Leica IC80 HD User manual

LeicaIC80 HD
Manual

Leica IC80 HD Manual 2
Table of Contents
Leica IC80 HD
Introduction 9
Eective Displayed Section 10
Standard Delivery and Optional Accessories 11
Installation
Assembling the Camera 13
Connecting to the Windows PC 14
Limitations in PC Mode 15
Using an Additional HDMI Monitor in PC Mode 16
Stand-alone Kit
Application, Standard Delivery, Requirements 18
Cables and Terminals 19
Information about SD Memory Cards 20
Capturing Images without a Computer 21
Adjusting the White Balance 22
Remote Control 23
Remote Control: Changing the Battery 24
Analog Video Display without a Computer 25
The Camera Menu
Calling up the Camera Menu 27
COLOR (Automatic White Balance) 28
COLOR (Manual White Balance) 29
EXPOSURE 30
RESOLUTION 31
SETUP CAM (Camera Settings) 32
SETUP USER (User-dened Settings) 33
Predened Illumination Scenarios 34
Care and Maintenance
Care and Maintenance 36
Specications
LeicaIC80 HD 38
Dimensional Drawings 40

Leica IC80 HD Manual 3
General Instructions
Safety Concept
Before using your Leica IC80 HD for the rst
time, please read the "Safety Concept" brochure
included with your instrument. It contains addi-
tional information on handling and care.
Use in clean rooms
The Leica IC80 HD can be used in clean rooms
without any problems.
Cleaning
ϘDo not use any unsuitable cleaning agents,
chemicals or techniques for cleaning.
ϘNever use chemicals to clean colored
surfaces or accessories with rubberized
parts. This could damage the surfaces, and
specimens could be contaminated by abra-
ded particles.
ϘIn most cases, we can provide special solu-
tions on request. Some products can be
modied, and we can oer other accesso-
ries for use in clean rooms.
Servicing
ϘRepairs may only be carried out by Leica
Microsystems-trained service technicians.
Only original Leica Microsystems spare
parts may be used.
Responsibilities of person in charge of
instrument
ϗEnsure that the Leica stereomicroscope
is operated, maintained and repaired by
authorized and trained personnel only.

Leica IC80 HD Manual 4
Safety Concept
The Leica IC80 HD is shipped with an interac-
tive CD-ROM, where you can nd all relevant
user manuals. Keep it in a safe place, and
readily accessible to the user. User manuals and
updates are also available for you to download
and print from our web site www.leica-micro-
systems.com.
The "Safety Concept" brochure contains additi-
onal safety information regarding service work,
requirements and the handling of the stereo-
microscope, electrical and other accessories as
well as general safety instructions.
You can combine individual system articles
with articles from external suppliers (e.g. cold
light sources, etc.). Please read the user manual
and the safety requirements of the supplier.
Before installing, operating or using the inst-
ruments, read the user manuals listed above.
In particular, please observe all safety instruc-
tions.
To maintain the unit in its original condition
and to ensure safe operation, the user must
follow the instructions and warnings contained
in these user manuals.

Leica IC80 HD Manual 5
Symbols Used
Warning of a danger
This symbol indicates especially impor-
tant information that must be read and
complied with. Failure to comply can cause the
following:
ϘHazards to persons!
ϘInstrument malfunctions and damage.
Warning of hazardous electrical voltage
This symbol indicates especially impor-
tant information. Failure to comply can
cause the following:
ϘHazards to persons!
ϘInstrument malfunctions and damage.
Danger due to hot surface.
This symbol warns against touching hot
surfaces, such as light bulbs.
Important information
This symbol indicates additional infor-
mation or explanations that are intended
to provide clarity.

Leica IC80 HD Manual 6
Safety Instructions
Description
The individual modules fulll the highest requi-
rements in terms of observation and documen-
tation with the Leica IC80 HD.
Intended use
ϘRefer to the "Safety Concept" brochure.
Non-intended use
ϘRefer to the "Safety Concept" brochure.
The instruments and accessories described
in this manual have been safety-tested and
checked for possible hazards. The responsible
Leica aliate must be consulted whenever
the instrument is altered, modied or used in
conjunction with non-Leica components that
are outside of the scope of this manual.
Unauthorized alterations to the instrument or
noncompliant use shall void all rights to any
warranty claims!
Installation location
ϘRefer to the "Safety Concept" brochure.
ϘElectrical components must be placed at
least 10 cm away from the wall and from
ammable substances.
ϘAvoid large temperature uctuations, direct
sunlight and vibrations. These conditions
can distort measurements and microgra-
phic images.
ϘIn warm and warm-damp climatic zones,
the individual components require special
care in order to prevent the build-up of
fungus.
Requirements to be met by the operator:
ϘRefer to the "Safety Concept" brochure.
Ensure that:
ϘThe Leica IC80 HD is operated, maintained
and repaired only by authorized and trai-
ned personnel.
ϘAll operators have read, understood and
observe this User Manual, and particularly
the safety regulations.

Leica IC80 HD Manual 7
Safety Instructions (continued)
Repairs, service work
ϘRefer to the "Safety Concept" brochure.
ϘOnly original Leica Microsystems spare
parts may be used.
ϘBefore opening the instruments, switch o
the power and unplug the power cable.
ϘTouching the live electric circuit can cause
injury.
Transport
ϘFor shipping or transporting the individual
modules of the Leica IC80 HD, use the origi-
nal packaging.
ϘIn order to prevent damage from vibrations,
disassemble all moving parts that (accor-
ding to the user manual) can be assembled
and disassembled by the customer and
pack them separately.
Installation in third-party products
ϘRefer to the "Safety Concept" brochure.
Disposal
ϘRefer to the "Safety Concept" brochure.
Legal requirements
ϘRefer to the "Safety Concept" brochure.
EC Declaration of Conformity
ϘRefer to the "Safety Concept" brochure.
Health risks
Workplaces equipped with stereomicroscopes
make it easier to examine extremely small
structures, but they also impose high demands
on the eyes and holding muscles of the user.
Depending on the duration of uninterrupted
work at such a workplace, impaired vision and
problems with the musculoskeletal system
may occur. Therefore, corresponding measures
should be taken to reduce the strain:
ϘOptimal arrangement of workplace, work
assignments and work ow (changing tasks
frequently).
ϘThorough training of the personnel, giving
consideration to ergonomic and organizati-
onal aspects.

Leica IC80 HD Manual 8
Leica IC80 HD

Leica IC80 HD Manual 9
Congratulations on purchasing the Leica IC80
HD Digital Camera Module by Leica Microsys-
tems. The special design of the Leica IC80 HD
makes it a universal, highly versatile tool for
viewing microscopic specimens and capturing
still images or even video.
Real Full HD display
The integrated HDMI output allows the micro-
scope image to be output to a High-Denition
(HD)-capable monitor, where the following
resolutions are possible:
Ϙ1920×1080i ("Full HD"). This resolution
provides the best possible imaging perfor-
mance on a Full HD-capable television.
Ϙ1280×720p ("HD ready"). This resolution is
suitable for display on televisions labeled
"HD ready".
Leica Application Suite
Along with your Leica IC80 HD, you also obtain
the "Leica Application Suite EZ" software (LAS
Core on request). It allows additional scenarios
to be implemented in which the television and
monitor can even be used together. Thus you
are ideally prepared for every situation: work at
the computer, presentations, training sessions,
trade show appearances, material testing and
more.
User-friendly even in the smallest detail
Like every digital camera, the Leica IC80 HD
reacts dierently to dierent light sources.
However, the white balance is factory set to
match the Leica LED illuminators. This means
that if you use a Leica LED illuminator, you auto-
matically obtain the best results!
Introduction

Leica IC80 HD Manual 10
Due to the sensor size in the camera, the
live image and the nal image capture do
not show the same section that you see when
looking through the eyepieces.
Using the optional graticule
The optional graticule can be inserted into the
eyepiece and shows the section of the live or
captured image.
Eective Displayed Section
Live image 1920×1080 (16:9)
Captured image 2048×1536 (4:3)
