E# N2
B SED_B# M4 F SED_F# N3
C SED_C# M5 G SED_G# N4
D SED_D# N1 D, P SED_DP# N5
left SED_CA0# P1 right SED_CA1# P2
common common
Switch Signal Name FPGA Pin Switch Signal Name FPGA Pin
SW315 SW316
1DSW0 R2 2 DSW1 R3
3 DSW2 R4 4 DSW3 R5
Pin Signal Name FPGA Pin Pin Signal Name FPGA Pin
1LED0# E3 5 LED4# F5
2 LED1# E4 6 LED5# G4
3 LED2# E5 7 LED6# G5
4 LED3# F4 8 LED7# H5
A
B
C
D
E
FG

16
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Key Matrix
The board also features a key matrix with 12 push-buttons, which are not debounced. They must be driven with
three column lines and can be read with four rows. The following table shows the connections.
Table 20. Key Matrix with the Keys SW302 ... SW313 Definition
Table 21. Key Matrix with the Keys SW302 ... SW313 Connection
To query all keys of the matrix, you must poll the column driver signals (TST COL0, TST COL1, and TST COL2). If
you press a key, a logic ‘1’ appears in the corresponding row. The following diagram explains the functionality:
Figure 7. Polling of the Key Matrix
You do not need the polling method if only four keys are used. Connect the column driver signals of one column to
VCC, the other two to GND and query the row data signals.
CPU Reset Key
The CPU reset key is a global reset. Please refer to the Reset Chip section of this document for detailed informa-
tion.
Single Step Key
The single step key is connected to a normal input of the FPGA and can be used by the application as required.
This key is connected to a Schmitt trigger, meaning it is debounced. This key is used as a single clock for testing
your design.
Signal Name TST_COL0 TST_COL1 TST_COL2
TST_ROW0 123
TST_ROW1 4 5 6
TST_ROW2 7 8 9
TST_ROW3 C 0 E
Signal Name FPGA Pin Signal Name FPGA Pin
TST_ROW0 T1 TST_COL0 U4
TST_ROW1 T2 TST_COL1 U6
TST_ROW2 T3 TST_COL2 V5
TST_ROW3 R1
Col0
Col1
Col2
Row0
Row1
1 pressed 3 pressed
6 pressed
6 pressed

17
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Components
Figure 8 illustrates the position of major components.
Figure 8. Components
Ethernet
PHY
Asynchronous
SRAM
SPI
Flash
MachXO
Audio
Codec
USB
Controller
USB Controller
for the
Configuration
8x 6 Prototyping
Area of the
MachXO
Parallel
Flash
12 x 12
Prototyping Area
of the FPGA
FPGA
LFEC33

18
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
12 x 12 FPGA Prototyping Area of The FPGA
A 12x12 prototyping area is available on the right side of the board. The lead-wire spacing of the prototyping area
is 100mil (2.54 mm). Figure 10 shows the prototyping area in top view. 14 plated-through-holes on its left side are
connected to the FPGA. Eight through-holes on the right side are wired to a 2.5V I/O bank. In the top row of the
prototyping area there are six connections to the 3.3V power supply as well as three to 2.5V. The bottom row has
ten plated-through-holes connected to GND.
Table 22. FPGA Connections for the 12x12 Prototyping Area
FPGA Pin Signal Name LRF Pin FPGA Pin Signal Name LRF Pin
AB13 BB3V3 IO0 TP0901 AB12 BB3V3 IO1 TP0902
AA12 BB3V3 IO2 TP0903 Y12 BB3V3 IO3 TP0904
W12 BB3V3 IO4 TP0905 V12 BB3V3 IO5 TP0906
V11 BB3V3 IO6 TP0907 U10 BB3V3 IO7 TP0908
T10 BB3V3 IO8 TP0909 U9 BB3V3 IO9 TP0910
T9 BB3V3 IO10 TP0911 U8 BB3V3 IO11 TP0912
AB10 BB3V3 CLK0+ TP0918 AB11 BB3V3 CLK0- TP0919
F11 BB2V5 IO0 TP09133 F12 BB2V5 IO1 TP09134
F13 BB2V5 IO2 TP09135 G13 BB2V5 IO3 TP09136
F14 BB2V5 IO4 TP09137 G14 BB2V5 IO5 TP09140
F15 BB2V5 IO6 TP09141 F16 BB2V5 IO7 TP09142
— VCC3V3 TP0913 — VCC3V3 TP0925
— VCC3V3 TP0937 — VCC3V3 TP0949
— VCC3V3 TP0961 — VCC3V3 TP0973
— VCC2V5 TP0997 — VCC2V5 TP09109
— VCC2V5 TP09121
— GND TP0924 — GND TP0936
— GND TP0948 — GND TP0960
— GND TP0972 — GND TP0984
— GND TP0996 — GND TP09108
— GND TP09120 — GND TP09132

19
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Figure 9. Schematic Illustration of the Prototyping Area
8 x 6 MachXO Prototyping Area
There is a second prototyping area connected to the MachXO. Its lead-wire spacing is also 100mil (2.54 mm). 22
drill holes are connected to the MachXO. The topmost row is connected to the 3.3V power supply; the bottom-most
to ground.
Table 23. MachXO Connections for the 8x6 Prototyping Area
MachXO Pin Signal Name LRF Pin MachXO Pin Signal Name LRF Pin
A6 AA3V3 IO0 TP0307 B6 AA3V3 IO1 TP0313
C6 AA3V3 IO2 TP0319 B7 AA3V3 IO3 TP0325
B8 AA3V3 IO4 TP0331 B14 AA3V3 IO5 TP0337
B10 AA3V3 IO6 TP0332 C10 AA3V3 IO7 TP0326
A11 AA3V3 IO8 TP0320 C11 AA3V3 IO9 TP0314
A12 AA3V3 IO10 TP0308 B12 AA3V3 IO11 TP0311
B12 AA3V3 IO12 TP0311 A13 AA3V3 IO13 TP0323
B13 AA3V3 IO14 TP0329 A14 AA3V3 IO15 TP0335
C14 AA3V3 IO16 TP0342 C13 AA3V3 IO17 TP0336
D12 AA3V3 IO18 TP0330 D14 AA3V3 IO19 TP0324
N6 AA3V3 IO20 TP0318 G3 AA3V3 IO21 TP0312
— VCC3V3 TP0301 — VCC3V3 TP0302
— VCC3V3 TP0303 — VCC3V3 TP0304
— VCC3V3 TP0305 — VCC3V3 TP0306
BB3V3_IO[11:0]
BB3V3_CLK0-
BB3V3_CLK0+
BB3V3_IO3
BB3V3_IO2
BB3V3_IO1
BB3V3_IO0
BB3V3_IO4
BB3V3_IO5
BB3V3_IO6
BB3V3_IO7
BB3V3_IO8
BB3V3_IO9
BB3V3_IO10
BB3V3_IO11
BB2V5_IO0
BB2V5_IO[9:0]
BB2V5_IO1
BB2V5_IO2
BB2V5_IO3
BB2V5_IO4
BB2V5_IO6
BB2V5_IO7
BB2V5_IO8
BB2V5_IO9
BB2V5_IO5
BB2V5_DAT0-
BB2V5_DAT0+
VCC3V3
GND
VCC2V5
TP09104
TP0935
TP0996TP0912
TP0963
TP09124
TP0954
TP09117
TP0944TP0908
TP09106
TP0936
TP0921
TP0964
TP0986
TP09125
TP0957
TP09115
TP0946
TP09107
TP09135
TP0926
TP0965
TP0985
TP09126
TP0955
TP0920 TP09116
TP0947
TP09108
TP0909
TP0975
TP09136
TP0925
TP0966
TP09129
TP0934
TP0956
TP09118
TP0948
TP0976
TP0998
TP09137
TP0969
TP0922
TP09127
TP0958
TP0903
TP09119
TP0938
TP0977
TP09133
TP0910
TP09138
TP0967
TP09128
TP0901
TP0959
TP0987
TP09120
TP0937
TP0923
TP0978
TP09141
TP0968
TP09130
TP0927
TP0960
TP0904 TP0988
TP09110
TP0981
TP0911
TP09139
TP0970
TP0924
TP09131
TP0928
TP0950
TP09121
TP0915
TP0989
TP0979
TP09140
TP0971
TP0999
TP09132
TP0929
TP0949
TP0990
TP0980
TP0914
TP09142
TP0939
TP0972
TP0916 TP09100
TP0905
TP09122
TP0930
TP0993
TP0982
TP09143
TP0940
TP0962
TP09109
TP09101
TP0933
TP0913
TP0991
TP0917
TP0983
TP0902
TP09111
TP09144
TP0941
TP0961
TP09102TP0906
TP0931
TP0992
TP0984
TP0951
TP09112
TP09134
TP0942
TP09105
TP0918
TP0932
TP0994
TP0952
TP0974
TP0997
TP09113
TP0945
TP09103TP0907
TP0995
TP09123
TP0953
TP0919
TP0973
TP09114
TP0943

20
LatticeMico32/DSP Development Board
Lattice Semiconductor User’s Guide
Figure 10. Schematic Illustration of the Prototyping Area
Asynchronous SRAM
The board is populated with two asynchronous K6R4016V1D-TC10 SRAMs from Samsung. Every one of them is 4
Mbit in size with a data bus width of 16 bits. They are wired as one memory with a 32-bit data bus and a depth of
256 k. The 18-bit address bus, the data bus and the control signals are connected directly to the FPGA.
MachXO
The LCMXO640 is a non-volatile, instant-on, reprogrammable logic device. It supports “background programming”
(i.e., the device can be programmed while in operation).
The MachXO comes preprogrammed from the factory. The factory program permits the CY7C68013A/MachXO
combination to work as a built-in USB ispDOWNLOAD cable. Using ispVM software the built-in download cable
permits the FPGA, and SPI PROM, to be programmed. It is not recommended for the MachXO to be repro-
grammed. However, the MachXO does provide some connections to the LatticeECP33 FPGA, and to an 8x6 proto-
typing area.
For further information, please consult the MachXO Family Data Sheet.
— GND TP0343 — GND TP0344
— GND TP0345 — GND TP0346
— GND TP0347 — GND TP0348
Table 23. MachXO Connections for the 8x6 Prototyping Area (Continued)
AA3V3_IO1
AA3V3_IO21
AA3V3_IO20
AA3V3_IO19AA3V3_IO2
AA3V3_IO3
AA3V3_IO0
AA3V3_IO18
AA3V3_IO7
AA3V3_IO8
AA3V3_IO9
AA3V3_IO10 AA3V3_IO11
AA3V3_IO12
AA3V3_IO13
AA3V3_IO14
AA3V3_IO4 AA3V3_IO17
AA3V3_IO6 AA3V3_IO15
AA3V3_IO5 AA3V3_IO16
VCC3V3
GND
TP0319
TP0318
TP0337
TP0332
TP0303
TP0325
TP0324
TP0338
TP0333
TP0310
TP0343
TP0330
TP0339
TP0334
TP0316
TP0301
TP0348
TP0340
TP0335
TP0322
TP0308
TP0306
TP0341
TP0336
TP0328
TP0314
TP0342
TP0346
TP0320
TP0304
TP0326
TP0311
TP0344
TP0317
TP0302
TP0323
TP0309
TP0329TP0327
TP0347
TP0315
TP0307
TP0305
TP0321
TP0313
TP0312
TP0331
TP0345
