LEGRAND Wattstopper PARTITION-SENSOR User manual

1
No: IS-00717 – Rev. B
The Wattstopper PARTITION-SENSOR uses an infrared transmitter/receiver
pair to detect partition opening and closing and, in conjunction with other
Architectural Dimming products, coordinates lighting and shade preset functions
in areas such as partitioned meeting rooms or ballrooms. When used with the
unique partitioning programming features of Design Center and the divide and
combine widget on the Equinox touchscreens, the PARTITION-SENSOR allows
for automation of partitioned spaces and visual indication of room lighting and
shade status.
Wattstopper
®
Partition Sensor
Installation Instructions
No: IS-00717– Rev. B
PARTITION-SENSOR
Country of Origin: Made in China
FEATURES AND OPERATION OVERVIEW
OVERVIEW
• Excess gain (sensitivity) controlled by a screwdriver adjustment to prevent tampering
• Fixed optics
• Immune to most indirect ambient light and direct strobes
• Waterproof and enclosed in high impact plastic housing
• High speed (1100 μs Thru-Beam)
• Potted 6’ cable
• Power supply requirements: 10 to 30 VDC Note: PARTITION-SENSOR ships with a BZ-50 Power Pack
SPECIFICATIONS
Description Specication
Supply Voltage 10- 30 VDC; 5 volt models: 4.5 to 5.5 VDC, polarity protected
Current Requirements Sinks up to 100mA
Response Time Light State response = 600 usµ (1,100 µs Thru-Beam)
Dark State response = 600 µs (1,100 µ Thru-Beam)
LED Light Source Infrared = 880nm, Pulse-modulated LED
Excessive Gain Adjustment Sensitivity controlled by a screwdriver adjustment to prevent tampering
Range 65’ (20m)
Hysteresis Approximately 20% of signal
Light Immunity High immunity to most ambient light
Diagnostic Indicators Red LED = Output Status, Green LED = Power “ON”
Ambient Temperature -40°F to 158°F (-40° to 70°C)
Rugged Construction Chemical resistant, high impact polycarbonate house
Waterproof ratings: NEMA 4X, IP66

2
No: IS-00717 – Rev. B
C
BZ-50 Power Pack
120/277VAC, 50/60Hz, 225mA output
20A ballast or incandescent load
Motor load: 1HP@120/240VAC
Class 2 power supply
UL 2043 Plenum Rated
www.wattstopper.com • 800.879.8585
Power Pack Red
Red
+24VDC
Common Any 3-Wire
24VDC
Sensor
Control Output
White
Neut.
Blue
Black
Red
Hot Black
Switch
88T9
Appliance
Control
Lighting
Load
+24VDC
CEILING
WIRING LEGACY
JUNCTION BOX
No
Connect Input
+24VDC
+24VDC
120/277V
COMMON
+24VDC
Green
Red
Red
White -
No Connect
Blue
Red
BLACK WIRE
RED WIRE
GREEN WIRE
WHITE WIRE
BLUE WIRE
1 In 1 2 In 2 3 In 3
4 In 4 5 +24 6 +24 8 +24 9 GND 10 P Cell 7 +24
3
4
LED 1
LED 2
Blue LEDs
Config.
Connect to
DLM local network
NOT Ethernet
LED 3
LED 4
24V Overload
2
1
Control Relay Terminal A
+24VDC 5, 6, 7, 8
Control Relay Te rminal B
INPUT 1, 2, 3, 4
PARTITION SENSOR WITH THE DLM SYSTEM
LMIN-104
NOTE: Requires a SPDT (single pole double throw) +24VDC Relay supplied by others
(OMRON LY2-DC24 Relay, PTF08A-E Socket)
• When partition is closed, the coil on the relay will be de-energized
• When partition is open, the coil on the relay will be energized
• 24 VDC Coil of relay connects to
Red = +24VDC
Green Out of Sensor = Common
NOTE 2: LMIN must be set so “Operating Mode” is Partition. In this mode, all four inputs are
dedicated to Partition detection and LMIN cannot be used with any other inputs
NOTE 3: Wall 1 = Input 1 • Wall 2 = Input 2 • Wall 3 = Input 3 • Wall 4 = Input 4
A
B
2
SENSOR ADJUSTMENT PROCEDURES
LIGHT SOURCE RECEIVER Step 1: Point the light beam emitted by the light source away from the receiver
Step 2: Turn the light source sensitivity adjustment fully clockwise (CW) to its maximum setting
Step 3: Monitor the output LED indicator on the receiver while moving the light beam emitted
from the light source in a scanning motion, rst from left to right and then up and down.
Use this technique to locate the mounting position that will ensure the best possible
beam alignment with the receiver.
Step 4: When acceptable beam alignment has been achieved, turn the sensitivity adjustment
fully counter clockwise (CCW)
Step 5: Turn the sensitivity adjustment clockwise (CW) 1/4 turn past the point the output LED
indicator toggles to the opposite state
PARTITION SENSOR WIRING DIAGRAM

3
No: IS-00717 – Rev. B
PARTITION SENSOR WIRING DIAGRAM
BZ-50 Power Pack
120/277VAC, 50/60Hz, 225mA output
20A ballast or incandescent load
Motor load: 1HP@120/240VAC
Class 2 power supply
UL 2043 Plenum Rated
www.wattstopper.com • 800.879.8585
Power Pack Red
Red
+24VDC
Common Any 3-Wire
24VDC
Sensor
Control Output
White
Neut.
Blue
Black
Red
Hot Black
Switch
88T9
Appliance
Control
Lighting
Load
+24VDC
CEILING
WIRING LEGACY
JUNCTION BOX
120/277V
DOOR
COMMON
+24VDC
Contact output
RECEIVER
TO:
- Contact Input Station
- LVOS
- Keypad Station
Green
Red
Red
White - No Connect
White -
No Connect
Blue Black
BLACK WIRE
RED WIRE
GREEN WIRE
WHITE WIRE
BLUE WIRE
LIGHT SOURCE
Mount to flanges
on each side of the
sliding door or partition
Align sensors on
all three axis
PWR
OUT
S
E
N
S
PWR
NOTE: In Design Center, make sure it is set to
normally closed (NC) polarity for the sensor
OUTPUT Green
IN
INPUT 1, 2, 3, 4
Green, Blue Wire
OUTPUT Black
Ground
Ground
Black Wire
PARTITION SENSOR WITH THE
ARCHITECTURAL DIMMING SYSTEM
CIS
(Contact Input Station)
LVOS
KEYPAD
When partition is closed, contact is open
When partition is open, contact is closed

4
800.555.9891
www.legrand.us/wattstopper
No. IS-00717 – Rev. B
© Copyright 2017 Legrand All Rights Reserved.
© Copyright 2017 Tous droits réservés Legrand.
© Copyright 2017 Legrand Todos los derechos reservados.
