LEGRAND Mosaic 335 25 User manual

87045 LIMOGES Cedex
Telephone: [phone] - Fax: [phone]
Technical data sheet: F01066EN/00
Catalogue number(s): 335 25
Updated on: Created on: 07/09/2010
1/2
MosaicTM
Wi-Fi 5 AP controller
1. GENERAL CHARACTERISTICS
Allows you to install a secure Wi-Fi network with personalised hotspot,-
filtering and traceability.
Ability to control private and public access within the Wi-Fi network.-
User identification data sent by SMS, email, self-registration by the user-
via a portal.
Ability to delegate management of accounts with simplified and-
restricted access to staff using the network (reception areas, hotel
receptions etc.).
Blocking/authorisation of connections according to the type of data-
(email, Web etc.), destination website, user account, time, time credit,
geographical area.
Ability to bill network access (for example in a hotel), interconnection-
with a payment system such as PayPal, PMS (Property Management
System - FIAS protocol), PPS (Prepaid System).
Can be installed in addition to a new or existing LCS-2structured wiring
system to meet mobile working requirements.
The management function allows the network administrator to manage-
Wi-Fi access points remotely via a web interface.
Supports SNMP management.-
Installation outside a patch enclosure or shelf-mounted inside-
Allows you to configure up to 5 terminals centralised on an IT network-
and to manage 50 connections at the same time.
The installation must include at least:
one supervisory controller-
Wi-Fi access points (false ceiling)-
one PoE injector conforming with IEEE 802.3 af (LCS2 unit format) to-
be installed in the patch enclosure.
If the installation involves more than 5 Wi-Fi access points, an extension-
licence must be provided.
Ability to update the automatic box.-
Accessories:
1 European standard cable + 1 BS standard cable-
Instructions in IT file format-
Rapid installation guide in paper format-
CONTENTS Page
1. General characteristics.............1
2. Presentation .....................1
3. Overall dimensions................1
4. Technical features ................1
5. Product options ..................2
6. Installation ......................2
7. Standards and approvals ...........2
Controleur WiFi
4. TECHNICAL FEATURES
2- network interfaces on RJ45 10/100/1000 BASE T
Compatible universal Plug-And-Play (UPnP)-
Several administration levels: administrator/user-
Multi-language support:-
Administrator: French, English, Italian, Spanish, Portuguese
User: French, English, Italian, Spanish, Portuguese, German,
Turkish, Polish, Hungarian, Russian, Greek, Flemish
Support from 5 to 50 Apps.-
Support up to 200 connections at the same time-
Mains supply: 100-240V AC-
Product power consumption: 55W-
Start/stop button at the rear-
2-year guarantee-
Ral 9005-
IK08-
Storage and transport temperature: 0 to + 60°C-
Operating temperature: 10 to + 35°C-
Humidity: 10 to 75%-
Noise 26 dB-
SWITCH
Wi-Fi
Wi-Fi
2. PRESENTATION
3. OVERALL DIMENSIONS
254 219
88
Keep a distance of 2cm on the upper side of the controller clear to
prevent obstruction of the ventilation grid.

Catalogue number(s): 335 25
Wi-Fi 5 AP controller
Technical data sheet: F01066EN/00 Updated on: Created on: 07/09/2010
2/2
6. INSTALLATION
Contrôleur
Contrôleur
Switch
Switch
100 - 240 V A C
50/60 Hz
55 W
Contrôleur
Switch



7. STANDARDS AND APPROVALS
EN 60 950
IEEE 802.3 af
Compliance with the requirements for the conservation of digital data within
the scope of providing electronic communication services accessible to the
public or public communication networks (e.g. a Wi-Fi network with public
access "hotspot").
EU directive 2006-24 EC of 15 March 2006 and decree no.
2006-358 of 24 March 2006
France:
Law no. 2004-575 of 21 June 2004 on confidence in the digital economy-
(LCEN).
Deliberation no. 2005-208 of the CNIL (French data protection authority)-
of 10 October 2005.
Spain:
Regulations in force:
Law no. 25/2007 of 18 October on the conservation of data relating to-
electronic communications and public communication networks.
Law no. 34/2002 of 11 July on information society and electronic com--
merce services.
Article 81 of the new regulations on data protection (LOPD).-
Italy:
Legislative Decree no. 109 30/05/08 - Article 132 of Legislative Decree no.
196 30/06/03.
The Act on the protection of privacy: Legislative Decree no. 196 of 30/06/03
in which art. 132 refers to the "conservation of data relating to electronic
communications".
Further to EU Directive 2006-24 EC, art. 132 has been amended as speci-
fied by Legislative Decree no. 109 30/05/08 which is, in effect, the reception
decree of the EU Directive.
Portugal:
Law no. 31/2008 of 17 July 2008 on the conservation and transfer of-
electronic communications users' traffic data available to the public for the
purposes of investigation, detection and reduction of serious crime.
Article no. 471/2009 of 6 May 2009.-
Law no. 24/96 of 31 July 1996.-
Turkey:
Internet access is regulated by Law no. 5651 of 23 May 2007.-
Compatible with Wi-Fi terminals:
Cat. No. Description
67366
a/b/g Celiane Wi-Fi access point
77913 a/b/g Mosaic Wi-Fi access point
77914 a/b/g + RJ45 Mosaic Wi-Fi access
point
572376 Arteor white a+bg+jack Wi-Fi access
point with POE
572876 Arteor magnesium a+bg+jack Wi-Fi
access point with POE
572377 Arteor white a+bg Wi-Fi access point
with POE
572378 Arteor white bg Wi-Fi access point
572877 Arteor magnesium a+bg Wi-Fi access
point with POE
572878 Arteor magnesium bg Wi-Fi access
point
33521 802.11N Wi-Fi ceiling access point
33522 802.11N Wi-Fi wall access point
(Available 2011)
5. PRODUCT OPTIONS
Extension licences: are used in addition to the controller to extend
the network.
33526 Allows you to extend the network to a maximum of 10 Wi-Fi
access points (5+5)
Manages up to 100 connections at the same time
33527 Allows you to extend the network to a maximum of 25 Wi-Fi
access points (5+20)
Manages up to 200 connections at the same time
33528 Allows you to extend the network up to a maximum of 50 users
via a wired infrastructure (on request only)
